BEMIS bioBidet UB-4800 User manual

OWNER’S MANUAL
UB4800

2 3
TABLE OF CONTENTS
PRODUCT INFORMATION
Features.......................................................................................5
Important Safeguards...........................................................6
Parts..............................................................................................12
Dimensions................................................................................13
Product Information..............................................................14
PRODUCT INSTALLATION
Seat Installation Guide.........................................................13
Water Connection Guide....................................................17
Testing & Seat Bumpers......................................................18
Remote Installation Guide..................................................19
PRODUCT OPERATION
How to use...............................................................................20
Side Control Panel................................................................22
Warnings....................................................................................23
Cleaning.....................................................................................24
Maintenance.............................................................................25
Troubleshooting Guide.......................................................29
WARRANTY
Warranty....................................................................................30

4 5
FEATURES
•Wireless remote with touch panel
•Wide cleaning
•Adjustable heated seat
•Pulsating
•Kids wash
•Massage cleaning
•Intelligent body sensor
•Satisfying posterior cleaning
•Splash guard
•Soft feminine cleaning
•Slow closing seat/lid
•Adjustable nozzle
•Quick release for easy cleaning
•Nozzle self-clean
•Automatic power save

6 7
IMPORTANT SAFEGUARDS
CAUTIONS BEFORE INSTALLATION
Note the following important points:
•Do not install in a location where water might be splashed on this
appliance or in a location exposed to excessive moisture where
condensation might form on the product’s surface.
•To avoid damage to electronic components due to high levels of
humidity, provide adequate ventilation by opening a window
and/or door when bathing.
•Water supply should have a water pressure of 0.007MPa to 0.74MPa.
•Connect the product to a pipe carrying potable water. Do not connect to
an industrial water line or other water supplies that are not potable.
•Cool the unit in the room before installation.
•The thermal protector in the water tank may malfunction when
transporting or storing warm water.
•The rated power voltage is AC 120V, 60Hz.
•Do not plug the unit in until installation. It may result in malfunction.
READ ALL INSTRUCTIONS BEFORE USING
DANGER- To reduce the risk of electric shock:
Do not place or store this appliance in a location where it can fall or be pulled
into a tub or sink.
•Do not place in, or drop into water or other liquids.
•Do not touch a product that has fallen into water. Unplug immediately.
WARNING-
To reduce the risk of burns, electric shock, fire or injury:
•Close supervision is necessary when this appliance is used by or is near
infants, elders, or handicapped persons. Children should not be permitted
to use or touch this appliance without adult supervision. Be sure to adjust
the toilet seat’s temperature for elders, handicapped persons, or people
with sensitive skin.
•Use this appliance only for its intended purpose as described in this
manual. Do not use attachments not recommended by the manufacturer.
•Do not operate this appliance if the cord is damaged or if the
product is dropped into water.
•Install the unit properly by following the installation procedure.
•Only authorized persons can install or repair the unit. Do not attempt to
service this appliance by yourself. Doing so could void the warranty.
•Keep the cord away from heated surfaces.
•Never drop or insert any objects into any opening or hose.
•Do not use outdoors. Do not use aerosol or oxygen
spray products on the unit.
•Always follow the grounding instructions in the
manual before plugging in the unit.
SAVE THESE INSTRUCTIONS

8 9
IMPORTANT SAFEGUARDS (CONT.)
WIRING REQUIREMENTS
Any other servicing should be performed by
authorized service representatives.
Grounding Instructions
•This product should be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This product is equipped with a
cord having a grounding wire with a grounding plug. The plug must be
plugged into an outlet that is properly installed and grounded.
•DANGER- improper use of the grounding plug can result in a risk of
electric shock.
•If the cord or plug is necessary to repair or needs to be replaced, do not
connect the grounding wire to a flat blade terminal. The grounding wire
can be identified by its insulated outer surface. It will either be colored
green or will not contain yellow stripes.
•Check with a qualified electrician or seviceman if you do not understand
grounding instructions or if you do not know whether the product is
properly grounded.
•This product is for use on a nominal 120V circuit. It has a grounding plug
that looks like the plug illustrated in sketch A. A temporary adapter, which
looks like the adapter illustrated in sketches B and C, may be used to
connect this plug to a 2-pole receptacle as shown in sketch B if a properly
grounded outlet is no available. The temporary adapter should be used
only until the properly grounded outlet (sketch A) can be installed by a
qualified electrician, the green colored rigid ear, lug and the like extending
from the adapter must be connected to a permanent grounded such as
a properly grounded outlet box cover. Whenever the adapter is used, it
must be held in place by the screw.
•If it is necessary to use an extension cord, use only a three wire
extension cord that has a three-blade grounding plug, and a three-slot
receptacle that will accept the plug on the product. Replace or repair
a damaged cord.
•Remote control power: AAA (1.5V), 3EA
CAUTION RISK OF EXPLOSION TO BATTERY IF REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

10 11
IMPORTANT SAFEGUARDS (CONT.)
Follow these basic instructions to ensure the safe
use of your appliance.
•Do not use a faulty or loose electric outlet or cord. Doing so may result in
a short circuit, electric shock, or fire.
•Do not throw anything flammable into the toilet. Doing so may
result in fire.
•Do not splash water on this product. Doing so may result in
fire or electric shock.
•This product must be grounded. Not doing so
may result in short circuit, electric shock, or malfunction.
•Do not use too many appliances on one power strip. Doing so may result
in fire or damage. Be sure to use a dry and clean outlet.
Do not use a faulty or loose outlet.
•Plug and unplug properly. Do not plug or unplug with wet hands. it may
result in injury or short circuit. Do not grab the cord when unplugging.
Pull out the plug properly.
•Do not use when the seat and lid are disassembled.
Doing so may result in electric shock due to high voltage inside.
•Unplug when beeping or emitting a strange odor. Unplug right away.
Contact your dealer from whom you made the purchase.
•Do not disassemble, repair,or modify this appliance.
Doing so may result in fire or electric shock.
•Use tap potable water only (ground water).
Not doing so may cause irritation or injury.
•Do not step on or place heavy objects on this appliance.
Doing so may damage the unit or result in malfunction of the appliance.
•Be aware of urine splash on nozzle. Doing so may
result in malodor or failure of appliance.
•Do not sit or lean against the lid or control panel.
Doing so may cause malfunction or breakage.
•Unplug if you do not plan to use for a long period of time.
•Unplug while there is thunder or lightning.
•Do not pull out the waterhose forcefully.
Doing so may cause water leakage.
•Do not put a vase, water cup, or small materials on this appliance.
•Be aware of low-grade burns. Sitting on the heated seat for a long
time may result in a low-grade burn. Use care when being used by the
following: children, senior citizens, patients, or others who can not control
the temperature level. Sleeping pill users or people who are on medication
that causes drowsiness. Those who are intoxicated or very tired may fall
asleep while sitting on the unit.
•Unplug when cleaning. Not doing so may result in fire or electric shock.
•Use low temperature for children and disabled. High temperature may
result in burns if person fails to recognize the temperature.

12 13
PARTS
15mm Water supply hose (2pcs)
DIMENSIONS
The toilet dimensions must be
within those shown above. Do
not install this appliance on a
toilet that does not meet those
dimensional requirements.

14 15
PRODUCT INFORMATION
This appliance is equipped with an
occupied sensor. The unit will not work
unless the seat is occupied.
SPECIFICATIONS
Recommended water supply pressure are 0.1~0.69MPa. The minimum available
water supply pressure is 0.07MPa, however under 0.1MPa pressure, water spray
pressure might not be adequate.
Item UB-4800
Standard power supply AC 120V 60Hz660W
Water supply Way of connection Direct connection to tap water
Water pressure 0.07MPa ~ 0.74MPa
Cleansing Spray for cleansing 900 +/- 100 ml/min
Spray for bidet 850 +/- 150 ml/min
Water capacity 800 ml
Spray temperature Room Temp ~ 104°F (40°C)
Heater capacity 600W +/- 10%
Safety feature Thermal switch, Temperature fuse, Floating
switch
Heated seat Seat temperature Room temp ~ 104°F (40°C)
Heater capacity 55W +/- 15%
Safety feature Temperature fuse
Circuit breaker Within 15mA 0.03 seconds
Length of power cord 1.2m
Dimensions (W) 407 mm X (L) 532mm X (H) 170mm
(W) 16.02 in X (L) 20.94 in (H) 6.69 in
Weight 4.16kg (9.17lbs)
INSTALLATION
1
3
3
2
2
4
5
6
1
6
5
4
Mounting Plate
Cone packing Washer Nut
Mounting bolt
Guide
1. Remove the seat from
the existing toilet body.
•Remove the nuts,
washers, and cone packings
from the toilet seat and
mounting bolts.
•Then remove the toilet
seat, lid, and mouning bolts.
Keep them in case you
need them later.
2. Mount the plate
•Place the mounting plate
and guides over each
mounting hole.
•Insert the mounting bolts
through the plate and
mounting holes.
•Slide the cone packings and
washers onto the bolts and
fasten with nuts.

16 17
WATER CONNECTION GUIDEINSTALLATION (CONT.)
DO NOT plug in until
installation is finished
completely. Not doing so
may damage the appliance.
If electric work is
needed, please contact
a qualified electrician or
serviceman only.
•Slide the unit onto the
mounting plate until it clicks.
•To detach the unit, lift upward
and forward.
•After installing your
bidet attachment, check to
see if there is a gap between
the toilet base and toilet seat.
3. Attach the unit •Close the shutoff valve
by turning it clockwise.
•Then flush the water
tank completely to
empty it.
•Remove the existing
water supply hose
from the water tank.
•Install the T-valve
on the water tank.
•Connect one end
of the water supply
hose (7/8 to 3/8)
from the T-valve to
the shutoff valve.
2W ater tank
4
6
6
5
1
7
5
T-valve
Water supply hose
(7/8” to 3/8”)
Water supply hose
(1/2” to 1/2”)
Optional 1/2” Spare Nut
(Available by request)
To the unit
Main unit
•Connect the other end of the water supply hose (1/2 to 1/2) from the
T-valve to the main unit.
•Open the shutoff valve by turning it counter clockwise.
•Check for any water leaking or dripping.
Using an Inline Carbon Filter
The use of an external inline carbon water filter is not required unless the unit
is used in an area with extreme hardwater. If a carbon filter is used, the filter
must be replaced every 6 months. Inline carbon filters can be purchased
from any authorized Bio Bidet reseller.
NOTE:
This product is designed and intended for use exclusively with Bio Bidet
USPA water filters. The purchase or use of any other water filter is not the
responsiblity of BBC Innovation LLC. As such, any use of non USPA water
filters is prohibited and will void the warranty for those Bio Bidet products.
Bio Bidet will not be responsible for any resulting damages or claims related
to the misuse or distribution of non Bio Bidet Uspa filters.

18 19
REMOTE INSTALLATION GUIDETESTING & SEAT BUMPERS
•Plug the power cord into the
outlet, and then the water
tank will be filled with water in
2 minutes.
•Check all the functions.
Cover the toilet using the
sheet of plastic wrap on the
unit to prevent the washing
water from being sprayed
out of the toilet. Then check
for all functions described in
this manual.
•There are possibilities
of water coming out
that remains in the unit
while heating.
•After installing your
bidet attachment, check to
see if there is a gap between
the toilet base and toilet seat.
•If necessary, place
the bumpers on the
underside of your toilet seat
as indicated above.
•Open the battery lid and
inster AAA batteries (3pcs).
Remember to place the
remote in a spot you can
easily reach while seated.
•Fasten the remote control
bracket with double sided
adheasive tape on the proper
area of the wall as shown.
CAUTION
•Use AAA batteries
•Do not use old and new batteries together only use the same
type of batteries.
•Remote control and remote control mounting panel have magnets.
•Check batteries if the remote control is not working.
The remote control should be
installed on the wall.
Keep the remote control in
the bracket to prevent damage
by dropping.

20 21
OPERATION
Stop
•Press “stop” to stop
current operation
•When a user stands
up, all operations will
stop automatically.
Cleaning
•Press “Cleansing” for
posterior wash. The
function will stop
automatically in 1 minute.
•Press this button again to
activate oscillation. The
nozzle moves back and
fourth automatically to
widen cleansing area.
•Oscillation wash stops if this
button is pressed again.
Massage
•Press “Massage” to
help you to stimulate
bowel movements with
aerated wash.
•Press the button
again to stop.
Bidet
•Press “Bidet” for feminine
wash. The function will stop
automatically in 1 minute.
•Press this button again to
activate oscillation. The
nozzle moves back and
fourth automatically to
widen cleansing area.
•Oscillation wash stops if
this button is pressed again
Kids
•Press “Kids” to change all
functions to be suitable
for children: 1 minute for
oscillation, level 1 of water
pressure, and level 5 of
nozzle position.
•This unit should be
used under the supervision
of an adult.
Water/Seat
Temperature Adustment
•Press “Water Temp” while on
or off the unit.
•Press again to adjust
water temperature to
93°F →98°F →104°F →OFF
(room temperature).
•Press “Seat Temp” while on or
off unit.
•Press again to adjust seat
temperature to 93°F →98°F
→104°F →OFF
(room temperature).
Self Cleaning
•Nozzles are cleaned by
automatically rinsing off
before and after every use.
Self-Diagnosis System
•The power indicator LED
light on the side of the unit
will flash if the appliance has
a problem.
•Unplug and contact service
center immediately.
*Do not forcefully push or pull
the nozzles or bend them. It
may result in failure.

22 23
SIDE CONTROL PANEL WARNINGS
Side Control Buttons
•Use side control buttons
on unit when remote
control is broken or its
batteries are dead
•Press “Cleansing” or
“Bidet” to start.
•Press again to stop. Do
not use sharp items to
press buttons.
Do not drop the remote control in water.
It may cause out of order malfunction.
All functions will be operational when the seat is
occupied except Nozzle Cleaning and Power/Economy.
Before operating, ensure that the water tank is
filled up completely.
Beeping
•Press “Beeping” to enable the beeping sound.
•To disable, press the button again.
Water Pressure
•Water spray pressure can be adjusted in 5 levels by
pressing (HI)(LO) buttons.
•Set water pressure level will remain.
Nozzle Position
•Nozzle position can be adjusted in 5 levels by pressing (FR)/(BK) buttons.
•Set nozzle position will remain.
Economy
•Press “Stop” button for 3 seconds to activate the power saving function.
•Economy function will be disabled once user sits on bidet.
*When the power cord is plugged in initially, nozzles for feminine wash and
posterior will come out in turn.
*All the operating times indicate are approximate.

24 25
CLEANING MAINTENANCE
NOZZLE CLEANING
DO NOT Forcefully push, pull, or bend the nozzles. It may result in failure.
Make sure to use “Stop” button on the remote control.
Auto Cleaning
•Press “Back” (BK) button for 3 seconds to start
auto cleaning. Cleansing and Bidet nozzles will be
cleaned automatically by turns.
•Press “Stop” and nozzle will return to
stand-by mode.
Manual Cleaning
•Make sure the occupied sensor is not
activated. (Do not sit on the seat or place hands
on the seat sensor.)
•Press “Front” (FR) button for 3 seconds
to extract feminine nozzle. Press “Front”
(FR) or “Back” (BK) button for 3 seconds
to extract posterior nozzle. Press “Stop”
button to retract nozzle.
•Use a toothbrush or soft cloth to clean nozzles.
•Press “Stop,” and nozzle will return to
stand-by mode.
STRAINER MAINTENANCE
This appliance will not operate properly if the strainer is clogged. Be sure to
clean the strainer regularly.
•Close the shutoff valve by turning it clockwise.
•Unscrew the nut.
•Clean the strainer with a small brush.
•Rescrew the nut.
•Open the shutoff valve by turning it counter clockwise.
CLEANING THE BODY
•Regularly wipe off the body with a dry soft cloth or sponge, or wash with
a damp cloth and mild detergent.
•For care of plastic body, do not use any cleansers such as: toilet cleanser,
home cleanser, bleach, benzene, paint thinner, cresol etc.

26 27
MAINTENANCE (CONT.)
DRAINING WATER
Drain water while not using the unit over an extended period of time.
•Unplug the power supply
cord. Not doing so may cause
electric shock or fire.
•Unscrew the mounting
bolts. Refer to the
installation procedure.
•Raise the unit and thoroughly
drain the water by unscrewing
the drain bolt from the closed
position. (Do not lose the
drain bolt.)
*The following figure is only
to check the location of ‘Drain
Bolt.’ To prevent malfunction,
do not place the vertical
positionor tilt the product.
•Screw drain bolt back to
closed position and reinstall
the unit. Refer to the trial
operation procedure before
using the appliance again.
•Close the shutoff valve.
1. Unplug the power
supply.
2. Close the shutoff valve. 3. Unscrew the
mounting bolts.
4. Drain the water

28 29
MAINTENANCE (CONT.)
Problem Possible Cause Solution
Completely fails
to work
Is there a
power outage?
Is the power cord
unplugged?
Are you sitting on the
seat correctly?
Check for a
power failure or a
tripped breaker.
Plug the power cord
in properly.
Sit on the seat correctly
to activate the sensor.
Water does not spray Is the water shutoff
valve closed?
Is the strainer clogged?
Are the nozzles
clogged?
Check for any water
leaking or dripping.
Clean the strainer.
Clean the nozzles.
Water is leaking
or dripping
Are all hoses tightened
up properly?
If water is still leaking
or dripping, contact
your dealer.
Seat or water is not
warm enough
Is the temperature set
to OFF?
Is the appliance used
in eco mode during
cold weather?
Reset the temperature.
Press “eco” again to
release the function
PREVENT FREEZING
•Make sure the power cord is properly plugged in.
•Set the water temperature to low or middle. (Freezing can be prevented
by thermal efficiency of water tank.) If there is no heating system in the
toilet, wrap the pipes with cloth or other materials.
•If the unit has been not used for a long time during winter, unplug and
drain the water from the water tank and pipes thoroughly. Refer to the
“Drain water” procedure above.
TROUBLESHOOTING GUIDE

30 31
WARRANTY
USPA Personal Hygiene Appliance Limited Warranty
We warrant our products to be free from manufacturing defects under normal
use and service for a period of one (1) year from the date of your purchase.
100% Coverage of all parts and labor for the product for the first year from
original date of purchase. This warranty is only valid within the United States
and Canada.
Our obligation to you under this warranty is limited to repair or replacement,
at our option, of defective products or parts, provided that the products
were properly installed and used in accordance with instructions. We reserve
the right to make inspections in order to determine the cause of the defect.
We will not charge for labor or parts in connection with warranty repairs or
replacement. We are not responsible for the cost of removal, return and/or
reinstallation of products.
This limited warranty does not apply to:
•Damage or loss from a fire, earthquake, flood, storm, etc.
•Damage or loss resulting from any unreasonable use, abuse, negligence,
or improper maintenance.
•Damage or loss from improper installation, removal, or modification.
•Damage or loss resulting from sediment or other matters contained in
your water system.
This warranty gices you specific legal rights.
For warranty or service information, please contact your dealer whereyou
bought this appliance or us.
Only the original purchaser may submit a claim under this limited warranty.
This limited warranty is our only warranty covering your product.
Repair or replacement as provided under this warranty shall be the
exclusive remedy available to you. We shall not be responsible for loss of
the product or for other incidental, or consequantial damage or expenses
you may incur or for labor or other costs due to installation or removal, or
cost of repairs by others, or for any other expense not specifically stated
above. Except to the extent prohibited by applicable law, any implied
warranties, including that of merchantability or fitness for use, are expressly
limited to the duration of this warranty.
WARNING! We are not responsible or liable for any failure of, or damage to,
thsi plumbing product or product component caused by in-tank bowl cleaners
containing chlorine (calcium hypochlorite).
NOTE: The use of high concentration of chlorine related products can
seriously damage the fittings. This damage can cause leakage and serious
property damage.
For more information, please contact your dealer or us.

Technical Support/Customer Service
7900 S Route 31 Crystal Lake, IL 60014
T: 847.458.2334
U.S. TOLL FREE: 877.339.5214
[email protected]om
www.biobidet.com
Thank You
