Burkert 2064 User manual

Quickstart
English Deutsch Français
Type 2063, 2064, 2065
Piston-controlled diaphragm valve
Kolbengesteuertes Membranventil
Vanne à membrane commandée par piston

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modications techniques.
© Bürkert Werke GmbH & Co. KG, 2016 - 2018
Operating Instructions 1808/02_EU-ML_ 00810478/ Original DE

1 QUICKSTART
The quickstart contains the most important information and notes
regarding the use of the device. Keep the quickstart in a location
which is easily accessible to every user, and make these instruc-
tions available to every new owner of the device.
Important Safety Information.
Failure to observe these instructions may result in hazardous
situations.
▶Quickstart must be read and understood.
A detailed description of the device can be found in the operating
instructions for Type 2063, 2064 and 2065.
The operating instructions can be found on the Internet
at: www.burkert.com
1.1 Denition of term
The term “device” used in these instructions always stands for
the diaphragm valve Type 2063, 2064 and 2065.
Contents
1 QUICKSTART ........................................................................ 3
2 AUTHORIZED USE ............................................................... 4
3 BASIC SAFETY INSTRUCTIONS.......................................... 5
4 GENERAL INFORMATION .................................................... 6
5 STRUCTURE AND FUNCTION ............................................. 7
6 TECHNICAL DATA................................................................. 8
7 INSTALLATION .................................................................... 10
8 REMOVAL............................................................................ 15
9 MAINTENANCE WORK....................................................... 15
10 TRANSPORT, STORAGE, REMOVAL ................................. 16
3
Quickstart
english
Type 2063, 2064, 2065

1.2 Symbols
DANGER!
Warns of an immediate danger.
▶Failure to observe the warning may result in a fatal or serious
injury.
WARNING!
Warns of a potentially dangerous situation.
▶Failure to observe the warning may result in serious injuries
or death.
CAUTION!
Warns of a possible danger.
▶Failure to observe this warning may result in a moderate or
minor injury.
NOTE!
Warns of damage to property.
Important tips and recommendations.
Refers to information in these operating instructions or in
other documentation.
▶designates an instruction to prevent risks.
→designates a procedure which you must carry out.
2 AUTHORIZED USE
Non-authorized use of the diaphragm valve Type 2063, 2064
and 2065 may be a hazard to people, nearby equipment and
the environment.
▶The device is designed for the controlled ow of liquid
media.
▶In areas at risk of explosion, only use devices approved for use in
those areas. These devices are labeled with a separate Ex type
label. When utilized in a potentially explosive atmosphere, always
pay attention to the details on the separate Ex type label and
the Ex additional instructions contained in the scope of delivery.
▶During use observe the authorized data, the operating
conditions and conditions of use specied in the contract
documents and operating instructions.
▶The device may be used only in conjunction with third-party
devices and components recommended and authorized by
Bürkert.
▶Protect device from damaging environmental inuences
(e.g. radiation, humidity, steam, etc.). If anything is unclear,
consult the relevant sales oce.
▶Correct transportation, correct storage and installation and
careful use and maintenance are essential for reliable and
faultless operation.
▶The exhaust air may be contaminated with lubricants in the
actuator.
▶Use the device only as intended.
4
Authorized use
english
Type 2063, 2064, 2065

3 BASIC SAFETY INSTRUCTIONS
These safety instructions do not make allowance for any
•contingencies and events which may arise during the installation,
operation and maintenance of the devices.
•local safety regulations, whereby the operator is responsible for
their compliance, by the installation personnel too.
Danger – high pressure.
▶Before loosening the lines and valves, turn o the pressure
and vent the lines.
Danger of bursting from overpressure.
▶Observe the specications on the type label for maximal
control and medium pressure.
▶Observe permitted medium temperature.
Risk of injury from electric shock (when electrical component
installed).
▶Before reaching into the device or the equipment, switch o
the power supply and secure to prevent reactivation!
Observe applicable accident prevention and safety regulations
for electrical equipment!
Risk of injury when opening the actuator!
The actuator contains a tensioned spring. If the actuator is
opened, there is a risk of injury from the spring jumping out!
▶Do not open the actuator.
Risk of injury from moving parts in the device!
▶Do not reach into openings.
Risk of burns and risk of re if used continuously through hot
device surface.
▶Keep the device away from highly ammable substances and
media and do not touch with bare hands.
Danger due to loud noises.
▶Depending on the operating conditions, the device may gener-
ate loud noises. More detailed information on the likelihood of
loud noises is available from the relevant sales oce.
▶Wear hearing protection when in the vicinity of the device.
Leaking medium when the diaphragm is worn.
▶Regularly check relief bore for leaking medium.
▶If medium is leaking out of the relief bore, change the
diaphragm.
▶If the media is hazardous, protect the area surrounding the
discharge point against dangers.
5
Basic safety instructions
english
Type 2063, 2064, 2065

General hazardous situations.
To prevent injury, ensure:
▶That the system cannot be activated unintentionally.
▶Installation and repair work may be carried out by authorized
technicians only and with the appropriate tools.
▶After an interruption in the power supply or pneumatic
supply, ensure that the process is restarted in a dened or
controlled manner.
▶The device may be operated only when in perfect condition
and in consideration of the operating instructions.
▶Observe the safety regulations specic to the plant for appli-
cation planning and operation of the device.
▶The plant operator is responsible for the safe operation and
handling of the plant.
▶The general rules of technology apply to application planning
and operation of the device.
To prevent damage to property of the device, ensure:
▶Supply the media connections only with those media which
are specied as ow media in the chapter entitled “6 Technical
data”.
▶Do not put any loads on the valve (e.g. by placing objects on
it or standing on it).
▶Do not make any external modications to the valves. Do not
paint the body parts or screws.
▶Do not transport, install or remove heavy devices without the
aid of a second person and using suitable auxiliary equipment.
4 GENERAL INFORMATION
4.1 Contact address
Germany
Bürkert Fluid Control Systems
Sales Center
Chr.-Bürkert-Str. 13-17
D-74653 Ingelngen
Tel. : 07940 - 10 91 111
Fax: 07940 - 10 91 448
E-mail: [email protected]
International
Contact addresses are found on the nal pages of the printed
operating manual.
Information on the Internet under: www.burkert.com
4.2 Warranty
The warranty is only valid if the device is used as authorized in
accordance with the specied application conditions.
4.3 Information on the Internet
The operating instructions and data sheets for 2063, 2064 and 2065
can be found on the Internet at: www.burkert.com
6
General information
english
Type 2063, 2064, 2065

5 STRUCTURE AND FUNCTION
5.1 Structure
The piston-controlled diaphragm valve consists of a pneumati-
cally operated piston actuator and a 2/2-way valve body.
The actuator is manufactured from stainless steel.
5.1.1 2/2-way valve Type 2063
Actuator
Line connection
Valve body
Pilot air port 1 CFA and CFI /
Air discharge connection CFB
Pilot air port 2 CFB and CFI /
Air discharge connection CFA
Transparent cap with
position indicator
Diaphragm socket
Fig. 1: Piston-controlled diaphragm valve, structure and description
5.1.2 T-valve Type 2064
Actuator
Line connection
T-valve body
Pilot air port 1 CFA and CFI /
Air discharge connection CFB
Pilot air port 2 CFB and CFI /
Air discharge connection CFA
Transparent cap with
position indicator
Diaphragm socket
Fig. 2: T-valve Type 2064, structure and description
5.1.3 Tank bottom valve Type 2065
Actuator
Line connection
Pilot air port 1 CFA and CFI /
Air discharge connection CFB
Pilot air port 2 CFB and CFI /
Air discharge connection CFA
Transparent cap with position indicator
Tank bottom valve with
welding ange
VA diaphragm socket
Fig. 3: Tank bottom valve Type 2065, structure and description
7
Structure and function
english
Type 2063, 2064, 2065

5.2 Function
Spring force (CFA) or pneumatic pilot pressure (CFB and CFI) gen-
erates the closing force on the diaphragm pressure piece. The force
is transferred via a spindle which is connected to the actuator piston.
5.2.1 Control functions (CF)
WARNING!
For control function I: Danger if pilot pressure fails.
For control function I (CFI) control and resetting occur pneumati-
cally. If the pressure fails, no dened position is reached.
▶To ensure a controlled restart, rst pressurize the device with
pilot pressure, then switch on the medium.
A
P
A
Closed by spring force in rest position
B
P
A
Opened by spring force in rest
position
I
P
A
Actuating function via reciprocal
pressurization
6 TECHNICAL DATA
6.1 Conformity
Type 2063, 2064 and 2065 conforms with the EU Directives
according to the EU Declaration of Conformity (if applicable).
6.2 Standards
The applied standards (if applicable), which verify conformity
with the EU Directives, can be found on the EU-Type Examination
Certicate and / or the EU Declaration of Conformity.
6.3 Labeling of the forged body
XXXXXXXXXX
XX F
1.4435/316L(VS)
PN16/CWP150
XXXXXXXX/XXX
XXXXXX
XXXX
Surface quality code
Customer-specic text
(optional)
Orice connection and
pipe dimension
Batch number
Material
Production number /
serial number
Nominal pressure
Fig. 4: Labeling of the forged body
8
Technical data
english
Type 2063, 2064, 2065

6.4 Labeling of the tube valve body
1.4435
316L(VP)
XXXXXXXX
XXXXXXXXXX
PN16 / CWP150
XXXXXXXX / XXX
XXXX / XXXXXX
Material HeatCompany logo
Nominal
pressure
Connection orice
and pipe dimensions
Surface quality code /
Customer-specic text
(optional)
Production number /
serial number
Fig. 5: Labeling of the tube valve body
6.5 Type label
WARNING!
Risk of injury from high pressure.
Excessive pressure can damage the device.
▶Comply with pressure range values on the type label.
Made in Germany
00999999
W28UU
Pilot 5.0-10bar
D33.7 Pmed 6bar
2063 A 25,0 PTFE VS
Orice
Seal material
Body material
Control function (SF)
Type
Permitted medium pressure
Identication number of the device,
Date of manufacture
CE identication (if applicable)
Port connection,
Permitted medium pressure
Fig. 6: Description of the type label (Example)
9
Technical data
english
Type 2063, 2064, 2065

6.6 General technical data
Media
Control medium neutral gases, air
Flow media liquids; ultrapure, sterile, dirty,
aggressive or abrasive media
Installation position
Type 2063, 2064 at will, preferably actuator in upright
position
Type 2065 preferably with the actuator to the
bottom
(tank bottom valve)
7 INSTALLATION
DANGER!
Danger - high pressure.
▶Before dismounting the lines and valves, turn o the pressure
and vent the lines.
WARNING!
Risk of injury from improper installation.
▶Installation may only be performed by qualied and trained
personnel.
▶Use an open-end wrench for the assembly.
▶Following assembly, perform a controlled restart.
For control function I – Danger if pilot pressure fails.
For control function I control and resetting occur pneumatically.
If the pressure fails, no dened position is reached.
▶To ensure a controlled restart, rst pressurize the device with
pilot pressure, then switch on the medium.
CAUTION!
Risk of injury due heavy devices!
▶During transport or during assembly, a heavy device may fall
and cause injury.
▶Do not transport, install or remove heavy devices without the
aid of a second person and using suitable auxiliary equipment.
▶Use appropriate tools.
10
Installation
english
Type 2063, 2064, 2065

7.1 Installation position
Installation for self-drainage of the body
It is the responsibility of the installer and operator to
ensure self-drainage.
Installation for leakage detection
One of the bores in the diaphragm socket for monitoring
leakage must be at the lowest point.
7.1.1 Installation position Type 2063
Installation position: at will, preferably with the actuator upright.
To ensure self-drainage:
→Install body inclined by an angle α= 10° to 40° to the hori-
zontal.
Forged and cast body: Mark on the body must point upwards
(12 o’clock position, see “Fig. 7”).
→Observe an inclination angle of 1° to 5° to the line axis.
Angle α: 10° to 40°
Inclination to the line axis 1° to 5°
Mark
α
Fig. 7: Installation position for self-drainage of the body
7.1.2 Installation position Type 2064
For the installation of the T-valves into circular pipelines, we rec-
ommend the following installation positions:
When media is supplied: When media is removed:
Fig. 8: Installation position type 2064
7.1.3 Installation position Type 2065
Preferably with the actuator to the bottom.
7.2 Before installation
•Before connecting the valve, ensure the pipelines are ush.
•The ow direction is optional.
7.2.1 Preparatory work
→Clean pipelines (sealing material, swarf, etc.).
→Support and align pipelines.
11
Installation
english
Type 2063, 2064, 2065

Devices with VG/VS/VP welded body
NOTICE!
Damage to the diaphragm or the actuator.
▶Before welding in the body, remove the actuator
7.3 Remove the actuator from the valve
body
NOTE!
Damage to the diaphragm or the seat contour.
▶When removing the actuator, ensure that the valve is open.
→Control function A pressurize the pilot air port 1 with compressed
air: valve opens.
→Remove actuator with diaphragm by loosening the body
screws.
Pilot air port 2 CFB and CFI /
Air discharge connection CFA
Pilot air port 1 CFA and CFI /
Air discharge connection CFB
1
2
Fig. 9: Pneumatic connection
7.4 Installation of the valve body
WARNING!
Risk of injury from improper installation.
▶Installation may only be performed by qualified and trained
personnel.
▶For installation use an open-end wrench.
▶Observe the tightening torque.
7.4.1 Installation 2-way body and T-valve body
Welded bodies
→Weld valve body in pipeline system.
Other bodies
→Connect body to pipeline.
7.4.2 Welding tank bottom body type 2065
Observe sequence:
1. Weld the tank bottom body onto the base of the tank
before installing the tank.
Welding onto a tank which has already been installed is
possible but more dicult.
Weld the tank bottom body in the middle of the tank
base so that the tank can be optimally drained.
2. Weld valve body into the pipeline.
12
Installation
english
Type 2063, 2064, 2065

Installation requirements:
Pipelines: Ensure that the pipelines are aligned.
Preparation: Support and align pipelines. To ensure that the
pipeline is self-draining, observe an inclination angle
of 1° – 5°.
DANGER!
Risk of injury from high pressure!
▶Before working on the system, switch o the pressure and
vent or drain lines.
For information on tanks and instructions on welding
observe the standard ASME VIII Division I.
Before you start welding, check the batch number indi-
cated on the supplied manufacturer’s certicate 3.1 .
Observe the applicable laws and regulations of the
respective country with regard to the qualication of
welders and the execution of welding work.
1. Welding tank bottom body onto the tank:
ATTENTION!
Before welding, note the following:
▶Use only welding material which is suitable for the tank
bottom body.
▶The tank bottom valve must not collide with any other instal-
lation part. The actuator must be easy to install and remove.
2. Welding tank bottom body into the pipeline:
→Weld in tank bottom body.
Ensure installation is de-energized and low-vibration.
After welding in the valve body:
Install the diaphragm and the actuator.
7.5 Installation of the actuator (welded
body)
NOTE!
Damage to the diaphragm or the seat contour.
▶When installing the actuator, ensure that the valve is open.
Installation for actuator with control function A:
→Pressurize the pilot air port 1 with compressed air: valve
opens.
→Lightly cross-tighten the body screws until the diaphragm is
between the valve body and actuator.
Do not tighten the screws yet.
→Actuate the diaphragm valve twice.
→Tighten body screws without pressurization in diagonal pairs in
three stages (approx. 1/3, approx. 2/3, 3/3 of the tightening torque),
according to Table ( see “Tab. 1”). The diaphragm should be
positioned and pressed evenly all around the actuator and body.
13
Installation
english
Type 2063, 2064, 2065

Installation for actuator with control functions B and I:
→Lightly cross-tighten the body screws without pressurization
until the diaphragm is between the valve body and actuator.
Do not tighten the screws yet.
→Actuate the diaphragm valve twice.
→Tighten body screws with pressurization in diagonal pairs in three
stages (approx. 1/3, approx. 2/3, 3/3 of the tightening torque),
according to Table ( see “Tab. 1”). The diaphragm should be
positioned and pressed evenly all around the actuator and body.
Orice DN
(diaphragm size)
Tightening torques for diaphragms [Nm]
EPDM/FKM PTFE/
advanced PTFE/
laminated PTFE
15 3.5 4
20 4 4.5
25 5 6
32 8 10
40 8 10
50 12 15
Tab. 1: Tightening torques for installation of the actuator
→A tolerance of +10% of the respective tightening torque
applies to all values.
7.6 Pneumatic connection
WARNING!
Risk of injury from unsuitable connection hoses.
▶Use only hoses which are authorized for the indicated pressure
and temperature range.
▶Observe the data sheet specifications from the hose
manufacturers.
For control function I: Danger if pilot pressure fails.
For control function I control and resetting occur pneumatically.
If the pressure fails, no dened position is reached.
▶To ensure a controlled restart, rst pressurize the device with
pilot pressure, then switch on the medium.
7.6.1 Connection of the control medium
Control functions A and B
→Connect the control medium to the pilot air port 1 of the
actuator
(see “Fig. 10: Pneumatic connection”).
Control function I
→Connect the control medium to the pilot air port 1 and 2 of
the actuator (see “Fig. 10: Pneumatic connection”)
Pressure on connection 1 opens the valve.
Pressure on connection 2 closes the valve.
If used in an aggressive environment, we recommend
conveying all free pneumatic connections into a neutral
atmosphere with the aid of a pneumatic hose.
14
Installation
english
Type 2063, 2064, 2065

Pilot air port 2 CFB and CFI /
Air discharge connection CFA
Pilot air port 1 CFA and CFI /
Air discharge connection CFB
1
2
Fig. 10: Pneumatic connection
8 REMOVAL
DANGER!
Risk of injury from discharge of medium and pressure.
It is dangerous to remove a device which is under pressure due
to the sudden release of pressure or discharge of medium.
▶Before removing a device, switch o the pressure and vent
the lines.
→Loosen the pneumatic connection.
→Remove the device.
9 MAINTENANCE WORK
9.1 Actuator
The actuator of the diaphragm valve is maintenance-free pro-
vided it is used according to these operating instructions.
9.2 Wearing parts of the diaphragm valve
Parts which are subject to natural wear:
•Seals
•Diaphragm
→If leaks occur, replace the particular wearing part with an
appropriate spare part.
A bulging PTFE diaphragm may reduce the ow.
9.3 Inspection intervals
The following maintenance work is required for the diaphragm valve:
→After the rst steam sterilization or when required retighten
body screws crosswise.
→After maximum 105switching cycles check the diaphragm for
wear and replace if required.
Muddy and abrasive media require correspondingly
shorter inspection intervals!
15
Maintenance work
english
Type 2063, 2064, 2065

9.4 Cleaning
Commercially available cleaning agents can be used to clean the
outside.
NOTE!
Avoid causing damage with cleaning agents.
▶Before cleaning, check that the cleaning agents are compat-
ible with the body materials and seals.
10 TRANSPORT, STORAGE, REMOVAL
NOTE!
Transport damages.
Inadequately protected equipment may be damaged during
transport.
•During transportation protect the device against wet and dirt
in shock-resistant packaging.
•Avoid exceeding or dropping below the permitted storage
temperature.
Incorrect storage may damage the device.
•Store the device in a dry and dust-free location.
•Storage temperature -20...+65 °C.
Damage to the environment caused by device components
contaminated with media.
•Dispose of the device and packaging in an environmentally
friendly manner.
•Observe applicable regulations on disposal and the
environment.
16
Transport, storage, removal
english
Type 2063, 2064, 2065

www.burkert.com
