INSTRUCTION MANUAL
K1 GYM STRENGTH TRAINING SYSTEM
MA4109
Bodycraft is a division of Recreation Supply Inc.
P.O. BOX 181
Sunbury, OH 43074
QUESTION?
As a quality home gym supplier we are committed to your complete satisfaction. If you have
questions, or find missing or damaged parts, we will guarantee your complete satisfaction through
our authorized dealer service centers or our home office customer service department. Please call
your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained
technicians will provide immediate assistance to you, free of charge.

1
BEFORE YOU BEGIN
Congratulations and thank you for selecting the K1 GYM strength training
system. The K1 GYM offers an impressive array of strength training exercises
to develop every major muscle group of the body. Whether your goal is
cardiovascular fitness, a shapely, toned body or dramatic muscle size and
strength, the K1 GYM will help you achieve the specific results you want.
For your safety and benefit, read this manual and the accompanying literature
before using the K1 GYM. Keep this manual for future reference.
If you have additional questions, please call your local dealer or our customer
service department at 800-990-5556 Monday through Friday, 9 a.m. until 5 p.m.
Eastern Time.
IMPORTANT SAFETY NOTES
1.This product must be assembled on a flat, level surface to assure its
proper function.
2.Clean pads and frame on a regular basis. We recommend warm,
soapy water. Do not use harsh or abrasive chemicals.
3.Inspect and tighten all parts before every use. Replace any worn
parts immediately. Failure to do so may result in serious injury.
4. Keep children away from the K1 GYM at all times.
5. Keep your hands away from cables and pulleys during operation.
Keep your hands away from moving parts other than the designated
handles.
6.When adjusting the seat, make sure the spring pin is fully engaged.
If not, the seat may slip and cause serious injury.
7. Make certain all cables are seated within the pulleys before every use.
8.Exercise with care to avoid injury.
9.If unsure about the proper use of the K1 GYM strength
training system call your local dealer or our customer
service department at 800-990-5556.
There is a risk assumed by individuals who use this type of equipment.
Before beginning this or any other exercise program consult your physician.
This is especially important for individuals over the age of 35 or persons
with pre-existing health problems. Recreation Supply, Inc. assumes no
responsibility for personal injury or property damage sustained by or
through use of this product.

65
138
118
118
138
138
1
46
53
51
68
68
2
8
4
57
3
5
27
28
6
80
91
33
73
73
64
33
64
28
65 80
91
28
33
64
64
28
65
7
48
9
70
82
82
82
82 82
19
20
82
20
10
79
11
98
99 72
81
86
72
70
28
93
94
94
71
65
65
28
47
38
81
31
38
43
89
93
47
12
80
92
80
92
13
14
85
82
82
70
15
56
44
55
45
44 55 65
67
23
67
65
97
95
90
97
96
65
65
45
15
24
24
25
2954
26
82
82 118
118
141
66
56
18
78
78
34
60
60
61
61
60
60
61
61
32
75 75
99
76
75
76
76 65
53
49
32
83
83
69
17
84
84
86
79
75
76
16
62
63
21
52
50
21
50
70
35
39
65
42
36
52
77
87
65
118
40
54
65
77
88
65 28
65
37
41
66
83
87
40
41
22
22
30
74
58
70
59
23 97 96 90
95
65
95
96
95
97
96
136 140
132
122
126
100
135
101
65
28
65
65
65
77
102
118
142
138
121
102
103
113
130
130 138
104
113
125
138
131
133 133
124
131
134
134
124
123
123
114
138
144
104
144
104
144
127 134
134
118
138
104
105
138
105
106 108
129
138
117
116
130
138
138
129
129
129
107
119 127
119
130
129
137
130
115
129
137
110
118
138
111
130
118
112
130
129
107
127
127
107
129
129
143
125
138
130
120
112 137 129
130
138
129
129
138
137
110
137
129
106
131
129
130
130
138
128
113
110
124
131
137
129
129
108
109
120
129
108
129
129
137
137
111
148
51
148
130
129 108
137
130
112
129
137
115
130
114 120
131
131
114
118
138
138
118
137
129
129
138
138
137
130
130
138
128
119 118
129
137
140
118
138
139
118
138
144
121
138
122
126
136
132 141
139
124
127
127
131
131
120
131
131
131
131
2
130
142
EXPOLDED VIEW

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
12
3
4
5
67
89
10 11 12 13 14
15 16 17 18 19
20 21 22 23 24 25 26 27
28 29 30 31 32 33 34
37 38
39
40
41
42
43 45
48 49 50 51
44
35 36
47
1
1
1
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
2
2
2
2
2
1
1
1
9
1
1
1
2
4
1
19
1
1
2
1
2
4
1
1
3
2
1
2
4
1
4
3
BASE FRAME
REAR UPRIGHT
TOP FRAME
REAR STABILIZER
BENCH PRESS UPRIGHT
BENCH PRESS ARM
SEAT SUPPORT
GUIDE ROD
BACK PAD SUPPORT
SEAT SLIDER
CHROMED CAM ASSEMBLY
CABLE ARM ASSEMBLY
TOP GUIDE ROD RETAINER
HANDLE
CABLE ARM
SQUAT HANDLE
LEG EXTENSION CABLE ARM
LEG EXTENSION ARM
FLAT POSITION SUPPORT
BACK SUPPORT PLATE
LAT BAR HOLDER
SEAT HINGE
SWIVEL CABLE TOP
FLOATING PULLEY BLOCK
SINGLE PULLEY BLOCK
SINGLE PULLEY BLOCK
METAL TAB W/SCREW
PULLEY GUARD
CABLE GUIDE PLATE
SEAT SUPPORT CLAMP
AXLE OF BENCH PRESS ARM
FOAM ROLLER HOLDER
METAL ROLLER
METAL BUSHING OF LEG EXTENSION
WEIGHT PLATE
TOP PLATE
SELECTOR ROD
BEARING HOUSING
POSTER PLATE
SHROUD
TRIM OF SHROUD
TRIM OF POSTER PLATE
LAT BAR
SNAP HOOK
SINGLE HANDLE
ANKLE STRAP
1" HAND GRIP
HAND GRIP
AXLE
PLASTIC SLEEVE FOR LAT BAR
LINK CHAIN
46
PARTS LIST
NO. DESCRIPTION QTY.
01/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/41" 2" 3" 4" 1/4 1/2 3/4 1/4 1/2 3/45" 6"
(inch)
3

52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
PARTS LIST
NO. DESCRIPTION QTY.
01/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/41" 2" 3" 4" 1/4 1/2 3/4 1/4 1/2 3/45" 6"
(inch)
58
59
61
62 63
65 66 67 68 69
79
70
71 72 73 74 75 76
77 78 80 81
84
82
83 85 86 87
89 90 91 92
88
98
100
99
101 102
4
64
93
95 96 97
52
53
56
60
94
1
1
1
1
2
1
1
1
4
4
1
1
4
24
3
2
2
1
5
1
3
2
1
4
4
4
2
2
4
2
10
4
2
1
2
2
2
1
2
2
2
2
2
4
4
4
1
2
1
1
2
1
4
4
TOP CABLE
LEG EXTENSION CABLE
CONNECTING CABLE
CABLE ARM CABLE
CLUTCH CABLE
MAGNETIC SELECTOR PIN
SEAT PAD
BACK PAD
FOAM PAD
COVER OF FOAM PAD
FOAM OF SQUAT HANDLE
COVER OF FOAM OF SQUAT HANDLE
METAL CAP
115mm PULLEY
90mm PULLEY
SMALL PULLEY
50 X 75mm END CAP
50 X 75mm END CAP
50mm SQ. PLUG
50 X 75mm RECT. END PLUG
25 X 50mm RECT. END PLUG
50mm ROUND PLUG
25mm ROUND PLUG
PLASTIC COVER
PLASTIC WASHER
PLASTIC GUIDE ROD HOLDER
PLASTIC CAP
60 X 50mm BUSHING
1-1/8" STEEL BUSHING
1" STEEL BUSHING
1/2" BUSHING
3/8" STEEL BUSHING
BEARING
1" PLASTIC STOPPER
1" STOPPER
ADJ. STOPPER
RUBBER DONUT
HOOK PLATE
CABLE ARM COLLAR
STEEL SPACER
CABLE ARM AXLE COLLAR
COLLAR
SEALING RING
BEARING
BEARING BASIN
BEARING COVER
POP PIN (LONGER)
POP PIN (SHORTER)
SPRING KNOB
HANDLE
POP PIN
TOP PLATE BOLT
5/16" X 1-1/4" SET SCREW
5/16" X 3/4" SET SCREW
55
54
57
103 104 105

106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
PARTS LIST
NO. DESCRIPTION QTY.
01/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/4 1/4 1/2 3/41" 2" 3" 4" 1/4 1/2 3/4 1/4 1/2 3/45" 6"
(inch)
106
113
114
115
116
117
119
120
121 133
123
124
125
107
108
109
110
111
112
5
118 142
143 144 145 146
147 148
126
122
127
129
130
128
135
136
131
137
132
138
139
134
140
141
3
5
6
1
4
2
4
5
3
2
1
1
16
3
8
2
2
4
5
2
4
6
2
37
31
13
4
2
4
1
2
18
33
2
2
2
4
1
4
1
1
1
2
1/2" X 5-1/4" HEX BOLT
1/2" X 3-1/2" HEX BOLT
1/2" X 3-1/4" HEX BOLT
1/2" X 3" HEX BOLT
1/2" X 1" HEX THREADED BOLT
3/8" X 5-3/4" HEX BOLT
3/8" X 3-1/8" HEX BOLT
3/8" X 3" HEX BOLT
3/8" X 2-3/4" HEX BOLT
3/8" X 2-3/4" HEX THREADED BOLT
3/8" X 2-1/2" HEX BOLT
3/8" X 2" HEX BOLT
3/8" X 1-3/4" HEX BOLT
3/8" X 1" HEX THREADED BOLT
5/16" X 1/2" HEX THREADED BOLT
5/16" X 1-1/2" HEX BOLT
M5 X 18mm ROUND SCREW
M6 X 5/8" CONIC SCREW
5/16" X 5/8" INNER SCREW
3/8" X 5/8" INNER SCREW
3/8" X 1/2" INNER SCREW
5/16" X 1/4" SET SCREW
M6 SET SCREW
1/2" WASHER
3/8" WASHER
5/16" WASHER (φ19)
3/8" SPRING WASHER
5/16" SPRING WASHER
5/16" NUT
METAL CAP
24mm NYLON NUT
1/2" NYLON NUT
3/8" NYLON NUT
5/16" NYLON NUT
M5 NYLON NUT
CLUTCH LEVER OF CABLE ARM
30 X 155L FOAM PAD
3/8" X 4-3/4" HEX BOLT
5/16" WASHER (φ30)
4mm HEX WRENCH
5mm HEX WRENCH
6mm HEX WRENCH
BELT

108
109
129
21
138
130
130
113
108
129
129
68
68
88
77
77
77
37
36
103
35
88
77
57
69
112
130
130
129
129
137
137
130
130
110
110
129
129
137
26
106
129
129
113
130
130
130
130
21
138
138
129
129 137
137
129
137
137
129
129
129
137
70
2
4
1
5
8
13
3
STEP 1 Base Frame Assembly
6
5. Insert two Plastic Guide Rod Holders (77) into the
holes in the weight base on the Base Frame (1).
Slide a Rubber Donut (88) onto one end of
each Guide Rod (8) and then
insert the Guide Rods (8) into the
Plastic Guide Rod Holders (77).
6. Slide each Weight Plate (35) over the
Guide Rods (8). Make certain that each plate
is oriented with the selector holes on bottom
and facing forward. Attach the Top Plate (36)
to the Selector Rod (37) using the Top
Plate Bolt (103). Tighten the Top Plate
Bolts (103). Slide the Top Plate (36)
and Selector Rod (37) onto the Guide
Rods (8).
7. Insert two Plastic Guide Rod Holders (77)
into the holes in the Top Guide Rod
Retainer (13). Slide the Top Guide Rod
Retainer (13) over the Guide Rods (8)
and then attach the Top Guide Rod
Retainer (13) to the bolts welded on
the Top Frame (3), using two 1/2"
Washers (129) and two 1/2" Nylon
Nuts (137).
8. Attach the Lat Bar Holder (21) to the Top Frame
(3) and Rear Upright (2), using four 3/8" X 3" Hex
Bolts (113), eight 3/8" Washers (130) and four
3/8" Nylon Nuts (138).
To ease the assembly process, do NOT tighten bolts until instructed.
1. Attach the Rear Stabilizer (4) to the Base Frame (1) using two 1/2" X 3-1/4" Hex Bolts (108), four 1/2"
Washers (129) and two 1/2" Nylon Nuts (137). Attach the 50 X 75mm End Cap (69) to the front of
the Base Frame (1) and attach two 50 X 75mm End Caps (68) to the Rear Stabilizer (4).
2. Attach the Rear Upright (2) to the bolts welded on the Rear Stabilizer (4), using two 1/2" Washers
(129) and two 1/2" Nylon Nuts (137). Attach a 50mm SQ. Plug (70) to the top of the Rear Upright (2).
3. Slide the Bench Press Upright (5) over the Base Frame (1), align the holes and attach the Bench
Press Upright (5) to the Base Frame (1), using two 3/8" X 3-1/8" Hex Bolts (112), four 3/8" Washers
(130) and two 3/8" Nylon Nuts (138).
4. Lay the Top Frame (3) atop the Bench Press Upright (5), then attach to the Rear Upright (2), using
one 1/2" X 3" Hex Bolt (109) in the top threaded hole, and one 1/2" X 3-1/4" Hex Bolt (108), two 1/2"
Washers (129) and one 1/2" Nylon Nut (137) in the bottom hole. Attach the Top Frame (3) to the
Bench Press Upright (5), using two 1/2" X 1" Hex Threaded Bolts (110) and two 1/2" Washers
(129). Attach the Single Pulley Block (26) to the Bench Press Upright (5) using 1/2" X 5-1/4"
Hex Bolt (106), two 1/2" Washers (129) and 1/2" Nylon Nut (137).

130
129
138
130
129
137
5
1
12
15
15
137
92
91
91
112
110
129
129
110
130
130
92
127
127
73
73
107
107
38
38
129
129
129
129
31
72
127
127
72
11
6
STEP 2 Cable Arm and Bench Press Assembly
7
We recommend two people for completion of this step.
1. Attach the Cable Arm Assembly (12) to the Bench Press Upright (5), using two 3/8" X 3-
1/8" Hex Bolts (112), four 3/8" Washers (130) and two 3/8" Nylon Nuts (138). Remember
to keep all bolts loose to ensure the holes will align easily. Attach the Cable Arm
Assembly (12) to the Base Frame (1) using two 1/2" X 1" Hex Threaded Bolt (110) and
two 1/2" Washers (130).
2. Slide the axle of each Cable Arm (15) through the holes in the selector plates in the
Cable Arm Assembly (12) and then fasten using the Axle Collars (91 & 92). Tighten the
set screws on the Axle Collars (91 & 92) with a 5/16" Allen wrench. Check to ensure that
each Cable Arm (15) pivots freely and that the cables are not twisted.
3. Attach the Chromed Cam Assembly (11) to the Bench Press Arm (6) by inserting the Axle
of Bench Press Arm (31). Slide a Bearing Housing (38) onto each end of the Axle of
Bench Press Arm (31).
4. Attach the two Bearing Housings (38) to the Bench Press Upright (5), using two 1/2" X 3-
1/2" Hex Bolts (107), four 1/2" Washers (129) and two 1/2" Nylon Nuts (137).
5. Plug the back side of the Bench Press Arm (6) with two 25 X 50 mm Plugs (72), and plug
the front side of the Bench Press Arm (6) with two 50mm Round Plugs (73).

59
58
60
60
76 144
144
76
75
127
75
75 60
60
75
127
133
107
115
130
130
20
20 9
70
70
108
129
129
137
19
129
129
129
14
129
129
106
106
108
129 137
137
115
129
129
74
137
22
22
119
119
130
130
100
124
124
131
133
131
32
32
49
7
1
10
18
104
104
104
76
144
144
76
137
129
129
104
STEP 3 Seat and Leg Extension Assembly
8
1. Slide the Seat Slider (10) onto the Seat Support (7) and then attach the Handle Set (14) and Seat
Support (7) to the Base Frame (1), using two 1/2" X 3-1/4" Hex Bolts (108), four 1/2" Washers (129)
and two 1/2" Nylon Nuts (137).
2. Attach the Leg Extension Arm (18) to the Seat Support (7) by aligning the holes and then inserting
the Leg Extension Axle (49). Fasten the Leg Extension Axle (49) using two 5/16" Washers (131),
two 5/16" Spring Washers (133) and two 5/16" X 5/8" Inner Hex Screws (124). Double check two
bearings pre-assembled on the Leg Extension Arm (18) at factory by pulling the "u" shaped spring
pin and making sure it rotates freely.
3. Insert a Foam Roller Holder (32) into the tube on the front of the Seat Support (7). Insert a Foam
Roller Holder (32) into the tube on the bottom of the Leg Extension Arm (18). Slide a Plastic Cover
(75) onto each end of the Foam Roller Holders (32). Mount the Foam Pads (60) to the Foam Roller
Holders (32). TIP: Moisten the center of the Foam Pads (56) with water to make it easier. Secure
the Foam Pads (60) with Plastic Washers (75), 5/16" Washer (144) and 5/16" X 1-1/4" Set Screws
(104). Tighten the pre-installed 5/16" X 1/4" Set Screw (104) with an Allen wrench to help hold
Foam Roller Holder (32) in place.
4. Slide the Seat Hinges (22) onto the Seat Slider (10) as shown. Screw the Seat Pad (58) to the
Seat Hinges (22), using two 3/8" X 1" Hex Threaded Bolts (119) and two 3/8" Washers (130).
5. Attach the Back Support (9) to the Seat Slider (10), using one 1/2" X 3-1/2" Hex Bolt (107), two 1/2"
Washers (129) and one 1/2" Nylon Nut (130). Attach the Flat Position Support (19) to the Back
Support (9), using one 1/2" X 3-1/4" Hex Bolt (108), two 1/2" Washers (129) and one 1/2" Nylon Nut
(130). Note: Use the Flat Position Support (19) when the bench is in the flat position. Fold it away
when bench is in incline or decline positions. Attach both Back Support Plates (20) to the Back
Support (9) and to the Base Frame (1), using (on each end) one 1/2" X 5-1/4" Hex Bolt (106), two
1/2" Washers (129) and one 1/2" Nylon Nut (137). Tighten these bolts, and then loosen just enough
to allow the Plates to pivot while sliding the Seat Slider (10). Plug the 25mm Round
Plug (74) to the Seat Slider (10).
6. Attach the Back Pad (59) to the Back Support (9), using two 3/8"
X 2-3/4" Hex Threadrd Bolts (115) and two 3/8" Washers
(130). Plug both ends of the Back Support (9) with a
50mm SQ. Plug (70).

STEP 4 Top Cable Assembly
T9
65
118 24
138
TOP CABLE (52)
Bolt end Ball with hook end
9
T1
T2
T6
T7
T5
T4 T3
T8
T9
T10
T11
T1
65
3
138
114
130
130 3
T2,T6
66
118
83
130
138
138
130
114
T6
T2
T3,T5
143
28
28
65
65
138
T3
T5
26
5
118
138
66
65
118
138
24
T7
65
13
118
118
T8
138
138
T8,T10
T10
T11
57
T4
Assemble cables and pulleys simultaneously
1. Start by inserting the threaded end of the Top Cable (52) into the slot in the front of the Top Frame (3) as
shown in inset T1. Then insert a pulley into the slot, making sure the cable is seated in the pulley groove
and running over the top of the pulley. Attach the pulley to the Top Frame (3) using one 3/8" X 2-3/4" Hex
Bolt (114), and one 3/8" Nylon Nut (138).
2. Push the cable through the Top Frame (3) until it emerges from the slot just behind Press Upright (5). Mount
a pulley in the slot using one 3/8" X 2-3/4" Hex Bolt (114), two 3/8" Bushings (83), two 3/8" Washers (130)
and one 3/8" Nylon Nut (138) as shown inset T2.
3. Loosely mount pulleys T3 and T5 to the each rear side of the Press Cam Assembly (11) using one 3/8" X 4-
3/4" Hex Bolt (143), two Pulley Guards (28), and one 3/8" Nylon Nut (138) as shown in inset T3, T5. Route
the cable down and around pulley T3 (left side pulley from the point of view as if lying on bench), then up
and around pulley T4 mounted to the Press Upright (5) using one 3/8" X 1-3/4" Hex Bolt (118) and one 3/8"
Nylon Nut (138) as show in inset T4. Then continue routing down and around pulley T5. Tighten these two
bolts while making certain the Pulley Guards (28) do nut rub the cable.
4. Route cable up and around pulley T6 mounted to bracket welded at an angle on Top Frame (3) using one
3/8" X 1-3/4" Hex Bolt (118) and one 3/8" Nylon Nut (138) as shown in inset T2, T6.
5. Run the cable under pulley mounted at the closed end of the top of Double Pulley Block (24), using one 3/8"
X 1-3/4" Hex Bolt (118), and one 3/8" Nylon Nut (138) as shown in inset T7. Then route cable up and
around pulley T8 mounted at front of Top Guide Rod Retainer (13) using one 3/8" X 1-3/4" Hex Bolt (118),
and one 3/8" Nylon Nut (138).
6. continue routing cable down under pulley mounted at the closed end of the top of Double Pulley Block (24),
using one 3/8" X 1-3/4" Hex Bolt (118), and one 3/8" Nylon Nut (138) as shown inset T9, then route cable up
and over pulley mounted at the rear of the Top Guide Rod Retainer (13) using one 3/8" X 1-3/4" Hex Bolt
(118), and one 3/8" Nylon Nut (138) as shown inset T10.
7. Then route the cable down through the looped end of the Selector Pin (57) lanyard
and to screw the threaded end into Top Plate (36), approximately half way.
The threaded end of the cable is an adjustment point, but should always
have at least one third of the threads screwed into the Top Plate (36).
When all cable are strung and cable are adjusted, make sure to tighten
the jam nut.

LEG EXTENSION CABLE (53)
STEP 5 Install Leg Extension Cable
Eyelet end Ball end
L4
65
7
114
130
83
83
138
130
L5 113
17
138
10
L1L3
L2
L4
L5
L2
T9
118
138
65
24
1
116 130
65 L3
1
118
65
138
L1
1. With the ball end of the cable to the outside (under weight stack), mount pulley L1 to the
base frame directly behind the weight stack using one 3/8" X 1-3/4" Hex Bolt (118) and one
3/8" Nylon Nut (138) as shown in inset L1. Then route the cable up and around pulley L2
mounted in the second hole in the bottom of the Double Pulley Block (24) using one 3/8" X 1-
3/4" Hex Bolt (118) and one 3/8" Nylon Nut (138) as shown in inset L2.
2. Route the cable down and under a pulley you will now mount in the slot in the Base Frame
(1), using one 3/8" X 2-1/2" Hex Bolt (116) and one 3/8" Washer (130) as shown inset L3.
3. Slide the cable through the Base frame (1) exiting through the hole in the End Cap. Run the
cable through the slot in the front of the Seat Frame (7) and attach the eyelet end of the
cable to Leg Extension Cable Arm (17), using one 3/8" X 3" Hex Bolt (113), and one 3/8"
Nylon Nut (138) as shown in L5.
4. Mount pulley L4 in the slot in the front of the Seat Frame (7), using one
3/8" X 2-3/4" Hex Bolt (114), two 3/8" Bushings (83), two 3/8" Washers
(130) and one 3/8" Nylon Nut (138).

CONNECTING CABLE (54)
STEP 6 Install Connecting Cable
Threaded Bolt end Threaded Bolt end
C3
25
11
C1
L6
C2
C3
C2
T7
118
138
65
24
C1
27
L6
27
117
65
53
28
138
138
119
1
24
L2
L6
L3
1. Attach pulley on bracket welded on Base Frame (1) with Pulley Guard (28) and Metal Tab W/Screw
(27), using one 3/8" X 2" Hex Bolt (117), one 3/8" X 1" Hex Threaded Bolt (119) and two 3/8" Nylon
Nuts (138) as shown inset L6.
2. Screw one threaded end of the cable into the receptor bolted (27) to the Base Frame (1) as shown in
C1. Screw about one half of the bolt into the receptor. This can be an adjustment point for the
cables. Always be sure to have at least one third of the threads engaged in the receptor, and always
use the jam nut to prevent loosening. Route the cable up and around pulley C2 mounted to the
second hole from the bottom of the Double Pulley Block (24) using one 3/8" X 1-3/4" Hex Bolt (118)
and one 3/8" Nylon Nut (138).
3. Screw the end of the cable into the Single Pulley Block (25) as shown in C3. Screw about one half
of the bolt into the receptor. This can be an adjustment point for the cables. Always be sure to have
at least one third of the threads engaged in the
receptor, and always use the jam nut to
prevent loosening.

STEP 7 Cable Arm Cable
K1
K5
K7
K4
K2
K9
K8
K3
K10
K6
K11
CABLE ARM CABLE (55) Ball endBall end
138
118 28
65
15
12
K1,K2,K3
K1
K2
111
130
65
28
28
138
130
K4,K8
12
K4
65
K8
1
65
28
111
130
K5,K7
65
28
138
130
K5
K7
65
138
118
25
29
54
K6
28
65
138
118 K9,K10,K11
K9 K10
K11
12
The Cable Arms and Cable are preassembled. Inset K1, K11 is there just to show you the internal
components in the unlikely event you have a future internal problem. You need to complete the routing
of the Cable Arms Cable (55) to the rest of the machine.
1. Attach a 115mm Pulley (65) and a Pulley Guard (28) to each side of the top of the Cable Arm Assembly (12)
using one 3/8" X 1-3/4" Hex Bolt (118) and one 3/8" Nylon Nut (137) for each as shown in K3 and K9. These
pulleys are located where the cable exits the rear of the Cable Arm (15). Make sure to run the cable over top
of these pulleys. Tighten the bolt while making sure the Pulley Guard (28) does not rub on the cable.
2. Attach a 115mm Pulley (65) and a Pulley Guard (28) to each side of the bottom of the Cable Arm Assembly
(12) using one 3/8" X 5-3/4" Hex Bolt (111) and one 3/8" Nylon Nut (138) as shown in K4, K8. One bolt for
both pulleys. These pulleys are located at the base of the Cable Arm Assembly (12). Make sure to run the
cable underneath these pulleys. Tighten the bolt while making sure the Pulley Guards (28) do not rub on the
cable.
3. Attach the final pulley for the Cable Arm Cable (55) to the Single Pulley Block (25) dangling from the end of the
Connecting Cable (54). Make sure to run the cable around the pulley. Secure the Cable Guide Plate (29)
(facing upward) to the Single Pulley Block (25) as shown
in inset K6, using one 3/8" X 1-3/4" Hex Bolt (110) and
3/8" Nylon Nut (138). This cable guide is included to
ensure that the Cable Arm Cable (52) does not twist
during use. Slip the Connecting Cable (54), which is
running vertically just behind, into the slot of the cable
Guide Plate (29).

a. The Cables should be tightened to the point just before the Top Plate lifts off the stack. In
other words, if the Top Plate is not resting on the stack, you will need to add length, or, if there
is slack in the cables, you will need to shorten the cables. There are several adjustment
points. If only minor adjustments need to be made, you can adjust the Screw ends on the Top
Cable (at the Top Plate), the Low Cable (where it screws into the Single Pulley Block), or the
Bench Press cable (where it screws into the Single Pulley Block with Stopper). These ends
of these cables must be screwed in at least 1/3 of their length for safety purposes.
Once you are done with these adjustments, lock them into place using the jam nuts.
b. Broader adjustments are made at the Floating Pulley Block (24). Moving the bottom pulley
toward the center decreases length (takes up slack). Conversely, moving the bottom pulley
outward gains cable length.
c. Once the cables have been adjusted to remove all slack, adjust the Adjustable Stoppers (87)
in the Top Frame to where they just touch the Floating Pulley Block (24), and the Single Pulley
with Stopper (87). The Adjustable Stoppers (87) aid in the function of the gym by eliminating
the need to engage all cables in any given exercise routine.
Step 8 The Cable Adjustment
24
24
87
16
13

STEP 9 Shroud and Poster Plate Assembly
120
120
120
120
120
120
120
120
131
131
131
131
41
41
40
40
5
3
6
5
13
1
39
43
16
44
44
45
45
51
148
51
148
400 LBS.
ATTACHMENT
400 LBS.
ATTACHMENT
46
131
131
42
124
124
124
131
131
131
131
1. Attach the two Shrouds (40) to the Base Frame (1) and Top Guide Rod Retainer (13) using four 5/16" X 1/2" Hex Bolts (120)
and four 5/16" Washers (131) on each.
2. Attach the Poster Plate (39) to the Bench Press Upright (5) using three 5/16" X 5/8" Inner Screws (124) and three 5/16"
Washers (131).
3. Trim the Shrouds (40) and Poster Plate (39) with the provided Plastic Trim (41 & 42). You may need to cut the trim to proper
length.
Now tighten all bolts. First, tighten the bolts at the base of the Rear
Upright, where it attaches to the Rear Stabilizer. Then tighten all
bolts, working your way from the base of the gym to the top of
the gym. Check to ensure all bolts are tight, all cables are
tight and cables are seated into the pulley grooves.
14

Assembly is complete! Please take the following steps before using the gym:
1.
2.
3.
4.
5.
6.
7.
Make certain all bolts are tightened securely.
Make certain all cables are seated into all pulley grooves. A cable rubbing
against steel will peel the nylon coating, voiding warranty and resulting in a
need for replacement.
Pre-stretch the cables. Put the Magnetic Selector Pin (57) in the bottom hole
on the weight stack. Pull on the cables with great force, helping remove any
kinks and providing any initial cable stretch.
Be aware the cables can loosen and slightly stretch upon initial use.
The cables should be adjusted as tight as possible, but no so tight as to lift
the Top Plate (36) above the weight stack. Be certain to secure the jam nuts
after adjustments are made.
For better performance, apply a household lubricant (such as silicone) to any
adjustable areas and to the Guide Rods (8).
Enjoy many years of a Fit Lifestyle.
Thank you for purchasing the K1 Gym. If You have any questions,
please call your local BodyCraft dealer or call our
customer service department at 800-990-5556
