Burkert 2300 Series User manual

Quickstart
English
Type 2300
2/2-way angle-seat control valve

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© Bürkert Werke GmbH & Co. KG, 2013 - 2018
Operating Instructions 1802/03_EU-EN_00810317 / Original DE

3
Quickstart
1 QUICKSTART ........................................................................ 3
2 SYMBOLS ............................................................................. 4
3 INTENDED USE .................................................................... 4
4 BASIC SAFETY INSTRUCTIONS.......................................... 5
5 GENERAL INFORMATION .................................................... 6
6 STRUCTURE AND FUNCTION ............................................. 7
7 TECHNICAL DATA................................................................. 8
8 INSTALLATION .................................................................... 10
9 PACKAGING, TRANSPORT, STORAGE ............................. 17
Typ 2300
1 QUICKSTART
The operating instructions describe the entire life cycle of the device.
Keep these instructions in a location which is easily accessible
to every user and make these instructions available to every new
owner of the device.
Important Safety Information!
Read Quickstart carefully and thoroughly. Study in particular
the chapters entitled “Basic Safety Instructions” and “Intended
use”.
▶Quickstart must be read and understood.
Quickstart explains, for example, how to install and start-up the
device.
A detailed description of the device can be found in the oper-
ating instructions for Type 2300.
The operating instructions can be found on the Internet at:
www.burkert.com
1.1 Denition of term / abbreviation
In these instructions, the term “device” always refers to the
angle-seat control valve type 2300.
The abbreviation “Ex” used in these instructions always stands
for “explosion-protected”.
english

4
Symbols
Typ 2300
2 SYMBOLS
DANGER!
Warns of an immediate danger!
▶Failure to observe the warning may result in a fatal or serious
injury.
WARNING!
Warns of a potentially dangerous situation!
▶Failure to observe the warning may result in serious injuries or
death.
CAUTION!
Warns of a possible danger!
▶Failure to observe this warning may result in a moderately
severe or minor injury.
NOTE!
Warns of material damage!
Important tips and recommendations.
Refers to information in these operating instructions or in
other documentation.
▶designates instructions for risk prevention.
→designates a procedure which you must carry out.
3 INTENDED USE
Non-authorized use of the globe valve Type 2106 may be a
hazard to people, nearby equipment and the environment.
▶The device is designed for the controlled ow of liquid and
gaseous media.
▶In the potentially explosion-risk area the globe valve type
2106 may be used only according to the specication on
the separate Ex type label. For use observe the additional
information enclosed with the device together with safety
instructions for the explosion-risk area.
▶Devices without a separate Ex type label may not be used in
a potentially explosive area.
▶The admissible data, the operating conditions and condi-
tions of use specied in the contract documents, operating
instructions and on the type label are to be observed during
use. These are described in the chapter entitled “7 Technical
data”.
▶Protect device from damaging environmental inuences (e.g.
radiation, humidity, steam, etc.). If anything is unclear, consult
the relevant sales oce.
▶The device may be used only in conjunction with third-party
devices and components recommended and authorized by
Bürkert.
▶Correct transportation, correct storage and installation and
careful use and maintenance are essential for reliable and
faultless operation.
english

5
Basic Safety Instructions
Typ 2300
4 BASIC SAFETY INSTRUCTIONS
These safety instructions do not make allowance for any
•contingencies and events which may arise during the installation,
operation and maintenance of the devices.
•local safety regulations; the operator is responsible for observing
these regulations, also with reference to the installation personnel.
DANGER!
Risk of injury from high pressure in the equipment or device!
▶Before working on equipment or device, switch o the pres-
sure and deaerate or drain lines.
Risk of injury from electric shock (when electrical component
installed).
▶Before reaching into the device, switch o the power supply
and secure to prevent reactivation!
▶Observe applicable accident prevention and safety regulati-
ons for electrical equipment!
WARNING!
Risk of injury when opening the actuator!
The actuator contains a tensioned spring. If the actuator is
opened, there is a risk of injury from the spring jumping out!
▶The actuator must not be opened.
Risk of injury from moving parts in the device!
▶Do not reach into openings.
Danger due to loud noises.
▶Depending on the operating conditions, the device may generate
loud noises. More detailed information on the likelihood of loud
noises is available from the relevant sales oce.
▶Wear hearing protection when in the vicinity of the device.
CAUTION!
Risk of burns!
The surface of the device may become hot during long-term
operation.
▶Do not touch the device with bare hands.
Leaking medium when the packing gland is worn.
▶Regularly check relief bore for leaking medium.
▶If the media is hazardous, protect the area surrounding the dis-
charge point against dangers.
General hazardous situations.
To prevent injury, ensure:
▶That the system cannot be activated unintentionally.
▶Installation and repair work may be carried out by authorized
technicians only and with the appropriate tools.
▶After an interruption in the power supply or pneumatic
supply, ensure that the process is restarted in a dened or
controlled manner.
▶The device may be operated only when in perfect condition
and in consideration of the operating instructions.
▶Observe the safety regulations specic to the plant for applica-
tion planning and operation of the device.
english

6
General Information
Typ 2300
▶The plant operator is responsible for the safe operation and han-
dling of the plant.
▶The general rules of technology apply to application planning
and operation of the device.
To prevent damage to property of the device, ensure:
▶Supply the media connections only with those media which are
specied as ow media in the chapter entitled “7 Technical data”.
▶Do not put any loads on the valve (e.g. by placing objects on
it or standing on it).
▶Do not make any external modications to the valves. Do not
paint the body parts or screws.
▶The exhaust air may be contaminated with lubricants in the
actuator.
▶Do not transport, install or remove heavy devices without the aid
of a second person and using suitable auxiliary equipment.
5 GENERAL INFORMATION
5.1 Contact addresses
Germany
Bürkert Fluid Control Systems
Sales Centre
Christian-Bürkert-Str. 13-17
D-74653 Ingelngen
Tel. + 49 (0) 7940 - 10 91 111
Fax + 49 (0) 7940 - 10 91 448
E-mail: [email protected]
International
Contact addresses are found on the Internet under:
www.burkert.com
5.2 Warranty
The warranty is only valid if the device is used as authorized in
accordance with the specied application conditions.
5.3 Information on the internet
The operating instructions and data sheets for Type 2300 can be
found on the Internet at: www.burkert.com
english

7
Structure and function
Typ 2300
6 STRUCTURE AND FUNCTION
The angle-seat control valve Type 2300 can be operated
only in combination with the following control units:
Positioner Type 8692, 8694, 8696 and 8792;
Process controller Type 8693 and 8793.
6.1 Structure
The valve seats are incorporated directly. Via a dowel pin, the
control cone is modularly coupled to the actuator spindle for quick
changeovers. The ow direction is always below seat.
6.2 Function
The seat of the valve is always closed against the medium ow.
Spring force (CFA) or pneumatic pilot pressure (CFB and CFI) gen-
erates the closing force on the control cone. The force is transferred
via a spindle which is connected to the actuator piston.
6.2.1 Control functions (CF)
WARNING!
For control function I – Danger if pilot pressure fails!
For control function I control and resetting occur pneumatically.
If the pressure fails, no dened position is reached.
▶To ensure a controlled restart, rst pressurize the device with
pilot pressure, then switch on the medium.
A
P
A
Normally closed by spring action
B
P
A
Normally open by spring action
I
P
A
Actuating function via reciprocal pressurization
6.2.2 Flow direction below the seat
Depending on the version, the valve is closed against the
medium ow with spring force (control function A, CFA) or with
pilot pressure (control function B or I, CFB or CFI).
As the medium pressure is under the control cone, this pressure
contributes to the opening of the valve.
WARNING!
Medium may be discharged if minimum pilot pressure is too
low or medium pressure too high!
If the minimum pilot pressure is too low for CFB and CFI or the
permitted medium pressure is exceeded, leaks may occur.
▶Observe minimum pilot pressure.
▶Do not exceed medium pressure (see chapter “Pressure
ranges”).
Rest position
CFA
Rest position
CFB / CFI
Fig. 1: Flow direction below the seat
(Rest open/closed, closing against medium)
english

8
Technical data
Typ 2300
7 TECHNICAL DATA
7.1 Conformity
Type 2300 conforms with the EU Directives according to the EU
Declaration of Conformity.
7.2 Standards
The applied standards, which verify conformity with the EU Direc-
tives, can be found on the EU Type Examination Certicate and /
or the EU Declaration of Conformity.
According to Pressure Equipment Directive the following operating
conditions must be observed:
Line connection
orice
Maximum pressure for compressible uids
of Group 1 (hazardous gases and vapors
according to Art. 3 No. 1.3 Letter a rst
dash)
DN65 15 bar
7.3 Type label
00285864
2300 A 25M PTFE VA
Tmed -10°C - +130°C
Flow 1 2
Pilot 5,5 - 7bar
Pmed 12bar
W1XMS
CE
G1 Kvs16
CE identication
Permitted pilot pressure
Permitted medium
pressure
Type
Control function (CF)
Orice of the seat /
actuator size
Sealing material Body material
Identication
number
Flow direction
Permitted medium
temperature
Date of
manufacture
Main dimensions
of line connection
Flow capacity in standard
production conditions
english

9
Technical data
Typ 2300
7.4 Operating conditions
Observe permitted ranges on the type label of the
device!
7.4.1 Temperature ranges
Actuator
size
[mm]
Actuator
material
Medium
Environment1)
Seat seal
steel - steel
Seat seal
PTFE - steel
ø 50
PPS -10 ...
+185 °C
-10 ...
+130 °C
-10 ...
+60 °C 2)
-10 ...
+100 °C 3)
ø 70
ø 90
ø 130
Tab. 1: Temperature ranges
1) If a pilot valve/control unit is used, the max. ambient
temperature is +55 °C.
The angle-seat control valve is suitable for steam
sterilization.
2) Pilot air ports with push-in connector
3) Pilot air ports with threaded bushing
7.4.2 Control medium
In conjunction with pneumatic control units (positioner and
process controllers), pilot air according to DIN ISO 8573-1 must
be used:
•Class 3 (for water content),
•Class 5 (for dust and oil content).
The specication is described in detail in the operating
instructions of the respective positioner / process con-
troller in the chapter entitled “Technical data”.
7.4.3 Pressure ranges
Maximum pilot pressure for valves without pneumatic control
units
Actuator size [mm] Actuator material Max. permitted
pilot pressure 4)
ø 50, 70, 90 PPS 10 bar
ø 130 7 bar
Tab. 2: Pilot pressure for valves without pneumatic control units
4) 4) Observe the maximum pressure range according to the
type label!
Minimum control pressure Pmin for control function A
Actuator size
[mm]
50 / 70 / 90 130
(Connection size
DN40 and DN50)
130
(Connection size
DN65)
Pmin [bar] 5.5 5.5 5.6
Tab. 3: Minimum control pressure for CFA
english

10
Technical data
Typ 2300
Pilot pressure for control function B
Actuator
size
Connection
size [mm]
Pilot pressure [bar] Max. per-
mitted medium
pressure [bar]
for medium pressure
0 bar max
ø 50 mm
15 4.6 6.6 16
20 5.1 7.0 9
25 5.1 7.0 5
ø 70 mm
15 4.4 5.3 16
20 5.2 6.8 16
25 5.2 7.0 12
32 5.2 7.0 6
ø 90 mm
25 2.4 4.2 16
32 2.4 5.3 16
40 2.5 6.5 16
50 2.5 7.0 14
ø 130 mm
40 2.7 4.5 16
50 2.7 5.6 16
65 2.7 7.0 16 (15*)
Tab. 4: Pilot pressure for control function B
* According to Pressure Equipment Directive for compressible uids of Group
1 (hazardous gases and vapors according to Art. 3 No. 1.3 Letter a rst dash)
The required minimum pilot pressure Pmin with control function B
and I (ow below the seat) is dependent on the pressure of the
medium.
The pressure diagrams are in the operating instructions on
the Internet: www.burkert.com
7.5 General technical data
Media
Control medium neutral gases, air
Flow media Water, Alcohol, Fuel, Hydraulic liquids,
Saline solutions, Lyes, Organic solvents
Installation position as required, preferably with actuator in
upright position
Protection class IP67 in accordance with
IEC 529/EN 60529
Control functions (CF) The valve seat is always closed against
the medium ow
Control function A Normally closed by spring action
Control function B Normally open by spring action
Control function I Actuating function via reciprocal pressur-
ization (not for actuator size ø 50 mm in
combination with Type 8696)
8 INSTALLATION
8.1 Safety instructions
DANGER!
Danger – high pressure in the equipment!
▶Before loosening the lines and valves, turn o the pressure
and vent the lines.
english

11
Technical data
Typ 2300
WARNING!
Risk of injury from improper installation!
▶Installation may be carried out by authorised technicians only
and with the appropriate tools!
Risk of injury from unintentional activation of the system and
an uncontrolled restart!
▶Secure system from unintentional activation.
▶Following assembly, ensure a controlled restart.
For control function I – Danger if pilot pressure fails!
For control function I control and resetting occur pneumatically.
If the pressure fails, no dened position is reached.
▶To ensure a controlled restart, rst pressurize the device with
pilot pressure, then switch on the medium.
Risk of injury from moving parts in the device!
▶Do not reach into openings.
CAUTION!
Risk of injury due heavy devices!
▶During transport or during assembly, a heavy device may fall
and cause injury.
▶Do not transport, install or remove heavy devices without the
aid of a second person and using suitable auxiliary equipment.
▶Use appropriate tools.
8.2 Before installation
•The globe control valve can be installed in any installation
position, preferably with the actuator in upright position.
•Before connecting the valve, ensure the pipelines are ush.
•Make certain the ow direction is correct (ow direction always
below the seat).
8.2.1 Preparatory work
→Clean pipelines (Sealing material, swarf, etc.).
Devices with welded body
NOTE!
For valves with installed control:
When welding the valve body into the pipeline, the control
must not be installed.
▶Remove control from the actuator described below.
english

12
Technical data
Typ 2300
Remove the control unit from the actuator (if present):
→Clamp the valve body in a holding device.
→Loosen the fastening screws (2x).
→Remove the control unit upwards.
Fastening
screw (2x) Control unit
Actuator
Fig. 2: Disassembly the control unit
Remove the actuator from the valve body.
→Install collet (white grommet) in pilot air port 1.
NOTE!
Damage to the seat seal or the seat contour!
▶When removing the actuator, ensure that the valve is in open
position.
→Control function A pressurize the pilot air port 1(see “Fig. 3”)
with compressed air (5 bar): valve opens.
→Using a suitable open-end wrench, place the wrench at on the
pipe.
→Unscrew the actuator from the valve body.
Actuator
Nipple
Valve body
Flats for open-end
wrench
Pilot air port
CFA, CFB, CFI
Exhaust air port
CFA, CFB
Pilot air port CFI
2
1
Install collet:
Fig. 3: Installation
Other device versions
→Do not remove actuator unless this is a customer-specic
requirement.
→Procedure see “Devices with welded body”.
english

13
Technical data
Typ 2300
8.3 Installation
WARNING!
Risk of injury from improper installation!
Assembly with unsuitable tools or non-observance of the tight-
ening torque is dangerous as the device may be damaged.
▶For installation use an open-end wrench, never a pipe wrench.
▶Observe the tightening torque (see “Tab. 5”).
Dirt trap for devices with authorisation in acc. with DIN EN 161
In accordance with DIN EN 161 “Automatic shut-o valves for gas
burners and gas appliances” a dirt trap must be connected upstream
of the valve and prevent the insertion of a 1 mm plug gauge.
8.3.1 Installation of the valve body
Welded bodies
→Weld valve body in pipeline system.
Other body versions
→Connect body to pipeline.
8.3.2 Install actuator (welded body)
Seal
Fig. 4: Seal
→Check the seal and if required, replace it.
WARNING!
Danger if incorrect lubricants used!
Unsuitable lubricant may contaminate the medium. In oxygen
applications there is a risk of an explosion!
▶In specic applications, e.g. oxygen or analysis applications,
use appropriately authorized lubricants only.
→Grease nipple thread before re-installing the actuator (e.g.
with Klüber paste UH1 96-402 from Klüber).
NOTE!
Damage to the seat seal or the seat contour!
▶When installing the actuator, ensure that the valve is in open
position.
→Control function A pressurize the pilot air port 1 (see “Fig. 3”)
with compressed air (5 bar): valve opens.
→Screw actuator into the valve body. Observe tightening
torque (see “Tab. 5”).
Tightening torques of valve body / nipples
DN Tightening torques [Nm]
15 45 ±3
20 50 ±3
25 60 ±3
32/40 65 ±3
50 70 ±3
65 100 ±3
Tab. 5: Tightening torques of valve body / nipples
english

14
Technical data
Typ 2300
8.3.3 Install control unit
Before installation, check the position of the ports on the
control unit and, if required, align the actuator.
Description see chapter “8.3.4 Rotating the actuator”.
→Remove collet from pilot air port 1.
→Check that the O-rings are correctly positioned in the pilot air
ports.
→Align the puck holder and the control unit until
1. the puck holder can be inserted into the guide rail of the
control unit and
2. the supports of the control unit can be inserted into the
pilot
air ports of the actuator (see “Fig. 5”).
NOTE!
Damaged printed circuit board or malfunction!
▶Ensure that the puck holder is situated at on the guide rail.
Guide rail
Puck holder
Fig. 5: Aligning the puck holder
→Push the control unit, without turning it, onto the actuator
until no gap is visible on the form seal.
NOTE!
Too high torque when screwing in the fastening screw does
not ensure protection class IP65 / IP67!
▶The fastening screws may be tightened to a maximum
torque of 1.5 Nm only.
→Attach the control unit to the actuator using the two side fas-
tening screws. In doing so, tighten the screws only hand-tight
(max. torque: 1.5 Nm).
Supports
Pilot air
ports
actuator
Fastening
screws max.
1.5 Nm
Fig. 6: Install control unit
english

15
Technical data
Typ 2300
8.3.4 Rotating the actuator
The position of the connections can be aligned steplessly by
rotating the actuator through 360°.
Only the entire actuator can be rotated. The control unit
cannot be rotated contrary to the actuator.
NOTE!
Damage to the seat seal or the seat contour!
▶When rotating the actuator, ensure that the valve is in open
position.
Procedure:
→Clamp the valve body in a holding device (applies only to
valves which have not yet been installed).
→Control function A:
Without unit control: pressurize the pilot air port 1 with com-
pressed air (5 bar): valve opens.
With unit control: open the valve according to the operating
instructions for the control unit.
→Counter on the ats of the nipple with a suitable open-end
wrench.
WARNING!
Risk of injury from discharge of medium and pressure!
If the direction of rotation is wrong, the body interface may become
detached.
▶Rotate the actuator module in the specied direction only (“Fig.
7”)!
→Place suitable open-end wrench on the hexagon of the
actuator.
→Rotate counter-clockwise (as seen from below) to bring the
actuator into the required position.
Open-end wrench
Fig. 7: Rotating with open-end wrench
8.4 Pneumatic connection
DANGER!
Danger – high pressure in the equipment!
▶Before loosening the lines and valves, turn o the pressure
and vent the lines.
WARNING!
For control function I – Danger if pilot pressure fails!
For control function I control and resetting occur pneumatically.
If the pressure fails, no dened position is reached.
▶To ensure a controlled restart, rst pressurize the device with
pilot pressure, then switch on the medium.
english

16
Technical data
Typ 2300
Risk of injury from unsuitable connection hoses!
Hoses which cannot withstand the pressure and temperature
range may result in hazardous situations.
▶Use only hoses which are authorized for the indicated pres-
sure and temperature range.
▶Observe the data sheet specications from the hose
manufacturers.
The pneumatic connection of the angle-seat control
valve can be carried out only in connection with the
appropriate control unit.
Possible control units are:
Positioner Type 8692, 8694, 8696 and 8792;
Process controller Type 8693 and 8793.
8.4.1 Connection of the control medium
→Connect the control medium to the pilot air port (“Fig. 8”: 1)
(3 – 7 bar; instrument air, free of oil, water and dust).
→Fit the exhaust line or a silencer to the exhaust air port
(“Fig. 8”: 3) and, if available, to the additional exhaust air port
(“Fig. 8”: 3.1).
If used in an aggressive environment, we recommend
conveying all free pneumatic connections into a neutral
atmosphere with the aid of a pneumatic hose.
Pilot air port
Exhaust air port
Additional exhaust air port only
with pilot-operated control
system for high air output from
(actuator size ø 130)
1
3
3.1
Fig. 8: Pneumatic connection
Control air hose:
6/4 mm or 1/4” pilot air hoses can be used.
A pilot air port via G 1/8” thread is available as an option.
8.5 Start-up
After installing the device, run the X.TUNE function. This function
presets the control parameters.
Description – see operating instructions for the control.
8.6 Removal
WARNING!
Risk of injury from discharge of medium and pressure!
It is dangerous to remove a device which is under pressure
due to the sudden release of pressure or discharge of medium.
▶Before removing a device, switch o the pressure and vent the
lines.
english

17
Technical data
Typ 2300
Procedure:
→Loosen the pneumatic connection.
→Remove the device.
8.7 Maintenance work
→Complete a visual inspection of the equipment once a year.
Shorter maintenance intervals may be recommended depending
on the operating conditions.
Wear parts: seals and control cone.
→In the event of a leak, replace the relevant wear part.
The maintenance and repair instructions are available on
the Internet: www.burkert.com
Visual inspection:
Perform regular visual inspections according to the application
conditions:
→Check media connections for leaks.
→Check release bore on the tube for leaks.
Release bore
Fig. 9: Release bore
9 PACKAGING, TRANSPORT,
STORAGE
NOTE!
Transport and storage damage!
•Protect the device against moisture and dirt in shock-
resistant packaging during transportation and storage.
•Permitted storage temperature: -20...+65 °C.
Damage to the environment caused by device components
contaminated with media.
•Ensure the device and packaging are disposed of in an envi-
ronmentally sound manner!
english

www.burkert.com
