BOMBAY X-Montego Console-JV 1853735 User manual

1853735
X-Montego Console-JV
Parts and Hardware List
A. Top Assembly 1 pc
B. Side Assemblies 2 pcs
C. Stretcher 1 pc
D. Phillips Head Screws 4 pcs
E. Allen Head Bolts 6 pcs
F. Lock Washers 6 pcs
G. Flat Washers 6 pcs
H. Allen Head Wrench 1 pc
I. Phillips Head Screwdriver 1 pc
J. Optional Allen Head Screwdriver Bit 1 pc
∗Please make sure that you have all the parts and hardware indicated above before you begin assembly of this item.
∗This item should be assembled on a soft surface to prevent scratching the finish during assembly.
* This item may require periodic tightening.
* Take care not to overtighten bolts if using supplied Allen Head Screwdriver Bit.
Hardware Illustrations
D. Phillips Head E. Allen Head Bolt
G. Flat Washer
F. Lock Washer
Page 1 of 2 R1-9-28-04

1853735
X-Montego Console-JV
Assembly Instructions
1. Attach Side Assemblies (B) Place Top Assembly (A) upside down on a soft surface. Align the pre-drilled holes in
the top rails of Side Assemblies (B) with the pre-threaded holes in the apron of Top Assembly (A) ends. Secure
with Allen Head Bolts (E), Lock Washers (F) and Flat Washers (G) using Allen Head Tool (H or J). See
Illustration.
2. Attach Stretcher (C) Align the pre-drilled holes in the ends of Stretcher (C) with the pre-drilled holes in the legs
of Side Assemblies (B). Secure with Phillips Head Screws (D) using Phillips Head Screwdriver (I). See Illustration.
Page 2 of 2 R1-9-28-04
