BEMIS bioBidet DISCVOERY DLS User manual

USER MANUAL DISCVOERY DLS
v3.0

32
PRODUCT INFORMATION
Important Safeguards
Overview & Parts
Remote Control
Operation
PRODUCT INSTALLATION
Installation Guide
Unit Separation
PRODUCT SETTINGS
Maintenance
Cleaning The Discovery DLS
Cleaning The Nozzle
Cleaning The Strainer
Water Draining
Troubleshooting Guide
Specifications
WARRANTY
Warranty
04
16
21
23
TABLE OF CONTENTS
Questions?
We’re here to help.
847.458.2334
[email protected]
www.biobidet.com
Technical support and alternate
fittings are available.

54
•Persons (including children) with physical, perceptual, intellectual disabilities
or lack of experience and common sense are requested to use the product
in the company of someone. Otherwise use for a long time, may cause low
temperature burns.
•Children should not play with this product. It may cause personal injury.
•It is forbidden to disassemble, repair or modify the product if it is not the after-
sales maintenance personnel or the designated professional maintenance
personnel. Otherwise, it is easy to cause electric shock, fire or abnormal
operation and cause personal injury.
•Do not urinate into the warm air outlet. There is the risk of electric shock.
•Do not put your hands or other things into the warm air outlet. Do not cover
the warm air outlet when using the product. Otherwise, it is easy to cause
electric shock, fire or abnormal operation and cause personal injury.
•Cleaning and maintenance of plastic parts, please do not use inappropriate
cleaner (such as sulfuric acid, nitric acid, glacial acetic acid, carbon
tetrachloride, chloroform, acetone, butanone, benzene, toluene, phenol,
cresol and dimethyl formamide, methyl ether, soybean oil, 95% acetate,
40% nitric acid and concentrated hydrochloric acid, alcohol, gasoline,
kerosene, brake oil, etc.) Otherwise, the plastic may crack, causing personal
injury, electric shock or fire.
•Please do not force back, stand on the cover plate, or roughly open and close
the cover plate, seat ring, to avoid damage. Otherwise, it is easy to damage and
cause personal injury.
•Do not add water or detergent to the inside of the smart toilet seat. Do not wet
intelligent toilet lid and power plug with water or detergent.
PLEASE OBSERVE THE FOLLOWING PRECAUTIONS
AND INSTRUCTIONS BEFORE INSTALLATION AND USE.
•The product must be reliably grounded. Otherwise, electric shock may
be caused by fault or short circuit. When in doubt, contact the electrical
installation company.
•Do not touch or plug the power plug with wet hands. Otherwise there is
the risk of electric shock.
•Do not use defective power outlets or damaged power plugs. Otherwise,
poor contact and damage will lead to electric shock or fire hazard. Please
use the power socket within the specified range (ac 120V±10%, maximum
current above 10A). Otherwise easy to cause fire, electric shock.
•Do not pull, break, bend or twist the power cord at will, stretch, crimp,
bundle, load bearing or over squeeze. Otherwise, damaged power lines
may lead to electric shock or fire. If the power cord is damaged, it must
be replaced by a professional from the manufacturer, its maintenance
department or similar department to avoid danger. Otherwise easy to
cause electric shock, fire.
•Do not use industrial water or contaminated water sources. Otherwise it
is likely to cause cystitis, dermatitis and internal corrosion of machinery
will cause electric shock, fire.
•Please avoid installation in damp and easily soaked bathroom. Do not
spray water on the product or rinse it with water, in case of internal water
flooding and loss. Otherwise easy to cause electric shock, fire.
•Do not put lit cigarettes and other incendiary materials into the intelligent
toilet lid. Otherwise fire is likely to happen.
•Do not use in lightning weather (in the vicinity of lightning, please unplug
the power plug). Otherwise, an accident or malfunction may occur.
•In case of damage to the seat and cover plate, in order to avoid danger,
please be sure to remove the power plug, turn off the water source, and
contact the local dealer for replacement. Otherwise easy to happen
electric shock, fire danger.
•Please pull out the power plug regularly and wipe the dust on the
power plug with dry cloth. Otherwise, when the insulation is poor,
it will cause a fire.
IMPORTANT SAFEGUARDS
PRODUCT INFORMATION

6 7
PRODUCT INFORMATION
PRODUCT INFORMATION
General Cautions
•Do not use the “high” or “medium” range of seat temperature, warm air/
wind temperature for a long time. Otherwise, there will be the risk of
burns if used for a long time.
•During use, keep the skin close to the sensing area of the seat, otherwise
the product will stop cleaning or warm air drying. It can be difficult for
children to touch the sensing area.
•Do not pour urine on the nozzle of the washer. Otherwise it creates dirt
and causes clogging.
•Please use the new hose assembly that comes with this machine. The old
one cannot be reused If it is equipped with other appliances connected
to the water source, please replace them as well. Otherwise, it is easy to
cause water leakage and property loss.
•When sudden power failure, please unplug the power plug, close the
Angle valve, to prevent leakage. Otherwise, it is easy to cause water
leakage and property loss.
•Please avoid direct sunlight or keep heating equipment near this product.
Otherwise it may cause discoloration of the product.
•In order to avoid the danger caused by the wrong resetting of the thermal
circuit breaker, do not supply power through external switching devices,
such as timers or circuits connected to regular on-off or off-off by
common components.
•Be sure to turn off the water supply Angle valve when removing strainer.
Tighten the strainer firmly when installing it. Otherwise easy to cause
water leakage.
•When it is not used for a long time, such as business trip or travel, please
be sure to remove the power plug, close the water source, and drain the
internal water. Otherwise, damage caused by frozen internal water can
lead to fire and water leakage.
•During the cold winter months, when products are transported long
distances or stored for a long time, the remaining water in the products
may freeze. To prevent damage caused by freezing, please take anti-
freezing measures. Otherwise, damage caused by frozen internal water
can lead to fire and water leakage.
•In the same room where this product is installed, a water stop valve shall be
installed at a convenient position to cut off the inlet water of this product in
case of emergency without the help of tools. Otherwise, unexpected failure of
the product may lead to loss of users.
•Please do not pour newsprint, paper pad, sanitary napkin and
other easily blocked articles into the toilet.
•Please do not use in the environment below 0°C.
•Do not hit the ceramic with gravity to prevent damage and leakage.
•Please do not insert cementing materials (cement mortar, etc.) in the base of
the toilet to prevent cracking due to expansion.
•Please use the battery correctly according to the following methods.
•Please press plus or minus to install the battery correctly; Remove the
battery when not in use for a long time. Battery power depletion will affect
signal reception, please replace the battery in time; When the battery is
discarded, please use tape to insulate it. Please place the battery out of the
reach of infants; When the electrolyte touches the body, please wash it with
clean water. Do not rub your eyes if the electrolyte accidentally enters your
eyes. Rinse with water immediately and seek medical advice immediately.
Otherwise, fluid from the battery could cause a fire. If swallowed, seek medical
advice. Otherwise it is easy to cause blindness.
•Do not do the following when using the battery.
•Do not carry or keep with metal products (necklaces, watches, etc.);
Do not mix old and new batteries; Do not decompose the battery or
put it into water or fire.

98
OVERVIEW & PARTS
Discovery DLS Discovery DLS Parts
Side Buttons Stainless Steel Nozzle
Lid
Warm Air Dryer
Side Buttons
Nozzle
Release Button
Seat Sensor
Heated Seat
1. Rear Wash
2. Front Wash/Dynamic Stream
1. Power/Stop
2. Auto Wash
PRODUCT INFORMATION
T-Valve
(2) Rubber Anchors
Bidet Hose
Remote Control
Toilet Hose
Remote
Control Holder
Catch Plate
(2) AAA Batteries
(2) Bolt Guides (2) Mounting Screws
L-Valve 1/2 Conversion
Nut
2
1
1 2

1110
Front, Top, and Back Side
REMOTE CONTROL
Stop Button
Front Wash
Rear Wash
Warm Air Dryer
Auto Clean
Open/Close Lid & Seat
Adjustable
Water Pressure
Adjustable
Air Temperature
Adjustable
Nozzle Position
Adjustable
Water Temperature
Adjustable
Seat Temperature
Nozzle Clean
Dynamic Stream
LED Night Light
Remote Control Pairing
(Follow these instructions if the bidet seat is not responding to the remote)
•Unplug the bidet seat. Press and hold the “STOP” button on the
remote until the indicator lights flash.
•Hold the remote close to the bidet seat and plug it back in.
The indicator lights will stop flashing when the remote has
successfully paired.

1312
Warm Air Dryer
Reduce the need for toilet paper with a built in adjustable warm air dryer.
Press to activate the warm air dryer. Adjust the fan speed to your liking.
The dryer automatically turns off after 4 minutes.
•Low - Blue
•Medium - Purple
•High - Red
Auto Clean (Side button or Remote)
Press “Auto” to activate a pre-programmed wash and dry cycle. A rear wash
will run for 90 seconds, followed by the warm air dryer for 4 minutes. Press
again during a wash to skip ahead to the dryer.
Adjustable Water Pressure
Press the “Water Pressure” (+, -) buttons to adjust the water
pressure to your liking.
Adjustable Nozzle Position
Adjust the nozzle position forward or backward to achieve maximum
cleanliness and comfort by pressing the “Nozzle Forward” and
“Nozzle Backward” buttons.
Nozzle Clean
Press to extend the nozzle for manual cleaning. This feature can only
be activated when the seat is not occupied. The nozzle will fully extend. Gently
clean the nozzle with a soft cloth or toothbrush. Press “Stop” button to retract
nozzle to stand by mode. (not sure if this applies to dls)<<<<--------
Preparation
•To turn on the seat, press the Power button on the side of the seat
•Pre-Nozzle Rinse - As soon as the seat sensor is activated, a pre-rinse
cycle will begin. This process rinses the nozzle in preparation for a wash
function. Water will drain into the bowl during this time.
•Turn Sound On/Off - Press and hold the night light button for 3 seconds
to turn beeping sounds on/off.
Open/Close Lid & Seat
Press to open or close the lid and/or seat. Press and hold the “Nozzle Clean”
and “Dynamic Stream” buttons for 3 seconds to turn the automatic open
function on/off. This is an automatic hands-free function which makes each trip
to the bathroom a safe and luxurious experience.
Stop Button
Stops all operations.
Front Wash
Press “Front” to activate an oscillating front wash. Automatically, the nozzle
comes out and sprays warm water towards the front. Press again
to disable oscillation.
Rear Wash
Press “Rear” to activate an oscillating rear wash. Automatically, the nozzle
comes out and sprays warm water towards the rear. Press again
to disable oscillation.
Operating Your Discovery DLS
OPERATION
PRODUCT INFORMATION

14 15
PRODUCT INFORMATION
Dynamic Stream
Press “Dyanmic Stream” to activate a wash that quickly alternates between
hot and cold water. This feature assists in stimulating bowl movements.
LED Night Light
Easily find your way at night with the soothing glow of the night light.
Press to turn the night light on/off.
Adjustable Water/Air/Seat Temperature
Adjust the temperatures of the heated seat, warm water, and the warm air
dryer to your liking.
•Low - Blue
•Medium - Purple
•High - Red
Ultraviolet (UV) Sterilization
Clean in comfort with the confidence that your bathroom and body
are free from germs. The built-in UV sterilizer automatically
cleanses the nozzle after each use.
Power/Stop Button (Side button)
Turn the bidet on/off by pressing the “Power/Stop” button on the side.
Short press to power on or long press to enter standby mode. Short press
while powered on to stop any operations.
•When the power button is blue, it is in UV sterilization mode or in use.
•When the power button is red, it is ready to use.
PRODUCT INFORMATION

1716
INSTALLATION GUIDE
CAUTION BEFORE INSTALLATION
Do not plug in before installation. If you need an electric power
system or extension, please consult a qualified electrician.
Please contact our service center at 847.458.2334 for alternate
fittings or assistance with this process.
1. Turn Off Water
Turn off the water shut-off
valve. Drain the toilet tank
completely by flushing the
toilet. Unscrew the hose
connected to the toilet tank. Existing
Toilet Hose
2. Remove Seat & Lid
Remove mounting bolts to
release the existing toilet
seat from the toilet.
3. Install Catch Plate
Insert the rubber anchors into the mounting holes. Place the catch plate and guides
over each mounting hole. Insert the mounting screws through the bolt guides, catch
plate, and rubber anchors. Fasten the catch plate to the toilet tank.
PRODUCT INSTALLATION
Slide the bidet seat all the way
onto the catch plate until you
hear a click.
4. Install Your
Discovery DLS
Screw
Bolt Guides
Catch Plate
Rubber Anchors
Release
Button

18 19
PRODUCT INSTALLATION
6. Plug It In!
Plug the power cord into a 120V power outlet.
Please contact our service center at 847.458.2334 if you have any questions.
1. Install the t-valve on to the toilet tank. Ensure the rubber gasket is
properly seated inside the t-valve.
2. Connect the provided toilet hose to the water shut-off valve
and t-valve. You may also use your existing toilet hose.
3. Connect the bidet hose to the bidet seat and t-valve.
4. Open the water shut-off valve. Check for any leaking or dripping.
5. Connect the Water Hose
*Shut-off valve may vary. If supplied parts do not fit, please call 847.458.2334.
Alternate fittings are available upon request.
7. Mounting the Remote
1. Drill two 6mm holes on the wall that lines up with the remote holder.
2. Install the wall anchors in the newly drilled holes.
3. Place the remote holder over the wall anchors and attach it to the wall
with the provided screws.
4. Insert supplied batteries (1.5V AAA), close the battery cover, and place
the remote control in the holder.
ScrewsWall Anchors
Remote Holder
PRODUCT INSTALLATION
Toilet Tank
T-Valve
Toilet Hose
Bidet Hose
(Optional)
1/2” Conversion Nut
Shut-off Valve
Washer
*Available upon request

20
UNIT SEPARATION
Removing the Discovery DLS
1. Disconnect the power plug.
2. Close water supply shut-off valve.
3. Drain the water from the bidet by holding the release
button as shown above.
4. Remove the bidet seat from toilet as illustrated.
Release Button
21
Cleaning the Discovery DLS
•Do not use thinner, benzene or toilet bowl cleaner,
as it may cause discoloration or damage.
•Disconnect the power cord and use a wet cloth when you clean this
product. Do not spray water directly on to this product.
Extended Travel
When the seat will not be used for more than a few days, it is
recommended to unplug the unit and turn off the water shutoff valve.
MAINTENANCE

22
SPECIFICATIONS
Specifications Discovery DLS
Model Discovery DLS
Rated Voltage 120 V, 60 Hz
Rated Power 1050 W
Waterproof Guide IP X 4
Seat Temperature Off / 93.2 - 102.2°F
Water Temperature Off / 95 - 102.2°F
Water Heating Instant
Air Temperature 102.2°F
Ambient
Temperature Requirements
102.2°F
Dimensions
(Elongated)
20.79 in. x 16.38 in. x 5.59 in.
23
WARRANTY
5 YEAR PREMIER WARRANTY COVERAGE
Bio Bidet Innovation LLC warrants the Discovery DLS to be free from
manufacturing defects under normal use for a period of 5 years from the
date of purchase.
Our obligation to you under this warranty is limited to repair or replacement,
at our option, of defective products or parts, provided the products were
properly installed and used in accordance with the instructions. We reserve
the right to make inspections in order to determine the cause of the defect.
We will not charge for labor or parts in connection with warranty repairs or
replacements. We are not responsible for the cost of removal, return shipping,
and/or reinstallation of products.
This warranty does not apply to:
•Damage or loss from a fire, earthquake, flood, storm, etc.
•Damage or loss resulting from any unreasonable use, abuse,
negligence, or proper maintenance.
•Damage or loss from improper installation, removal,
repair, or modification.
•Damage or loss resulting from sediment or other matters contained
in your water system.
This warranty gives you specific legal rights. For warranty service information,
please contact your dealer or Bio Bidet Innovation LLC. Only the original
purchaser may submit a claim under this warranty.
This warranty is our only warranty covering your product. Repair or
replacement as provided under this warranty shall be the exclusive remedy
available to you. We shall not be responsible for loss of the product of for other
incidental, or consequential damage or expenses you may incur for labor or
other costs due to installation or removal, or cost of repairs by others, of for
any other expense not specifically stated above. Except to the extent
prohibited by applicable law, any implied warranties, including that of
merchantability or fitness for use, are expressly limited to the
duration of this warranty.

24 2524
WARRANTY
Warning - Bio Bidet Innovation LLC shall not be responsible or
liable for any failure of, or damage to, this plumbing product or
product component caused by either chloramines in the treatment
of public water supply or in-tank bowl cleaners containing chlorine
(calcium hypochlorite).
Note - The use of high concentration of chlorine or chlorine related
products can seriously damage the fittings. This damage can cause
leakage and serious property damage.
BIO BIDET INNOVATION LLC
7900 S RT 31 Crystal Lake IL 60014
T: 847-458-2334
F: 847-854-1296
[email protected]
www.biobidet.com

Customer Support
7900 S Route 31 Crystal Lake, IL 60014
T: 847.458.2334
U.S. TOLL FREE: 877.339.5214
[email protected]
www.biobidet.com
THANK YOU!
