Beninca KMB24 User manual

L8542881
02/2016 rev 4
KMB24
UNIONE NAZIONALE COSTRUTTORI
AUTOMATISMI PER CANCELLI, PORTE
SERRANDE ED AFFINI

3
ENG WARNING
The product shall not be used for purposes or in ways other than those for which the product is intended for and as
described in this manual.
Incorrect uses can damage the product and cause injuries and damages.
The company shall not be deemed responsible for the non-compliance with a good manufacture technique of gates as
well as for any deformation, which might occur during use.
Keep this manual for further use.
This manual has been especially written to be use by qualified fitters.
Installation must be carried out by qualified personnel (professional installer, according to EN 12635), in compliance with
Good Practice and current code.
Make sure that the structure of the gate is suitable for automation.
The installer must supply all information on the automatic, manual and emergency operation of the automatic system and
supply the end user with instructions for use.
The manufacturer also supply further documentation (for example handover pack or a CD with the standards) to safely
set up the gate automation (machine).
Packaging must be kept out of reach of children, as it can be hazardous.
For disposal, packaging must be divided the various types of waste (e.g. carton board, polystyrene) in compliance with
regulations in force.
Do not allow children to play with the fixed control devices of the product.
Keep the remote controls out of reach of children.
This product is not to be used by persons (including children) with reduced physical, sensory or mental capacity, or who
are unfamiliar with such equipment, unless under the supervision of or following training by persons responsible for their
safety.
Apply all safety devices (photocells, safety edges, etc.) required to keep the area free of impact, crushing, dragging and
shearing hazard.
Bear in mind the standards and directives in force, Good Practice criteria, intended use, the installation environment, the
operating logic of the system and forces generated by the automated system.
Installation must be carried out using safety devices and controls that meet standards EN 12978 and EN 12453.
Only use original accessories and spare parts, use of non-original spare parts will cause the warranty planned to cover
the products to become null and void.
All the mechanical and electrical parts composing automation must meet the requirements of the standards in force and
outlined by CE marking.
An omnipolar switch/section switch with remote contact opening equal to, or higher than 3mm must be provided on the
power supply mains.
Make sure that before wiring an adequate differential switch and an overcurrent protection is provided.
Pursuant to safety regulations in force, some types of installation require that the gate connection be earthed.
During installation, maintenance and repair, cut off power supply before accessing to live parts.
Also disconnect buffer batteries, if any are connected.
The electrical installation and the operating logic must comply with the regulations in force.
The leads fed with different voltages must be physically separate, or they must be suitably insulated with additional
insulation of at least 1 mm.
The leads must be secured with an additional fixture near the terminals.
During installation, maintenance and repair, interrupt the power supply before opening the lid to access the electrical parts
Check all the connections again before switching on the power.
The unused N.C. inputs must be bridged.
WASTE DISPOSAL
As indicated by the symbol shown, it is forbidden to dispose this product as normal urban waste as some parts might
be harmful for environment and human health, if they are disposed of incorrectly.
Therefore, the device should be disposed in special collection platforms or given back to the reseller if a new and similar
device is purchased.
An incorrect disposal of the device will result in fines applied to the user, as provided for by regulations in force.
Descriptions and figures in this manual are not binding. While leaving the essential characteristics of the product unchanged, the
manufacturer reserves the right to modify the same under the technical, design or commercial point of view without necessarily
update this manual.

4
GENERAL RECOMMENDATIONS
Automatismi Benincà SpA is not liable for damage caused by improper use or by incorrect installation of products or components.
WARNING: Important safety instructions. Follow all instructions since incorrect installation can lead to severe injury.
If this is the first time you realise an automation for swing gates with KMB24, we recommend that you read this manual carefully as
it contains important advice and information for the realisation of the plant in safe conditions.
Keep the various components on hand to gain confidence with them while reading this manual.
Keep this manual for future use
Attention!
Potentially dangerous operations. Scrupulously respect the indications given.
Useful indication.
Suggestions and recommendations for simplifying and/or improving the installation operations.
The automation of a door cannot be considered the only device for protection against intrusion.
Do not use any of the components in unsuitable environments (salty, acid or potentially explosive atmosphere)
All operations that require the protection shells of the devices opened, must take place without mains power supply.
Check that the temperature range marked on the drive is suitable for the location.
The drive cannot be used with a driven part incorporating a wicket door (unless the drive cannot be operated with the wicket door
open).
Ensure that entrapment between the driven part and the surrounding fixed parts due to the opening movement of the driven part is
avoided.
After installation, ensure that the mechanism is properly adjusted and that the protection system and any manual release function
correctly.
PRODUCT DESCRIPTION
DESTINATION OF USE
This product is destined exclusively for the opening and closure of swing doors for residential use, characterised by dimensional
limits and weight as indicated in this manual in the “Limits of use” paragraph”.
No other use is allowed.
BENINCÀ is not liable for uses that are not in compliance with those indicated in these instructions.
The kit is made up from two electromechanical operators with 24Vdc motor (LOW VOLTAGE),which allows movement of the leaves
via an articulated anti-shearing arm. The irreversible electromechanical gear motori keeps the gate locked in the closing and opening
positions.
Functioning is controlled by and electronic control unit, installed in one of the two operators.
The control unit commands the movement of the two motors and the functioning of the various accessories.
PRELIMINARY CHECKS
Before installation it is indispensable to perform several checks:
• Check the solidity of the structure installed in relation to the forces generated by the motor. Attach the motor stably using adguate
materials.
• The pillars supporting the leaves must be suitable for fixing the gear motors.
• If avialable, check the contenent of the EC declaration of conformity of the manual gate.
• If necessary, carry out the structural calculation and attach it to the technical file.
• Carry out the analysis of the risk and choice of solutions in accordance with the Machinery Directive 2006/42/CE and the standards
EN 13241-1, EN 12453, EN 12445.
Referer to Fig.4:
A - Impact and crushing of the main closing edge.
B - Impact and crushing in the area of opening.
C - Impact in the area of closure.
the KMB24 has been built to guarantee the PL c (Performance Level c), category 2, according to the EN 13849-1 standard(Safety
of Machinery).
• Try and open the gate manually, the leaves must move without effort and without points of resistance for the entire run.
• When left in any intermediate position the leaf must not move.
• The hinges and components subject to wear must be in perfect working condition. If this is not the case, replace the faulty parts.
• With the gate completely closed, check that the leaves are aligned perfectly along their entire length.
• The presence of a opening and closing stop is indispensable (Fig.3 ref. 5 and 8). It mist be installed if not present.
The reliability and safety of the automation depend on the state of the gate structure.
Check that there is enough space for installation of the operator in safe and comfortable conditions.

5
A
C
DE B
350
350
184
184
245
95
234
28
35
350
350
184
184
245
95
234
28
35
1 2
Door leaf max. rotation
3
α° A (mm) B (mm) C (mm) D (mm) E (mm)
90° 0 470 350 243 140
90° 50 470 339 255 140
90° 100 470 331 262 140
90° 150 470 328 264 140
90° 185 470 356 237 160
90° 200 440 410 160 200
110° 0 420 244 318 200
105° 100 420 262 310 200
6
3
7
1
2
8
4
5
5
10
12
11
9
A
A
H
I
G
E
F
L
D
M
B
C

6
4
5
5
B
A
B
C
6
57
27,5
140 mm min.

7
Self locking nut M8
Screw M8x65 Fixing bracket
10
A
8 9
YES!
NO!
57
27,5
140 mm min.
Bracket
Articulated bracket
7

8
1 2
see label manual relase
Customized key C
Lever L
S
T
SN
D
R
N
B2
S1
B1
T1
P
A
11 12
13 14
GND
LN
SWC2 (17) SWO2 (16) COM (13) M2 (3,4)
MBE24V
GND
LN
SWC2 (17) SWO2 (16) COM (13) M2 (3,4)
MB24V
Cavi
Cables

9
Inside.
Open. Open.
Left Right
Open.
Close.
Lower cam
Upper cam
Microswitch
Lower cam
Upper cam
Key
Key
Open.
Close.
Upper cam
Lower cam
Key
Key
MB24
MBE24
15
16

10
SHIELD
ANT
ANT
M1 M2
LAMP
24Vdc
SCA
TEST
II°CH/SERL
24Vac
Lock 12Vdc
10W (5s)
24Vac/dc
500mA max
(+) (-)
SWO1
SWC1
SWO2 SWC2
PHOT
PHOTC
STOP
OPEN
CLOSE
PED
P.P.
COM +
COM
F1
T 2A
DAS
J1 DAS
Open
DAS N.C.
J1 DAS
Close
DAS 8K2
2827
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
2827
8k2
DAS
32313029
+-
RADIO
U11
Code
____
F2:1.6AT (230V)
F2:3.2AT (115V)
L
N
17
SWC2 (17) SWO2 (16) COM (13) M2 (3,4)

11
PHOT C
PHOT RX2
TX2
TX1
RX1
24Vac 24Vac
COM
NC NO
RX1TX1
24Vac 24Vac
COM
NC NO
RX2TX2
11
24Vac
COM PHOT COM PHOT-C 24Vac
12 11 1213 18 13 199 10 9 10
test1:on test2:ON
PHOTOTEST
PHOTOCELLS ACTIVE IN OPENING AND CLOSING PHOTOCELLS ACTIVE IN OPENING AND CLOSING
PHOTOTEST
SCA
AUX1:0 AUX1:2
SERVICE/ZONE LIGHT Service Light
AUX1:3
Zone Light
L N
Service/Zone
Light
230Vac
Relè 24Vac
32313029
24Vac/dc
500mA max
11 12
32313029
24Vac/dc
500mA max
11 12
18
19

12
v1.05
8888 PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
on PRG
OFF PRG
OFF PRG
OFF PRG
OFF PRG
OFF PRG
OFF PRG
off PRG
off PRG
OFF PRG
Off PRG
off PRG
off PRG
off PRG
tca
tm1
tm2
tped
pmo1
pmo2
pmc2
tdmo
tdmc
tls
tloc
40
5
5
50
50
pmc1
50
50
2
3
60
5
sld1 50
sld2 50
spd1 99
99
spd2
50
LOG
TCA
tca
IBL
IBCA
SCL
PP
PRE
ham
blco
blcc
soft
ltca
htr
imot
cvar
0000 conf OK
res PRG
OFF PRG
0012 3456
Nman
MACI
RES
CODE
par
9000 9C5a
AUTO OK
PUSH
TCA
LOG
radi
PAR
Power ON
Display OFF
RE-ENTER
CODE
Display OFF
2 Cycle
OPEN/CLOSE
Firmware Ver. (3s)
Diagnostic
off PRG
off PRG
OFF PRG
Off PRG
off PRG
off PRG
off PRG
mloc
bb
2ch
tst1
tst2
tstm
rem
PRG
PRG
PRG
PRG
PRG
PRG
PRG
pso1
psc1
pso2
20
20
20
psc2 20
seau 0
sear 0
250
tinc
PUSH OK
PUSH OK
PUSH OK
rtr PRG OK
PUSH OK
RADI pp
ped
clr
rtr
2ch

13
v1.05
8888 PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
PRG
on PRG
OFF PRG
OFF PRG
OFF PRG
OFF PRG
OFF PRG
OFF PRG
off PRG
off PRG
OFF PRG
Off PRG
off PRG
off PRG
off PRG
tca
tm1
tm2
tped
pmo1
pmo2
pmc2
tdmo
tdmc
tls
tloc
40
5
5
50
50
pmc1
50
50
2
3
60
5
sld1 50
sld2 50
spd1 99
99
spd2
50
LOG
TCA
tca
IBL
IBCA
SCL
PP
PRE
ham
blco
blcc
soft
ltca
htr
imot
cvar
0000 conf OK
res PRG
OFF PRG
0012 3456
Nman
MACI
RES
CODE
par
9000 9C5a
AUTO OK
PUSH
TCA
LOG
radi
PAR
Power ON
Display OFF
RE-ENTER
CODE
Display OFF
2 Cycle
OPEN/CLOSE
Firmware Ver. (3s)
Diagnostic
off PRG
off PRG
OFF PRG
Off PRG
off PRG
off PRG
off PRG
mloc
bb
2ch
tst1
tst2
tstm
rem
PRG
PRG
PRG
PRG
PRG
PRG
PRG
pso1
psc1
pso2
20
20
20
psc2 20
seau 0
sear 0
250
tinc
PUSH OK
PUSH OK
PUSH OK
rtr PRG OK
PUSH OK
RADI pp
ped
clr
rtr
2ch
Legenda
Press key (-)
Press key (+)
Press key (PG)
Press simultaneously keys (+) and (-)
Increase/decrease the value with keys (+) and (-)
Press the transmitter key, which is to be assigned to function

14
TECHNICAL DATA MBE24 (With Control Unit) MB24
Power supply
Motor feed
Power drawn
Current drawn
Torque max.
Noise level
Working Temperature
Operating time at 90°
Door leaf max. weight
Door leaf max.
Duty cycle
Lubrication
Index Protection
Weight
Built-in release:
230 Vac ± 10%
24 Vdc
160 W
0,76 A
180 Nm
<70 dB
-20°C/+50°C
10 s (with slowdown disabled)
300 kg (see limits for use)
3,0 m (see limits for use)
30 min. ON /30 min. OFF
Permanent grease
IP44
10,7 kg
Customized key
--
24 Vdc
160 W
6,2A
180 Nm
<70 dB
-20°C/+50°C
10 s (with slowdown disabled)
300 kg (see limits for use)
3,0 m (see limits for use)
30 min. ON / 30 min. OFF
Permanent grease
IP44
9 kg
Customized key
INDEX
1) LIMITS FOR USE....................................................................................................................................................................................... 15
2) OVERALL DIMENSION (FIG.1).................................................................................................................................................................... 15
3) INSTALLATION DIMENSIONS (FIG.2).......................................................................................................................................................... 15
4) TOOLS AND MATERIALS........................................................................................................................................................................... 15
5) STANDARD INSTALLATION (FIG.3).............................................................................................................................................................15
6) ANCHORING OF BRACKETS (FIG.6-7)........................................................................................................................................................ 15
7) POSITIONING THE GEARED MOTOR (FIG.10) ............................................................................................................................................. 15
8) POSITIONING THE ARTICULATED ARM BA (FIG.11) .................................................................................................................................... 15
9) MANUAL AND EMERGENCY OPERATION (FIG.12) ...................................................................................................................................... 16
10) WIRE CONNECTIONS (FIG.3) ................................................................................................................................................................... 16
11) ADJUSTING THE LIMIT SWITCHES (FIG.15) ............................................................................................................................................. 16
12) CHECKS ................................................................................................................................................................................................ 16
12.1) CHECKS INSTALLING POSITIONS .................................................................................................................................................... 16
12.2) CHECK MOTOR AND LIMIT SWITCHES CONNECTIONS..................................................................................................................... 17
13) SAFETY DEVICES (FIG.16)....................................................................................................................................................................... 17
14) CP.MBY24 CONTROL UNIT ..................................................................................................................................................................... 17
14.1) AUTOSET FUNCTION....................................................................................................................................................................... 17
14.2) WIRE DIAGRAM .............................................................................................................................................................................. 18
15) PROGRAMMING ..................................................................................................................................................................................... 19
16) PARAMETERS, LOGIC AND SPECIAL FUNCTIONS .................................................................................................................................... 19
16.1) PARAMETERS (PAR)....................................................................................................................................................................... 19
16.2) LOGIC (LOG)................................................................................................................................................................................... 20
16.3) RADIO (RAD).................................................................................................................................................................................. 22
16.4) CYCLES NUMBER (NMAN)............................................................................................................................................................... 22
16.5) MAINTENANCE CYCLES (MACI)...................................................................................................................................................... 22
16.6) RESET (RES).................................................................................................................................................................................. 22
16.7) AUTOSET (AUTO)........................................................................................................................................................................... 22
16.8) PROTECTION CODE (CODE)............................................................................................................................................................ 23
17) TRANSMITTERS REMOTE LEARNING ...................................................................................................................................................... 23
18) FUSES ................................................................................................................................................................................................... 23
19) EMERGENCY BATTERY OR SOLAR PANEL ............................................................................................................................................... 23
20) DIAGNOSTICS ........................................................................................................................................................................................ 23
21) ERROR MESSAGES ................................................................................................................................................................................ 24
22) INSPECTION AND COMMISSIONING........................................................................................................................................................ 24

15
1) LIMITS FOR USE
Do not use the automation on leaves with dimensions / weights above the values indicated in the below enclosed table chart:
Door leaf width
(m)
Door leaf weight
(kg)
1
1,5
2
2,3
300
250
215
200
2) OVERALL DIMENSION (FIG.1)
On Fig 1 main overvall dimensions are indicated, value to be in millimiters.
3) INSTALLATION DIMENSIONS (FIG.2)
On Fig. 2 and enclosed table chart , different installation dimensions are indicated.
Any change on the A, B, E dimensions, C and D dimensions changes accordingly.
Verify to have enough space to guarantee the necessary articulated arm movement before proceeding with the installation.
4) TOOLS AND MATERIALS
Make sure that there are all tools and materials necessary for installation (fig.5). Also check that they are in compliance with Stand-
ards and in perfect working order.
Use suitable individual protection devices I.P.D. (goggles, gloves, etc)
The length and type of connection cables depend on the accessories installed (see “Electric connections” paragraph).
The fixing screws for the gear motor are not supplied as they depend on the features of the materials used for the pillars
and the leaves.
5) STANDARD INSTALLATION (FIG.3)
On Fig. 3 a standard installation complete with the main accessories is showed.
Keys
1 MBE.24 with control unit CP.MBY24
2 MB.24
3 Wall Photocell transmitter TX1
4 Wall Photocell receiver RX1
5 Opening leaf stop
6 Internal Photocell transmitter TX2
7 Internal Photocell receiver RX2
8 Closing leaf stop
9 Key selector
10 Flashing signal light connection with aerial
11 Safety edge Left leaf
12 Safety edge Right leaf
6) ANCHORING OF BRACKETS (FIG.6-7)
Once the fixing value “E”(fig.2) it taken from the relevant table, and considering a minimum height from floor of 100mm, fit the bracket
to the pillar by means of the screws M8 with relevant screw anchors.
Once the fixing value “B” is calculated, fit the articulated bracket to the gate with the same screws M8 and relevant screw anchors
or weld it to the gate by aligning the articulation bracket to the fitting bracket for the pillar, as shown in the drawing. Reinforce the
fitting areas which are not sufficiently thick, or in any case not strong enough.
7) POSITIONING THE GEARED MOTOR (FIG.10)
Place the geared motor in the fitting bracket for assembly to pillar by using the special nuts and screws supplied.
8) POSITIONING THE ARTICULATED ARM BA (FIG.11)
- Release the gear motor (see paragraph “Emergency manual operation”)
- Insert pin P in the hole of the motor shaft A
- Join arm B1 to arm B2 and lock them by means of pin T1 and lock ring S1
- Fix the arms to the motor shaft A and lock them by means of nut D by inserting washer R and ring N
- Hook the arm to bracket SN and lock it by means of pin T1 and release ring S1.
- Apply cover C and fix it by means of the two screws V.
The gear motor can be installed on the other gate leaf (Fig. 6) in a similar way. The only difference between right-hand and left-hand
leaves relies in the position of arm B2.
With released gear motor, completely open the gate and check the operating clearances of the two arms.

16
9) MANUAL AND EMERGENCY OPERATION (FIG.12)
To manually open or close the door in case of power failure or faults, two solutions are possible:
• Built-in release
Introduce the customized key C, turn it clockwise and pull lever L. At this point the geared motor is released and the gate can be
manually pushed.
To reset the normal operation, close lever L again and turn key C anticlockwise. Manually move the gate until the geared motor
is engaged again.
• Rope external release: optional
It is available for fitting to external wall or with accessory to be mounted flush (see MB.SE).
10) WIRE CONNECTIONS (FIG.3)
The cables necessary for the installation can vary according to the accessories installed.
No connection cable is supplied.
Fig. 3 indicates the cables for standard installation.
List of cables
Connection Type Maximum length and notes
A Mains power supply (MBE.24 with control unit CP.MBY24) 3x1,5mm230m - [1]
B Motor connection (MB.24 without control unit) 5x1,5mm215m - [2]
C Wall Photocell transmitter connection 2x0,5mm220m
D Wall Photocell receiver connection 4x0,5mm220m
E Column Photocell transmitter connection 2x0,5mm220m
F Column Photocell receiver connection 4x0,5mm220m
G Key selector connection for external command 4x0,5mm220m
H Flashing signal light connection 2x1,0mm210m
I Connection of the aerial built-in the flashing light RG 58
L Connection for safety edge Right leaf 2x1,0mm210m
M Connection for safety edge Left leaf 2x1,0mm210m
Note
[1]
An omnipolar switch should be provided with the contact opening of at least 3 mm, provided with overload protec-
tion and able to cut off the system from the mains.
Means for disconnections must be incorporated in the fixed wiring in accordance with the wiring rules.
The MBE24 gear motor can be installed indifferently on the right of left leaf.
It is preferable to install it on the leaf that is most easily reached by the electricity line.
[2] It is recommended not to exceed 15 m in length. If it is indispensable to exceed this limit, increase the section of the
cable.
The cables used must be suitable for the type of connection. For example, for connection protected by raceways
use H03VV-F cables, for cables in the outdoor environment always use the H07RN-F type.
11) ADJUSTING THE LIMIT SWITCHES (FIG.15)
N.B.: The position of the cams referring to micro-switches varies according whether the installation of the geared motor is
lefthand or righthand, view from inside. Pay attention to diagrams.
• Closing limit switches
Release the geared motor and manually close the door.
Turn the related cam to the position shown by using the special key supplied, until the micro-switch is activated. Lock the cam
by tightening the central screw supplied.
• Opening limit switches
Release the geared motor and manually open the door.
Turn the related cam to the position shown by using the special key supplied, until the micro-switch is activated. Lock the cam by
tightening the two screws supplied.
12) CHECKS
12.1) CHECKS INSTALLING POSITIONS
1) Check that the arms are perfectly horizontal using a spirit level (fig.8).
If the arms are not perfectly horizontal, malfunctioning and breakage can occur. The shape of the holes on the fixing plate allows
any minimum adjustments.
2) With both gear motors released, take the leaves into the completely open position and check that the arms do not strike any
obstacle during movement.
Fig.9 represents the two motors installed, the dotted line indicates the two arms with the leaves in the opening position.
Control the presence and functionality of the mechanical block in closing “A”.

17
12.2) CHECK MOTOR AND LIMIT SWITCHES CONNECTIONS
1) Cut-off power supply.
2) Manually release the wings, move them to approx. half-stroke and lock them again.
3) Restore power supply.
4) Send a step-by-step control signal by pressing the <-> push-button.
5) The leeaves must move in OPENING.
In case this does not happen, it is sufficient to invert among them the motor run wires. (1<>2 for M1 motor, and 3<>4 for M2
motor) and, if used, the relative Limit switch inputs (14<>15 for M1 motor, and 16<>17 for M2 motor).
13) SAFETY DEVICES (FIG.16)
IMPORTANT!
READ CAREFULLY!
Measure opening and closing forces (by means of the special instrument required by the standard EN 12445).
If the values of the forces are higher, install a protective device in accordance with the standard EN 12978 (for example
a sensitive edge) and repeat the measurement.
The dynamic forces can be reduced, for example, by reducing the speed of the leaf or using a sensitive edge wit high
elastic deformation.
BENINCÀ can provide all the devices necessary for your installation and relative accessories , contact your trusted
supplier for any further information.
On fig.16 an example of application on the primary closing edges.
To prevent the impact in the area of closure (figure 4, risk C) install a pair of photocells (recommended height 500 mm) so as to sense
the presence of the test paralleledpipe height 700 mm (in according to MD).
To reduce further the possibility of impact in the area of opening (figure 4, risk B) install a pair of photocells (recommended height
500 mm) in the area of movement of the gate, so as to sense the presence of the test paralleledpipe height 700 mm (in according
to MD).
We suggest to connect photocells in phototest mode (see Fig.18 and set logics TST1=ON e TST2=ON), or check the if photocell
working correctly at least every 6 months.
14) CP.MBY24 CONTROL UNIT
14.1) AUTOSET FUNCTION
IMPORTANT: The control unit is equipped with the Autoset function to automatically set the main functioning values based on the
type of installation.
The AUTOSET function must be repeated at every function parameter change or upon change of automation conditions. See the
AUTO menu for further information.
The first and most important function to program is the self-regulation of the parameters, which allows the control unit to automa-
tically set the end run points, the torque applied to the leaf and the slowing phases*.
During the autoset operations, the control unit automatically performs several opening and closure manoeuvres.
Before proceeding, check that no person, animal or obstacle is or can be in the door manoeuvre area.
All the accessories provided for the system should be already connected to the control unit. If further accessories should
be added, self-adjustment must be repeated.
To carry out autoset, proceed as follows:
a) Ascertain that no obstacles of any nature are present in the manoeuvre area, if necessary, block off the area in order to prevent
access from people, animals, vehicles, etc.
During autoset phase, the anti-crushing function is not active.
b) Select the AUTO function and press OK.
c) Select with the <+> or <-> button the submenu LSW.
LSW: if the motor is equipped with Limit switch.
d) once selected press OK to begin the autoset phase.
The control unit carries out a series of manoeuvres for learning of the run of the leves and for parameter configuration.
Perform an autostop procedure after every maintenance intervention or modification of the door.
After every autoset procedure and/or PMO/PMC,PSO/PSC parameters changing, measure opening and closing forces (by means
of the special instrument required by the standard EN 12445).

18
14.2) WIRE DIAGRAM
Wire connections shown in Fig. 18 are described hereunder:
Terminal No. Function Description
1-2 Motor 1 Connection, motor 1: 24VDC PRE-WIRED
3-4 Motor 2 Connection, motor 2: 24VDC MB24
5-6 Flashing light Connection, flashing light 24VDC 15W max.
7-8 Lock Output, 12Vdc/10W power supply for electric lock (7:0V, 8:+12V)
9-10 SCA/
PHOTO TEST
Contact free from N.O. Voltage, may be configured as open gate indicator or photocell
test.
For use as “Open gate indicator” the TEST1 and TEST2 logics must be OFF
For use as photocell test it is sufficient to activate one or both TEST logics and connect
the photocells as indicated in Fig.3.
11-12 24 Vac/dc
Output, accessory power supply, 24VAC/0.5A max.
IMPORTANT: If the battery charger board is installed, the output (without mains power
connected) has a 24Vdc polarised voltage.
Make sure the devices are correctly connected (i.e. 11:+24Vdc / 12:-0Vdc).
13 COM Common for limit switch and all the command inlets.
14 SWO1 Motor 1 OPEN limit switch input (N.C. contact) PRE-WIRED.
15 SWC1 Motor 1 CLOSE limit switch input, (N.C. Contact) PRE-WIRED
16 SWO2 Motor 2 OPEN limit switch input, (N.C. Contact).
17 SWC2 Motor 2 CLOSE limit switch input, (N.C. Contact)
18 PHOT Input, photocell activated in both opening and closing phases
19 PHOT C Input, photocell activated in closing phase only (Normally closed contact)
20 STOP Input, STOP push-button (Normally closed contact)
21 OPEN Input, OPEN push-button (Normally open contact).
It is possible to connect a timer for opening in time slots.
22 CLOSE Input, CLOSE push-button (Normally open contact)
23 PED Pedestrian button input (N.O. Contact), controls the motor 1 opening, see TPED pa-
rameter.
24 Step-by-Step Input, step-by-step push button (Normally open contact)
25 COM Common for Limit switch and all the command inputs.
26 N/A N/A
27-28
SENSITIVE
EDGE
(DAS)
Input, sensitive edge contact
Resistive edge 8K2: “DAS” Jumper closed (see paragraph 13 “SAFETY DEVICES”).
Mechanical edge N.C.: “DAS” Jumper open
When the edge is activated, the gate movement is stopped and reversed for about 3s.
29-30 II°CH/SERL
N.O. Contact free from Voltage, may be configured as second radio channel or service
light. For use as second radio channel the 2CH logic must be ON.
For use as courtesy light the 2CH logic must be OFF.
31-32 Antenna Connection to the built-in radio receiver card (30-signal/31-screen).
+ / - 24VAC/dc
Input, 24VAC/24VDC power supply.
In case of use of plug batteries connect the battery charging card as indicated in the
specific installation instructions.
U11 CONFIGURATION
MEMORY
Extractable Eprom Memory. Contains all the control unit configurations (logics, param-
eters, etc.), including the radiotransmitters. In case of faults it is possible to extract Eprom
and insert it into a different control unit, avoiding reprogramming.

19
15) PROGRAMMING
The programming of the various functions of the control unit is carried out using the LCD display on the control unit and setting the
desired values in the programming menus described below.
The parameters menu allows you to assign a numerical value to a function, in the same way as a regulating trimmer.
The logic menu allows you to activate or deactivate a function, in the same way as setting a dip-switch.
Other special functions follow the parameters and logic menus and may vary depending on the type of control unit or the software
release.
TO ACCESS PROGRAMMING:
1 – Press the button <PG>, the display goes to the first menu, Parameters “PAR”.
2 – With the <+> or <-> button, select the menu you want (PAR>LOG>RAD>NMAN>MACI>RES>AUTO>CODE).
3- Press the button <PG>, the display shows the first function available on the menu.
4 - With the <+> or <-> button, select the function you want.
5 - Press the button <PG>, the display shows the value currently set for the function selected.
6 - With the <+> or <-> button, select the value you intend to assign to the function.
7 - Press the button <PG>, the display shows the signal “PRG” which indicates that programming has been completed.
NOTES:
Simultaneously pressing <+> and <-> from inside a function menu allows you to return to the previous menu without making any
changes. Hold down the <+> key or the <-> key to accelerate the increase/decrease of the values.
After waiting 120s the control unit quits programming mode and switches off the display.
When the board is switched on, the software version is displayed for around 5 sec
Hold down the <+> key or the <-> key to accelerate the increase/decrease of the values.
16) PARAMETERS, LOGIC AND SPECIAL FUNCTIONS
The tables below describe the individual functions available in the control unit.
16.1) PARAMETERS (PAR)
MENU FUNCTION MIN-MAX-(Default) MEMO
TCA Automatic closing time. Active only with logic “TCA”=ON.
At the end of the set time the control unit orders a closing manoeuvre. 1-240-(40s)
TM1
Operating time, motor 1. The operating time is adjusted at normal speed during
motor 1 opening and closing phases. See Paragraph “Adjustment of the gate leaf
speed”.
By setting the value to 0, the operation is performed with around 2 seconds of
pick-up and then the movement is carried on at reduced speed for the entire
stroke. In the motors with encoder, the value is expressed in percentage. In mo-
tors without encoder the value is expressed in seconds.
0-99-(5)
TM2
Operating time, motor 2. The operating time is adjusted at normal speed during
motor 2 opening and closing phases. See Paragraph “Adjustment of the gate leaf
speed”.
By setting the value to 0, the operation is performed with around 2 seconds of
pick-up and then the movement is carried on at reduced speed for the entire
stroke. In the motors with encoder, the value is expressed in percentage. In mo-
tors without encoder the value is expressed in seconds.
0-99-(5)
Tped
Adjusts the motor 1 opening percentage (pedestrian function).
The value is expressed in seconds. In the motors with encoder, the value is
expressed in percentage. In motors without encoder the value is expressed in
seconds.
1-99 (50)
PMo1 The anti-crash device (amperometric sensor) operation is adjusted in the opening
phase, at normal speed - Motor 1. 1-99-(50%)*
PMC1 The anti-crash device (amperometric sensor) operation is adjusted in the closing
phase, at normal speed - Motor 1. 1-99-(50%)*
PMo2 The anti-crash device (amperometric sensor) operation is adjusted in the opening
phase, at normal speed - Motor 2. 1-99-(50%)*
PMc2 The anti-crash device (amperometric sensor) operation is adjusted in the closing
phase, at normal speed - Motor 2. 1-99-(50%)*
TDMo Mot.2 opening delay time.
Regulates the delay time of motor 2 on opening with respect to motor 1 0-15-(2s)
TDMC Mot.1 closing delay time
Regulates the delay time of motor 1 on closing with respect to motor 2 0-40-(3s)
TLS
SERL contact activation time (Service light) 29/30 terminals.
At each manoeuvre the contact closes for the set time.
See Figure 19 connection scheme.
1-240-(60s)
TLOc Electric lock activation time. The value is expressed in 1/10s (0=0s - 50=5s) 0-50 (5=0,5s)
SLD1 Adjusts motor 1 speed during slowing phases.
This value is expressed in percentage. 30-70 (50%)

20
SLD2 Adjusts motor 2 speed during slowing phases.
This value is expressed in percentage. 30-70 (50%)
SpD1 Adjusts motor 1 speed during normal speed phase.
Value expressed in percentage. 30-99 (99%)
SpD2 Adjusts motor 2 speed during normal speed phase.
Value expressed in percentage. 30-99 (99%)
Pso1 The anti-crash device (amperometric sensor) operation is adjusted in the opening
phase, at reduced speed - Motor 1. 1-99-(20%)*
Psc1 The anti-crash device (amperometric sensor) operation is adjusted in the closing
phase, at reduced speed - Motor 1. 1-99-(20%)*
Pso2 The anti-crash device (amperometric sensor) operation is adjusted in the opening
phase, at reduced speed - Motor 2. 1-99-(20%)*
Psc2 The anti-crash device (amperometric sensor) operation is adjusted in the closing
phase, at reduced speed - Motor 2. 1-99-(20%)*
SeaU NOT USED 0-99-(0%)
SEAR NOT USED 0-99-(0%)
tinc NOT USED 1-250-(250)
* 1: minimum force/torque - 99: maximum force/torque.
16.2) LOGIC (LOG)
MENU FUNCTION ON-OFF-(Default) MEMO
TCA
Enables or disables automatic closing
On: automatic closing enabled
Off: automatic closing disabled
(ON)
IbL
Enables or disables condominium function.
On: condominium function enabled. The step-by-step impulse or transmitter
impulse has no effect during the opening phase.
Off: condominium function disabled.
(OFF)
ibca
The multi-flat function is enabled or disabled during the TCA counting.
On: the bloc of flat function is enabled. The Step-by-Step signal or the transmitter
signal has no effect during the TCA counting.
Off: the bloc of flat function is disabled.
(OFF)
SCL
Enables or disables rapid closing
On: rapid closure is enabled. With open gate, or in the opening phase, the
activation of the photocell causes the automatic closure 3sec after the total
opening of the gate. It is activated only with TCA:ON
Off: rapid closing disabled.
(OFF)
PP
Selects the operating mode of the ”Step by step button” and of the transmitter.
On: Operation: OPEN > CLOSE > OPEN >
Off: Operation: OPEN > STOP > CLOSE > STOP >
(OFF)
PRE
Enables or disables pre-blinking.
On: Pre-blinking enabled. Blinking is activated 3s before the motor starts.
Off: Pre-blinking disabled.
(OFF)
HAM
Enables or disables the inversion stroke function
On: Function enabled. Before each opening manoeuvre the control unit orders a
manoeuvre of 2s in the opposite direction to facilitate the release of the electric
lock.
Off: Function disabled.
(OFF)
Blco
Enables or disables the block function in opening.
On: Block function enabled. After the intervention of the opening Limit switch the
control unit delays arrest by about 0.5s, so to allow a better strike of the shutter
on the stop locks.
Off: Block function disabled
(OFF)
Blcc
Enables or disables the block function in closing.
On: Block function enabled. After the intervention of the opening Limit switch the
control unit delays arrest by about 0.5s, so to allow a better strike of the shutter
on the stop locks.
Off: Block function disabled.
(OFF)
