BLUM TANDEM plus BLUMOTION 568R User manual

TANDEM plus BLUMOTION bottom mount runner set
Set includes:
■ TANDEM plus BLUMOTION heavy duty runner set with #6 x 5/8"
wood screws for installation (qty 10)
■ Standard locking device (qty 2) with #6 x 1/2" truss head wood
screws for installation (qty 4)
■ Instructions
Overall cabinet
depth
Drawer
length Extension loss TANDEM plus BLUMOTION set
610 (24") 533 (21") 19 (3/4") 568R5330B
NOTE: These runners are for 16 (5/8") max. drawer side thickness
2
1
2
1
© 2011 Blum, Inc. Subject to technical modifications without notice.
8
TANDEM plus BLUMOTION 568R
heavy duty bottom mount drawer runners
Runner profile
Locking device
Bottom mount
Description Basic components
■ Full extension bottom mount concealed
drawer runners with BLUMOTION
■ For 16 (5/8") max. drawer side thickness
■ For face frame and panel applications
■ Tool free height and tilt adjustment
■ Concealed roller carriages with
permanently lubricated synthetic rollers
create a smooth running action
■ Locking devices enable easy drawer
insertion and removal
■ Force-guided right side and ±1.5 (1/16")
tolerance-compensating left side
■ 125 lb static, 110 lb dynamic load capacity
Components
Application
Applications
Interior roll-out
Rear mounting bracket for frame cabinets
Rear brackets and sockets cannot be used. Cabinet bottom must be
flush with top surface of bottom rail.
BLUMOTION
inside
Interior roll-outs and roll-out shelf applications
Interior roll-outs and roll-out shelf applications must be mounted to
the bottom of the cabinet or to a fixed shelf/panel.
Roll-out shelf

Installation
Place drawer on runners and
close. Locking devices auto-
matically connect to runners.
Removal
Squeeze orange release
levers on locking devices
Pull drawer out and up
Height adjustment
Press up on adjustment tab
Push toward back of drawer
Maximum 3 (1/8") rise of front
Tilt adjustment
Rotate tilt adjustment lever on
rear of each runner. Tool-free
tilt adjustment of +5(3/16").
1
2
1
2
1
2
Dimensions in millimeters (inch equivalents as noted) © 2011 Blum, Inc. 9
Specifications
Runner comparison
Drawer and cabinet specifications
Profile mounting specifications
Top view NOTE: Orange dots
indicate screw locations
required to meet specified
load capacities (minimum
4 screws)
Front view
Calculating outside drawer width
For drawer side thickness 16 (5/8") 15 (19/32") 14 (9/16") 13 (1/2") 12 (15/32")
Deduct from inside cabinet width 10 (3/8") 12 (15/32") 14 (9/16") 16 (5/8") 18 (23/32")
Example: For 21" inside cabinet width and a 5/8" thick drawer, 21" minus 3/8" = 20-5/8" drawer width
Drawer back preparation
7 (9/32")
11 (7/16")
Ø6 x 10
bore for hook
35 (1-3/8") minimum rear notch
13 (1/2")
minimum top
clearance
6(1/4")
outside drawer width
13 (1/2")
bottom recess
drawer side thickness
maximum 16 (5/8")
14 (9/16")
bottom clearance
21 (13/16")
drawer height
maximum =
opening minus
20 (13/16")
inside cabinet opening width
opening height
#6 wood screws
568R – No vertical profile
568H – Vertical profile
529 (20-13/16")
499 (19-21/32")
37
(1-7/16")
30 (1-3/16")
546 (21-1/2")
553 (21-3/4") minimum
4
11
(7/16")
BLUMOTION
inside
