BLUM Wellborn WDVC3030 User manual

These instructions should be used for Wellborn Cabinets
WDVC3030 and WDVC3630. (Page 1 of 6)
04/2008
without notice. © 2008
Subject to technical modifications
Attaching Doors
Attach the top door
Attach top door to the cabinet.
Attach the bottom door
2a
2b
Attach bottom door to the top door and
attach the telescopic arms.
1

These instructions should be used for Wellborn Cabinets
WDVC3030 and WDVC3630. (Page 2 of 6)
04/2008
without notice. © 2008
Adjustment
Subject to technical modifications
Finalizing the door adjustments
1. Adjust each top door hinge and
mounting plate to properly align the
top door to the cabinet.
2. Adjust each bottom door hinge and
mounting plate to properly align doors
to the cabinet and to the top door.
± 2 mm± 2.5 mm ± 2 mm± 2 mm± 3 mm + 3/- 2 mm
1 2
Adjust tension of the mechanism
Use a screw gun and the supplied #2x2 POZI driver bit to adjust the lift
Close and flush doors to cabinet. Open and close door to test closing force.
mechanism to the desired tension. Test door again and repeat until desired
function is achieved.
Tension adjustment should be the same on both lift mechanisms.
21
Although not illustrated here, telescopic arm mounting plates can also be adjusted
horizontally ± 2 mm if needed.

These instructions should be used for Wellborn Cabinets
WDVC3030 and WDVC3630. (Page 3 of 6)
04/2008
without notice. © 2008
Adjustment (Part 2)
Subject to technical modifications
Attach covers
Attach the left and right cover plates
to each lift mechanism then attach the
symmetrical cover caps.
Adjust and lock telescopic arms
pressing on the top door, pull the bottom
door open one inch.
12
2. Slightly open door and lock the1. Close and flush doors to cabinet. While
telescopic arms into position using the
levers as shown.
Open door
enough to
lock levers

These instructions should be used for Wellborn Cabinets
WDVC3030 and WDVC3630. (Page 4 of 6)
04/2008
without notice. © 2008
Subject to technical modifications
2. Detaching the telescopic arms
Removal
1. Remove covers
Risk of injury from spring-loaded arm
Do not push lever arm down or leave in the down position
Remove mechanism before installing or removing cabinet
WARNING
Release both arms and gently rest
the top door on the loose arms.
The tension will hold the doors up
for the next step.
2
1
Warning: Risk of injury
from spring-loaded
telescopic arm!
Maintain control of telescopic
arm while releasing the CLIP
mechanism.

These instructions should be used for Wellborn Cabinets
WDVC3030 and WDVC3630. (Page 5 of 6)
04/2008
without notice. © 2008
Subject to technical modifications
Removal (Part 2)
3. Removing the doors
1. Hold the bottom door while unclipping
the bottom hinges.
2. Hold the top door while detaching the
top hinges. Simply unclip them if using
2
1
4. Removing the telescopic arms
Using a screwdriver, depress the
release tabs to remove telescopic arms.
If transporting the cabinet to the jobsite,
stop here. Lift mechanisms stay inside the
cabinet for easy transport.
1
2
the CLIP top hinges or loosen them if
using COMPACT.

These instructions should be used for Wellborn Cabinets
WDVC3030 and WDVC3630. (Page 6 of 6)
04/2008
Door clearance above cabinet
Inch mm
1
/
32 .031 1
1
/16 .063 1.5
3
/
32 .094 2
1
/
8.125 3
5
/32 .156 4
3
/
16 .188 5
7
/32 .219 5.5
1
/
4.25 6
9
/
32 .281 7
5
/
16 .313 8
11
/32 .344 9
3
/
8.375 9.5
13
/
32 .406 10
7
/
16 .438 11
15
/32 .469 12
1
/
2 .5 13
17
/32 .531 13.5
9
/
16 .563 14
19
/32 .594 15
5
/
8.625 16
21
/32 .656 17
11
/
16 .688 17.5
23
/
32 .719 18
3
/
4.75 19
25
/
32 .781 20
13
/
16 .813 20.5
27
/32 .844 21
7
/
8.875 22
29
/32 .906 23
15
/
16 .938 24
31
/
32 .969 24.5
1125.4
Other information
INST-AVT04
Blum, Inc.
7733 Old Plank Rd.
Stanley, NC 28164
toll free 800-438-6788
local 704-827-1345
fax [phone]
internet www.blum.com
www.dynamicspace.us
Z
TDH
Z = TDH x .44 +
Z = 7 1/2”
23
7 1/2”
