BullFrog OD0319 TAO User guide

Functional back cushions
ensure individual sitting comfort
Practical stools or armrest cushions
ASSEMBLY AND INSTRUCTION MANUAL
www.bullfrog-design.com
MODEL OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R
360°
360° rotational function
For general informations please refer to the information about outdoor furniture!
Bullfrog recommends the suitable waterproofed protective covers for outdoor furnitures.

OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R
Side view with back
cushion (type 611)
Front view (type 23TF) = Label
112
41
174
15
= Pivot
234
54
68,5
1.
2.
112
174
60
174
234
60
360°
Each piece of furniture is handmade and unique. Deviations to the listed measurements may be caused by:
1. different upholstery materials (fabric, leather), 2. processing of ticking mats, 3. the preasure to combine individual parts, etc.
The seat comfort of a sofa type with larger seat depth usually differs from one with lower depth.
Attention! Element 23TF can be used for both sides (left element/right element).
The pivot signs the direction left/right!
The side of the pivot is marked at plateau!
Seat element with 360° turn and sliding function:
Sofa 2-seat,deep,
360° turn function
and sliding function
23TF
Attention! If a functional element 23TF stands separately or isn`t connected
with another element, it can tip-over if it is not in a centre position as shown
beside. Therefore always shift the upholstery back to the centre position!
Position
centrig!
To avoid tip-over with a single element,
push upholstery centric
Functional bracket,
exterior coating
606
Optionally back-/armrest bracket
at type 23TF:
Attention! Consistent with functional
bracket: back-/floor cushion 585
Max. height of back with bracket:
With cushion: approx. 93 cm/
bracket: approx. 66 cm
2. Rotate upholstery
by 90° on the plateau,
and push into desired
position. Then lift up
functional bracket and
place cushion 585.
Attention! Bracket extends laterally by approx. 1,5 cm.
Use of functional bracket:
1. Push upholstery to the
most left position!
Now it it possibel to lift
up functional bracket!

1. Place the enclosed parts in front of you.
2. Position the elements at the place supposed to stay and place the upholstery
upside down on the floor. To avoid damages at the furniture or at the floor use a
suitable support.
3. Screw in the enclosed grub screws (a) into the 4 threads (d).
a
d d
d d
a
a a
ATTENTION! To ensure secure assembly, please observe the individual steps of instruction!
It is necessary that the furniture always be mounted in pairs (2 persons)!
Assembly of type 23T:
4 x grub screw (a)
4 x washer (b)
4 x nut (c)
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

a
e
ee
e
a
aa
4. Apply the plateau with its 4 bores (e) onto the 4 grub screws (a).
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

5. Plug washers (b) onto grub screws (a) and tightem them with a nut (c).
Seat cushion
Plateau
Grub screw
Washer
Nut
c
b
a
6. Mount the connectors! See page 9, 10 and 11, mounting of connectors!
7. Tilt mounted sofa forward onto its feet.
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

1. Unscrew bolt with enclosed allen key from cone and place bolt, large washer and
small washer in front of you.
2. Position the elements at the place supposed to stay and place the upholstery
upside down on the floor. To avoid damages at the furniture or at the floor use a
suitable support.
3. Lift plateau above the seat cushion.
Assembly of type 23TF:
ATTENTION! To ensure secure assembly, please observe the individual steps of instruction!
It is necessary that the furniture always be mounted in pairs (2 persons)!
1 x bolt
1 x washer,
large
1 x washer,
small
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

4. Position the bearing bush (a) of plateau above cone (b) of seat cushion.
b
a
5. Plug bearing bush (a) of plateau onto cone (b) of seat cushion.
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

8. After assembly of connectors: tilt mounted sofa forward onto its feet. Pay
attention to plateau and seat cushion, it may move unintentional due to rotary
and sliding system.
7. Mount the connectors! See page 9, 10 and 11, mounting of connectors!
Inside:
plug onto
cone
Outside:
closed surface
6.
1) Place the large washer onto cone.
2) Place the small washer on large washer and tighten it with enclosed screw.
Turning heaviness is adjustable by contact pressure of screw.
Information
Information
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

Mounting of connectors:
Possible connector points:
23T
23TF
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

Mounting of connectors:
B
2
2
1
1
A
Connector
1
1
2
2
Connector
Hand screw
Hand screw
1. Screw connectors (1) of element (A) with the hand screws (2) into threaded sockets and
tighten hand screws (2).
Place the enclosed parts in front of you.
2
1
1
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

B
2
2
2
2
B
A
A
2. Screw hand screws (2) slightly into element (B), so that hand screws do not drop of.
3. Firmly push together (A) and (B) so the threaded bar of hand screw (2) will slide into the slot of
connector (1) of element (B).
1
2
Connector
Hand screw
4. Tighten hand screws (2).
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

Use of functional bracket:
Adjustment of functional bracket:
1. Pull the functional bracket into desired position.
ATTENTION! DON`T SIT ON FUNCTIONAL BRACKET!
3. From zero position you can easily snap the armrest into desired position.
2. To obtain zero position pull the functional bracket carefully beyond the top position (a) and fold
down into zero position (b).
ab
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

If necessary the functional bracket can be pulled out of the Plateau. Proceed as follows:
1. Slightly lift up functional bracket.
2.Grasp the bracket with both hands (a) and pull it with a powerful jolt horizontal (b) out of
the plateau!
a
bbb
c
c
Attention! Functional bracket 606 is subsequently mountable with type 23TF.
Therefore needed parts can be ordered separately!
1. Put the functional fitting into a horizontal position (c).
2. Push the seat upholstery in a positon so that the slots for functional fittings are visible.
How to plug the bracket in again:
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

d
4. Place the functional fittings straight at the provided slots (d).
Fasten it with a powerful jolt in forward direction.
d
Fixed bracket!
Fitting
Bracket
Slots
3. Position the functional fittings horizontal between the wooden planks.
OD0319 TAO
© 2019 K URT BEI E R &KATI QU I N G E R

Use of back function
Adjustment of back slant:
1. To adjust the desired position grip the back
from the outside and pull it carefully towards
yourself.
2. To obtain zero position pull the back carefully
beyond the top position towards yourself and fold
down into zero position (horizontal).
3. From zero position you can easily snap the back into desired position.
