BEA MAGIC SWITCH CHROMA User manual

1
MAGIC SWITCH CHROMA
DESCRIPTION
CONTACTLESS KNOWING ACT SENSOR
FOR AUTOMATIC DOORS
EN
Antimicrobial front face
Multicoloured LED-feedback
IP65
Toggle-function
Antimicrobial front face
Multicoloured LED-feedback
IP65
Toggle-function
Audible feedback
Remote control adjustments (see remote control settings annex)
Application-focused settings through external signal input
Field size adjustment
Antenna
Terminal block
Gasket/seal
Dip switches
Front face
Fixing frame
Remote control receiver*
Field size adjustment
Antenna
Terminal block
Gasket/seal
Dip switches
Front face
* only available in the advanced version.
Fixing frame
Remote control receiver
RECESSED INSTALLATION
SURFACE INSTALLATION
STANDARD VERSION ADVANCED VERSION
Led
Led

2
x 4
2
DIP
12 3
DIP
3
2
DIP
12
x 4
50 mm
70 mm
x 4
12
2
ADJUSTMENTS
DIP SWITCH SETTINGS
COLOUR
LOGIC
AUDIO
ALERT*
Control input*
Output*
* See page 3
POWER
(Polarity-free)
click!
CLOSE OPEN
DETECTION FIELD
INSTALLATION
RECESSED INSTALLATION
OUTPUT
SURFACE INSTALLATION
* available only in the advanced version.

3
2 2
2 2
2 2
2
DI DI
DI DI
DI DI
DI DI
P P
P P
P P
P P
1 1
1 1
1 1
1 1
2 2
2 2
2 2
2 2
3 3
3 3
3 3
3 3
BU
BU
BU
GN
GN
GNRD
RD
GN
GN
1
DI
DI
DIP
P
P
1
1
1
2
2
2
DIP
12
DI DIP P
3 3
COLOUR LOGIC
CONTROL INPUT*
Connect the input to an external signal to force the LED
colour as dened.
OUTPUT MODE
PULSE MODE normally open (NO) :
recommended for automatic doors applications.
TOGGLE MODE: recommended for switch applications.
PULSE MODE normally closed (NC)
RELAY RELAY
DOOR OPENS
AND CLOSES
DOOR OPENS
AND CLOSES
ON
DOOR OPENS
AND CLOSES
DOOR OPENS
AND CLOSES
OFF
- min. 1 sec -
* available only in the advanced version.
FREQUENCY MODE *
DOOR OPENS AND CLOSES
RELAY RELAY
INPUT
LED according to DIP switch settings
NO DETECTION DETECTION DETECTIONNO DETECTION
RD RD
output remains functional
Input signal must be a dry contact (no voltage)
AUDIO ALERT*
* available only in the advanced version.
OFF ON
OFF
OFF
OFF
OFF
OFFOFF

4
BEA SA | LIEGE Science Park | ALLÉE DES NOISETIERS 5 - 4031 ANGLEUR [BELGIUM] | T [phone] | F [phone] | [email protected] | WWW.BEASENSORS.COM
Technology Microwave motion sensor
Radiated frequency 24.150 GHz
Radiated power < 20 dBm EIRP
Radiated power density < 5mW/cm2
Detection range (hand) +/- 10 to 60 cm if movement towards sensor at 90° (adjustable)*
Detection mode Motion (bidirectional)
Speed of target to create detection Min. 5Hz or +/- 3cm/s, Max. 200Hz or +/- 1.2m/s
Supply voltage** 12 - 24V AC +/- 10% (50 - 60 Hz)
12 - 24V DC +30% / - 10%
Power consumption < 1.5W
Output**
Max. voltage
Max. current
Electronic relay (galvanic isolation - polarity free)
42V DC / 30V AC
100 mA
Output hold time 0.5s (in PULSE mode)
Temperature range -20°C to +55°C
Degree of protection IP65 with front face and gasket mounted on a smooth surface
Material PMMA / PC
Front face is treated with biomaster silver biocide tested to ISO
22196:2011. Please use biocides responsibly.
Wiring cable Stranded cable up to 16 AWG - 1.5mm2
Door does not open even
when moving the hand
towards the sensor.
Bad or no power supply. Check power supply. If LED switches on or flashes,
power connection is OK.
Detection range is too short. Adjust the detection range.
Remove any metal plates in front of the sensor.
Incorrect wiring / connection. Check wiring and relay connection.
Sensor stays in detection. The environment influences the
good functioning of the sensor.
Remove any moving object around the sensor.
Incorrect wiring / connection. Check wiring and relay connection.
Door remains open after
detection/activation.
Wrong output mode. Switch the output mode to PULSE.
Incorrect wiring / connection. Check wiring and relay connection.
TROUBLESHOOTING
* An adjustment of the detection field below 10 cm is possible but the detection capability of the sensor can not be guaranteed.
Technical specifications are subject to changes.
BEA hereby declares that the MAGIC SWITCH CHROMA is in compliance with European Directives 2014/53/EU
(RED) and 2011/65/EU (RoHS).
The full text of the EU declaration of conformity is available on our website.
This product should be disposed of separately from unsorted municipal waste.
TECHNICAL SPECIFICATIONS
©BEA | Original instructions | 47.0381 / V3 - 10.21- PLEASE KEEP FOR FURTHER USE - DESIGNED FOR COLOUR PRINTING
** External electrical sources must be within specified voltages, max 15W and ensure double insulation from primary voltages.
