Brita On tap User manual

1
Installation and instructions for use
取り付けおよび取扱説明書
安裝及使用說明
OnTap
1017032-00-ELA_OnTap_GA_Asia.indb 1 17.12.18 09:22

2
Index
ENGLISH 1. Congratulations Page 3
2. Important notes Page 3
3. Conditions for use Page 3–4
4. Installation Page 4–5
5. Initial operation Page 5–6
6. Changing the filter cartridge Page 6–7
7. Changing the battery Page 8
8. Removing the housing Page 8
9. BRITA service Page 9–10
10. Technical features Page 10
日本語 1. はじめに ページ 11
2. 重要 ページ 11
3. 使用条件 ページ 11 – 12
4. 取り付け ページ 12 –13
5. 初期操作 ページ 13 –14
6. フィルターカートリッジの交換 ページ 14 – 15
7. 電池の交換 ページ 16
8. ハウジングの取り外し ページ 16 – 17
9. ＜ブリタ＞カスタマーセンター ページ 17 – 18
10. 技術的な特長 ページ 18
繁體中文 1. 恭喜您 頁碼 19
2. 重要注意事項 頁碼 19
3. 使用條件 頁碼 19
4. 安裝 頁碼 20 – 21
5. 初步操作 頁碼 21 – 22
6. 更換濾芯 頁碼 22 – 23
7. 更換電池 頁碼 23
8. 拆開外殼 頁碼 24
9. BRITA服務 頁碼 24 – 25
10.技術特色 頁碼 25
1017032-00-ELA_OnTap_GA_Asia.indb 2 17.12.18 09:22

ENGLISH 3
1. Congratulations
Thank you for choosing BRITA quality for great tasting
BRITA filtered water. BRITA filtered water improves taste
of hot and cold drinks and is economical and convenient.
To ensure you achieve the best results, please read the
following instructions carefully before fitting the BRITA On
Tap water filter system to your tap.
2. Important notes
2.1 Ideal use
• Do not use any tools when installing the
BRITA On Tap water filter.
• Do not disconnect the BRITA On Tap
water filter system while running water
through the filter.
• Clean the outside of the BRITA On Tap water filter
system with a damp sponge and mild washing-up liquid.
Abrasive cleaners, detergents or chrome polish may
mark the finish.
• Do not put the BRITA On Tap water filter system or any
of its parts in the dishwasher.
• Should the BRITA On Tap water filter system require
repairs or servicing, do not attempt to disassemble the
unit. Please contact the BRITA Customer Service in your
country.
• For all notes on installation, operation and servicing,
please see the following sections of the instructions
for use.
2.2 Optimum performance
• The OnTap filter is designed for the use with cold tap
water. Please filter cold tap water only.
2.3 Filter first, and then boil
• The BRITA On Tap water filter system is designed to
be used only with municipally treated tap water. If an
instruction is received from the authorities that mains
water must be boiled, then BRITA filtered water must
also be boiled. When the instruction to boil water is no
longer in force, please clean the BRITA On Tap water
filter system thoroughly and insert a new cartridge.
• For certain groups of people (e.g. those with impaired
immunity and babies), it is generally recommended that
tap water should be boiled; this also applies to filtered
water.
2.4 Exclusion of liability
• BRITA cannot accept any liability if one does not follow
the given instructions of use.
3. Conditions for use
3.1 When does the BRITA OnTap filter not work?
The BRITA On Tap filter is not intended to be connected
to a low-pressure water heater; it is an external contact
system and its internal receptacle will not support the
pressure of the supply pipe.
The following characteristics will help you determine
whether your equipment is a low-pressure water heater:
!A low-pressure water heater is
usually installed immediately next
to the sink or underneath it.
!Low-pressure taps are fitted with 3
connections (open system).
1. Congratulations / 2. Important notes / 3. Conditions for use
1017032-00-ELA_OnTap_GA_Asia.indb 3 17.12.18 09:22

4 ENGLISH
!Hand tighten only. Do not use any tools when
attaching the diverter to the tap.
Step 3:
To remove the top cap (H) carefully turn the cap to the
right (see Fig. 3). Insert the supplied battery to the battery
mount. Reinsert the top cap and tighten it.The three lights
in the top cap will blink twice consecutively. The electronic
cartridge change indicator is now ready to go.
H
3
!Always make sure that the BRITA logo on the
housing is facing downwards when connecting it to
the diverter (see Fig. 3 above).
4. Installation / 5. Initial operation
!When the supply of hot water has been used
(between 5 and 10 litres), only cold water will come
out of the tap.
4. Installation
Step 1:
Remove the existing aerator (C) from the tap.The tap will
either have an external threat (Fig.1.A) or an internal thread
(Fig.1B).
C
1A
C
1B
Step 2 with external thread
Screw the diverter (A) onto the tap. No adapter is
necessary.
A
B
2A
Step 2 with internal thread:
To attach the diverter (A) to an internal thread you will need
to use the flat gasket (D) and adapter (E) which you will find
in the packaging. First insert the flat gasket into the internal
thread on the tap. Now screw the adapter to the tap, and
then screw the diverter (A) tightly onto the adapter.
D
E
B
A
2B
4. Installation
1017032-00-ELA_OnTap_GA_Asia.indb 4 17.12.18 09:22

ENGLISH 5
!Hand tighten only. Do not use any tools when
attaching the diverter to the tap.
Step 3:
To remove the top cap (H) carefully turn the cap to the
right (see Fig. 3). Insert the supplied battery to the battery
mount. Reinsert the top cap and tighten it.The three lights
in the top cap will blink twice consecutively. The electronic
cartridge change indicator is now ready to go.
H
3
!Always make sure that the BRITA logo on the
housing is facing downwards when connecting it to
the diverter (see Fig. 3 above).
5. Initial operation
Step 1:
The BRITA On Tap water filter system has separate outlets
for filtered and unfiltered water.
Unfiltered water:
If you move the lever (F) to the right (at 3:00 o’clock
position), unfiltered water will come out of the regular
outlet.
F
4
Filtered water:
To get filtered water, move the lever (F) to the left (1/4 turn
towards you until it faces you directly). Filtered water will
come directly out of the filtered outlet.
4. Installation / 5. Initial operation
Step 2 with external thread
Screw the diverter (A) onto the tap. No adapter is
necessary.
A
B
2A
Step 2 with internal thread:
To attach the diverter (A) to an internal thread you will need
to use the flat gasket (D) and adapter (E) which you will find
in the packaging. First insert the flat gasket into the internal
thread on the tap. Now screw the adapter to the tap, and
then screw the diverter (A) tightly onto the adapter.
D
E
B
A
2B
4. Installation
1017032-00-ELA_OnTap_GA_Asia.indb 5 17.12.18 09:22

6 ENGLISH
Green light: The BRITA On Tap water filter is working.
Yellow light: 90% of the filter capacity has been used.
Remember to buy a new replacement
filter cartridge.
Red light: The filter cartridge needs to be changed.
BRITA recommends that you change the filter cartridge
after 1200 litres of water has been filtered. Irrespective of
the filtered volume, the cartridge should be changed after 4
months of use. The red light comes on if the water quantity
or time period has been exceeded.
When the red light in the top cap starts to blink during
filtering the cartridge should be changed. Proceed as
follows:
J
I
B
7
Step 1:
The filter cartridge is attached to the base of the housing
(B). Screw the exhausted filter cartridge (I) to the left.
Unscrew it and pull it downwards and out of the housing.
The housing may still contain water, which will now leak
out. The exhausted filter cartridge can be disposed of with
normal domestic waste.
F
5
The symbols on the diverter are designed to assist you in
selecting the required position:
Filtered water Unfiltered water
To prevent damage to the diverter, choose the required
position before turning on the tap.
Step 2:
If the BRITA On Tap water filter is new, the filter cartridge
may still contain materials residue. This is harmless to
health and does not influence the performance of your
water filter. Run water through the filter for approximately
1 minute before using the water.
Please repeat this process with every new filter cartridge.
The water may briefly become darker in colour until fine
particles are eliminated. You may use this water for your
plants or discard it.
!If the BRITA On Tap water filter system has not been
used for more than 24 hours, allow water to pass for
30 to 60 seconds before using the filtered water
6. Changing the filter cartridge
To ensure optimal performance, one should change the
filter cartridge on a regular basis. The electronic cartridge
change indicator (G) in the top cap (H) tells one when to
change the filter cartridge.
H
G
6
The three lights on the top cap of the OnTap housing are
only activated in the filtering position.They indicate the
following:
6. Changing the filter cartridge
5. Initial operation / 6.Changing the filter cartridge
1017032-00-ELA_OnTap_GA_Asia.indb 6 17.12.18 09:22

ENGLISH 7
Green light: The BRITA On Tap water filter is working.
Yellow light: 90% of the filter capacity has been used.
Remember to buy a new replacement
filter cartridge.
Red light: The filter cartridge needs to be changed.
BRITA recommends that you change the filter cartridge
after 1200 litres of water has been filtered. Irrespective of
the filtered volume, the cartridge should be changed after 4
months of use. The red light comes on if the water quantity
or time period has been exceeded.
When the red light in the top cap starts to blink during
filtering the cartridge should be changed. Proceed as
follows:
J
I
B
7
Step 1:
The filter cartridge is attached to the base of the housing
(B). Screw the exhausted filter cartridge (I) to the left.
Unscrew it and pull it downwards and out of the housing.
The housing may still contain water, which will now leak
out. The exhausted filter cartridge can be disposed of with
normal domestic waste.
!If you have any difficulties unscrewing the cartridge,
please do not use any tools. Use a towel to give you
a firm grip as you unscrew the cartridge this will
prevent your hand from slipping.
Step 2:
Guide the new filter cartridge from below, into the housing
and screw it tight (clockwise). Hand tighten only.
!When inserting the new cartridge, make sure that
the round, black O-ring seal (J) fits evenly inside the
filter cartridge cap (see Fig.7).
Step 3:
The electronic cartridge change indicator in the top cap (H)
has to be reset every time you change the filter cartridge.
To do this, turn the top cap carefully to the right and pull
it upwards and off (see Fig.8 below).To reactivate, push
the button (K), then reinsert the top cap and tighten it. The
three lights will blink twice consecutively. The display has
now been reset.
K
H
8
!If the BRITA On Tap water filter system has not been
used for more than 24 hours, allow water to pass for
30 to 60 seconds before using the filtered water
6. Changing the filter cartridge
To ensure optimal performance, one should change the
filter cartridge on a regular basis. The electronic cartridge
change indicator (G) in the top cap (H) tells one when to
change the filter cartridge.
H
G
6
The three lights on the top cap of the OnTap housing are
only activated in the filtering position.They indicate the
following:
6. Changing the filter cartridge
5. Initial operation / 6.Changing the filter cartridge
1017032-00-ELA_OnTap_GA_Asia.indb 7 17.12.18 09:22

8 ENGLISH
7. Changing the battery
The battery should be changed after approximately a year.
One can tell when the battery is exhausted when one sees
the lights on the top cap do not blink during the filtration
process. When the light no longer blink, the battery needs
to be changed. When this occurs, use the filter cartridge as
usual for the remaining part of the three months and then
insert a new battery.
To replace the battery, proceed as described in section
4. “Installattion/Step 3.” Instead of inserting the supplied
battery as described above, you now have to replace
the battery. Always use a type CR 2032 battery. Please
dispose of the old battery in accordance with the
applicable law and regulations.
8. Removing the housing
The BRITA On Tap water filter system is supplied
preassembled. It is not necessary to unscrew the diverter
(A) and the housing (B) to operate the water filter (see
Fig.2A). If you do wish to unscrew these parts (e.g. for
cleaning purposes), please do so properly without force,
following the instructions below. Please ensure that the
housing is always cleaned without the filter cartridge
inserted.
Step 1:
Detach the OnTap housing (see Fig.9) by first rotating it by
¼ turn towards you until the top cap is facing you and the
BRITA logo is facing down. Secondly, pull it carefully to the
left and out. Discard any water left inside the unit.
1
2
9
Step 2:
To install the housing again (see Fig.10), first guide the
housing carefully to the right and into the diverter. Make
sure that the top cap is facing you and the BRITA logo is
facing down. Secondly, rotate the housing ¼ turn away
from you and upwards. To re-use the filter cartridge, allow
the water to run through for 1 to 2 minutes.
1
2
10
9. BRITA service
In the event of faults, please read the following potential
causes and their remedies. If the problem persists, contact
the authorized distributor for your country.
9.1Troubleshooting
Problem Cause/ Remedy
Problem Cause Remedy
Cannot attach
diverter to the tap.
Determine whether you need an
adapter (see section Installation
— Step 2). If the adapter does
not fit, please contact the official
distributor for your country.
Filtered water drips
out of the water
outlet even when
the tap is turned off.
There is still water under pressure
in the On Tap housing when the
tap is turned off. It is normal for
the filtered water flow to continue
for a few seconds.
Hot water was
accidentally run
through the filter for
a short time.
A small amount of hot water
running through the water filter
will not damage it. However,
make sure you always use cold
water for the filtering process.
Water leaks from
the connection
between the
diverter and the tap.
A) Ensure that you have attached
the diverter to the tap correctly
(do not use any tools!).
B) If the tap has an internal
thread, ensure that the flat
gasket has been fitted right at
the top of the adapter.
Water leaks from
between the
diverter and the On
Tap housing.
Please contact the BRITA service
hotline.
9. BRITA service
7. Changing the battery / 8. Removing the housing
1017032-00-ELA_OnTap_GA_Asia.indb 8 17.12.18 09:22

ENGLISH 9
1
2
9
Step 2:
To install the housing again (see Fig.10), first guide the
housing carefully to the right and into the diverter. Make
sure that the top cap is facing you and the BRITA logo is
facing down. Secondly, rotate the housing ¼ turn away
from you and upwards. To re-use the filter cartridge, allow
the water to run through for 1 to 2 minutes.
1
2
10
9. BRITA service
In the event of faults, please read the following potential
causes and their remedies. If the problem persists, contact
the authorized distributor for your country.
9.1Troubleshooting
Problem Cause/ Remedy
Problem Cause Remedy
Cannot attach
diverter to the tap.
Determine whether you need an
adapter (see section Installation
— Step 2). If the adapter does
not fit, please contact the official
distributor for your country.
Filtered water drips
out of the water
outlet even when
the tap is turned off.
There is still water under pressure
in the On Tap housing when the
tap is turned off. It is normal for
the filtered water flow to continue
for a few seconds.
Hot water was
accidentally run
through the filter for
a short time.
A small amount of hot water
running through the water filter
will not damage it. However,
make sure you always use cold
water for the filtering process.
Water leaks from
the connection
between the
diverter and the tap.
A) Ensure that you have attached
the diverter to the tap correctly
(do not use any tools!).
B) If the tap has an internal
thread, ensure that the flat
gasket has been fitted right at
the top of the adapter.
Water leaks from
between the
diverter and the On
Tap housing.
Please contact the BRITA service
hotline.
Problem Cause Remedy
Water leaks from
the side of the filter
cartridge cap.
A) Ensure that the filter cartridge
cap has been tightened
properly.
B) Check that the “O-ring” seat
inside the filter cartridge cap is
in correct position.
The electronic
cartridge change
indicator lights do
not flash in filtering
position.
A) Ensure that the battery has
been installed correctly.
B) The battery is exhausted.
See section of “Changing the
battery”.
9.2 BRITA quality guarantee:
For over 40 years, BRITA has stood for constant innovation
and the highest quality in the development of water filter
solutions. To justify high quality requirements at BRITA
there are stringent internal and external quality controls.
9.3 BRITA Satisfaction Guarantee
BRITA is convinced that this BRITA product will satisfy
your demands of quality and performance. If you are not
completely satisfied with your BRITA product, BRITA
guarantees to give you your money back within 30 days
from date of purchase. Please call your local customer
service before sending your OnTap water filter System.
On Tap water filter system is warranted to be free from
defects in material and workmanship at the time of
delivery. Any warranty claims will be voided if defective
installation is deemed to have contributed to malfunction.
Illustration needs to take place in accordance with the
instructions and all relevant plumbing codes and standards.
9.4 BRITA Service hotline
Do you have any questions about your BRITA product,
or on the subject of water filtration? Just give us a call!
You can find the contact details for your BRITA customer
service next to your country code on the back page.
9. BRITA service
7. Changing the battery / 8. Removing the housing
1017032-00-ELA_OnTap_GA_Asia.indb 9 17.12.18 09:22

10 ENGLISH
9.5 BRITA on the Internet
Are you looking for your nearest BRITA stockist? Do you
want more detailed information about BRITA products, or
about the BRITA Company? Do you want to benefit from
our many services and offers? Up-to-date information,
consumer trips, seasonal competitions can all be found at
www.brita.net
10. Technical features
Filter cartridge life: Approx. 1200 litres/ 4 months
Working pressure: min. 0.7 bar (70kPa)
max. 3.5 bar (350kPa)
Working temperature: min. 9°C (48°F)
max. 29°C (84°F)
Nominal flow: 2.0 litres/minute at 1.0 bar
(100 kPa)
10. Technical features
1017032-00-ELA_OnTap_GA_Asia.indb 10 17.12.18 09:22
