Breezesta BH-0905 User manual

REV01-4/19
COASTAL BAR CHAIR
BH-0905
1 BH-0905 Assembly
1-877-904-1234
www.Poly-Lumber-Furniture.com

A
B
C
D
F
E
a b c d
e
Suggested Tools:
Drill, Plastic Mallet
f
G
H
I
J
g
PARTS
PART DESCRIPTION PART NO. QTY
A FRONT LEG ASSEMBLY SA-00080 2
B LEFT BACK LEG ASSEMBLY SA-00081 1
C RIGHT BACK LEG ASSEMBLY SA-00082 1
D UNDER ARM SUPPORT PRT-00146 2
E LEFT ARM ASSEMBLY SA-00066 1
F RIGHT ARM ASSEMBLY SA-00067 1
G FOOT REST PRT-00168 1
H SEAT ASSEMBLY SA-00068 1
I LEG BASE ASSEMBLY SA-00078 1
J BACK ASSEMBLY SA-00069 1
HARDWARE
PART DESCRIPTION PART NO. QTY
a #8 X 2" TORX SCREW H-0000-S82 2
b #8 X 2-1/2" TORX SCREW H-0000-S825 4
c 5/16" X 1-1/2" CHAIR BOLT H-0000-CB51615 2
d 5/16" X 2-1/8" CHAIR BOLT H-0000-CB516218 12
e DOUBLE SCREW H-0000-DS 4
f T20 & T25 TORX BIT H-0000-CTD 1
g #8 X 3" TORX SCREW H-0000-S83 4
BH-0905 Assembly 2
1-877-904-1234
www.Poly-Lumber-Furniture.com

A
B
E
e
x2
T20
b
x2
D
T25
H
I
d
x12
1.
Attach Parts A & B to Part E by
inserting Hardware e into the pre-
drilled holes and rotating Parts A &
B clockwise, stopping when the
assembly is tight
3.
Repeat Steps 1 & 2 with
Parts A, C, F & D
2.
Attach Part D to the previous
assemblies using Hardware b
4.
Attach Parts H & I to the previous
assemblies using Hardware d
Please read entire instructions
before beginning
3 BH-0905 Assembly
1-877-904-1234
www.Poly-Lumber-Furniture.com

T20
G
g
x4
T20
J
T25
c
x2
a
x2
5.
Drop Part G into place and secure it
with Hardware g as shown
6.
Slide part J into place and
connect it as shown
