Breezesta PB-1607 User manual

PALM BEACH LEFTHAND ARM
LOUNGE CHAIR
-
PB-1607
1 PB-1607 Assembly

A B
C
D
E
F
G
H
ab
c
d
e
f
g
h
i
Suggested Tools:
Drill, Plastic Mallet
FOR USE IF CONNECTING FURNITURE-SEE LAST
PAGE OF INSTRUCTIONS
PARTS
PART DESCRIPTION PART NO. QTY
A PB LOUNGE CHAIR LH FRAME SA-00383 1
B PB ARMLESS RH FRAME ASSY SA-00370 1
C 24"X24" SEAT SLING H-0000-SLG 1
D PB SLING SPACER ASSEMBLY SA-00382 1
E PB SLING RAIL ASSEMBLY SA-00407 1
F PB SLING RAIL ASSEMBLY SA-00408 1
G PB 1-ARM LOUNGE BACK SLAT PRT-00863 3
H PB 1-ARM LOUNGE FRONT BOTTOM SPREADER PRT-00866 1
SA-00399 HARDWARE KIT
ITEM NO. DESCRIPTION
PART NO. QTY
a #8 X 1-1/4" TORX SCREW H-0000-S8125 12
b #8 X 1-3/4" TORX SCREW H-0000-S8175 12
c #8 x 2-1/2" Torx Screw H-0000-S825 6
d 1/4"-10 X 3" LAG SCREW H-0000-S103 1
e T20 & T25 TORX BIT H-0000-CTD 1
f LEVELLING MOUNT H-0000-LM 4
g 6-INCH T20 TORX BIT H-0000-T20X6 1
h CONNECTOR PLATE H-0000-CP 2
i #8 X 1-1/4" TORX SCREW-UNPAINTED H-0000-S8125 8
2 PB-1607 Assembly

G
A
B
G
A
E
H
F
For E & F , the small board faces the
inside of the seat with its overhanging
end toward the armless side of the chair.
1.
Place Frame Assembly
A
on a flat surface either
as shown or with the slats
on the ground and frame
sticking up in the air. Insert
the 3 Back Slats
G
into the
slots of the frame. This may
require some tapping with
a mallet to set them firmly
into the slot.
The Back Slat tenon is
offset, and is positioned to
the rear of the chair as
seen at right.
Please read the entire instruction
before beginning
2.
If you did not start with the
slats on the floor, carefully rotate
the chair to its back. Align the
top back slot of assembly
B
with
the top back slat. Align the
remaining slats and use a mallet
to start the slat tenons into the
frame, leaving them slightly out.
Insert the front and rear sling rails
(
E
&
F
) and the front bottom
spreader (
H
) into their respective
slots. Then complete the process
of seating the back slats into the
frames so all tenons are fully
seated in their slots.
3 PB-1607 Assembly

B
G
A
E
H
F
f
b
(2) 1-3/4" screws (
b) are used on
each end of
E
,
F
&
H
.
4.
Before flipping the chair to it's feet,
install the (4) leveling mounts
(hardware
f
) by threading them into the inserts
located at the four corners on the
bottom of the chair.
3.
Using the 6" torx bit (hardware
g
),
screw the (12) 1-3/4" screws (
b
) into
the bottom spreader (
H
) and sling
rails (
E
&
F
). When tight, the ends of
the spreader and rails should be flush
to the two side frame assemblies.
3.00 3.00
d
a
KEEP FLUSH WITH TOP OF FRAME
C
D
c
i
h
5.
Screw in the back seat slats using (12) hardware
a
. Start at the top, making sure the top of the slat is
flush to the top of the chair frame. Then work your
way down to the remaing two slats. For reference,
slats are spaced 3" from the bottom of one to the
top of the next. While looking at the back, install
the remaining (1) hardware
d
. This will require the
larger end of bit
e
.
6.
Insert sling spacer
D
into the seat frame as shown
at left. Be sure it is pushed against the back of the seat.
Install (6) hardware
c
to hold it in place. Insert the seat
sling (
C
) into the seat frame. It should drop into the
frame with minor pressure applied to the frame sides.
Optional:
If you wish to physically connect multiple
pieces of furniture together, use the included plates
and 1-1/4" screws (
h
&
i
) as shown at left. Connect
plates to the inside faces of the front and back legs
allowing approximately 1-1/2" of the plate to protrude
from the side of the chair. Then move the next
furniture piece into place and fasten the plates to it.
4 PB-1607 Assembly
