BullFrog 1047 AKITO User guide

ASSEMBLY AND INSTRUCTION MANUAL
29.11.2021
MODEL 1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
www.bullfrog-design.com
Functional back and armrests
are completely foldable
...up to a comfortable relax lounger Due to lateral seat adjustment arises
a useful clipboard

1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
Use of back- and armrest function
Akito does not need connectors to build a corner group.
Sitting
1. Adjustment of back slant:
To adjust the desired position grip the back from the outside and pull it carefully into your direction.
3. From zero position you can easily snap the back into desired position.
2. To obtain zero position pull the back carefully beyond the top position into your direction and fold down into
zero position.
ATTENTION!
DON`T SIT DOWN ON BACK OR ARMREST EXCEPT THEY ARE AT LOWEST POSITION.
To adjust armrest, proceed the same way.

1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
1. Connect cable A (fixed at seat element) to provided transormer and plug it into socket.
2. Press button B and C at remote control to move seat continuously to the right or to the left.
TRANSFORMER
A
Power supply
ATTENTION!
TRANSFORMER HAS TO
BE SITUATED OUTSIDE
OF THE SOFA!
At types with manual adjusment, the seat cushion can be moved manually back
and forth in the direction of the arrow .
TRANSFORMER
A
Power supply
To avoid traces of usage at cover material, seat should (as possible) only be adjusted
when back and armrest are folded up (like fig. above).
Lying position
Relax position
ATTENTION!
TRANSFORMER HAS TO
BE SITUATED OUTSIDE
OF THE SOFA!
Motorised seat adjustment
C
B

1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
Delivery condition: already synchronised November 2021
B
C
A
1. Press pairing buttons Aat receiver 2 x until the LED
indicates. The pairing process is active for about 10 seconds.
2. Press simultaneous button B and C at the transmitter
until the green LED at the receiver vanishes.
This confirmes a successful pairing process.
Note:
For the pairing prozess the distance between transmitter
and receiver should be less than 2 metres.
Motorised seat adjustment - Programming of transmitter and receiver
The programming is completed, the transmitter is now ready for operation. If the motor doesn´t start while pressing,
release the button and press again. If necessary retry the process.
Transmitter
Brief instruction, Pairing-Method:
Should a new start-up of remote control be necessary the wireless communication with the
control/motor must be established. Proceed as follows:
Receiver
LED
Put drive systems into operation successively, don`t operate several systems simultaneous. Otherwise the
remote control cannot be assigned clearly by control/motor.

1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
Technical data – for elements with motor-driven seat adjustment
Electrical connection
To be connected to common household alternating current (AC) with an input voltage of up to 240 V.
To ensure a non-hazardous operation, the alternating current from the socket is converted in „low-voltage current“
(direct current, DC) by means of an integrated rectifier and an output voltage of 24 V is output. The main
adapter respectively the charging unit also features a protective circuit which prevents malfunctions
due to surge voltages and damages to the unit.
Safety notes
The construction of the piece of furniture as well as the used materials ensure that it may be used without
causing risks to the user when used as intended and in compliance with the present operating instructions.
All service, maintenance and repair operations shall only be carried out and documented by authorized
persons. If it is necessary to disassemble individual safety devices during e.g. service or repair operations,
then it is required to perform the re-establishment and examination of the effectiveness of all safety
devices immediately upon completion of the operations.
Note: The warranty claim will be invalidated if the device is connected incorrectly. Please also pay
attention to a proper routing of the mains cable. The drive system is designed for alternating voltage.
Technical data – for all elements with seat adjustment
Caution: It is prohibited to put safety devices and/or guards out of operation respectively
to remove them! The motor cover must not be removed! The piece of furniture is not suitable
for operation in wet rooms!
Use accumulator only in dry rooms!
Do not dispose of the accumulator in the domestic waste!
Motors www.lusch.de
Device type ON 20-xx
Mains connection (VAC) 100 - 240 V AC
Motor voltage 24 V DC
Protection type IP 20
Continuous operation / pause cycles 2 min. / 18 min.
Accumulator www.limoss.de
Device type MC 160
Accumulator capacity approx. 50 Cycles / ø 21 days
Charging of the accumulator by means of separate charging adapter
Life cycle 80% capacity after 300 charging cycles
(depending on use and environment)

1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
Technical data – for all elements with seat adjustment
Notes: Before first operation, please charge the accumulator completely (8 hours).
The charging and adjusting is possible at the same time. Recharge the accumulator
after 3 months at the latest because otherwise the capacity will suffer. As soon
as the critical accumulator capacity is reached, an acoustic alarm signal will
sound when the function is activated. Immediately charge the accumulator.
The optimal performance of the accumulator is only ensured at normal room
temperature (20° to 30° C).
Accumulators, batteries, electric motors, manual switches etc. belong to the wear
and tear parts of a model. They are subject to a continuous loss of performance
that differs depending on the intensity of the use (or application respectively purpose).
Their lifetime is therefore limited by their very nature. This is part of the normal wear
and tear of the parts and does not constitute any valid cause for complaint.
If, however, a complaint is occurs within the first six months after purchase, it is
assumed that a material defect existed already at the beginning. In such cases,
we will replace the respective wear and/or tear part.
For wear and tear parts, we herewith provide all pieces of information, among
other things regarding charging, connection, operation or storage in order to ensure
a proper use. Please understand that failure to follow the instructions and incorrect
handling will make claims under warranty null and void for those parts.

---------------------------------
---------------------------------
Bullfrog
Marketing & Design GmbH
Landwehrstr. 32
96247 Michelau
Germany
It is certified herewith, that the above-mentioned products correspond to the
mentioned EC guidelines
Michelau, November 2014
Jan Beier, director of Bullfrog Marketing & Design GmbH
declares for the following programme:
1047 Akito, types with motor-driven adjustment
the compliance and the equivalent with the EC guidelines:
EC machinery directive 2006/42/EG
EC low-voltage directive 2006/95/EG
other used standards EN 60335-1
EN 55014-1
EN 55014-2 Kat II
EN 61000-3-2/-3-3
Authorized representative of documents: Jan Beier
Landwehrstr. 32
96247 Michelau
Germany
Bullfrog Marketing and Design GmbH - County court Coburg HRB 2401 Director: Jan Beier - UST.-IdNr.: DE 173833663
EU – declaration of conformity
for all elements with motor-driven adjustment

1047 AKITO
© 2014 K URT BEI E R &KATI QU I N G E R
seam
zipper
FUNKI - how it works!
3. Now you are able to move the upper
part backwards until the upper part of
the cushion will click into place in the
zero position.
1. Take the cushion at its upper side
and put the cushion on your knees
with the zipper on the bottom. The
seamless side faces you.
2. Move the upper part of the cushion
towards yourself until the final position
is reached.
4. Now put the cushion in the preferred
position (e.g. in the back, seamless side
in front and zipper at the bottom).
By pulling the upper part of the chushion
towards yourself, you are now able
to choose among 16 raster positions,
however you like it.
