1 About this manual
This manual provides all the information required to
install and operate the CCS 800 Ultro Discussion
System.
Conventions
2 Introduction
The CCS 800 Ultro Discussion System is a discussion
system for use in meeting and conference venues with a
limited number of participants.
A CCS 800 Ultro Discussion System consists of:
• One Central Unit (CU).
• Maximum 50 units of which one or more chairman
unit(s).
• Extension cables if required (5m or 10m).
• Peripheral audio and/or telecommunication
equipment.
• A built in MP3 recorder.
The CU is the heart of the discussion system which
controls the microphones of the chairman and delegate
units as well as providing facilities for audio inputs and
outputs. It also supplies the power for the CU itself,
chairman unit(s) and delegate unit(s).
With the use of Digital Acoustic Feedback Suppression
the loudspeaker volume can be increased significantly
before feedback appears. Digital Acoustic Feedback
Suppression is only available in CCS-CUD /
CCS- CURD.
A delegate unit enables participants to actively join in
a discussion (i.e. speaking and listening) by means of a
microphone, controlled by an on/off button and
a built-in loudspeaker or external headphone.
A chairman unit has the same function as a delegate
unit with the addition of a 'Priority' button, that enables
its operator to control the debate by temporary or
permanently overruling and muting all active
microphones, depending on an internal setting in the
chairman unit.
The built in MP3 recorder enables participants to:
record discussion; listen to discussion before playing it
back to the floor; play discussion back to delegates.
Warning
Warnings draw attention to instructions that
must be followed to prevent personal injury.
Caution
Cautions draw attention to instructions that
must be followed to prevent damage to the
equipment.
Note
Notes draw attention to special instruction tips
or other useful information.

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 6
3 Central Unit (CU)
Figure 3.1
1 Mains On/Off switch.
2 MP3 recorder (for more information, see section 7).
3 Microphone-mode switch.
Open mode with auto switch-off. To select
the maximum number of delegate microphones
to be activated simultaneously (1, 2, 3 or 4).
The microphone automatically switches off if
the speaker does not speak for 30 seconds.
The microphone can manually be switched off
by pushing the button on the delegate unit.
Open mode. To select the maximum number
of delegate microphones to be activated
simultaneously (1, 2, 3 or 4). The microphone
must be switched on or off manually by pushing
the button on the delegate unit.
Override mode. Only one delegate
microphone can be activated. If a new delegate
presses his microphone button, the microphone
unit of the current speaker will be switched off.
Chairman only mode. Only the chairman
units can be activated.
Test mode. For proper installation check.
All the light-rings and LED's of the connected
units will lit, if properly connected.
4 Speaker volume control of all connected delegate
and chairman units.
5 Volume control of the speaker or headphone of the
CU.
6 Headphone connection with 3.5 mm stereo jack plug
socket.
7 Trunk output 1 and 2. For loopthrough connection of
the delegate and chairman units. To each output a
maximum of 25 units can be connected.
The maximum length of cable between the outputs
of the CU and the last unit in the system is
100 m (328 ft).
8 Microphone input with gain adjustment for external
microphone. The external microphone will be
muted when the priority button on the chairman unit
is pressed.
9 Recorder input with gain control and recorder
output connection.
10 Line input and output for connecting a PA-system or
other audio equipment.
11 Telephone coupler input and output for connecting a
remote participant.
12 Insertion connection. To connect an external audio
equalizer for speech quality improvement under
difficult acoustic conditions (1 = without equalizer,
0 = insertion connection is internally open,
providing means to connect an external equalizer in
the path from microphone signals to delegate/
chairman loudspeakers).
13 Digital Acoustic Feedback Suppression (DAFS)
switch to activate or deactivate the DAFS (optional).
14 USB connector. Used for downloading recorded
speech to a PC (optional).
0
1
2
3
456
7
8
9
100
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
GainGain
100-240 V~
Trunk in/out Recorder Line Telephone Insertion
Digital Acoustic
Feedback Suppression
Microphone
In
Out
CCS
800 ULTRO
FIELD A
7 8 9
10
11 1513 14
123456
12
Note
The telephone input signal to the CU is not
added to the telephone output signal from the
CU to prevent line echo due to feedback.
Note
Position "1" required for internal loop-through
of the microphone signals to the delegate/
chairman unit loudspeakers.

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 7
15 Mains input connection. Use the included mains
cord to connect the CU to the mains socket.
In some countries it may be necessary to replace the
supplied mains cable by a local one. Brown = live,
blue = neutral and green/yellow = earth.
(Replacement and colour indication not applicable
to mains cords for North America).
4 Delegate and Chairman unit
Figure 4.1
The chairman unit (B) has the same function as a
Delegate unit (A) with the exception of a 'priority'
button.
1 Microphone with red illuminated indicator ring,
lights when the microphone is ON.
2 Two 3.5 mm stereo headphone sockets, one at each
side, for headphone or recorder connection.
Insertion of a headphone jack in one or both sockets
automatically mutes the unit's loudspeaker.
3 Built-in loudspeaker, automatically muted when the
microphone is on.
4 Red (LED) indicator above the microphone push
button, for microphone ON indication.
5 7-pole circular female socket for loopthrough
connection to the next unit.
6 2m flying lead connection cable with sturdy
moulded 7-pole circular male connector for
connection to the previous unit or CU.
7 Rotary volume control for headphones only.
8 Microphone ON/OFF push-button.
9 Chairman Priority button. When pressed emits
chime tone, overrules/mutes all active microphones
of delegate units in the system and keeps the
chairman's microphone on for as long as the button
is pressed (setting can be changed in the chairman
unit).
In systems with several chairman units these settings
are independently selectable for each chairman unit.
5 Installation
5.1 Connecting the delegate and
chairman units
Figure 5.1
Connect the delegate (2) and chairman (3) units to the
trunk connectors of the CU (1). Use an extension cable
(4) if necessary.
AB
83 7 2
45 6 9
1
8
AB
83 7 2
45 6 9
1
8
Warning
The CU must be earthed via the mains supply
for safety reasons and to ensure the specified
audio performance of the system. Do not open
the CU and/or delegate/chairman units, no user
serviceable parts inside.
GainGain
100-240 V~
Trunkin/out Recorder Line Telephone InsertionMicrophone
In
Out
1
Digital Acoustic
Feedback Suppression
FIELD A
3...25
3
22
3
1
4
1
2
2
3...25

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 8
5.2 Connecting up to 150 units
The CCS 800 Ultro can be used with up to 150 units by
adding a maximum of 2 additional control units acting
as power supply units only. The cables necessary for
these connections can be delivered by your local dealer.
5.3 Locking the extension cable
Figure 5.3
Cable locking clamps can be used in combination with
the extension cables to prevent accidental
disconnection.
5.4 Connecting an external
microphone
Figure 5.4
Put the external microphone (2) connector in the
microphone input of the CU (1).
Adjust the sensitivity by use of the gain control (3).
Use only microphones with balanced output.
The microphone input provides a 12V phantom power
supply.
Figure 5.2
max. 6 x 25 units
CCS
800 ULTRO
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
GainGain
100-240 V~
Trunk in/out Recorder Line Telephone InsertionMicrophone
In
Out
1
3
2
Digital Acoustic
Feedback Suppression
FIELD A

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 9
5.5 Connecting a wireless
microphone
Figure 5.5
Connecting a wireless microphone to the external
microphone input is possible with the included 50dB
attenuator. This way of connection allows interruption
of the wireless microphone by the chairman's priority
button.
5.6 Recording/play back the
conversation
Figure 5.6
Connect the cabling of the tape recorder (2) to the
recorder input and output of the CU (1). Use the gain
control (3) to adjust the sensitivity of the recorder input
of the CU.
5.7 Connecting a PA-system or
other external equipment
Figure 5.7
Connect a PA-system (3) or other devices (2) to the in-
and output of the CU (1).
Connect audio sources to the line input, a PA amplifier
or other sound-processing devices to the line output.
5.8 Connecting a telephone coupler
Figure 5.8
GainGain
100-240 V~
Trunk in/out Recorder Line Telephone InsertionMicrophone
In
Out
receiver
Digital Acoustic
Feedback Suppression
FIELD A
GainGain
Recorder
Line Telephone Insertion
In
Out
1
3
2
Out
In
RECORD PLAY
2
GainGain
Recorder
Line
Telephone Insertion
In
Out
1
3
GainGain
Recorder Line
Telephone
Insertion
In
Out
2
1
3
4

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 10
Connect the telephone coupler (2) to the telephone
input and output of the CU (1). The telephone coupler
is further connected to the telephone wall socket (4) and
a telephone (3) for dialing.
A connection to a telephone network must always be
made via a telephone coupler that provides adequate
isolation between the telephone network (PBX) and the
CCS 800 Ultro system. The telephone coupler shall also
meet all relevant requirements for this type of
communication equipment as imposed by law and/or
responsible telecommunication organisations in the
country of use.
5.9 Connecting an equalizer
Figure 5.9
Put the insertion switch (3) in position "0" and connect
the cabling (2) of the (mono) equalizer (4) to the
insertion input and output of the CU (1). Switch (3) must
be in position "1" (loop through) if the insertion input/
output is not used.
5.10 Mains connection
Figure 5.10
Use the supplied mains cord set (5) to connect the CU
(1) to a protective earthed mains socket (2). Press the
on/off switch (3) to power up the system, the display (4)
will be lit.
5.11 Connecting a USB cable
Use the optional USB cable to connect the CU (1) to a
PC. Data can then be downloaded from the CU to the
PC. See section 7 for more information.
Caution
Never try to make a direct connection between
the telephone network and the CCS 800 Ultro
discussion system.
GainGain
Recorder Line Telephone
Insertion
In
Out
2
1
3
4
Caution
Do not connect the USB cable and audio out-
put/input to the same PC, otherwise the system
will not work.
GainGain
100-240 V~
Trunk in/out Recorder Line Telephone InsertionMicrophone
In
Out
12
34
CCS
800 ULTRO
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
5
Digital Acoustic
Feedback Suppression
FIELD A

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 11
6Operation
6.1 Testing the connection of the
delegate and chairman units
Figure 6.1
Put the mode selector in the test position, all light-ring
indicators and LEDs of the delegate and chairman units
must lit if properly connected.
6.2 Using the microphone button of
the delegate unit
Depending on the position of the microphone mode
switch on the CU, pressing the microphone button on a
delegate unit will activate the delegate microphone.
Pressing again switches the microphone off.
4
3
2
1
12
3
4
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
Figure 6.2

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 12
6.3 Using the microphone button of
the chairman unit
Pressing the microphone button on a chairman unit
always activates the chairman microphone, independent
of the selected microphone mode.
Chairman units don't switch off automatically.
6.4 Using the priority button
Figure 6.4
Pressing the priority button of the chairman unit "B"
may be indicated by a chime tone and will deactivate all
active delegate units "A" and activates the chairman
microphone. Release of the button will either leave the
delegate units deactivated or activates them again
(depending on priority mode settings).
6.5 Priority mode settings in
chairman unit
Figure 6.5
Remove the cable relief bracket (1) to set the chime and
microphone switches in the required position at priority.
0 = : no chime at priority
1 = : (default) chime at priority
0 = : delegate microphones permanently OFF at
priority
1 = : (default) microphones temporary OFF at
priority
Figure 6.3
1...4 1...4
2
1
1
2
A
AB
B
0 I
0I
1

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 13
6.6 Open mode
Select the max. number ( 1, 2, 3 or 4) of delegate
microphones which can be active at the same time.
6.7 Open mode with auto switch-off
Select the max. number (1, 2, 3 or 4) of delegate
microphones which can be activated by the delegates
themselves at the same time. If the speaker is silent for
approximately 30 sec. the active microphone switches
off automatically.
Note
Chairmen can always switch on and off their
microphones and are not included in the max.
number.
Figure 6.6
4
3
2
1
12
3
4
1...4 1...4
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
Figure 6.7
1...4 1...4
4
3
2
1
12
3
4
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 14
6.8 Override mode
Each time a delegate presses the microphone button on
a delegate unit, it will override the currently active
delegate unit. So only one delegate microphone is active
at the same time. Chairman microphones can always be
switched on.
6.9 Chairman only mode
Figure 6.9
Only the chairman units (B) can be activated. Delegates
(A) can not switch on their microphone.
Figure 6.8
AA A B
4
3
2
1
12
3
4
B
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
4
3
2
1
12
3
4
A B
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 15
6.10 Volume control of the delegate
and chairman units
Turn the volume control (1) to set the volume of the
loudspeakers of the delegate and chairman units (2).
Adjust for maximum level without feedback. In the fully
counterclockwise position all loudspeakers are muted.
6.11 Using Digital Acoustic
Feedback Suppression (DAFS)
Figure 6.11
Put the Digital Acoustic Feedback Suppression switch
(1) in position "0" and adjust the loudspeakers for
maximum level without feedback. Switch Digital
Acoustic Feedback Suppression on by changing the
switch (1) to position "1". Then set the loudspeaker
volume to the required level, but increasing the volume
level more than 2 or 3 steps is not recommended.
Figure 6.10
0
1
2
3
456
7
8
9
10
21 1
0
1
2
3
456
7
8
9
10
0
1
2
3
456
7
8
9
10
2
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
GainGain
100-240 V~
Trunk in/out Recorder Line Telephone Insertion
Digital Acoustic
Feedback Suppression
Microphone
In
Out
FIELD A
1
Note
With the use of Digital Acoustic Feedback
Suppression the loudspeaker volume can be
increased significantly before acoustic feedback
appears. The maximum achievable volume gain
depends on the acoustical environment and
positioning of the units. Artefacts may occur
during microphone switching at very high
volume levels. In general the achievable
increased volume gain is 4 - 6 dB.
The Digital Acoustic Feedback Suppression is
optimised for speech.

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 16
6.12 Monitoring volume control
Use the built-in loudspeaker or a headphone to monitor
the discussion. Adjust the volume using the monitoring
volume control. The maximum level is controlled by
the setting of the volume control for delegate and
chairman units.
6.13 Using a headphone
Figure 6.13
Use the rotary volume control (1) to adjust the volume
of the headphones connected to the left and/or right
side of the units. Inserting a headphone jack mutes the
loudspeaker.
The maximum level depends on the setting of the
volume control (2) on the CU.
Figure 6.12
CCS
800 ULTRO
0
1
2
3
456
7
8
9
100
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
0
1
2
3
456
7
8
9
100
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
0
1
2
3
456
7
8
9
10
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
0
1
2
3
456
7
8
9
10 0
1
2
3
456
7
8
9
10
4
3
2
1
12
3
4
CCS
800 ULTRO
1
2

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 17
7 Built-in MP3 recorder
7.1 Introduction
The built in MP3 recorder allows users to:
• record discussion
• listen to discussion before playing it back to the floor
• play discussion back to delegates
Recording is started and stopped by the user. The
settings of the MP3 recorder can be changed so that
recording only takes place when any one of the
microphones is active (for more information, see section
7.3).
When recording is activated, the MP3 recorder will
automatically create an MP3 file, using the current date
and time as the file name. Recorded files have a
maximum duration of 60 minutes. After 60 minutes, the
file will be automatically closed, and a new file will be
created. This process is repeated as long as recording is
active or until the SD card is full.
Recorded speech is saved on an SD card, which is
inserted into the top of the unit (see following figure), or
saved internally. After recording, the SD card can be
removed, or the recorded speech can be downloaded to
a PC by connecting a USB cable to the back of the CCS
800 Ultro Central Unit.
The MP3 recorder has a card exchange feature that
allows the user to exchange the SD card during
conversation without loss of discussion/audio (for a full
explanation of this feature, see section 7.4.3).
Once discussion has been recorded, the user can choose
to pre-listen to or playback the file (for more
information, see section 7.5).
7. 2 O v e r v i e w
7.2.1 User display
The user display has five soft buttons for operating the
MP3 recorder (see following figure).
Figure 7.1: Overview of user display and buttons
1Soft button 1
2Soft button 2
3Soft button 3
4Soft button 4
5Softbutton5
6User display: displays user data and icons (see
section 7.2.3).
7Slot for SD card: Slot for inserting the SD card.
8LED for SD card: LED is on during recording.
2
6 7 8
345
1

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 18
7.2.2 Modes of operation
Use button (1) to select the mode of operation. An icon
appears in the top right-hand corner of the display to
show which mode is selected. The following modes are
available (see following table).
7.2.3 Start-up screen
After powering up the CCS 800 Ultro, the start-up
screen is briefly displayed, which shows the name of the
recorder, as well as the revision number of the software.
The software then automatically displays the Record
screen (see following figure).
Figure 7.2: Overview of record screen (after start-up)
1Mode selected icon: Shows the selected mode
2VU-meter: Shows the audio level during recording,
pre-listening, and playback.
3Change mode icon: Shows the user when another
mode can be selected.
4Date: Shows the date in year, month, day format.
5Progress and separator line: during recording
shows the amount of used/free memory. In pre-listen
mode and playback mode shows how much of the
file has been played.
6Icons: The space underneath the Progress and
separator line is reserved for icons. Various icons are
used during recording, pre-listening, and playback.
The icons vary according to the mode selected (for
more information, see section 7.3 through section
7.5).
7Time: Shows the time in hours, minutes, and
seconds.
8Time counter: Shows the elapsed time during
recording, pre-listening, and playback.
9Total time: In record mode, shows the remaining
time in hours, minutes, and seconds. The timer
counts down during recording; in pre-listening
mode, and playback mode, shows the total time of
the selected recorded session. Note: Total time is
constantly displayed.
7.3 Setting up the MP3 recorder
Use this mode to set-up the MP3 recorder. The
following options are available (see following table for
an overview of the set-up icons):
•Delete files
• Set the date
•Setthetime
• Select the bit rate
• Set recording to continuous
• Set recording options
table 7.1: Mode selected icons
Icon Mode selected
Record
Pre-listen
Playback
Set-up
123
74
5
89
6

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 19
7.3.1 Overview of set-up icons
table 7.2: Overview of icons for navigating set-up screens
Icon Icon name Function of icon
Next (displayed at lower
left of set-up screen)
Go to next set-up screen. This icon is also displayed at the top left of
the set-up screen to indicate that the other modes can be selected at
any time, by pressing the change mode button (1).
Select Selects next value to change.
Down Decreases value, or selects another value or file.
Up Increases value, or selects another value or file.
Date Indicates that the date set-up screen is selected.
Time Indicates that the time set-up screen is selected.
Bit rate Indicates that the bit rate set-up screen is selected.
Microphone recording Unit will only record if one or more microphones are active.
Constant recording Unit will constantly record (one or more microphones do not have to
be active).
Confirm delete Confirms file to be deleted.
Delete file Permanently deletes selected file.
Cancel delete Cancels the delete file command.
Record to card Sets up recording so that files are saved to the SD card. Data will still
be saved to the internal memory during card exchange, as described
in section 7.4.3.
Record to memory Sets up recording so that files are saved to the internal memory.
Hourglass Initializing SD Card.
SD card status Card flashing at 2 Hz: card is initializing.
Card flashing at 5 Hz: card is either: full, write protected, or
incompatible.

Bosch Security Systems B.V. | 2007-08
CCS 800 Ultro | Installation and Operating Manual en | 20
7.3.2 Deleting files
Use this option to delete files.
1 Press the up or down button to select the file to
delete. The filename will change on the display as
the button is pressed.
2 Press the confirm delete button to confirm the file to
delete (the following screen will be displayed).
Figure 7.4: Confirm delete screen
3 On this screen, you can either:
- select the delete file button to permanently delete
a file.
- select the cancel delete button to cancel the delete
file command.
4 Press the select button to select the next value to
change (see following section).
7.3.3 Setting the date and time
Before using the MP3 recorder you should make sure
that the date and time are correctly set. If necessary,
adjust the date and time as follows:
1 Press the change mode button (1) to select the set-up
mode. When selected, the set-up icon should be
shown in the top right-hand corner of the display
(see following figure).
Figure 7.3: Set-up screen for date
2 Press the up or down button (4 or 5) to change the
value (year number), and then press the select button
(2) to select the next value to change.
3 Set the date (year, month, and day) as described in
the previous step, and then press the next button (3)
to jump to the time set-up screen.
4 Set the time (hours, minutes, and seconds), using the
same method as described in step 2, and then press
the next button to jump to the bit rate set-up screen
(see following section).
Note
After deleting a file, the software jumps back to
the delete file screen.
Note
To change settings in the set-up mode, you must
follow the programmed sequence of events
(there is no back button). To exit the set-up mode
at any time, press the change mode button
(button 1 at the left-side of the display).
