BEA IRIS User manual

The Iris is a presence detector
utilizing focused active infrared
technology to provide increased
safety for all types of automatic doors.
The Iris will easily bring your
existing doors up to the safety
requirements of the new
2005 ANSI 156.10 standard
Why wait? Start upgrading now!
The 2005 ANSI 156.10 Standard requires existing automatic sliding doors with a
double set of beams to add an overhead sensor on the opposite side of the beams.
This provides a retrofit opportunity for existing doors with beams as primary safety.
What are you waiting for?
nProven infrared technology based on the wizard platform (2 rows of 24 beams of
focused infrared beams for extra safety).
> Efficient performance thus, less service calls.
nProvides optimal level of safety throughout door opening and door closing cycles.
> Increased safety thus, potentially reducing your liability.
nAbility to provide sidelite protection with the option to inhibit safety curtain
furthest from the door. Infinite learn time and high mounting capability make it
ideal for industrial safety applications.
> Versatile features provide additional opportunity for different applications
in multiple markets.
nFaster set-up time of 2, 6, and 16 seconds.
> Quick and convenient installation.
The IRIS
BEA’s Presence
Detector for
Safety
Compliance!
www.beasensors.com

Iris Accessories
Spotfinder
for precise positioning
of the infrared curtains
in front of the door
WMB
mounting bracket for
ceiling mounting WCA
for recessed and
concealed application
ISLL
3 lenses set (left, center and right)
for custom sidelite detection zones
Iris Components
Cable
Mounting Screws
Manual Set-up Push Buttons
Presence Sensor
Cover
LED Indicator
I.R. Remote Receiver
Front Lenses
1
1
4
2
2
3
3
4
5
56
7
6 7
8
8
www.beasensors.com
1
3
2
nThe Iris provides optimal safety around the threshold of an
automatic sliding door with 2 rows of 24 focused infrared spots.
The application above shows the Iris installed as additional overhead
safety sensor (as required by the upcoming 2005 ANSI 156.10 standard)
on an automatic sliding door equipped with an existing double set of
beams and a set of motion detectors.
APPROACH SIDE
APPROACH SIDE
Iris Applications
Threshold Safety for Sliding Door Sidelite Safety for Sliding Door
Remote Control
for easy and accurate
setup of the Iris
nThe Iris has the ability to inhibit the safety curtain furthest
from the door for sidelite protection. Different lenses are
available for a customized detection zone. The application
above shows the Wizard installed as primary detection and
safety sensor and the Iris used as sidelite protection sensor.
The ISSL accessory is recommended for that specific installation.
