BEA LZR SIGMA User manual

Assembly
Installation area
Scan
me to
start
X0006F
Scan
me to
start
X0006F
OR +
FRONT FACE COUNTING
HEAD
PoE
Open Sigma
Sigma ts anywhere (doors, walls, ceilings).
Just make sure you place it overhead
Determine the width of the counting area to choose the number of sensors needed
Use more than
one sensor if
W > H
SURFACE
MOUNTING BASE
SCREWS
POWER SUPPLY LZR SIGMA APP
A
B
H
W
W
max. W = H
OPENING TOOL
H
Remove the counting head by unclipping it
Choose a direction for your ow of people
(Tip : A towards the inside)
2
1
Scan
me to
start
X0006F
Scan
me to
start
X0006F

Mobile App
3
"CLICK"
Searching for network (0 - 5 min.)
Connected to the network
OR
Scan the QR Code (on the device or on the box) or download the LZR Sigma app on:
Scan
me to
start
X0006F
Scan
me to
start
X0006F
Pass the cable through the base
Fix the base on the ceiling Connect the cable to the counting head.
Clips the counting head to the base and close Sigma
If needed, you can remove a piece of the base with a tool
to do so
"CLICK"
"CLICK"

©BEA | 47.0206 / VA / 03.18
Technical Specications
Technology LASER scanner, time-of-ight measurement
Emission characteristics - IR LASER Wavelenght 905 nm; max. output pulse power 25 W; Class 1
Device dimensions 200 mm [L] x 142 mm [W] x 61 mm [H] (elliptical)
(if mounted with ceiling accessory : visible height 37 mm, invisible height 65 mm)
Temperature range - 25° C to 55°C if powered (storage temperature -35°C to +70°C)
Humidity 0 - 95% non-condensing
Power External DC power or PoE (IEEE802.3af)
Power consumption Max. 12 W/Peak - Average 6 W
Data transfer 3G/2G cellular, Ethernet
Ports MQTTS 883 / HTTPS 443 / SFTP 22
Installation height 2 m to 5.5 m
Counting width coverage Equivalent to mounting height (ratio 1:1)
Video validation
(optional feature)
Resolution 160px x 120px, frame rate 15 fps
(for counting proof purposes only)
Counting data refresh rate 15 min. to 24h
Counting data granularity 5 min.
Level of access on Sensorio 4
LED signal Cause Action
Updating Connection to the device is impossible
Wait for update completion
Searching for network The device is connecting to the network
No internet connection The ethernet conguration is wrong or no cellular
network is available
Check the network connection
Communicating with the app
or with sensorio.
Connected to the network
The device is communicating
Learning Dene the max. limit on your right or left
Error If this occurs, please contact BEA.
BEA SA | LIEGE SCIENCE PARK | ALLÉE DES NOISETIERS 5 - 4031 ANGLEUR [BELGIUM] |T [phone] | F [phone] |
[email protected] | WWW.BEA-SENSORS.COM
WEB SERVER
Static IP adress : 192.168.1.2
User name: user
Password: password
ONLINE DEVICE MANAGER
Go to www.sensorio.com to
manage your portfolio of sensors.
Understanding
Sigma
Other
information
Open and follow the app to complete the installation.
Discover
all of Sigma’s features!
