Bosch DICENTIS User manual

DICENTIS
Conference System
en Installation manual
PRELIMINARY

PRELIMINARY

DICENTIS Table of contents | en 3
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
Table of contents
1Safety 5
2About this manual 7
2.1 Intended audience 7
2.2 Alerts and notice signs 7
2.3 Copyright and disclaimer 7
2.4 Document history 7
3System installation overview 9
3.1 Typical system setup 10
3.2 System extension 13
4System installation design and planning 16
4.1 System capabilities 16
4.2 Hardware requirements 18
4.3 Power supply capacity calculation plan 21
4.3.1 Calculation using DCNM-APS2 or DCNM-PS2 21
4.3.2 Calculation using PoE switches 25
4.4 Redundancy options 27
4.4.1 Redundant cabling for DCNM-APS2/DCNM-PS2 units 28
4.4.2 Redundant server PC 30
5Installation material and tools 31
5.1 DCNM-CBCPLR Cable couplers 31
5.1.1 Using a cable coupler to extend a cable 32
5.1.2 Using a cable coupler as a break-out box 32
5.1.3 Using a cable coupler as an interface between different types of cable 33
5.1.4 Using a cable coupler to insert power locally 34
5.1.5 Using a cable coupler to switch the system on 35
5.2 DICENTIS System cable assemblies 38
5.3 DCNM-CBCON Connectors for DICENTIS cable 39
5.4 DCNM-CBTK System Network Cable Toolkit 40
5.5 DCNM-CB250 System installation cable 41
5.6 DCNM-IDESKINT On-air & teleph. DCNM-IDESK 42
6Mechanical installation of Central Equipment 46
6.1 Audio processor and powering switch and Powering switch 46
6.2 System server 50
6.3 Dante gateway 51
7Mechanical installation of Contribution Devices 55
7.1 Connecting DICENTIS devices 55
7.2 DICENTIS tabletop devices 57
7.3 DICENTIS flush-mounted devices 60
7.3.1 DCNM-FBD2 Flush base device 65
7.3.2 DCNM-FMCP Flush microphone connection panel 68
7.3.3 DCNM-FMICB Flush microphone button panel 69
7.3.4 DCNM-FPRIOB Flush priority button panel 70
7.3.5 DCNM-FLSP Flush loudspeaker panel 71
7.3.6 DCNM-FVP Flush voting panel 73
7.3.7 DCNM-FSLP Flush language selection panel 73
7.3.8 DCNM-FAI Flush audio interface 74
7.3.9 DCNM-FHH / DCNM-FHHC Flush hand held microphones 77
7.3.10 DCNM-FIDP Flush identification panel 77
PRELIMINARY

4en | Table of contents DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
7.3.11 DCNM-FICH Flush ID card holder 78
7.3.12 DCNM-FSL Flush language selector 79
7.3.13 Flush setups 82
7.4 DCNM-IDESK / DCNM-IDESKVID Interpreter desk 85
7.5 DICENTIS Microphones 88
7.6 DCNM-MMDSP Anti-reflection foil 90
7.7 DICENTIS Card holders 91
7.7.1 DCNM-NCH Name Card Holder 91
7.7.2 DCNM-DICH ID card holder for DCNM-D 91
8Installation Test 93
PRELIMINARY

DICENTIS Safety | en 5
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
1 Safety
Prior to installing or operating products, always read the Important Safety Instructions which
are available as a separate multilingual document: Important Safety Instructions (Safety_ML).
These instructions are supplied together with all equipment that can be connected to the
mains supply.
Safety precautions
Some of the DICENTIS Conference System products are designed to be connected to the
public mains network.
To avoid any risk of electric shock, all interventions must be carried out with disconnected
mains supply.
Interventions with the equipment switched on are authorized only when it is impossible to
switch the equipment off. The operation must only be performed by qualified personnel.
Old electrical and electronic equipment
This product and/or battery must be disposed of separately from household waste.
Dispose such equipment according to local laws and regulations, to allow their reuse
and/or recycling. This will help in conserving resources, and in protecting human
health and the environment.
Class A equipment (commercial broadcasting equipment)
This equipment is for professional (Class A) electromagnetic compatibility equipment. Seller
or user should pay attention to this point. It is intended for use outside the home.
!
Warning!
Changes or modifications made to this equipment, not expressly approved by Bosch Security
Systems B.V. may void the user’s authority to operate the equipment.
FCC Statement - Wired Class A digital device (unintentional radiator)
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Note: The FCC Wired Class A statement applies to:
– DCNM-D
– DCNM-FBD2
– DCNM-FMCP
– DCNM-FMICB
– DCNM-FPRIOB
– DCNM-FLSP
– DCNM-MICSLS
– DCNM-MICSLL
– DCNM-FVP
– DCNM-FAI
PRELIMINARY

6en | Safety DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
– DCNM-FSLP
– DCNM-FIDP
– DCNM-FHH
– DCNM-FHHC
FCC Statement - Wired Class B digital device
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Note: The FCC Wired Class B statement applies to:
– DCNM-MMD2
FCC and IC Wireless Statement
This device complies with Part 15 of the FCC Rules and with Industry Canada license exempt
RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Note: The FCC and IC Wireless statement applies to:
– DCNM-MMD2
– DCNM-DVT
– DCNM-DSL
– DCNM-DE
– DCNM-IDESK
– DCNM-IDESKVID
– DCNM-FIDP
PRELIMINARY

DICENTIS About this manual | en 7
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
2 About this manual
The purpose of this manual is to provide information required for installing the DICENTIS
Conference System.
This installation manual is available as a digital document in the Adobe portable document
format (PDF).
For more information, refer to the product related information on www.boschsecurity.com
2.1 Intended audience
This hardware installation manual is intended for installers of a DICENTIS Conference System.
2.2 Alerts and notice signs
Four types of signs can be used in this manual. The type is closely related to the effect that
may be caused if it is not observed. These signs - from least severe effect to most severe
effect - are:
i
Notice!
Containing additional information. Usually, not observing a ‘notice’ does not result in damage
to the equipment or personal injuries.
!
Caution!
The equipment or the property can be damaged, or persons can be lightly injured if the alert
is not observed.
!
Warning!
The equipment or the property can be seriously damaged, or persons can be severely injured
if the alert is not observed.
Danger!
Not observing the alert can lead to severe injuries or death.
2.3 Copyright and disclaimer
All rights reserved. No part of this document may be reproduced or transmitted in any form by
any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of the publisher. For information on getting permission for reprints and
excerpts, contact Bosch Security Systems B.V.
The content and illustrations are subject to change without prior notice.
2.4 Document history
Release date Documentation version Reason
2023-01 V4.2 Update to DCNM-CB250-I and
OMN-DANTEGTW.
Added:
– DCNM-SERVER3
– DCNM-FBD2
– DCNN-CB250-CPR
PRELIMINARY

8en | About this manual DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
Release date Documentation version Reason
– INT-TXO.
2023-03 V4.3 Added:
– DCNM-FVP
– DCNM-FSLP
– DCNM-FAI
– DCNM-FHH
– DCNM-FHHC
– DCNM-FIDP
– DCNM-FICH.
PRELIMINARY

DICENTIS System installation overview | en 9
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
3 System installation overview
It is advisable to participate in the DICENTIS Conference System training before you install,
configure, prepare, and operate a DICENTIS Conference System.
The DICENTIS Conference System is an IP based conference system which runs on an OMNEO
compatible Ethernet network. It is used for distributing and processing audio, video and data
signals.
The DICENTIS Conference System can be quickly and easily configured as a daisy‑chain
configuration or as a star configuration:
–Daisy‑chain configuration: Uses dedicated cabling, consisting of CAT‑5e cables including
two additional power conductors (see
Typical system setup, page 10 ).
–Star configuration: Each DICENTIS device is connected with an individual standard
CAT‑5e cable. An Ethernet switch is also required for providing Power over Ethernet
(PoE).
i
Notice!
When Power over Ethernet is used, DICENTIS devices cannot be daisy‑chained.
Refer to
– Typical system setup, page 10
PRELIMINARY

10 en | System installation overview DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
3.1 Typical system setup
This system overview does not give information on redundant network options. For more
information, refer to
Redundancy options, page 27 .
13
11
812
16
7
6
6
5
3
2
1
15
10
14
9
10
10
4
Figure3.1: Typical DICENTIS Conference System setup
A typical DICENTIS Conference System consists of:
1. Hall display of the conference room:
– Shows a synoptic layout of the meeting or meeting notes.
2. Client PC:
– Can be used to: Manage meetings, prepare meetings and configure the system.
3. DICENTIS System server:
– The heart of the system. It licenses functionality, configures and controls the system.
4. Optional video camera (Onvif Profile-S compatible cameras, Sony IP cameras via CGI
commands, or Panasonic HD Integrated IP) + external power supply:
– Captures the image of a speaking participant.
5. Ethernet switch:
– Ethernet switch with PoE on some ports.
- Routes the system data via Ethernet.
- Provides power to the DICENTIS devices via PoE.
6. CAT‑5e Ethernet cable (minimum requirement).
PRELIMINARY

DICENTIS System installation overview | en 11
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
7. Multimedia device:
– Only one DICENTIS device should be connected here.
8. Powering switch:
– Used to increase the number of DICENTIS devices connected to the system.
9. Audio processor and powering switch:
– Controls the system audio, routes audio from and to the system and supplies power
to the DICENTIS devices.
10. System Network Cable:
– Connects DICENTIS devices, the Audio processor and powering switch, and one or
more Powering switches to each other.
11. Multimedia device:
– This device is used for “system power on/off”. It is always connected to the powered
socket of the Audio processor and powering switch or Powering switch.
Note: Only one DICENTIS Multimedia device should be connected here.
12. Transmitter OMNEO:
– This device allows for wireless language distribution.
13. Flush base device:
– This device is intended for use in flush-mounted solutions, adding a number of
functions.
14. Interpreter Desk:
– Provides extensive facilities for professional interpretation for the DICENTIS
Conference System.
Note: A maximum of 10 desks can be installed per booth.
15. Flush language selector:
– This device allows the participants to easily choose their preferred language.
16. IR distribution:
– Through infrared distribution, the signals from the INT-TXO are transmitted to the
radiators in the room.
A typical camera setup in a DICENTIS Conference System consists of:
PRELIMINARY

12 en | System installation overview DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
Figure3.2: Typical camera setup
1 H.264 encoder to encode the HD SDI
video to H.264 if the video camera is
not able to supply the supported
H.264 stream
2 HD-SDI switcher to switch the HD-SDI
streams of the cameras
3 Projector to show the active speaker
on the large screen
4 Video camera (Onvif Profile-S
compatible camera, Sony, Panasonic)
5 DICENTIS System server 6 L3 Ethernet switch
7 DCNM-APS2 8 DCNM-MMD2, displaying the active
speaker on the device
….. HD-SDI (coax cable) ----- Ethernet TCP/IP
_____ DCNM-Cables
PRELIMINARY

DICENTIS System installation overview | en 13
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
3.2 System extension
The DICENTIS Conference System is scalable from small to medium to large. This section
describes what a small, medium and large system is and what the requirements are for these
systems:
A small to medium DICENTIS Conference System (see
Typical system setup, page 10 ) consists
of:
– up to 450 DICENTIS nodes.
Refer to table Node and device count of DICENTIS equipment below about the node and
device count of DICENTIS equipment.
– all DICENTIS devices in 1 subnet.
– 1 DICENTIS Audio processor and powering switch for the audio processing.
– 1 Server PC which hosts the DICENTIS services.
A large DICENTIS Conference System consists of:
– up to 1500 DICENTIS devices.
– multiple subnets connected by use of a router/L3 switch.
– Each subnet can have up to 450 DICENTIS nodes.
Refer to the following table for the node count of DICENTIS equipment.
– The first subnet has:
- 1 DICENTIS Audio processor and powering switch for the audio processing.
- 1 Server PC which hosts the DICENTIS services.
- 1 ARNI-Enterprise to increase the size of the system.
– All other subnets have 1 ARNI-Standard to increase the size of the system.
Note: There is no DICENTIS Audio processor and powering switch in the other
subnets.
Device Node count Device
count
IP addresses
DICENTIS Server 0 0 1
DICENTIS meeting application 0 0 0
DICENTIS Audio processor and powering switch 1 1 1
DICENTIS Powering switch 1 1 1
DICENTIS Multimedia device 2 1 2
DICENTIS Discussion device 1 1 1
DICENTIS Discussion device select language 1 1 1
DICENTIS discussion device voting 1 1 1
DICENTIS Discussion device extended 1 1 2
DICENTIS Interpreter desk 1 1 2
DICENTIS Interpreter desk with video 1 1 3
DICENTIS Flush base device 2 1 1 1
DICENTIS Flush language selector 1 1 1
INT-TXO Transmitter OMNEO 1 1 2
PRELIMINARY

14 en | System installation overview DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
Device Node count Device
count
IP addresses
OMN-DANTEGTW Dante gateway 1 0 1
PRS-4OMI4 OMNEO media interface 1 0 1
OMN-ARNIE ARNI‑E OMNEO interface 0 1 1
OMN-ARNIS ARNI‑S OMNEO interface 0 1 1
Table3.1: Node and device count of DICENTIS equipment
An ARNI (Audio Routed Network Interface) is used to connect multiple DICENTIS system
subnets. If more than one subnet is required, two types of an ARNI must be used.
– OMN-ARNIS (ARNI‑S OMNEO interface): The ARNI‑S is required for increasing the system
size above 450 DICENTIS nodes. It supports up to 450 DICENTIS nodes in its subnet. It
also acts as a DHCP server in its subnet.
– OMN-ARNIE (ARNI‑E OMNEO interface): The ARNI‑E is required for increasing the system
size above 450 DICENTIS nodes. It supports up to 450 DICENTIS nodes in its subnet. It
also acts as a DHCP server in its subnet. It can connect up to 40 subnets, each with an
ARNI‑S.
Defining subnets and subnet masks
A subnet is a logical, visible subdivision of an IP network. The number of DICENTIS devices
that can be in the same subnet depends on the subnet mask.
A standard class C subnet (255.255.255 or /24) can contain 254 IP addresses. Some
DICENTIS devices have 2 IP addresses. For this reason, Bosch advises to use 255.255.252.0
(or /22) as a subnet mask. This allows you to have 1018 IP addresses.
PRELIMINARY

DICENTIS System installation overview | en 15
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
Multi subnet DICENTIS Conference System
The following figure illustrates a typical multi subnet DICENTIS Conference System with a total
of 1500 DICENTIS devices.
– The system is divided over four (4) subnets, where two (2) subnets having a maximum of
450 DICENTIS nodes and an OMN-ARNIS are connected.
– The system has one OMN-ARNIE installed in the first subnet with a maximum of 450
DICENTIS nodes connected (Note that only one OMN-ARNIE is allowed within a multiple
subnet DICENTIS Conference System).
– Subnet four (4): When using multiple subnets, make sure that all cameras needed to
capture video of the seats are all connected to the same subnet.
192.168.76.x
VLAN76
192.168.79.254
192.168.72.1
VLAN72
192.168.75.254
192.168.72.x
192.168.68.1
VLAN1 (internet)
192.168.68.x
VLAN67
192.168.71.254
192.168.67.254
Figure3.3: Typical DICENTIS Conference System with multiple subnets
–1: External video switcher.
–2: Dome camera.
Refer to
– Typical system setup, page 10
PRELIMINARY

16 en | System installation design and planning DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
4 System installation design and planning
Before you start to install system devices and connect system cabling, you should make a
system design and planning:
– Familiarize yourself with the product and system capabilities.
– Make a cable (connection) plan:
– Calculate the system network cable length.
– Calculate the system power consumption.
– Calculate the required power capacity of the system.
i
Notice!
The DICENTIS Conference System uses the RSTP protocol when redundant cabling mode is
enabled. If the DICENTIS Conference System needs to be connected with the locally present
network, please consult the local IT department before continuing with the installation
design.
i
Notice!
Make sure that the cable lengths and power consumptions do not exceed the specifications.
Not doing so will result in malfunctioning at any moment of the DICENTIS Conference System
and products.
!
Caution!
When the relative humidity is below 40%, synthetic materials can cause static discharge and
result in malfunctions.
4.1 System capabilities
The capability of the DICENTIS Conference System and DICENTIS products depends on:
– The lengths of the system network cables.
– The number of connected devices.
– The system power supply capacity.
Cable length
System network cables (DCNM‑CBxx-I) lengths (2, 5, 10 or 25m) have a direct effect on the
available power supply capacity. The longer the system network cable, the less power supply
capacity is available to drive the connected devices. Therefore, choose the lengths of the
system network cables carefully.
i
Notice!
Custom network cables must never exceed the maximum Ethernet specification of 100m
(IEEE 802.3ab).
Keep your network hierarchy as flat as possible. This means having as few levels as possible.
It is recommended not to exceed 7 levels. See the following example: 1: 1st level = Root
switch, 2: 2 nd level = switch, 3: 3 rd level = switch.
PRELIMINARY

DICENTIS System installation design and planning | en 17
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
Figure4.1: Example: Switch-levels
Power supply capacity
The total system network cable length and connected devices determine the required power
supply capacity. The power within the DICENTIS Conference System is supplied by:
– The Audio processor and powering switch and the Powering switch, or
– Off‑the‑shelf PoE Ethernet switches.
Calculation tool
The calculation tool can be used to calculate the total power capacity of the system. This
makes the design and planning of the DICENTIS Conference System easier. The calculation
tool uses the power consumption of the devices and the system network cable lengths to
calculate the needed system power supply capacity.
The calculation tool is on the DVD supplied with the Audio processor and powering switch and
is part of the DICENTIS software DCNM.iso file. The DCNM.iso file can be downloaded from
the Bosch website at: https://licensing.boschsecurity.com/software
PRELIMINARY

18 en | System installation design and planning DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
4.2 Hardware requirements
Switches
The following minimum requirements and recommendations apply to switches used in a
DICENTIS:
Requirement Standard Settings
Gbit Ethernet IEEE802.3 Switch latency is maximally 10µSec with Gbit.
Valid for both copper and/or fiber ports.
Packet forwarding in
HW per port
>1.2Mpps
n.a. If SW is responsible for packet switching, this would
result in variable latency which is unacceptable.
Quality of Service
With strict priority
DiffServ To make sure PTP synchronization packets and
audio packets get priority over control packets.
OMNEO uses QoS on IP level to avoid
synchronization and audio problems on busy
networks. Although the system does work without
problems on relatively quiet networks (< 10%
network load) it is important to configure your
network switches correctly.
The used QoS is Differentiated Services or DiffServ,
which is part of the Type of Services field (ToS) in
the IP header. For more details on DiffServ & IP
header, see Wikipedia.
Warning: IEEE802.1p is also used for QoS, but is limited to layer 2. Since OMNEO uses IP
communication, this mechanism is not suitable, so make sure the used equipment uses
DiffServ QoS!
The table below gives an overview of the used DSCP values which need to be configured in
the switch:
Data DSCP dec DSCP hex DSCP Label TOS byte
(hex)
Switch
Priority
queue
PTP sync,
delay req
56 0x38 CS7 0xE0 Highest
PTP follow-
up, delay
response,
audio
46 0x2E EF 0xB8 High
(reserved) 8 0x08 CS1 0x20 Low
Control 0 0x00 Best effort 0x00 None
Warning: Please check thoroughly if your switch’s highest priority queue is label as #1 or e.g.
#8, because this may differ per brand. Unfortunately this is not consistent over the different
brands. Setting it wrong is worse than not having priority.
PRELIMINARY

DICENTIS System installation design and planning | en 19
Bosch Security Systems B.V. Installation manual 2023-02 (draft) | 4.3-draft |
Switches must be configured to support DiffServ (DSCP) quality of service The switch needs
to have 4 priority queues for the DiffServ mechanism to work.
Warning: Never use VOIP QoS settings!
Requirement Standard Settings
MAC table >1000 n.a. To avoid the switch starts broadcasting unicast
packets because it runs out of space.
Disable EEE IEEE 802.3az Most implementations of EEE cause problems
because of implementation flaws. A good
implementation should work, but does not save
energy since the PTP synchronization avoids this.
Therefore, EEE (green or low power Ethernet)
must
always be disabled.
Disable RSTP (when
no cable loops are
used)
Rapid Spanning Tree Protocol (RSTP) is required
when (cable) loops are created for redundancy. When
no loops are created, RSTP needs to be
disabled for
optimal operation. When enabled, it can cause slow
connections to the switch.
Possibility to create
VLANS
n.a. VLAN separation is recommended instead of IGMP
snooping, because most switches are unable to
handle the multicast changes in the system. Filtering
multicast data may be necessary for some devices,
such as 100 Mb devices (Sony cameras, TVOne, AMX,
and others).
IGMPv3 IGMPv2
snooping in
hardware
IGMPv3 or IGMPv2 snooping. To optimize bandwidth
usage, IGMP snooping can be used. This is useful in
systems with >10 multicast streams, although not
absolutely required. Sufficient performance for
handling a large number of IGMP query responses,
depends on the number of (directly or indirectly)
connected devices to that switch. Hardware support
for IGMP snooping is strongly recommended.
Requirements when
Redundant wiring is
used
Standard Settings
RSTP IEEE802.1D-20
04
RSTP is used to allow the creation of loops for
redundancy. The switch must support changing the
following parameters to the listed values:
– Hello_Time = 9 seconds
– Forwarding_delay = 30 seconds
– Max_age = 22 seconds
Diagnostics
Link Layer discovery IEEE 802.1AB For network diagnoses using Network Docent.
SNMP SNMP For network diagnoses using Network Docent.
PRELIMINARY

20 en | System installation design and planning DICENTIS
2023-02 (draft) | 4.3-draft | Installation manual Bosch Security Systems B.V.
Routers
The following minimal requirements apply to routers:
– 1Gbit or higher Ethernet ports.
– Supports PIM‑DM or Bidirectional PIM.
– Performs IP routing in hardware (i.e. a ‘layer 3 switch’) to minimize the routing delay.
– Packet forwarding rate > 1,000,000 packets per second per port (e.g. 8Mpps for an
8‑port router).
– Non-blocking backplane per switching port, i.e. 2Gbit per port (e.g. 16Gbps for an
8‑port router).
– MAC address table of at least 1000 addresses per directly connected subnet.
PRELIMINARY
