Beninca BRAINY User manual

L8542910
04/2011 rev. 1
UNIONE NAZIONALE COSTRUTTORI
AUTOMATISMI PER CANCELLI, PORTE
SERRANDE ED AFFINI
BRAINY

2
111098765 13124
33323130292827 3534 3626252423222120
F2
115/230Vac
50/60Hz
N
G N D
L
R A D I O
TLS
Encoder M1
24Vac
500mA max
AUX1
AUX2
COM
M1
C
COM
M2
C
M1
191817161514
3837
NL
F1
LAMP
230Vac
Encoder M2
M2
8k2
DAS
SWO-M1 (Open)
SWC-M1 (Close)
SWO-M2 (Open)
SWC-M2 (Close)
P.P.
COM
COM
PED.
OPEN
CLOSE
PHOT
PHOT (Close)
STOP
SHIELD
ANT
ANT
SCA 24Vac
3W max
24Vac
1A max
191817161514
Lock
12Vac
10W
191817161514 31 32 3331292827 31 32 3331292827
24Vac 24Vac
COM
NC NO
RX1TX1
SCA PHOTO-TEST
191817161514
24Vac 24Vac
COM
NC NO
RX2TX2
J2 DAS
Open
DAS N.C.
J2 DAS
Close
DAS 8K2
DAS
____
Code
Encoder M1
M1
+ s -
Encoder M2
M2
+ s -
3+3 x 0.5mm2
max 10m
U11
Fig. 1 BRAINY
OPEN/CLOSE CLOSE

3
1SFNFSFMFBMFUUFTVJmBODIJQFSTHBODJBSFMFEVFNBTDIFSFDPQSJWJUJ3JNVPWFSFMFEVFWJUJTVMMBUPEJBQFSUVSBEFTJEFSBUP"MMFOUBSFMFEVFWJUJDPOGVO[JPOFEJDFSOJFSBTFO[BSJNVPWFSMFJONPEPEBDPOTFOUJSFMBQFSUVSBEFMDPQFSDIJP1SFTTUIFUBCTPOUIFTJEFTUPSFMFBTFUIFUXPNBTLTUIBUDPWFSUIFTDSFXT3FNPWFUIFUXPTDSFXTPOUIFEFTJSFEPQFOJOHTJEF4MBDLFOUIFUXPTDSFXTUIBUBDUBTBIJOHFXJUIPVUSFNPWJOHUIFNTPBTUPBMMPXPQFOJOHPGUIFDPWFS"VGEJFTFJUMJDIFO-BTDIFOESàDLFOTPEBTTEJFCFJEFO4DISBVCFOCMFOEFOCFGSFJUXFSEFO%JFCFJEFO4DISBVCFOBOEFSHFXàOTDIUFO½GGOVOHTTFJUFBVTCBVFO;VMFU[UEJFCFJEFOBMT4DIBSOJFSEJFOFOEFO4DISBVCFOMPDLFSOBCFSOJDIUBVTCBVFOEBNJUEFS%FDLFMHFÚGGOFUXFSEFOLBOO1SFTTFSMFTEFVYBJMFUUFTMBUÏSBMFTQPVSEÏDSPDIFSMFTEFVYDBDIFWJT&OMFWFSMFTEFVYWJTTVSMFDÙUÏEPVWFSUVSFEÏTJSÏ%FTTFSSFSMFTEFVYWJTGBJTBOUGPODUJPOEFDIBSOJÒSFTBOTMFTFOMFWFSEFNBOJÒSFËQFSNFUUSFMPVWFSUVSFEVDPVWFSDMF1SFTJPOBSMBTBMFUBTFOMPTMBEPTQBSBEFTFOHBODIBSMBTEPTUBQBTDVCSFUPSOJMMPT&YUSBFSMPTEPTUPSOJMMPTEFMMBEPEFBQFSUVSBEFTFBEP"nPKBSMPTEPTUPSOJMMPTDPOGVODJØOEFCJTBHSBTJOFYUSBFSMPTBmOEFQPEFSBCSJSMBUBQB
/BDJTOįİCPD[OFLMBQLJXDFMVPEIBD[FOJBEXØDINBTFLOBLSZXBKįDZDIŔSVCZ
8ZDJįHOįİEXJFŔSVCZQPXZCSBOFKEPPUXJFSBOJBTUSPOJF1PMV[PXBİEXJFŔSVCZCMPLVKįDFCF[XZDJįHBOJBJDIXTQPTØCVNPŤMJXJBKįDZPUXBSDJFOBLSZXLJ"650."5*4.*#&/*/$®4Q"7JB$BQJUFMMP4BOESJHP7*5FMSB'BY
1SFNFSFMFBMFUUFTVJmBODIJQFSTHBODJBSFMFEVFNBTDIFSFDPQSJWJUJ3JNVPWFSFMFEVFWJUJTVMMBUPEJBQFSUVSBEFTJEFSBUP"MMFOUBSFMFEVFWJUJDPOGVO[JPOFEJDFSOJFSBTFO[BSJNVPWFSMFJONPEPEBDPOTFOUJSFMBQFSUVSBEFMDPQFSDIJP1SFTTUIFUBCTPOUIFTJEFTUPSFMFBTFUIFUXPNBTLTUIBUDPWFSUIFTDSFXT3FNPWFUIFUXPTDSFXTPOUIFEFTJSFEPQFOJOHTJEF4MBDLFOUIFUXPTDSFXTUIBUBDUBTBIJOHFXJUIPVUSFNPWJOHUIFNTPBTUPBMMPXPQFOJOHPGUIFDPWFS"VGEJFTFJUMJDIFO-BTDIFOESàDLFOTPEBTTEJFCFJEFO4DISBVCFOCMFOEFOCFGSFJUXFSEFO%JFCFJEFO4DISBVCFOBOEFSHFXàOTDIUFO½GGOVOHTTFJUFBVTCBVFO;VMFU[UEJFCFJEFOBMT4DIBSOJFSEJFOFOEFO4DISBVCFOMPDLFSOBCFSOJDIUBVTCBVFOEBNJUEFS%FDLFMHFÚGGOFUXFSEFOLBOO1SFTTFSMFTEFVYBJMFUUFTMBUÏSBMFTQPVSEÏDSPDIFSMFTEFVYDBDIFWJT&OMFWFSMFTEFVYWJTTVSMFDÙUÏEPVWFSUVSFEÏTJSÏ%FTTFSSFSMFTEFVYWJTGBJTBOUGPODUJPOEFDIBSOJÒSFTBOTMFTFOMFWFSEFNBOJÒSFËQFSNFUUSFMPVWFSUVSFEVDPVWFSDMF1SFTJPOBSMBTBMFUBTFOMPTMBEPTQBSBEFTFOHBODIBSMBTEPTUBQBTDVCSFUPSOJMMPT&YUSBFSMPTEPTUPSOJMMPTEFMMBEPEFBQFSUVSBEFTFBEP"nPKBSMPTEPTUPSOJMMPTDPOGVODJØOEFCJTBHSBTJOFYUSBFSMPTBmOEFQPEFSBCSJSMBUBQB
/BDJTOįİCPD[OFLMBQLJXDFMVPEIBD[FOJBEXØDINBTFLOBLSZXBKįDZDIŔSVCZ
8ZDJįHOįİEXJFŔSVCZQPXZCSBOFKEPPUXJFSBOJBTUSPOJF1PMV[PXBİEXJFŔSVCZCMPLVKįDFCF[XZDJįHBOJBJDIXTQPTØCVNPŤMJXJBKįDZPUXBSDJFOBLSZXLJ"650."5*4.*#&/*/$®4Q"7JB$BQJUFMMP4BOESJHP7*5FMSB'BY
LB-BOX

12
EC declaration of confirmity
Manufacturer: Automatismi Benincà SpA.
Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia
Herewith declares that: control unit BRAINY.
complies with the following relevant provisions:
EMC guidelines: 89/336/CCE, 93/68/CEE
Low voltage guidelines: 73/23/CEE, 93/68/CEE
Benincà Luigi, Legal responsible.
Sandrigo, 12/12/2010.
WARNINGS
This manual has been especially written to be use by qualified
fitters.
None of the information provide in this manual can be consi-
dered as being of interest for the end users.
Preserve this manual for future needs.
The technician has to furnish all the information related to the
step by step function, the manual and the emergency function
of the operator, and to deliver the manual to the final user.
;Foresee on the supply net an onnipolar switch or
selector with distance of the contacts equal or
superior to 3 mms.
Verify that of the electrical system there is an awry differential
interrupter and overcurrent protection.
Some typologies of installation require the connection of the
shutter to be link at a conductive mass of the ground according
to the regulations in force.
The electrical installation and the operating logic must comply
with the regulations in force.
The leads fed with different voltages must be physically
separate, or they must be suitably insulated with additional
insulation of at least 1 mm.
The leads must be secured with an additional fixture near
the terminals.
During installation, maintenance and repair, interrupt the
power supply before opening the lid to access the electrical
parts
Check all the connections again before switching on the
power.
The unused N.C. inputs must be bridged.
The descriptions and the present illustrations in this manual
are not binding. Leaving the essential characteristics of the
product unchanged, the manufacturer reserves himself the
right to bring any change of technical, constructive or com-
mercial character without undertaking himself to update the
present publication.
TECHNICAL DATA
Mains power supply 230 VAC 50/60 Hz (115VAC 50/60 Hz for BRAINY 115)
Output, Motor 1/2 motor, 230Vac (1/2 motors 115 Vac for BRAINY 115)
Motor maximum power 600W + 600W
Output, power supply of accessories 24VAC 1A max.
Protection level IP54
Operating temperature -20°C / +60°C
Radio receiver 433,92 MHz, incorporated and configurable
No. of codes storable in memory 64

13
BRAINY CONTROL UNIT
INPUT/OUTPUT FUNCTIONS
N° Terminals Function Description
1-2-3 Power supply Input 230Vac 50Hz (1-GND/2-Phase/3-Neutral)
4-5-6 Motor 1 Connection of motor 1: (4-start/5-Com/6-start)
7-8-9 Motor 2 Connection of motor 2: (7-start/8-Com/9-start)
10-11 Blinking light Connection of blinking light 230Vac 40W max.
12-13 TLS N.O. clean contact for courtesy light, timer, etc.
The activation time is regulated by the parameter TLS
14-15 24 Vac Accessories power supply output 24Vac/1A max.
16-17 Lock 12Vdc Accessories power supply output 12Vac/10W for electric lock (16:0V, 17:+12V)
18-19 AUX1 Normally Open clean contact, configurable as SCA- open gate light (default) or photocell test.
20-21 EDGE
Input, sensitive edge contact
Resistive edge: “DAS” Jumper closed
Mechanical edge: “DAS” Jumper open
When the edge is activated, the gate movement is stopped and reversed for about 3s.
22 SWO-M1 OPEN limit switch input motor 1 (N.C contact.)
23 SWC-M1 CLOSE limit switch input motor 1 (N.C. contact)
24 SWO-M2 OPEN limit switch input motor 2 (N.C. contact)
25 SWC-M2 CLOSE limit switch input motor 2 (N.C. contact)
26-27 COM Common for limit switch and all the control inputs.
28 Step-by-Step Step-by-Step button input (N.O. contact)
29 PED Pedestrian button input (N.O. contact)
30 OPEN OPEN button input (N.O. contact), configurable as Clock contact
31 CLOSE CLOSE button input (N.O. contact)
32 PHOT Active photocell input on opening and closing
33 PHOT CLOSE Active photocell input only on closing
34 STOP STOP button input (N.C. contact)
35-36 Antenna
Antenna connection for plug-in radio receiver board (35-screen/36-signal).
37-38 AUX2 Voltage-free Normally Open Contact. Configurable as second radio channel (default) or SCA-
open gate LED.
J3 Radio Plug-in connector for radio receiver.
NOTES
The EDGE must be connected exclusively to the special inputs 20/21. Two types of EDGE may be used:
If an edge with resistance 8K2 is used, close the Jumper “DAS”.
If a mechanical edge with N.C. contact is used, open the Jumper “DAS”.
If the edge is not used, bridge the terminals 20-21 and open the Jumper “DAS”.
TO CHECK CONNECTIONS:
1) Cut-off power supply.
2) Manually release the wings, move them to approx. half-stroke and lock them again.
3) Reset power supply.
4) Send a step-by-step control signal by pressing the button or the remote control key.
5) The wings should start an opening movement.
If this is not the case, invert the movement wires of the motor. (4<>6 for motor M1, and 7<>9 for motor M2) and the relevant limit
switch inputs (22<>23 for motor M1, and 24<>25 for motor M2).
PROGRAMMING
The programming of the various functions of the control unit is carried out using the LCD display on the control unit and setting the
desired values in the programming menus described below.
The parameters menu allows you to assign a numerical value to a function, in the same way as a regulating trimmer.
The logic menu allows you to activate or deactivate a function, in the same way as setting a dip-switch.
Other special functions follow the parameters and logic menus and may vary depending on the type of control unit or the software
release.
TO ACCESS PROGRAMMING
1 – Press the button <PG>, the display goes to the first menu, Parameters “PAR”.
2 – With the <+> or <-> button, select the menu you want.
3- Press the button <PG>, the display shows the first function available on the menu.

14
4 - With the <+> or <-> button, select the function you want.
5 - Press the button <PG>, the display shows the value currently set for the function selected.
6 - With the <+> or <-> button, select the value you intend to assign to the function.
7 - Press the button <PG>, the display shows the signal “PRG” which indicates that programming has been completed.
NOTES
Pressing <-> with the display turned off means an impulse of P.P.
Simultaneously pressing <+> and <-> from inside a function menu allows you to return to the previous menu without making any
changes.
Hold down the <+> key or the <-> key to accelerate the increase/decrease of the values.
After waiting 30s the control unit quits programming mode and switches off the display.
PARAMETERS, LOGIC AND SPECIAL FUNCTIONS
The tables below describe the individual functions available in the control unit.
MENU FUNCTION
Settable values
MIN-MAX-(Default)
MEMO
PARAMETERS
TCA Automatic closing time. Active only with logic “TCA”=ON.
At the end of the set time the control unit orders a closing manoeuvre. 1-240-(40s)
TM1
Motor 1 work time. Regulates the maximum duration of the opening and closing
manoeuvre of the motor 1.
It must be set about 4 sec. longer than the actual travel time of the automatism.
5-180-(24s)
TM2
Motor 2 work time. Regulates the maximum duration of the opening and closing
manoeuvre of the motor 2.
It must be set about 4 sec. longer than the actual travel time of the automatism.
5-180-(24s)
TPed
The operating time for partial opening (pedestrian) is adjusted on motor 1.
With ENC.: ON, the value is the opening percentage over the total stroke memorised
during self-setting.
With ENC.: OFF, the value is the opening percentage over the time preset in TM1
parameter.
1-99-(50%)
PMo1 The torque applied to motor 1 in the OPENING* phase is adjusted. 1-99-(40%)
PMC1 The torque applied to motor 1 in the CLOSING* phase is adjusted. 1-99-(40%)
PMo2 The torque applied to motor 2 in the OPENING* phase is adjusted. 1-99-(40%)
PMC2 The torque applied to motor 2 in the CLOSING* phase is adjusted. 1-99-(40%)
TDMo Mot.2 opening delay time.
Regulates the delay time of motor 2 on opening with respect to motor 1
0-15-(2s)
TDMC Mot.1 closing delay time
Regulates the delay time of motor 1 on closing with respect to motor 2 0-40-(3s)
TLS TLS contact activation time.
At each manoeuvre the contact closes for the set time. 1-240-(60s)
TLOc Electric lock activation time.
If the electric lock is not used, set the parameter at 0. 0-5-(3s)
TsM1
Motor 1 slowing time
Regulates the duration of the slowing phase of motor 1 on opening and closing.
Value is calculated as a percentage on the space covered during the complete ope-
ration. 0 = slowing time disabled.
0-99-(0%)
TsM2
Motor 2 slowing time
Regulates the duration of the slowing phase of motor 2 on opening and closing.
Value is calculated as a percentage on the space covered during the complete ope-
ration. 0 = slowing time disabled.
0-99-(0%)
Pso1 The torque applied to motor 1 during braking in the opening phase is adjusted * 1-99-(70%)
PsC1 The torque applied to motor 1 during braking in the closing phase is adjusted * 1-99-(70%)
Pso2 The torque applied to motor 2 during braking in the opening phase is adjusted * 1-99-(70%)
PsC2 The torque applied to motor 2 during braking in the closing phase is adjusted * 1-99-(70%)

15
MENU FUNZIONE Valori impostabili
ON-OFF-(Default) MEMO
PARAMETERS
SeaU
The intervention threshold of the anti-crashing device (Encoder) during the phase at
normal speed is adjusted.*
0:Off-1:minimum sensitivity - 99: maximum sensitivity
0-99-(0%)
SEAR
The intervention threshold of the anti-crashing device (Encoder) during braking is
adjusted *.
0:Off-1:minimum sensitivity - 99: maximum sensitivity
0-99-(0%)
** WARNING: AN INCORRECT SETTING OF THESE PARAMETERS MAY RESULT IN A DANGER.
COMPLY WITH REGULATIONS IN FORCE!
MENU FUNCTION Settable values
ON-OFF-(Default) MEMO
LOGIC
TCA
Enables or disables automatic closing
On: automatic closing enabled
Off: automatic closing disabled
(ON)
IbL
Enables or disables condominium function.
Off: condominium function disabled.
On: condominium function enabled. The step-by-step impulse or transmitter impulse
has no effect during the opening phase.
(OFF)
IbCA
The bloc of flat function is enabled or disabled.
On: the bloc of flat function is enabled. The Step-by-Step signal or the transmitter
signal has no effect during the TCA counting.
Off: the bloc of flat function is disabled.
(OFF)
SCL
Enables or disables rapid closing
On: rapid closing enabled. With the gate open or in the opening phase the intervention
of the photocell causes automatic closing after 3 s. Active only with TCA:ON.
Off: rapid closing disabled.
(OFF)
Sld
Enables or disables slowing.
On: Slowing active.
Off: Slowing excluded.
(OFF)
PP
Selects the operating mode of the ”Step by step button” and of the transmitter.
On: Operation: OPEN > CLOSE > OPEN >
Off: Operation: OPEN > STOP > CLOSE > STOP >
(OFF)
PRE
Enables or disables pre-blinking.
On: Pre-blinking enabled. Blinking is activated 3s before the motor starts.
Off: Pre-blinking disabled.
(OFF)
HAM
Enables or disables the inversion stroke function
On: Function enabled. Before each opening or closing manoeuvre the control unit
orders a manoeuvre of 2s in the opposite direction to facilitate the release of the
electric lock.
Off: Function disabled.
(OFF)
BLC
Enables or disables the block maintaining function.
Recommended for hydraulic motors to keep the leaf resting against the mechanical
stop block.
On: Block maintaining function enabled. Every 2 hours the control unit makes a clos-
ing manoeuvre with a duration of about 3s to keep the leaf in contact.
Off: Block maintaining function disabled.
(OFF)
SPN
Enables or disables starting torque function.
On: Starting torque enabled. At the start of each manoeuvre for 2s the motor oper-
ates at maximum torque.
Off: Starting torque disabled.
(ON)
LTCA
Selects the operating mode of the blinking light during the time TCA
On: Blinking light on during TCA
Off: Blinking light off during TCA
(OFF)
CLOC
Selects the mode of the OPEN input
On: OPEN input with CLOCK function.
To be used for connection to a timer for timed opening/closing. (Contact CLOSED-
gate open, Contact open, normal operation).
(OFF)

16
MENU FUNCTION Settable values
ON-OFF-(Default) MEMO
LOGIC
htr
Enables or disables Man present function.
On: Man Present operation.
The OPEN/CLOSE buttons must be held down during the whole manoeuvre.
Off: Automatic operation.
(OFF)
not
The calculation of residual operating time is activated or deactivated in the event of
partial operations:
On: Calculation of deactivated time. In case of partial operations, the operating time
is reset. The following operation restarts for the entire time preset by parameter TM1/
TM2.
Off: Calculation of activated time. In case of partial operations, the operating time
is stored in memory and then subtracted from the TM1/TM2 parameter value in the
following operation.
(ON)
1mot
Select the 1/2 motors operating mode:
On: only one motor (motor 1) active. Function to be used in the following cases:
- for single motor, to connect M1:4-5-6.
- for two syncronized motors (for instance overhead door), to connect M1:4-5-6 and
M2:7-8-9. You need to regulate the parameters related to the motor 1, the limit
switch entries M2 are disarmed (not activate).
Off: Both motors operating.
(OFF)
ENC
The Encoder is enabled or disabled. See section “ TYPES OF INSTALLATIONS”
On: Encoder enabled – The anti-crash sensor is activated.
Off: Encoder disabled – The anti-crash sensor is deactivated.
(ON)
Cvar
The code programmable transmitters is enabled or disabled.
On: Radio receiver enabled only for rolling-code transmitters.
Off: Receiver enabled for rolling-code and programmable code transmitters (self-
learning and Dip Switch).
(OFF)
mloc
Selects the type of electric lock used.
On: Magnetic electric lock, normally fed at 12Vdc.
Before each opening manoeuvre the power supply is interrupted for the time set by
the parameter TLOC.
Off: Electric lock with latch, normally not fed.
Before each opening manoeuvre power is fed at 12Vdc for the time set by the pa-
rameter TLOC.
(OFF)
TRK
The check for integrity of TRIAC is enabled or disabled.
On: Activated check: if TRAC is faulty, the motor does not start.
Off: the TRIAC is not checked.
(OFF)
TST1
The test of photocells to PHOT O input is enabled or disabled.
On: Test is enabled. If the test is negative, no operation is performed. See Fig.1
“PHOTO TEST”.
Off: Test is disabled.
(OFF)
TST2
The test of photocells to PHOT C input is enabled or disabled.
On: Test is enabled. If the test is negative, no operation is performed. See Fig.1
“PHOTO TEST”.
Off: Test is disabled.
(OFF)
2CH
On: AUX2 Output, preset as open gate light. See “SCA” figure.
Light switched on with open gate, fast flashing during closure, slow flashing during
opening, light off with closed gate.
Off: AUX2 output, preset as second radio channel of the built-in receiver.
(OFF)
BB
The thrust function in the closing phase is activated or deactivated by this logic. With
SLD logic only: ON
On: the operation in the closing phase is carried out at normal speed during the
last second (braking is disabled). In this way, a better hooking of the electric lock is
performed.
Off: disabled function.
(OFF)
Horm
The automatic switching is activated/deactivated in Service Man mode.
On: If the sensitive edge remains activated for at least 10 seconds with open or clo-
sed gate, the control unit automatically switches to Service man mode.
Off: Disabled function.
(OFF)
REM
The remote storage of the radio transmitter codes is enabled or disabled (see par.
REMOTE LEARNING).
On: Enabled remote storage
Off: Disabled remote storage.
(ON)

17
MENU FUNCTION
RADIO
PP
By selecting this function, the receiver is waiting for (Push) a transmitter code to be assigned to the step-by-step
function.
Press the transmitter key, which is to be assigned to this function.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
2Ch
By selecting this function, the receiver is waiting for (Push) a transmitter code to be assigned to the second radio
channel.
Press the transmitter key, which is to be assigned to this function.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
ped
When this function is selected, the receiver awaits (Push) a transmitter code to be assigned to the pedestrian
opening function (see TPED parameter).
Press the transmitter key, which is to be assigned to this function.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
CLR
By selecting this function, the receiver is waiting for (Push) a transmitter code to be erased from memory.
If the code is valid, it will be stored in memory and OK will be displayed.
If the code is not valid, the Err message will be displayed.
RTR
The memory of the receiver is entirely erased. Confirmation for the operation is asked.
By selecting this function, the receiver waits for (Push) the GPM key to be pressed again to confirm the operation.
At end of erasing, the OK message is displayed
Note: The transmitters are stored in an EPROM memory (Fig.1 -U11), which can be removed and repositioned in a new control
unit, it required.
MENU FUNCTION
auto
The control unit performs a series of operations for the learning of the door leaf stroke.
Initially, both leaves are moved to closed position, then, after one, or both leaves, has carried out some opening
and closing operations with different speeds, the working OK is displayed on the control unit. If this operation is
not successful, the message ERR is displayed. After checking both cables and the presence of obstacles again,
repeat the operation.
RES
RESET of the control unit. ATTENTION!: Returns the control unit to the default values.
Pressing the <PG> button for the first time causes blinking of the letters RES, pressing the <PG> button again
resets the control unit.
NMAN
Displays the number of complete cycles (open+close) carried out by the automation.
When the <PG> button is pressed for the first time, it displays the first 4 figures, the second time it shows the last
4. Example <PG> 0012 >>> <PG> 3456: made 123.456 cycles.
code
It allows to type in an access protection code to the programming of the control unit.
A four-character alphanumeric code can be typed in by using the numbers from 0 to 9 and the letters A-B-C-D-
E-F.
The default value is 0000 (four zeros) and shows the absence of a protection code.
While typing in the code, this operation can be cancelled at any moment by pressing keys + and – simultaneously.
Once the password is typed in, it is possible to act on the control unit by entering and exiting the programming
mode for around 10 minutes in order to allow adjustments and tests on functions.
By replacing the 0000 code with any other code, the protection of the control unit is enabled, thus preventing the
access to any other menu. If a protection code is to be typed in, proceed as follows:
- select the Code menu and press OK.
- the code 0000 is shown, also in the case a protection code has been previously typed in.
- the value of the flashing character can be changed with keys + and -.
- press OK to confirm the flashing character, then confirm the following one.
- after typing in the 4 characters, a confirmation message “CONF” appears.
- after a few seconds, the code 0000 appears again
- the previously stored protection code must be reconfirmed in order to avoid any accidental typing in.
If the code corresponds to the previous one, a confirmation message “OK” appears.
The control unit automatically exits the programming phase. To gain access to the Menus again, the stored protec-
tion code must be typed in.
IMPORTANT: TAKE NOTE of the protection code and KEEP IT IN A SAFE PLACE for future maintenance
operations. To remove the code from a protected control unit, it is sufficient to reset the code to the 0000
default value.
IF YOU LOOSE THE CODE, PLEASE CONTACT THE AUTHORISED SERVICE CENTER FOR THE TOTAL RESET
OF THE CONTROL UNIT.

18
BRAKING
With the ENC=OFF logics, braking is given by the TSM1/TSM2 parameter value referred to the TM1/TM2 operating time. For example,
if the operation of motor 1 lasts 20 seconds and TM1=24s and TSM1=8 are preset, 4 s braking will result (20-(24-8).
With ENC=ON logics, braking is calculated as a percentage on the space covered during the complete operation.
FUSES
F1: F6.3A (230VAC) / F10A (115VAC) – Motor protection
F2: T315mA (230VAC) – T500mA (115VAC) – Protection for primary transformer
TRANSMITTER REMOTE LEARNING
If the transmitter code is already stored in the receiver, the remote radio learning can be carried out (without accessing the control
unit).
IMPORTANT: The procedure should be carried out with gate in the opening phase, during the TCA dwell time.
Proceed as follows:
1 Press the hidden key of the transmitter, the code of which has already been stored in memory.
2 Within 5 seconds, press the already memorised transmitter key corresponding to the channel to be matched to the new transmitter.
The flashing light switches on.
3 Within 10 seconds, press the hidden key of the new transmitter.
4 Within 5 seconds, press the key of the new transmitter to be matched to the channel selected at item 2. The flashing light switches
off.
5 The receiver stores the new transmitter code and exits from the programming mode immediately.
TYPES OF INSTALLATION
AUTOMATIC SYSTEM WITH ELECTROMECHANIC LIMIT SWITCHES AND CONNECTION TO ENCODER
In this operating mode, the NOT=ON logics and the ENC=ON logics must be preset.
Start a self-test operation, as indicated in the AUTO Menu.
At completion of the lelf-learning, the value of all torques and the TDMO/TDMC value are preset by the control unit.
If an obstacle is present, the Encoder acts as anti-crash sensor. Its sensitivity is adjusted by SEAV and SEAR parameters.
AUTOMATIC SYSTEM WITH ELECTROMECHANIC LIMIT SWITCHES AND WITHOUT ENCODER
In this operating mode, the NOT=ON logics and the ENC=OFF logics must be preset.
All parameters must be preset manually. In particular, values of TM1/TM2 must be some seconds higher than the actual operating
time.
AUTOMATIC SYSTEM WITH ELECTROMECHANIC LIMIT SWITCHES AND CONNECTION TO ENCODER
In this operating mode, the NOT=OFF logics and the ENC=ON logics must be preset.
Start a self-test operation, as indicated in the AUTO Menu.
At completion of the lelf-learning, the value of all torques and the TDMO/TDMC value are preset by the control unit.
In this case, the encoder not only acts as snit-crash sensor, but it also performs the stop function in the presence of limit switches.
AUTOMATIC SYSTEM WITH ELECTROMECHANIC LIMIT SWITCHES AND WITHOUT ENCODER
In this operating mode, the NOT=OFF logics and the ENC=OFF logics must be preset.
All parameters must be preset manually. In particular, values of TM1/TM2 must be some seconds higher than the actual operating
time.
ERROR MESAGES
Some messages that are displayed in the event of malfunctions are shown hereunder:
Enc1 Error, motor 1 encoder Check the connection to motor 1 encoder
Enc2 Error, motor 2 encoder Check the connection to motor 2 encoder
Amp1 Error, motor 1 obstacle Check the presence of obstacles on the motor 1 leaf stroke
Amp2 Error, motor 2 obstacle Check the presence of obstacles on the motor 2 leaf stroke
Err1 Error, check motor 1 circuit Check connections to motor 1
Err2 Error, check motor 2 circuit Check connections to motor 2
Err3 Error, check actiation relay Ask for technical assistance
Err4 Error, check PHOTA photocell Check connections, alignment of PHOT A photocell or obstacle
present.
Err5 Error, check PHOTC photocell Check connections, alignment of PHOT C photocell or obstacle
present.
Err6 Error, activated sensitive edge (during self-set) During self-setting, the safety edge was activated.
Err7 Error, activated stop (during self-test) During self-setting, the STOP input was activated.
Err8 Error, activated input (during self-test) During self-setting, a Start/Pedestrian/Open/Close input was acti-
vated.

19
DIAGNOSTICS
In the event of malfunctions, by pressing key + or - the status of all inputs (limit switches,
control and safety) can be displayed. One segment of the display is linked to each input.
In the event of failure it switches on according to the following scheme.
PHOT-O
SWC-M1
STOP
SWO-M1 SWO-M2
SWC-M2
PHOT-C DAS
P.P. PED OPEN CLOSE
WASTE DISPOSAL
If the product must be dismantled, it must be disposed according to regulations in force regarding the differentiated waste disposal and
the recycling of components (metals, plastics, electric cables, etc..). For this operation it is advisable to call your installer or a specialised
company.

AUTOMATISMI BENINCÀ SpA - Via Capitello, 45 - 36066 Sandrigo (VI) - Tel. [phone] r.a. - Fax [phone]
