Bosch Standart Charger BCS220 User manual

Robert Bosch GmbH
Bosch eBike Systems
72703 Reutlingen
GERMANY
www.bosch-ebike.com
0 275 007 XCX (2018.04) T / 53 WEU
de Originalbetriebsanleitung
en Original operating instructions
fr Notice d'utilisation d'origine
es Instrucciones de servicio originales
pt Manual de instruções original
it Istruzioni d’uso originali
nl Oorspronkelijke gebruiksaanwijzing
da Original brugsanvisning
sv Originalbruksanvisning
no Original bruksanvisning
fi Alkuperäinen käyttöopas
el Πρωτότυπες οδηγίες λειτουργίας
Charger
BCS220 | BCS230 | BCS250

2 |
0 275 007 XCX | (24.04.2018) Bosch eBike Systems
eBike Battery Charger 36-6/230
0 275 007 918
Li-Ion
Use ONLY with BOSCH Li-Ion batteries
Input: 230V 50Hz 2.15A
Output: 36V 6A
Made in Vietnam
Robert Bosch GmbH, Reutlingen
Fast Charger BCS250
eBike Battery Charger 36-4/230
0 275 007 907
Li-Ion
Use ONLY with BOSCH Li-Ion batteries
Input: 230V 50Hz 1.5A
Output: 36V 4A
Made in PRC
Robert Bosch GmbH, Reutlingen
Standard Charger BCS220
Standard Charger
Fast Charger
(2)
(3)
(1)
(5)
(4)

| 3
Bosch eBike Systems 0 275 007 XCX | (24.04.2018)
BC S2 30
Compact Charger
(2)
(5)
(1)
(3)
(4)
