HAP-P Lubricator
Manual, One Shot
General
Lubricator includes a spring return piston pump and is operated by pushing a lever which raises a
piston and compresses a spring, discharging oil into the system. Discharge volume and pressure are
independent of oil viscosity.
Operation
Lubricator includes a spring return piston pump in a plastic reservoir. Pulling up slowly on the lever
handle to the stop fills the cylinder with a predetermined volume of oil. Upon release, spring
pressure discharges the oil into the system and returns the handle to the original position.
Lubricator must be operated at intervals recommended by machine manufacturer.
Technical Data
Reservoir Capacity 475cc (1 pint)
Lubricator Inlet Filter 40 micron particle separation
Discharge Pressure 60 psi average
Factory Discharge Setting 15cc
Piston Diameter 1/18”
Piston Stroke Setting 1/2 to 1-1/8”
Discharge Volume Per Stroke 5 to 15cc
Viscosity range 100 to 10,000 SSU at operating temperature
Outlet 1/8”NPTF
Notes Regarding Use
1. Lubricator inlet fi lter should be inspected periodically and cleaned/replaced as required. To
install replacement, disconnect discharge tubing and remove cylinder cap.
2. Discharge pressure will decrease as discharge volume decreases and the number of meter
units in the system increases.
Piston Stroke Setting 1-1/8" 13/16" 21/32" 1/2"
Discharge Volume/Stroke (cc) 15 10 7.5 5.0
System & Limitations
Use meter units type F. Total system fl ow (ø) limitation is given in the table below.
Meter Units (#) CC Per Shot
5.0 7.5 10 15
15 1750 2400 2900 3500
20 1500 1700 2200 2600
25 1230 1500 1700 2000
30 950 1200 1400 1700
40 780 960 1100 1300
50 640 820 920 1100
60 570 710 810 960
70 500 600 720 860

BIJUR DELIMON INTERNATIONAL
TEL [phone]
WWW.BIJURDELIMON.COM
WWW.BDICOOLING.COM
Denco Lubrication Ltd,
Ramsden Court, Ramsden Road,
Rotherwas Industrial Estate,
Hereford, Herefordshire, HR2 6LR
24375 • R3 04/132.
HAP-P Lubricator
Manual, One Shot
Startup Instructions
Fill reservoir; operate lubricator until oil flows freely at all bearings.
Maintenance
Filter Replacement
A filter at pump inlet protects the lubricating system and should be inspected every six months. If
not clean, replace. To remove filter, pry out snap ring with screwdriver and remove filter disc and
screens. To re-install, insert in the following order: filter disc support (coarse screen), filter disc
screen (fine screen), filter disc, filter clamp ring and filter snap ring.
How to Order
Name Part #
Lubricator HAP-P D3221C
When ordering, specify by name and part number, e.g. Lubricator HAP-P, Part #D3221C.
Service Parts
Item Description Part #
1 Reservoir C2966C
2 Filler Cap B9230C
3 Gasket B9058
4 Filter Group S130
Use clean oil only of the type and
viscosity recommended by machine
manufacturer.
Replace filter group annually.
Before removing cylinder cap, pull up
handle and place block between handle
and reservoir to hold piston above
lowest position.

BIJUR DELIMON INTERNATIONAL
TEL [phone]
WWW.BIJURDELIMON.COM
WWW.BDICOOLING.COM
Denco Lubrication Ltd,
Ramsden Court, Ramsden Road,
Rotherwas Industrial Estate,
Hereford, Herefordshire, HR2 6LR
24375 • R3 04/133.
HAP-P Lubricator
Manual, One Shot
Dimensional Schematic Measurements shown in inches.
