Bestop PowerBoard 75134-15 User manual

Installation Instructions
INSTALLATION TIME SKILL LEVEL
4 Hours 4 - Difficult
TOOLS
Vehicle Application
Automatic Retracting Running Board
8 mm,
13 mm 13 mm
7/32" and
5 mm
www.bestop.com - We’re here to help! Visit our web site and click on “Ask a Question”. Click here for more Truck Accessories by Bestop.
PowerBoard
•Ford Super Duty F-250/350/450
Crew Cab
2008 and newer
Part Number: 75134-15

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 2
Parts List and Hardware Identification
Wiring Harness, Part
Number 473.09,
Qty - 1 7" Cable Ties, Part Number 460.99, Qty - 25
Running Board Assembly, Qty - 2
79" - Part Number 460.87
Left End Cap,
Part Number
460.83, Qty - 1
Right End Cap,
Part Number
460.82, Qty - 1
T-Nut Insert, Part
Number 460.84,
Qty - 2 M6 Nut Plate,
Part Number
460.86, Qty - 2
M6-1.0 x 10mm Socket
Cap Screw, Part Number
460.85, Qty - 2
Idler Linkage,
Part Number
473.07, Qty - 2
Motor Linkage,
Part Number
473.08, Qty - 2
Controller, Part Number
473.11, Qty - 1
11" Cable Ties, Part Number 470.02, Qty - 2
M6-1.0 x 30 Socket
Cap Screw, Part Num-
ber 460.95, Qty - 6
M10-1.75 x 25 Socket
Cap Screw, Part Number
473.19, Qty - 8
M8 Washer,
Part Number
470.05, Qty - 8
8mm Fender
Washer, Part
Number 473.21,
Qty - 1
Nylock Nut, Part
Number 470.06,
Qty - 1
Posi-Tap, Part
Number 470.03,
Qty - 4
M8 U-Nut, Part Number
460.98, Qty - 8
Brake Cable Bracket,
Part Number 473.13,
Qty - 1
10mm Washer,
Part Number
473.20, Qty - 8
M8-1.25 x 30 Hex Bolt,
Part Number 473.18,
Qty - 8
M8-1.25 x 25 Hex Bolt, Part
Number 474.86, Qty - 1
Light, Part Number
470.15, Qty - 4
M6-1.0 x 20 Socket Cap Screw,
Part Number 470.00, Qty - 8
Motor, Part Number
489.39, Qty - 2

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 3
Install M8 U-Nuts Install Linkages
Remove the cable from the rear support bracket
and use the Hex Bolt, 8mm Washer and Nylock Nut
to install the Brake Cable Bracket on the front of the
support bracket. Reinstall the parking brake cable
and remove vise-grips.
Disengage parking brake.
Pull parking brake cable to the rear from the forward
support bracket to create slack in the cable. Secure
the cable slack with vise-grips.
Install Brake Cable Bracket
Loosen Parking Brake Cable
Counting from the front, locate the second (2nd) and last set of mounting holes
on the inner sill on the driver’s side. Use an M8-1.25 x 40 Hex Bolt and an 8mm
Washer to install an M8 U-Nut on each side of each hole. Do not tighten the bolts
at this time.
View from under vehicle
Front
Rear
Driver’s Side
M8
U-Nuts
8mm
Washers
M8-1.25 x 40
Hex Bolts
Idler
Linkage
Position
Motor Linkage
Position
Install an Idler Linkage in the
rear hole and a Motor Linkage in
the front hole. Slip the notches
in the Linkages under the bolts
and washers installed in Step
One. Secure the bottom of the
Linkages with two M10-1.75 x
25 Button Head Screws and two
10mm Washers.
Do not tighten the bolts at this
time.
Repeat Steps One and Two
on the passenger side of the
vehicle.
Idler
Linkage
Driver’s Side
M10-1.75 x 25
Button Head
Screws
10mm
Washers
Removethefusefromthe
Wiring Harness.
Remove the fuse from the Wiring Harness. Failure
to do so could result in severe electrical shock which
could harm the installer and/or damage the vehicle.
Remove Fuse from
Wiring Harness
Nylock
Nut
Brake Cable
Bracket
Hex
Bolt
8mm
Washer

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 4
Open the passenger door and remove the sill plate
and kick panel.
Remove Kick Panel
Connect the Controller to the vehicle wire loom.
Connect both connectors on the Wire Harness in the
parts kit to the connectors on the Controller. Secure
the locking tabs on the connectors.
Connect Controller to Wire
Loom and Wire Harness
Run the legs of the Wire Harness
down and along under the vehicle.
Use Cable Ties to secure it.
Run the trugger wires on the
passenger side through the
grommet as shown.
Controller
Connect the Controller power and ground
to battery, red lead to positive and black
lead to negative.
Route the Wire Harness legs down to the
wheels wells and to the Motor Linkages.
The long leg goes across the front to the
driver’s side.
Use Cable Ties to secure all loose
sections of the harness.
Secure Controller and
Wire Harness
Cable
Ties
Route Wire Harness
Driver’s Side
Wire
Harness
Cable
Ties
Passenger Side
Trigger Wires
Cable
Tie Wire
Harness

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 5
Pull back the carpet and pull the trigger wires
through the grommet. Seal the holes in the grommet
with silicone sealant.
Access Trigger Wire
The trigger wires are color coded to match the factory door ajar wires. Use the Posi-Taps to connect the
trigger wires to the matching door ajar wires.
DRIVER SIDE
Front Driver Side: Dark Green with Purple stripe. Avoid lighter green wires as these will not work.
Rear Driver Side: Dark Green. Avoid lighter green wires as these will not work.
REGULAR CAB / SUPER CAB: These models do not have rear door ajar wires. Connect this wire to
the constant ground wire (Purple with Black Stripe).
PASSENGER SIDE
Front Passenger Side: White wire found just below flat loom as shown.
Rear Passenger Side: Yellow. The correct yellow wire goes to the back door. Pull up on the yellow wire
that lieads to the back and does not cross over to the driver’s side at the junction. There will be move-
ment of the correct wire near where the trigger wires connect.
REGULAR CAB / SUPER CAB: These models do not have rear door ajar wires. Connect this wire to
the constant ground wire (Purple with Black Stripe).
If you can not find the wire with the correct color you will need to install the motor (Step 13) and test each
individual wire until you find the one that functions correctly.
Wiring
Grommet
Posi-Tap™ Instructions
Insert Tighten
Strip 3/8" Insert and
Tighten
Flat Loom
(under carpet)
White Wire
Trigger
Wires
Occasionally the actual wire color may be
different than stated here. You will need to
install the motor and test each wire until you find the
wire that functions correctly.

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 6
Reinstall Kick Panel
Secure the wires and reinstall the kick panel and
sill plate. Be careful not to pinch any wires when
replacing the panel.
Reinstall the fuse in the harness.
Reinstall Fuse
Slide Motor assembly onto drive shaft and mount-
ing bosses of Motor Linkage assembly. Use three
(3) M6-1.0 x 30mm Socket Cap Screws to secure
Motor. Plug female connector into Motor. Wrap any
exposed wires from the motor with electrical tape.
Install Motor
Clean the outboard surface
of the of the Linkage below
the bottom mounting bolt.
Peal the adhesive liner off
the back of the Light and
firmly press it 1/8" below
the mounting bolt. Plug the
light into the connector with
the black and orange wires
in the wire harness. Repeat
with the other three lights.
Secure lose wires with
Cable Ties.
Install Lights
Motor
Linkage
Motor
Wire
Harness
Light
Linkage
M6-1.0 x 30mm
Socket Cap Screws
M6-1.0 x 20mm
Socket Head Bolts
Arm
PowerBoard
Install Running Boards
M6-1.0 x 20mm
Socket Head Bolts
M6-1.0 x 20mm
Socket Head Bolts
Mount the Steps to the linkages. Slide the mounting
T-Nut into position. Install M6-1.0 x 20mm Socket
Head Bolts to secure the boards. Use a 5mm Allen
Wrench to tighten the bolts.
Make sure the board moves up and down freely by
hand. If it binds, loosen the linkage to body attach-
ment bolts and adjust the linkage position until the
boards move freely. Do not tighten the bolts at this
time. Tightening the fasteners before cycling
the step several times may create a
bind, causing a squeaking sound and preventing
the boards from retracting completely and
evenly.

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 7
Open the doors to make sure that the PowerBoard
drops into position on each side of the vehicle.
Cycle boards several times and then fully tighten
all bolts.
Reinstall any remaining trim panels.
Issue:
• Possible cause
Boards do not operate:
• Connected to incorrect vehicle wire
• Wire connections not secure
• Fuse burned
• Factory door-ajar circuit inoperable
Board creaks or squeaks during operation:
• Gear shaft wedge bolt is loose
• Loosen mounting bracket and board
attachment screws. Adjust linkages so they
are parallel to each other and the noise is
gone. Tighten all fasteners.
Intermittent operation:
• Wire connections not secure
• Bad ground
• Bad battery connection
Boards operate randomly:
• Wire connections not secure
• Connected to incorrect vehicle wire
Board stays down all the time and can be moved
by hand:
• Gear shaft wedge screw is missing or loose
Board shakes and or shutters during operation:
• Bad ground
• Wire connections not secure
• Bad battery connection
One or more doors operate the board and other
do not:
• Wire connections not secure
PowerBoard Troubleshooting Confirming PowerBoard is functional-black
controller:
To test if the red controller (473.11), wire harness,
motor and lights work, hook up to battery and touch
any of the 4 door trigger wires to + 12V. The board for
that side should go down and the lights should turn
on. The board should go up and the lights should turn
off when the wire is removed from + 12V.
Boards don’t operate correctly when connected
to wires identified in instructions:
Unfortunatelyvehiclemanufactures do notconsistently
keepthesamewirecolorsintheirwireharnesses. The
PowerBoard trigger wires need to be connected the
factory door-ajar wire that is connected to each door
latch switch. The correct wire is likely in the same
bundle that is identified in the instructions. If none of
themworkyoucanlocatethecorrectwirebyremoving
the door panel and tracing the wire bundle that leads
to the door latch.
Useavolt meterortestlighttofindthedoor-ajarwireon
PowerBoardswithredcontrollers.Thecorrectwirewill
go from ground to +12 volts when the door is opened
and return to ground when the door is shut. Connect
onetestleadtothenegativebatteryterminalandprobe
the wires with the other lead. You can use a pin or a
Posi-Tap connector to pierce the wire insulation. The
correctwirewill make the tester gofromno voltage to
positive voltage when the door is opened and return
to no voltage when the door is shut. You can also shut
the door latch with the door open by pushing on the
latch catch with a screw driver.
PowerBoard Service Tips
Test Doors and PowerBoards

PowerBoard – Installation Instructions
Rev. K 1011 75134 pg. 8
LIMITED WARRANTY
We warrant our product to be free from defects in material and workmanship, for the terms
specified below, provided there has been normal use and proper maintenance. This warranty
applies to the original purchaser only. All remedies under this warranty are limited to the repair
or replacement of any item or items found by the factory to be defective within the time period
specified. If you have a warranty claim, first you must call our factory at the number below
for instructions. You must retain proof of purchase and submit a copy with any items returned
for warranty work. Upon completion of warranty work, if any, we will return the repaired or
replaced item or items to you freight prepaid. Damage to our products caused by accidents,
fire, vandalism, negligence, misinstallation, misuse, Acts of God, or by defective parts not
manufactured by us, is not covered under this warranty.
THE WARRANTY TIME PERIOD ISAS FOLLOWS FOR ALL PowerBoards MANUFACTURED
BY OUR COMPANY: THREE YEARS / 36,000 MILES FROM DATE OF PURCHASE.
ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A
PARTICULAR PURPOSE CREATED HEREBY ARE LIMITED IN DURATION TO THE SAME
DURATION AND SCOPE AS THE EXPRESS WRITTEN WARRANTY. OUR COMPANY SHALL
NOT BE LIABLE FORANY INCIDENTAL OR CONSEQUENTIAL DAMAGE.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or
limitation of incidental or consequential damages, so the above limitations or exclusions may
not apply to you. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
For further information or request for warranty work, please contact:
Bestop Inc. Customer Service
Toll-Free: [phone]
Main: [phone]
E-mail: [email protected]
Website: www.Bestop.com
Linkage Component Identification
Motor Gear
Shaft
Motor
Mounting
Boss
Mounting
Tab
Upper
Casting
Outer
Link
Inner
Link
Lower
Casting
Mounting
Foot
Motor
Linkage
Idler
Linkage
Pivot
Leg
