Bishamon SCL3000A User manual

Aug. 2021
Sugiyasu Corporation
Dear Users,
Thank you for purchasing our Bishamon Tortoise G Lift. Before using the lift, read through
and be familiar with this manual. Fully understand the precautions, directions, and other
information contained in this manual to ensure correct use. Failure to do so may result
not only in insufficient performance of the lift but also in falling of the vehicle, serious
injury and death, and damage to properties.
Keep this manual in a safe place for future reference. In case of loss, immediately request
a new copy.
If the product is supplied with a wrong manual, contact your lift supplier for a correct copy.
Perform periodic maintenance inspection of the lift to ensure safe work
with the lift and keep the lift fully functional.

The contents of the manual may differ when the purchased lift is modified. For any
question about the product or this manual, feel free to contact your lift supplier.
Keep this manual in a safe place for future reference. In case of loss, contact your
lift supplier and request for a new copy immediately.
Thank you for purchasing our Bishamon Tortoise G Lift . Before using the lift, read
through and be familiar with this manual. Fully understand the precautions, directions,
and other information contained in this manual to ensure correct use. Failure to do so
may result not only in insufficient performance of the lift but also in falling of the
vehicle, serious injury and death, and damage to properties.
In this manual, 「Danger」,「Warning」, 「Caution」are defined and
specified as below. Notice of Warnings are very important for safe operations. As
these are very important to protect operators from accidents resulting in
personal injury and death, and damage to property, so make sure to read
thoroughly and understand fully before operation.
Danger
Incorrect operation may imminently result in serious
injury or death of the operator.
Warning Incorrect operation may result in serious injury or
death of the operator.
Caution Incorrect operation may result in injury and damage
to the property. The occurence of the danger is lower
than "Warning" articles.
Explanation of Terms and Symbols

1)
2)
3)
3) ～ 5)
6)
7)
7)
8) ～ 9)
8)
9)
9)
9)
10)
11)
12)
13)
14) ～ 17)
14)
14) ～ 15)
16)
17)
17)
17)
18) ～ 19)
19)
19)
20)
21) ～ 22)
23) ～ 24)
23)
24)
24)
25)
25)
25)
26)

This product is a lift to be used for oil and parts replacement, general maintenance,
motor vehicles inspection and maintenance etc. of mini-to ordinary sized passenger cars,
small sized trucks, and the like.
As there are very important to protect operators from accidents which may result in
injury and death,and damage to cars and properties, make sure to understand fully before
operating the lift.
1. Read and be familiar with the operation manual before operating.
2. Only trained operators are allowed to use the lift.
3. Make sure to perform daily and periodic inspections in accordance with the
instructions of Operation Manual.
4. If any abnormal conditions, such as noise, occur during operation, prohibit the
use of the lift and contact lift supplier for an inspection.
5. This lift is designed for motor vehicle servicing. DO NOT use for any other
purposes.
6. Do not remove any labels and do not modify the lift anyway.
The meaning of the mark (symbol) used behind pictures are as below.
When lift is operating,
get under the vehicle.
allow others to get under vehicle
Or it may result in death or serious injury.
If the
attempt to support vehicle.
Or it may result in death or serious injury.
Caution for Safety
The specified act
that should not be
conducted.
The specified act
that should be
conducted.
Warnings and
cautions that are
possible to occur due
to incorrect operation.

Read the Operation Manual DO NOT lower the lift
thoroughly before using while any stand, jack or and parallel to the lift.
the lift. support is in position
Important Warnings are under vehicle. evenly. And set the CG of
described. DO NOT use "Down" motion vehicle within the range
*Incorrect operation may of lift to push parts
result in an accident. into position. arrow on the lift.
Set the supporters on a DO NOT lift vehicles by DO NOT modify any Safety
flat spot with sufficient one end only. Or it may Device of the lift under
result in fall of the any circumstances.
Side Sill Block supporters vehicle and damage lift.
to avoid any accident.
KEEP FEET CLEAR
When lowering lift, make the raised vehicle. Or it evenly. DO NOT lift up
sure to keep feet clear may result in fall of the offset vehicle. Or it may
of hoist and vehicle. vehicle. result in fall of vehicle
DO NOT use lift unless ELECTRICAL HAZARD!
you have been trained in when raising and lowering DO NOT open control box
it's operation. lift, MAKE SURE to keep or remove cover plates
*Incorrect operation may hands and feet clear of without isolating
result in an accident. any scissor mechanism. electrical supply.
KEEP HANDS and FEET CLEAR
specified with Yellow Color
DO NOT swing, shake or push
strength. Use only genuine
Vehicle MUST BE positioned
Vehicle MUST BE positioned
Drive in vehicle straight

1. This lift is designed for motor vehicle servicing. DO NOT Use for other purpose.
2. This lift capacity is 3,000 kgs. DO NOT lift any vehicle exceeding the maximum lift capacity.
3. The unbalance load between right and left side Supporter should be less than 300 kgs.
4. Extreme unbalanced load on the lift could result in large inclination of the vehicle.
lifting points on the vehicle. Try to have as wider distance as possible between lifting points.
Refer to the maintenance manual of the vehicle for information of correct lifting points.
6. Make sure to put Slide Stopper Pin when using Slide Supporter.
7. DO NOT drive in or drive out when Slide Supporter is extended.
9. If any of safety device does not work properly, DO NOT use lift.
1. When operating the lift, pay constant attention to the area around the vehicle and the lift.
NEVER look aside during operation.
2. If there are other lifts installed in the same site, Pay attention not to operate the control
switch of other lifts.
3. DO NOT lift vehicles with passengers, baggage or cargo etc.inside (on board).
4. Make sure there is no oil or dirt on supporter when lifting vehicle.
5. Stop lifting after supporter have made firm contact with vehicle, and check locations of
supporter for correct lifting points before reraising the vehicle.
7. The lift height of both sides may become unbalanced during lifting and lowering operations.
2～3 seconds to synchronize. If lift becomes unbalanced extremely during lowering operations,
then stop using the lift and contact your lift supplier.
8. If the lift would not lower, raise the lift once and then relower.
9. If lower the lift with Sliding Supporter being used (extended), retract Sliding Supporter back
as soon as vehicle tyre hit the floor, and then lower the lift to lowest position. Or Supporters
and floor could be damaged.
10. Before lowering the lift, ensure that no person or objects is around vehicle or lift.
11. DO NOT operate the lift with anything such as tools or parts left in the pit or under the lift.
Failure to comply may result in failure of the lift or falling of the vehicle.
12. Drive the vehicle in and out only after the supporters have been lowered completely.
Failure to do so can cause damage of the vehicle or the lift.
1. Make sure Safety Hooks are engaged before getting under vehicle.
2. Keep anyone but the operator out from around the lift.
4. DO NOT leave a vehicle on the lift for long time. If the lift is left over at the height
where there is no Lowering Stop Rack, lift could lower and may damage the vehicle.
5. When not in use, the lift must be lowered to the lowest position.
1. DO NOT modify the lift without permission from the manufacturer. Failure to comply may result
in insufficient performance and lead to serious accident.
2. When an abnormality is detected during use or inspection, stop the use of the lift immediately
and repair. DO NOT use lift until the repair is completed.
3. Use only genuine Side Sill Block Supporter.
4. This lift is not weatherproof and is not to be used outdoors or for vehicle washing.
5. Do not supply air with air pressure exceeding 1.0 MPa to the air filter regulator. Or it may
damage the air filter regulator.
6. The air filter regulator must be set to 0.5 Mpa. If it is set to over 0.5 Mpa, it may damage
Selex Valve.
『 Lifting Point 』… Designated spot of the vehicle to be lifted. Refer to the maintenance manual of
the vehicle.
『 Side Sill 』… Body welding spot under rocker panel. Lifting point is located for passenger vehicle.
8. Drive in and out vehicle slowly, and DO NOT start and stop suddenly. Or it could damage Slide Supporter.
6. DO NOT put and use anything but genuine Side Sill Block between Supporter and vehicle lifting point.
5. Set the supporters securely at lifting points, and do not raise a vehicle when there are not clear
In such case, without vehicle on the lift, lift up to max height and keep pushing "UP" button for

CG Label
Capacity Label
Serial Plate
Caution Label E
showing how to do Pre Operation
Check of Filter Regulator.
Caution Label
Caution Label
Labels feature descriptions on important matters for preventing accidents and property damages,
as well as capacity of the lift. Purchase and apply these lables promptly when they become worn,
damaged or peeled off while the lift is used.

Slide Supporter
※ Drive-In Ramp
Double Scissor Link
Lowering Stop
Rack & Hook
Lift Cylinder
Serial Plate
Hyd. Unit
Push
Button
Switch
※ Drive On Ramp are not
supplied for Model SCL3000AP

Air Filter Regulator reduce the air pressure of the
air supplied to the Air Filter Regulator to appropriate
pressure levels, and drain water in the air. Air pressure
gauge shows the air pressure after depressurization.
① Verify that the air pressure supplied to the
Air Filter Regulator is more than 0.5 Mpa
② Loosen the screw on top of the Air Filter
Regulator.
③ Look at and check the air pressure gauge while
turning the pressure adjustment knob to set the
air pressure to 0.5 Mpa.
④ Tighten the screw on the top of Air Filter
Regulator.
① Push up the drain valve at the bottom.
Water sprays out with air.
Depressurize Pressurize
Pressure
adjustment knob
Air pressure
gauge
Screw
*The appropriate value of the pressure of air (primary side pressure) supplied to the filter
regulator is between 0.5 and 1.0 MPa. The filter regulator may be damaged if the pressure
is greater than 1.0 MPa.
* Always make sure that the air pressure gauge is pointing 0.5 MPa before operating lift.
The lift may malfunction if the pressure is under 0.5 MPa. Furthermore, the Selex valve
may be damaged if the pressure is over 0.5 MPa. Always set the pressure to 0.5 MPa.
Caution
Drain valve
Water must be drained from the air filter regulator every day.
Accumulation of water can cause malfunction.
Air Filter
Regulator
Push
Button
Switch
Caution

Push Button Switch is the device to raise and lower the lift.
・When pushing "UP" button, lift rises, and stops when releasing.
・When pushing "DOWN" button, lift lowers and stops when
releasing button.
・"UP" button and "DOWN" button can not be pushed together at
the same time.
Supporter length can be adjustable depending on the vehicle lifting point.
Side Sill Block is used to protect vehicle side sill when lifting vehicle
by Supporter.
There are 3 kinds height Side Sill Blocks as below.
・Height 30mm - Supplied as Standard for Model SCL3000A
・Height 70mm - Supplied as Standard for Model SCL3000AP
※ Height 115mm - Available only as Option
If operating Push Button Switch carelessly before confirming the safety of lift and vehicle
surroundings, it may result in serious accidents.
Warning

Lowering Air
Cylinder
(Unit side)
Hook Release Air Cylinder (Lift side)
Air Tube C (Red)
Air Tube A
Hook Release Air Tube A
Check Valve
Quick
Exhaust
Valve
Air Switching Valve
(Selex Valve)
Air Filter
Regulator
Fuse Valve
Fuse Valve
Lift Cylinder
(a)
Lift Cylinder (b)
Breather Valve
Breather Valve
Hyd. Hose c
Unit Hyd. Pipe
Bypass Pipe Synchro Check Valve
Synchro Check Valve
Unit Hyd. Pipe
Lowering Relief Valve
11.8 MPa
（Inside Sub Plate)
Lifting Relief Valve
20.6 MPa
（Inside Sub Plate)
Lowering Valve
(Emergency
Lowering Valve)
Flow Control Valve
Lowering Valve
Switching Valve
Gear Pump

Tortoise G Series Lift operate the Hyd. Cylinder by Electro Hyd. Pump, and lift up
Supporters would synchronize through Synchro Cylinder inside Hyd. Unit, and lift
and lower. This lift has function of correcting unbalance of synchronizing.
① Push "Up" button
② Motor run
③ Gear Pump rotates and feed the oil to Synchro Cylinder chamber
④ Through Synchro Cylinder mechanism, same volume oil would be feeded to
R・L Lift Cylinder and lift goes up
⑤ If release "Up" button, oil feeding stops and oil supplied to Lift Cylinder
would be stopped at Selex Valve (Back Flow Prevention Valve) and both sides
Supporter stop.
⑥ Lowering Stop Hook is always "In" positon during lifting and when stopped.
① Push "Down" button
② Lowering Stop Hook would be released
③ When both sides Lowering Stop Hook are completely released, Hyd. Circuit
would be switched to lowering motion.
④ Lift would be forcedly lowered by hydraulic.
Tortoise G lift has function of correcting the unbalance of synchronizing at
max height. Lift up to max height and keep pushing "Up" button for 2～3 seconds.
Then both sides Supporter height would be corrected to same height.
"Up" Button ➡ Motor run ➡ Synchro Cylinder operate ➡ Synchronized Lifting
"Down" Button ➡ Release Lowering Stop Hook ➡ Switch Hyd. Circuit ➡
➡ Motor runs ➡ Synchro Cylinder works ➡ Synchronized Lowering
Supporter through 2 stage X (Scissors) Link. Both sides, Right and Left side
Caution

It is installed at each cylinder to prevent lift
of hydraulic hose etc.
However, be noted that there is no safety hook
below approx. 200mm height from floor.
It is installed at the piping closest to each
cylinder. It would shut off oil flow from
cylinder in case of sudden flow of oil from
cylinder due to breakage of hydraulic circuit
etc.
a. Lifting excessing rated lift capacity
b. Lift is reaching the top
c. Excessive high pressure in hydraulic line
It is installed inside Sub Plate.
It would sense the excessive electric current,
and shut off the electric circuit and protect
electric components such as motor etc.
It is installed at magnetic contactor.
It would prevent lift from break in case of below
from lowering in case of oil leaking and breakage
Lowering Stop
Device
Fuse Valve
Relief Valve
Thermal Relay

Any damage, strain or distortion ? Visual
Any noise during lifting and lowering ? Hearing
Hydraulic Circuit Any leak ? Visual and touching
and Air Circuit Visual and touching
Does safety device make "clicking" noise
during lifting operation ?
Hook released without fail in lowering ?
Any obstacles inside Pit or Lift ?
① Verify that the air pressure supplied to the
Air Filter Regulator is more than 0.5 Mpa
③ Look at and check the air pressure gauge while
turning the pressure adjustment knob to set the
air pressure to 0.5 Mpa.
Inside Pit (Lift) Visual
Does lift rise and lower smoothly without noise ?
Hydraulic Unit
Any damage on Hyd. Hose, air hose and piping ?
Lowering Stop Device
Lift Structure
Lift Visual and hearing
Visual and hearing
Visual and hearing
Are both Right and Left side Lowering Stop
② Loosen the screw on top of the Air Filter Regulator
④ Tighten the screw on the top of Air Filter Regulator
If any possible abnormality is detected, prohibit the use of the lift until abonormality is
fully repaired. Then contact your lift supplier immediately. If the lift is used with
abnormality left unsolved, damage to the lift or serious accident may occur.
Caution
Hyd. Unit
Air Filter
Regulator
Lift Cylinder
Hook Release Cylinder
Lowering Stop Device
Depressurize Pressurize
Pressure
adjustment
knob
Air
pressure
gauge
Screw
※Make sure to check and adjust pressure everyday.
①Always make sure that the air pressure gauge is pointing 0.5MPa before operating lift. The
lift may malfunction if pressure is under 0.5MPa. Always set the pressure to 0.5MPa.
②Water can be drained by pushing Drain Valve upwards. Water and air come out together.
Caution
Drain Valve

･Lift (Supporter) must be lowered fully before vehicle enters
･Make sure to park the vehicle so that CG of the vehicle stay within the range
shown in Yellow Color Arrow on the side of the Supporter. If not, vehicle may fall
due to the vibration during lift operation and vehicle servicing.
Caution
Supporter
CG Label
･Support vehicle on lifting points which are designated by vehicle manufacturer.
DO NOT lift up vehicle on other points, or vehicle could be deformed or fall down.
DO NOT lift up vehicle if lifting point of the vehicle is not clear.
Warning
･DO NOT put any other supporter but genuine Side Sill Block between Supporter
and vehicle lifting point.
･If try to lift up vehicle (load) by only one side Supporter at around 30mm height
from floor, lift may lower. Pay close attention so that hands and fingers etc.
should not be pinched in the gap between Base and Supporter.
･The mud guard may hit the Supporter of the lift when vehicle entering if the
vehicle minimum height is low like sport car which please note. For those low
profile vehicle, use optional Sub Step Ramp.
Caution

Slide Stopper Pin
Grip
Side Sill Block
Put the Side Sill Block on the Supporter so that center of Side Sill Block stay
inside Double Scissors Link before lifting up. And for frontwards and backwards,
DO NOT put Side Sill Block off over the width of Side Sill Block.
→ Or Supporter would twist and result in unbalance between Right and Left side
Supporter, and damage vehicle or vehicle may fall down.
→ If the vehicle could not meet the required conditions, DO NOT lift up.
Warning
Center of Side Sill Block
should stay inside Double
Scissors Link width, and
should not off to outside
Double Scissors Link
Double Scissors
Link
Side Sill Block width
Side Sill Block width
Side Sill Block should not be off its
width.
※If need to change the spot, each
Side Sill Block should stay within
Line A and Line B

NEVER go and stand under the vehicle during lift operation.
Danger
･DO NOT lift vehicles with passengers, baggage or cargo etc. inside (on board).
･When operating the lift, NEVER look aside, and pay constant attention to the
area around the vehicle and the lift, or it could result in serious accident.
･DO NOT lift any vehicle exceeding the max lift capacity. Or it may damage the lift.
Warning
･Pay close attention on the unbalance between Right and Left side during
lifting and lowering operation. If unbalance occured, lift up to max height
without vehicle on the lift, and keep pushing "UP" button for 2～3 seconds to
synchronize. If lift became unbalanced extremely during lowering operation,
stop using the lift and contact lift supplier.
･DO NOT operate the lift with anything such as tools or parts left in the pit or
under the lift. Failure to comply may result in the failure of the lift or falling of
the vehicle.
･If there are other lifts installed in the same site, Pay attention not to operate
the control switch of other lifts.
･Lift up to the height Supporter is over 200mm high from lowest before
servicing vehicle. Lowering Stop Hook does not work below 200mm height.
Caution

NEVER go and stand under the vehicle during lift operation.
Danger
･DO NOT operate the lift with anything such as tools or parts left in the pit or under
the lift. Failure to comply may result in the failure of the lift or falling of the vehicle.
Caution
・Check and make sure the lift is lowered to the lowest. If the lift is left at midway,
it could result in damage to the lift and vehicle.
・If the Slide Supporter is not retracted (stored back), it could result in the
damage to the lift and vehicle.
Caution

Ask lift supplier for annual regular inspection besides above monthly regular inspection.
For Safe Use
