Bristan Jute JU PBSM C User manual

AFTERCARE INSTRUCTIONS
Your fitting has a high quality finish and should be treated with care to preserve the
visible surfaces. All surface finishes will wear if not cleaned correctly, the only safe
way to clean your mixer is to wipe with a soft damp cloth. Stains can be removed
using washing up liquid. All bath cleaning powders and liquids will damage the
surface of your fitting - even non-scratch cleaners.
GUARANTEE
All products are manufactured to the highest standards and a 5 year guarantee
covers any defect in manufacture.
NOTE: he 5 year guarantee on the valves is invalidated if damaged by any
waterborne debris.
In the interests of continuous product development we reserve the right to alter
specification as necessary
PRODUCT CODE: JU PBSM C
TELEPHONE HELPLINE: 0844 701 6273
Bristan Group Ltd
Birch Coppice Business Park
Dordon
amworth
Staffordshire
B78 1SG
UK
Web Site: www.bristan.com
elephone: 0844 701 6273
Facsimile: 0844 701 6275
Email: [e-mail]
(FI JU PBSM) (Rev. D4)
Jute Pillar Bath Shower Mixer
Before starting any installation project,
consider “safety” first. Look for the “safety
note” sign and read the safety advice.
Fitting Instructions
& Contents List
Ple se keep these instructions for future reference nd for the
ordering of sp re p rts.

WATER PRESSURE
his mixer is suitable for use at all supply pressures. However for optimum use,
both the hot and cold supplies should be reasonably balanced.
If the fitting is installed at low pressure (tank fed), then the minimum height from the
highest installed position of the showerhead to the underside of the cold tank should
be 1 metre to ensure adequate shower performance.
his mixer should be installed in compliance with Water Regulations. For further
details contact your Local Water Authority.
CONTENTS
1. Mixer Body (x1)
2. Handset (x1)
3. Diverter Knob (x1)
4. Sealing Washer (x2)
5. Shower Hose (x1)
6. Rubber Washers (x2)
7. Backnut (x2)
8. Wall Bracket (x1)
a. Valve (x2)
b. Handle (x2)
Ple se Note:
In the unlikely event you find a part missing please contact our Customer Service
Help line on 0844 701 6273 or email [email protected] for immediate despatch
of part.
INSTALLATION
1. Identify all components and check for completeness, particularly before arranging
fitting.
2. Install the mixer body (1) to the bath using the washers (6) and backnuts (7)
provided.
3. Fit the hose (5) to the mixer (1) and the handset (2) using the small sealing
washers (4).
Prior to drilling into walls, check there are no hidden
electrical wires, cables or water supply pipes with the aid
of an electronic detector. If you use power tools do not
forget to:
• Wear eye protection
• Unplug equipment after use
4. Fix the wall bracket (8) to the wall ensuring that the handset (2) will reach it.
5. Connect the hot and cold water supplies and turn water supplies on.
6. Fully open both valves (a) by turning handles (b), letting it run for a few minutes
to check for leaks.
7. 7. Operate the mixer in both bath and shower mode. o switch from bath to shower
mode, pull the diverter knob (3) up. After use, the mixer automatically reverts to the
bath filling mode.
8. See over the page for aftercare instructions.
MAINTENANCE
If the fitting begins to drip:
1. urn off the water supply.
2. Remove grub screws from rear of handle and then remove handle (b) by pulling
from valve (a).
3. Using a suitable socket or box spanner, remove valve. Once removed, carefully
clean seating, rubber washer and ceramic disc.
4. Replace all of the above then turn on the water supply.
5. If problem persists contact our helpline quoting the product code.
