BROSA Haedus Floor Lamp User manual

ASSEMBLY GUIDE
Haedus Floor Lamp
v1.0

Components
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit www.brosa.com.au/pages/product-return-and-parts-request
and we’ll sort it out right away.
What you need
Hardware
C x 1 (Plastic Washer) F x 1 (Spanner) D x 1 (Washer) E x 1 (Nut)
A x 2 (Bolt) B x 1 (Allen key)
Top
Pole x 1
Bottom
Pole x 1
Socket part x 1
Base x 1 Base weight x 1
1
24
3
5

Safety
1. For indoor use only
2. Follow instructions carefully. Any deviations may be hazardous, or void
your warranty.
3. Damaged power cords must be replaced by a professional.
4. Never use a bulb of a greater wattage than recommended.
5. To replace the bulb, unplug the lamp from its power source and allow it to
6. Periodically check and re-tighten all screws and fasteners.
8. Firmly secure all pieces. Small parts may present a choking hazard.
9. Bulb is not included.
MAX 40W E27
220-240v ~ 50Hz

Step 1
Step 1.1
Step 1.1
Step 1.2
Step 1.1 Align the socket pole (3) with the top pole
(2) so that the bolt hole is overlapping. Secure the
joint using a bolt (A) and the allen key (B). Continue
with the bottom pole (2) so that the bolt hole is over-
lapping and secure the joint using a bolt (A) and the
allen key (B).
Attach the formed part to the base parts (5)(6). Fit a
plastic washer (C), a washer (D) then a hex nut (E) to
the bolt and tighten with the spanner (F).
1
2
A
B
A
B
4
3
5
C
D
EF
A x 2
B x 1
C x 1
D x 1
E x 1
F x 1

Step 2 Gently screw the correct bulb (not included) into
the bulb socket. Gently pull the shade to change the
light direction.

Step 3 Check if all parts are secure.
Enjoy! We hope your new lamp lights up your life.
