BLUM Compact Blumotion User manual

BLUMOTION deactivation
Switch on the hinge cup
For small or light doors, the BLUMOTION can be deactivated on one of the hinges.
COMPACT BLUMOTION comes in the activated position, marked with a “I”.
The deactivated position is marked with a “0”.
Door must be closed once for the deactivation to be complete.
To reactivate, move switch back to the original position “I”.
2
1
COMPACT BLUMOTION
Subject to technical modifications without notice. © 2011 Blum, Inc.
LIT.HNG5501.04.11

Three-dimensional adjustment
Side adjustment
Rotate the front cam screw to increase or decrease door
overlay (+/- 1/16").
Height adjustment
Loosen installation screws to adjust door position
(+/- 1/8"), then retighten.
Depth adjustment
Rotate the rear cam screw to adjust door gap
(+ 3/32", - 1/32").
Door adjustment
Subject to technical modifications without notice. © 2011 Blum, Inc.
