Bosch Access Modular Controller 2 User manual

Access Modular Controller 2
ADS‑AMC2‑4WCF | APC‑AMC2‑4WCF
en Installation manual

Access Modular Controller 2 Table of contents | en 3
Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM
Table of contents
1Safety 5
1.1 Unpacking 6
1.2 FCC compliance 6
2Short information 7
3Introduction 8
3.1 Description 8
3.2 Product overview 10
3.2.1 Mainboard 10
3.2.2 Status display 12
3.3 System overview 14
4Installing 15
4.1 Mounting the device on a mounting rail 15
4.2 Unmounting the device from a mounting rail 15
4.3 Opening the case 16
4.4 Closing the case 17
4.5 Cabling 18
4.5.1 Conductor data for powering the controller 18
4.6 Grounding and shielding 19
4.6.1 Grounding for Host Interface 19
4.6.2 Gounding for Extension Interface 20
4.7 Connecting the power supply to the controller 21
4.8 Ethernet host interface 22
4.9 RS-485 host interface 23
4.9.1 RS-485 Two Wire Connection 24
4.9.2 RS-485 Four Wire Connection 24
4.9.3 DIP switch selector 24
4.10 RS-485 for extension modules 26
4.11 Wiegand interface for card readers 27
4.12 Connecting relay outputs 28
4.13 Connecting analog input devices 30
4.14 Tamper protection 32
5Operating 33
5.1 Configuring Ethernet interface 33
6UL requirements 34
6.1 System requirements 35
6.1.1 Computer 35
6.2 UL 294 level descriptions 35
6.3 Installation instructions 35
6.4 Extended technical specification 38
6.4.1 RS-485 extension 38
6.4.2 Power consumption 38
7Troubleshooting 39
7.1 Resetting the software 40
7.2 Resetting the device to factory default 41
8Service and repair 42
9Disposal 43
10 Technical specifications 44
11 Appendices 46

4en | Table of contents Access Modular Controller 2
2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.
11.1 Connecting diagrams 46

Access Modular Controller 2 Safety | en 5
Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM
1 Safety
Read instructions
Read all technical documentation before installing or using this product. Make sure that you
have understood all information described in the technical documentation. Do not ignore
safety messages, as this can cause property or personal damage. Retain instructions for future
reference.
!
Warning!
Risk of physical injury due to blocked escape routes
This product may block escape routes if not installed correctly. To keep escape routes free:
- Use locks in fail-safe mode, so that doors can be released if power fails.
- Install manual override switches, such as break-glass or lever stations, to unlock doors in an
emergency.
!
Warning!
Risk of explosion of lithium battery
The battery can explode if replaced incorrectly.
Replace the battery with the same type as recommended by Bosch.
Dispose used batteries according to the instructions of the manufacturer of the batteries.
!
Caution!
Fire hazard and risk of electric shock due to unauthorized spare parts and accessories
Unauthorized spare parts and accessories might lack grounding wires or other safety
elements. External power supplies must be installed by qualified personnel. The service
technician must use replacement parts or accessories that are specified by the manufacturer.
i
Notice!
Some features and functions described in this document depend on the firmware loaded into
the device and host software.
i
Notice!
Device damage due to electrostatic discharge
Protect the hardware from electrostatic discharge, especially when the device is open and
exposed. Always disconnect the controller from the power source before modifying the
installation. This product does not support hot plugging.
i
Notice!
Unauthorized access
If this product is installed in an unprotected environment, unauthorized people may be able
to enter.
Install the product in a location with restricted access.
i
Notice!
Device damage due to incorrect mounting
This product may fall and break if it is not mounted on the mounting rails.
Mount this product on the matching mounting rails.
This product is RoHS compliant. See Technical data for the full table of hazardous
components.

6en | Safety Access Modular Controller 2
2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.
1.1 Unpacking
Check the packaging for visible damage. If anything has been damaged during transport,
please inform the transport agency.
Unpack the product carefully. This is an electronic device that must be handled with care to
avoid damage. Do not attempt to put the product into operation if components are damaged.
If any parts are missing, inform your customer service representative or a Bosch Security
Systems salesperson. The shipping carton is the safest transport container for the unit. Store
the shipping carton and the other packaging material for future use. If the product has to be
sent back, use the original packaging.
1.2 FCC compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. The limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate receiving antenna.
2. Increase the separation between the equipment and the receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.

Access Modular Controller 2 Short information | en 7
Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM
2 Short information
This controller is able to control up to four Wiegand card readers.
It is designed to fully process the access logic at assigned access points. Access points
consist of doors, gates, barriers, turn stiles, revolving doors, mantraps, ID card readers, door
opening elements and sensors.
All the product versions use encrypted connections between the access modular controller
and the host system.
The controller stores all necessary information in a battery-buffered memory and in a compact
flash storage element. Even when the unit is offline, it is able to perform:
– Independent status and authorization checks on access points
– Take access decisions
– Activate and deactivate connected peripheral elements
– Detect and register all relevant events
The Access Modular Controller (AMC) is supported by the Access Professional Edition (APE),
BIS Access Engine (ACE) and the Access Management System (AMS).
For the latest information about our products, visit our online product catalog:
www.boschsecurity.com/xc/en/product-catalog/
Manufacturing dates
For product manufacturing dates, go to www.boschsecurity.com/datecodes/ and refer to the
serial number on the product label.
Remarks
This hardware is part of a security system.
Access should be granted to authorized people only.
Some states do not allow the exclusion or limitation of implied warranties, or limitation of
liability for incidental or consequential damages, hence the above limitation or exclusion might
not apply to you.
If you need further assistance or have any questions, contact:
Bosch Security Systems B.V.
Torenallee 49
5617 BA Eindhoven
Netherlands
www.boschsecurity.com
© Bosch Security Systems B.V., 2021

8en | Introduction Access Modular Controller 2
2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.
3 Introduction
3.1 Description
The controller is equipped with four independent interfaces for Wiegand type readers. It is
able to control two doors with one reader in each direction and up to four doors with a reader
in one direction only.
Figure3.1: Access Modular Controller
All necessary information for access verification is stored in a battery buffered on-board
memory and a Compact Flash (CF) memory card. This guarantees autonomous access
decisions and complete access registrations even if the management host system is offline.
The built in compact flash adapter provides adequate storage capability for cardholders and
events.
The electronics of the controller are completely covered by a plastic housing. The LCD (liquid
crystal display) provides all important status information.
Unsecured Area
Secured Area
Figure3.2: Example

Access Modular Controller 2 Introduction | en 9
Bosch Security Systems B.V. Installation manual 2021-04 | V04 | IM
The controller can communicate upstream to the host computer using RS-485 multi-dropped
or Ethernet. It has eight analog input devices and eight relay outputs. With its analog input
devices, the controller verifies, for example, if a lock is closed or open. The relay outputs can
be used, for example, to activate lock mechanisms if access is granted, or activate the burglar
alarm system if an intrusion or system alert is detected. If the eight inputs and eight outputs
on the board are not enough to configure the system, up to three additional extension boards
can be connected. The extensions offer 8 or 16 additional inputs and outputs.
In the Bosch Access Host Systems the setup procedure for a controller is made very simple
and fast by the use of door templates. Once selected, all the inputs and outputs are
predefined. These settings can be changed to choose every free contact of the controller or a
connected extension.

10 en | Introduction Access Modular Controller 2
2021-04 | V04 | IM Installation manual Bosch Security Systems B.V.
3.2 Product overview
3.2.1 Mainboard
1
7
3 4 52
10 11 89 6
Figure3.3: Upper circuit board with display (front)
1 DIP switch for RS-485 address and protocol selection.
2 Lithium battery for buffering of static RAM and real time clock (RTC). The battery life
is estimated at 10 years, nevertheless an error message is generated if the voltage
sinks below a preset minimum level.
NOTICE: In order to avoid an error message caused by an earlier voltage drop we
suggest to replace the battery every 8 years. Spare part: VARTA CR 2032 PCB.
3 Reset push button - reachable through the casing using a screwdriver
4 Liquid Crystal Display
5 Push button, available on top of the housing, to select different display modes
6 Jumper: Equalization of potential between different systems and earth ground
(shield)
7 Jumper: Interface selector RS-485 host connection, RS-485 two wire or RS-485 four
wire (depends on external wiring)
8 Configurable RS-485 host interface
9 Compact flash memory
10 Project-specific interface
11 Configurable 10/100 Mbit/s Ethernet host interface
