BEMIS BIOBIDET SLIM TWO User manual

OWNER’S MANUAL
SLIM TWO

32
TABLE OF CONTENTS
PRODUCT INFORMATION
Safety Precautions...................................................4
Parts & Dimensions..................................................8
Product...........................................................................9
Remote Control........................................................10
PRODUCT INSTALLATION
Product Installation..................................................11
PRODUCT OPERATION
How to Use.................................................................14
Maintenance & Cleaning......................................22
Settings.......................................................................24
Troubleshooting......................................................25
Specifications...........................................................26
WARRANTY
Warranty......................................................................27

54
SAFETY PRECAUTIONS
IMPORTANT SAFEGUARDS
•When using electrical products, especially when children are present, basic
safety precautions should always be followed.
READ ALL INSTRUCTIONS BEFORE USING
•For use with 120V 60Hz: Power supply must be a 15 Amp GFCI outlet.
•The electrical cord must be connected to a GFCI outlet.
•The GFCI outlet should be 1 ft. above the floor.
•Install only in well-ventilated areas to avoid excess humidity.
•Do not install in narrow toilet stalls or in shower stalls.
•Install only where direct contact with water is minimized.
•Do not install near any heat source.
•Avoid using extension cords if possible. Consult with a certified electrician
where extension cords are necessary.
DANGER - TO REDUCE THE RISK OF ELECTROCUTION
•Do not use while bathing.
•Do not place or store products where it can fall or be pulled
into a tub or sink.
•Do not place in or drop into water or other liquid,
•Do not reach for a product that has fallen into water. Unplug immediately.
WARNING - TO REDUCE THE RISK OF BURNS,
ELECTROCUTION OR INJURY TO PERSONS:
•Close supervision is necessary when this product is use by, on, or
near children.
•Use this product only for its intended use as described in this manual.
Only use attachments recommended by the manufacturer.
•Never operate this product if it has a damaged cord or plug, if it
is not working properly, has been dropped or damaged, or dipped into
water. Return the product to a service center for examination and repair.
•Keep the cord away from heated surfaces.
•Never drop or insert any objects into any opening or hose.
•Do not use outdoors or operate where aerosol (spray) products are being
used or where oxygen is being administered.
•Connect this product to a properly ground outlet only.
See grounding instructions.
•Unplug this product before filling. Fill (reservoir) with water only.

76
GROUNDING INSTRUCTION
DANGER- Improper use of the grounding plug can result in a risk
of electric shock.
This product has a three-prong grounding plug, which must be plugged into
an outlet that is properly installed and grounded. In the event of an electrical
short circuit, grounding reduces the risk of shock by providing an escape
wire for the electrical current. If repair or replacement of the cord or plug is
necessary do not connect the grounding wire to either flat blade terminal.
The wire with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire. Check with a qualified electrician or
service person if the grounding instructions are not completely understood, or
if in doubt as to whether the product is properly grounded.
This product is for use on a nominal 120V circuit, and has a grounding plug
that looks like the plug illustrated in sketch A in Figure 1.
A temporary adapter, which looks like the adapter illustrated in sketches B
and C, may be used to connect this plug to a 2-pole receptacle as shown in
sketch B if a properly grounded outlet is not available.
The temporary adapter should be used only until a properly grounded outlet
(sketch A) can be installed by a qualified electrician.
The green colored rigid ear, lug, or the like extending from the adapter must
be connected to a permanent ground such as a properly grounded outlet box
cover. Whenever the adapter is used, it must be held in place by the screw.
OPTIONAL GROUNDING INSTRUCTIONS
SAFETY PRECAUTIONS (CONT.)
GROUNDING
FIGURE 1

98
PARTS & DIMENSIONS PRODUCT
ELONGATED TYPE

1110
REMOTE CONTROL PRODUCT INSTALLATION
1. Remove the seat from
the existing toilet body.
•Release the nuts, and then
remove the seat and cover.
•Store the seat in a proper place
for future use.
•Turn off the water.
•Remove the existing water
hose and then install T-valve to
the bottom of the toilet tank.
Ensure the rubber washer is
properly seated and attach
the original water hose to the
T-Valve.
2. Install the T-Valve.

1312
5. Connect bidet hose. 6. Attach the remote
control bracket to
the wall.
•After installing the T-valve,
connect the supplied bidet
hose from the center of the
T-valve to the bidet.
•Turn on the water and check
for leaks.
•Remove the adheasive
protection to attach the remote
control bracket to the wall or
other surface.
•Clean the area thoroughly
before attaching the bracket.
7. Insert two “AA” type
batteries.
•Plug in and be sure that the
nozzle comes out and retracts
when powered on.
•Do not plug the power cord
with wet hands. Risk of
electric shock.
•Insert the included
batteries inside the
battery compartment.
•Identify a location in the
bathroom for the remote
control that is visible and
reachable from the toilet.
PRODUCT INSTALLATION (CONT.)
3. Fix the bracket
onto the toilet.
•Point the arrow on the catch
plate towards the toilet tank.
•Push it until you hear a “click”.
•When the product is
not installed well, it
may cause leakage.
•Adjust as needed before
tightening bolts. Do not
over tighten the bolts.
4. Push the main body
toward the catch
plate completely.
8. Plug in!

1514
•When pressing the Massage
button during the operation of
Wash, Bidet, and Turbo, water
pressure will repeat high and
low for smooth pulsating wash.
•Pulse function will not
operate during the operation
of Sitz bath.
•When selecting Child Function,
settings adjust to low pressure.
•1 min Bidet - 30 sec Bidet
Oscillating - 30 sec Bidet Pulse.
•It provides an extra
extended nozzle position,
lower water pressure, lower
seat temperature, lower
water temperature.
3. Massage 4. Child Function
•Be sure to sit on the seat
sensor. If the sensor is not
occupied, all functions will
not operate.
•Skin to seat contact needs to
occur to activate seat.
•Selected function can be used
as described.
•When pressing the selected
function again, the nozzle will
oscillate back and forth to wash
a wider range.
•Press the button once again to
stop oscillate function
•The specialized water spray
in Turbo function helps relieve
constipation.
1. Sit On The Toilet Seat 2. Wash, Bidet, Turbo
HOW TO USE
Seat sensor

1716
5. Nozzle Position Control 6. Water Pressure Control 7. Stop 8. Seat Temperature Control
•Nozzle position is adjustable
(5 levels).
•Water pressure is adjustable.
(5 levels)
•If the water or screen filters
become blocked, it may
cause low water pressure.
Regularly check the water
and screens filters.
•All operations will stop.
•When pressing the stop button
for 3 seconds,
unit will turn off.
•Press any of Stop, Wash, Bidet,
or Turbo to turn on.
•Seat temperature is adjustable.
(4 levels)
(Off - Low - Middle - High)
•To reduce the chance of low
temperature burns, the seat has
a safety feature that turns to
low temperature (35°C, 95°F)
when seat is occupied for more
than 15 minutes consecutively.
•If the seat is set lower than
middle level, the seat will
remain at off or low level.
HOW TO USE (CONT.)

1918
HOW TO USE (CONT.)
9. Energy Saving Function 10. Nozzle Cleaning
•ECO 1 - This mode will be
activated by pressing the
Energy Saving button until the
yellow LED light turns on. (Seat
and water temperature will be
kept at 32°C)
•ECO 2 - This mode will be
activated by pressing the
Energy Saving button until the
green LED light turns on.
•ECO OFF - Press the Energy
Saving button until LED light
turns off.
•When the unit is occupied,
it adjusts to the present
temperature and is returned
to the saving mode when seat
is unoccupied.
•If the seat and water
temperature are off,
they will remain off.
•When selecting Nozzle
Cleaning while not seated, the
nozzle cleans itself
3 times. Then, the nozzle
extends and stops for
manual cleaning process.
•Clean the nozzle with a
brush and press the STOP
button after completion of
manual cleaning. Then, the
nozzle cleans itself for
3 times and retracts.
•NOZZLE CLEANING
will not operate if the seat
sensor is activated.
11. Night Light 12. Water Temperature Control
•Water temperature is
adjustable. (4 levels)
(Off - Low - Middle - High)
•Blue LED night light provides
enough brightness to see the
toilet without turning on the
bathroom light.
•Night light can be turned on
and off by pressing + for 3 secs
while not seated.
•Night light setting cannot be
adjusted if seat sensor bypass
feature is activated.

2120
HOW TO USE (CONT.)
13. Sitz Bath 14. Seat Sensor Bypass
•Wash or Bidet is switched to
Wash Sitz Bath or Bidet Sitz
Bath if Nozzle Cleaning button
is pressed during use.
•Water pressure is
switched to 1st level
regardless of preset water
pressure settings and Sitz
Bath operates for 5 minutes.
•LED of Nozzle Cleaning
turns on during the
operation of Sitz Bath.
•Select the Nozzle Cleaning
again to switch to normal
Wash or Bidet.
•The seat sensor can be
activated and deactivated
by pressing Massage
button for 3 seconds.
•If the seat sensor is
deactivated, the unit works
without occupying the seat
and select features cannot
be controlled.
•Features are Night light, Silent
mode, and Nozzle cleaning.
15. Reset Using Inline Carbon Filter
•Press and hold the Stop
button on the auxiliary panel
for 5 seconds.
•After 3 seconds, the seat
will power off. Keep holding
another 2 seconds and the
seat will power back on. This
completes the factory
reset process.
Use of external water filter is only
recommended in areas with known
hard water issues.
If a filter is used, it must be
replaced every 3 months. This
product is designed and intended
for use exclusively with Bio Bidet
DIB water filters.
The purchase or use of any other
water filter is not the responsibility
of BBC Innovation LLC.
As such, any use of non DIB
water filters is prohibited and will
void the warranty for those Bio
Bidet products. Bio Bidet will not
be responsible for any resulting
damages or claims related to the
misuse or distribution of non Bio
Bidet DIB filters.

2322
MAINTENANCE & CLEANING
1. Close the water valve.
2. Disconnect the water
supply hose. Take the
screen filter out and clean
it with a soft brush.
3. Return the filter after
cleaning and reconnect the
water supply hose.
4. Open the water valve.
1. Exterior surface of unit is
made of plastic material,
which may be damaged by
scrubber, chemicals, etc.
2. Wipe the surface with a
soft damp cloth. Do not
spray water directly onto
the surface.
3. Clean the body after
removing the power plug
from the outlet. Be sure
no water splashes into the
power plug or outlet.
4. Be careful of not dropping
any chemical detergents
or toilet cleaner on the main
body or supply hose to
avoid damage.
1. Remove the power plug
from the outlet.
2. Close the water feed valve.
3. Press the release button and
gently pull to remove the unit
from the catch plate.
4. Use a coin to open the
drain plug.
•When bidet seat is not used
for an extended period of time,
unplug and drain the unit.
Screen Filter Cleaning Maintenance During Winter Cleaning the Unit Draining of Remaining Water
OR
Water supply hose
Screen filter

24 25
TROUBLESHOOTING
PLEASE CHECK THE FOLLOWING POINTS
BEFORE REQUESTING REPAIR SERVICE.
USER SETTINGS WITH SIDE CONTROL (AUXILIARY PANEL)
Problem Check list
Completely
out of order
• Check if the power plug is not connected
• Check if the power supply or outlet has failed
Water does not
spray out
• Check if the water supply is turned on
• Check if water valve is open
• Check if nozzle is blocked by foreign material
• Check if connection hose is bent
Water pressure
is low
• Check if screen filter is blocked and by
foreign material
• Check if the water pressure is set at too low level
Water is not
warm enough • Check if its temperature is set at o or low level
Seat is not warm
enough • Check if its temperature is set at o or low level
SETTINGS
•The unit will work without sitting on the seat if the occupied seat sensor is
deactivated. (Turned off)
•If the seat sensor is deactivated, some features cannot be controlled.
(Night light on/off, silent mode on/off, and nozzle cleaning)
USER SETTING WITH THE REMOTE CONTROL
No. Function Seat
Status
Switch
Operation Description Initial Status
1Silent
mode
“ ” For
longer than 3
seconds
To turn on/o
the operating
chime sound.
ON
2Seat
sensor
bypass
“ ” For
longer than 3
seconds
Seat sensor feature
will be deactivated. OFF
3Night
light
“ ” For
longer than 3
seconds
To turn on/o the
night light. ON
Seat sensor ‘off’ Seat sensor ‘on’
No. Function Seat
Status
Switch
Operation Description Initial Status
1Factory
reset
Press and
hold the Stop
button for
5 seconds.
After 3 seconds,
the seat will
power o. Keep
holding another
2 seconds and the
seat will power back
on. This completes
the factory
reset process.
ON
2Power o
“ “ for
longer than 3
seconds
Press one of Stop,
Wash, Bidet,
Intensive or Dry to
power on.

2726
WARRANTY
1 YEAR WARRANTY
Bio Bidet warrants its products to be free from manufacturing defects under
normal use and service for a period of 1 year from the date of purchase. This
warranty is extended only to the original purchaser.
For full warranty details, visit www.biobidet.com
Contact Bio Bidet customer support with any questions you may have.
847.458.2334
[email protected]om
www.biobidet.com
SPECIFICATIONS
ITEM SLIM TWO
Rated voltage 120V, 60Hz
Max. Power consumption 870W
Power cord length 1.2 m
Water feed method Directly connected to water pipe
Recommended inlet
water pressure
99~106.6 psi
Wash Feed
Volume
Wash 0.13~0.21 gal/min
Bidet 0.13~0.18 gal/min
Turbo 0.13~0.18 gal/min
Child 0.13~0.16 gal/min
Pressure control 5 levels
Temperature
control
4 levels (o-low-middle-high)
Heater capacity 800W
Safety device Water level sensor, Thermal fuse, Bi-metal,
Temperature sensor
Heated Seat Temperature
control
4 levels (o-low-middle-high)
Heater capacity 55W
Safety device Thermal fuse
Feed water temp.
tolerance range
37~95°F (recommended 54~95°F)
Usage room temp.
tolerance range
37~104°F (recommended 50~95°F)
Dimension Elongated 15.9”(406) x 20.8”(528) x 6.8”(173)
Weight Net
Weight
(Gross
Weight)
Elongated 10.4 lb (15.2)

Thank You
Technical Support/Customer Service
7900 S Route 31 Crystal Lake, IL 60014
T: 847.458.2334
U.S TOLL FREE: 877.339.5214
[email protected]om
www.biobidet.com
