Service Manual
Craniotome GB265R,GB268R and Macro CraniotomeGB299
Service-Manual
Craniotom GB265R, GB268R und Makro-Craniotom GB299
Aesculap Power Systems

TA003323
GB266203
GB299207
GB299801
GB299204
TA005803
GB299209
TA005799
GB299203
TA003904
GB299202
GB131202
GB125312
TA005581
GB299208
TA005761
GB299205
GB299805
TA003323 (3x)
TA 005 801
TA005800
TA003189
TA004018
GC303R
TA005761
TA003323 (1x)

GB115801

2
Craniotome GB265R, GB268R and Macro Craniotome GB299
Aesculap Power Systems
Copyright information
Copyright© 2006
Aesculap AG & Co. KG®
All rights reserved 08/06
This service information is copyrighted. This service information must not
be copied or reproduced by other means either in whole or in part without
the express permission of Aesculap AG & Co. KG.
This manual isintended for informationalpurposes only. Ownership of this
manual alone does not constitute or imply authorization to service the
product.
The technical information, illustrations and dimensions contained in this
manual are non-binding. No claims may be made on the basis of the
informationcontainedherein.Wereservetherightto makeimprovements
without altering this documentation. We reserve the right to make
technical changes without prior notice.
Main address for servicing:
Aesculap Technischer Service (ATS)
Am Aesculap-Platz
78532 Tuttlingen / Germany
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Other service addresses can be obtained through the address indicated
above.
Manufacturer’s liability
We expressly point out that we can accept responsibility for any effects
on the safety, reliability, and performance of our medical products, if and
only if:
• any assembly, extensions, readjustments, modifications, or repairs are
performed by technically experienced, knowledgeable and trained
personnel and
• the medical products are used as set forth in the instructions for use.
It is possible to learn to service the products through an appropriate
course of instruction given onthe premises of Aesculap about the relevant
medical products. To arrange for such a course, contact Aesculap
Technical Service (ATS).
To ensure that your Aesculap warranty remains valid, we recommend that
only spare parts that have been factory tested by Aesculap be used for
repairs. Spare parts, as well as the relevant tools, can be ordered from
Aesculap Technical Service (ATS). Any unauthorized opening and/or
alterations of the medical product by third partieslead to the exclusion of
our liability, as far as a fault is attributable to such unauthorized opening
and/or alteration of the product. Aesculap cannot accept responsibility for
the use of unsuitable spare parts, tools or devices. After repairs, dropping,
severe damage or misuse, the product should be inspected by a qualified
person.
This manual refers to the product as it was when the manual was
prepared. Technical changes may be made at any time, particularly in
software.
General advisory
This service manual contains illustrations and explanations. Each
explanation covers the following: modes of operation, spare parts list,
assembly, disassembly, functionality test, and the section tools/devices (if
applicable).
For further information about a specific product (e.g. troubleshooting list,
accessories) consult the relevant user instructions.
It is crucial that extreme cleanliness be maintained when the products
described below are repaired. All products must undergo a functionality
test after being repaired. If, in the course of a repair, a labeled component
is replaced, the labeling must be transferred to the spare part. Either the
original label should be used or the spare part bearing the relevant label
should be ordered. To this end, be sure to include the applicable
information when ordering.
Unless otherwise indicated, all medical products should be inspected
annually.
General information about motors and handpieces
It is critically important that ball bearings be inspected annually. Even the
slightest defect or soiling can lead tooverheating during use, whichwould
render the product unusable. If for the repair of, e.g., a motor a ball
bearing has to be replaced, it is best in most cases to replace all other ball
bearings as well.
If it is necessary to heat up adhesive joints during disassembly, a hot-air
blower is the appropriate tool.The smallest possible nozzle shouldbe used
so as to avoid damaging other components. When gluing parts together,
make certain that the surfaces to be joined are absolutely clean and free
of grease. We recommend using Loctite Rapid Cleaner 7063 for this
purpose (WS. no. 520001750). Only use adhesives listed in this manual.
Follow the glue manufacturer’s recommendations.
Lubricate components with the recommended Aesculap product only.
Following disassembly, clean all components thoroughly and inspect them
to ensure that they are undamaged. Do not install any component of
whose status you are uncertain. Products must always be test-run for
several minutes after being repaired.
Literature Art. no.
Instructions for use TA005834

3
Contents
1. Safe handling...................................................................................................3
2. Tools, auxiliary materials, supplies............................................................3
2.1 Tools....................................................................................................................3
2.2 Auxiliary materials..........................................................................................3
2.3 Supplies .............................................................................................................3
3. Expendable parts/Replacement parts........................................................4
4. Designation of the craniotome elements ...............................................4
5. Basic preparations and maintenance........................................................4
5.1 Preparations.....................................................................................................4
Surface inspection......................................................................................... 4
Checking the connections between elements....................................... 4
Function tests..................................................................................................4
5.2 Maintenance....................................................................................................4
6. Troubleshooting list........................................................................................5
7. Disassembling..................................................................................................6
7.1 Disassembling the support foot .................................................................6
Disassembling support foot GB266.......................................................... 6
Disassembling support foot GB298.......................................................... 6
7.2 Disassembling the housing (GB267) ........................................................6
7.3 Disassembling the spindle (GB267) ..........................................................6
7.4 Disassembling the housing (GB299) ........................................................6
7.5 Disassembling the spindle (GB299) ..........................................................6
8. Assembling......................................................................................................10
8.1 Preliminary work.............................................................................................7
8.2 Pre-assembling the spindle (GB267) ........................................................7
8.3 Assembling the housing (GB267) ..............................................................7
8.4 Pre-assembling the spindle (GB299) ........................................................7
8.5 Assembling the housing (GB299) ..............................................................7
8.6 Assembling the support foot.......................................................................7
Assembling support foot GB266................................................................ 7
Assembling support foot GB298................................................................ 7
8. Postmaintenance..........................................................................................11
9.1 Function tests..................................................................................................8
10. Parts list.............................................................................................................8
10.1 GB265R .............................................................................................................8
10.2 GB268R .............................................................................................................9
10.3 GB299 ...............................................................................................................9
1. Safe handling
!Operate craniotome GB265R, GB268R and GB299 with authentic
Aesculap accessories only.
!To avoid damage to the product, do not knock craniotome GB265R,
GB268R and GB299 against hard objects.
2. Tools, auxiliary materials, supplies
2.1 Tools
2.2 Auxiliary materials
2.3 Supplies
Designation Art. no.
Slotted screwdriver without
Clamping jaws without
Designation Art. no.
Instructions for use TA005834
Designation WS. no.
Special grease MI-setral-FKR 2 537001602
Loctite 222 560001813
Loctite 640 560001820
Eloxal Cleaner JG601
Oil spray GB149
