Burkert 3281 User manual

Operating Instructions
Bedienungsanleitung
Manuel d‘utilisation
Type 3281
Motor valve
Motorventil
Vanne motorisée

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© Bürkert Werke GmbH & Co. KG, 2022
Operating Instructions 2207/00_EU-ML_00815152 / Original DE

3
Contents
1 OPERATING INSTRUCTIONS ................................................................................................................6
1.1 Symbols........................................................................................................................................6
1.2 Denitionofterms........................................................................................................................6
2 INTENDED USE ......................................................................................................................................7
3 BASIC SAFETY INSTRUCTIONS ...........................................................................................................8
4 GENERAL NOTES...................................................................................................................................9
4.1 Contactaddresses.......................................................................................................................9
4.2 Warranty .......................................................................................................................................9
4.3 InformationontheInternet..........................................................................................................9
5 PRODUCT DESCRIPTION....................................................................................................................10
5.1 Intendedareaofapplication......................................................................................................10
5.2 Structureandfunction ...............................................................................................................10
5.2.1 Functions of the control electronics ...........................................................................10
5.3 Variants.......................................................................................................................................11
5.3.1 Positioner....................................................................................................................11
5.3.2 Process controller.......................................................................................................12
6 TECHNICAL DATA ................................................................................................................................13
6.1 Conformity..................................................................................................................................13
6.2 Standards ...................................................................................................................................13
6.3 Operatingconditions .................................................................................................................13
6.4 Mechanicaldata.........................................................................................................................13
6.5 Typelabel ...................................................................................................................................14
6.6 Electricaldata ............................................................................................................................14
6.6.1 Derating ......................................................................................................................16
6.7 Fluidicdata.................................................................................................................................16
7 INSTALLATION......................................................................................................................................17
7.1 Installingthedeviceuidically ..................................................................................................17
7.2 Mountingthevalveseat ............................................................................................................17
Type 3281
english

4
Type 3281
7.3 Installingvalvebody ..................................................................................................................18
7.4 Installingdeviceswithweldedconnection...............................................................................19
7.4.1 Removing actuator from the valve body.....................................................................19
7.4.2 Installing actuator on valve body................................................................................19
7.5 Turningactuator .........................................................................................................................20
7.6 Installingthedeviceelectrically ................................................................................................21
7.6.1 Pin assignment of the pins for positioner ...................................................................22
7.6.2 Pin assignment of the pins for process controller ......................................................23
7.7 LEDdisplay ................................................................................................................................24
7.7.1 Display Elements Standard ........................................................................................24
7.7.2 DisplayElementsNAMURNE107 .............................................................................25
8 START-UP .............................................................................................................................................26
8.1 Start-upwithBürkertCommunicator........................................................................................26
8.1.1 User interface .............................................................................................................26
8.2 ConnectingthedevicetotheBürkertCommunicator .............................................................27
8.3 Functionsofthepositionerandprocesscontroller .................................................................27
8.3.1 Functions for positioners and process controllers .....................................................27
8.3.2 Functions for process controllers ............................................................................... 28
8.4 Basesettings..............................................................................................................................29
8.4.1 Positioner....................................................................................................................29
8.4.2 Process controller.......................................................................................................30
8.5 Settingsforpositionersandprocesscontrollers .....................................................................31
8.5.1 INPUT/OUTPUT - selected standard signal ...............................................................31
8.5.2 SIGNAL. SIM - Simulation of the set-point value .......................................................31
8.5.3 X.CONTROL - Parameterisation of the positioner, insensitivity range
(dead band) of the positioner......................................................................................31
8.5.4 X.TIME - limitation of control speed ...........................................................................32
8.5.5 DIR.CMD-Eectivedirectionofthepositionerset-pointvalue..................................32
8.5.6 SAFEPOS - Entering the safety position ....................................................................32
8.5.7 X.LIMIT - Limitation of the mechanical valve adjustment range.................................33
8.5.8 CUTOFF......................................................................................................................33
8.5.9 CHARACT - Selection of the transfer characteristic between input signal
(set-point position) and stroke (correction characteristic) ..........................................34
8.5.10 Calibrate Position Sensor (X.TUNE) - Zero Flow Point Setting ...................................34
english

5
Type 3281
8.6 ProcessControllerSettings.......................................................................................................35
8.6.1 PV.SCALE/SP.SCALE - Scaling the process controller ..............................................35
8.6.2 P.LIN - Linearisation of the process characteristic .....................................................35
8.6.3 P.TUNE - Self-optimisation of the process controller.................................................35
8.6.4 P.CONTROL - Parameterisation of the process controller .........................................35
8.6.5 P.SIM - Simulation of the process ..............................................................................36
8.7 Othersettings.............................................................................................................................37
8.7.1 CAL INP ......................................................................................................................37
8.7.2 FACTORY RESET - Reset to factory settings.............................................................37
8.7.3 DIAGNOSTICS............................................................................................................37
8.7.4 CHANGEOVER of LED DISPLAY - Changeover of LED colours between
standardandNAMURNE107....................................................................................37
8.7.5 AUTO / MANU - Switching operating state AUTOMATIC / MANUAL.........................37
8.7.6 Access rights and password protection ..................................................................... 37
8.7.7 Changing the operating state .....................................................................................38
8.8 Congurationmanagement.......................................................................................................38
9 MAINTENANCE ....................................................................................................................................39
9.1 Maintenancework......................................................................................................................39
9.2 Cleaning......................................................................................................................................39
9.3 Troubleshooting .........................................................................................................................39
10 ACCESSORIES .....................................................................................................................................41
11 PACKAGING, TRANSPORT..................................................................................................................42
12 STORAGE .............................................................................................................................................42
13 DISPOSAL ............................................................................................................................................42
english

6
Operating instructions
Type 3281
1 OPERATING INSTRUCTIONS
The operating instructions describe the entire life cycle of the device. Keep these instructions ready to hand
at the operating site.
Importantsafetyinformation.
▶Read these instructions carefully.
▶Above all, observe the safety instructions, intended use and operating conditions.
▶Persons who work on the device must read and understand these instructions.
1.1 Symbols
DANGER
Warnsofanimmediatedanger.
▶Failure to observe these instructions will result in serious injuries or death.
WARNING
Warnsofapotentiallydangeroussituation.
▶Failure to observe these instructions may result in serious injuries or death.
CAUTION
Warnsofapotentialhazard.
▶Failure to observe these instructions may result in moderate or minor injuries.
NOTE
Warnsofdamagetoproperty.
▶Failure to observe these instructions may result in damage to the device or the system.
Indicates important additional information, tips and recommendations.
Refers to information in these operating instructions or in other documentation.
▶designates instructions for risk prevention.
→Designates a procedure which you must carry out.
1.2 Denition of terms
Term intheseinstructions,refersto
Device MotorvalveType3281
CANopen AeldbusbasedonCAN(ControllerAreaNetwork)whichisusedinautomation
technology to network devices
büS ACANopen-basedeldbuswithadditionalfunctionalities
english

7
Intended use
Type 3281
2 INTENDED USE
The2-waymotorvalveType3281isdesignedtocontroltheowofliquidandgaseousmedia.
▶Use the device only as intended. Non-intended use of the device may be dangerous to people, nearby
equipment and the environment.
▶Do not use the device outdoors.
▶Do not expose the valve to direct sunlight.
▶To use the device, observe the permissible data, operating conditions and conditions of use. These
specicationscanbefoundinthecontractdocuments,theoperatinginstructionsandontheTypelabel.
▶Use the device only in conjunction with third-party devices and components recommended or approved
by Bürkert.
▶The device must only be used in perfect working order; always ensure proper storage, transportation,
installation and operation.
english

8
Basic safety instructions
Type 3281
3 BASIC SAFETY INSTRUCTIONS
These safety instructions do not take into account any unforeseen circumstances and events which occur
during installation, operation and maintenance. The operator is responsible for observing the location-spe-
cicsafetyregulations,alsowithreferencetopersonnel.
Riskofinjuryduetohighpressureandescapingmedium.
▶Switchothepressurebeforeworkingonthesystemordevice.Ventoremptythelines.
Riskofinjuryfromelectricshock.
▶Beforeworkingonthesystemordevice,switchothepowersupplyandsecuretopreventreactivation.
▶Observe any applicable accident prevention regulations and safety regulations for electrical devices.
Riskofburnsorrefromhotdevicesurfacesduetoprolongedoperation.
▶Keepthedeviceawayfromhighlyammablesubstancesandmedia.
▶Only touch the device when wearing protective gloves.
Generaldangeroussituations.
To prevent injuries, observe the following:
▶DonotuseDevicekey3281inareaswhereexplosionsarepossible.
▶Do not to subject the housing to mechanical stress.
▶Do not make any internal or external changes to the device. Do not paint housing parts or screws.
▶Avoidtheuseofthemotorvalveinanenvironmentofstrongmagneticelds.
▶Secure the device against unintentional activation.
▶Only trained technicians may carry out installation and maintenance work.
▶Following an interruption in the power supply, ensure that the process is restarted in a controlled
manner.
▶Observe the general rules of technology.
NOTE
Electrostaticallysensitivecomponentsandassemblies.
Thedevicecontainselectroniccomponentsthataresusceptibletotheeectsofelectrostaticdischarging
(ESD). Components that come into contact with electrostatically charged persons or objects are at risk. In
the worst-case scenario they will be destroyed immediately or will fail after start-up.
▶Observe the requirements of EN 61340-5-1 for minimising or avoiding the possibility of damage caused
by sudden electrostatic discharge.
▶Do not touch electronic components when the supply voltage is connected.
english

9
General notes
Type 3281
4 GENERAL NOTES
4.1 Contact addresses
Germany
Bürkert Fluid Control Systems
Sales Centre
Christian-Bürkert-Str.13–17
D-74653Ingelngen
Tel.+49(0)7940-1091111
Fax+49(0)7940-1091448
Email: [email protected]
International
The contact addresses can be found on the back pages of the printed operating instructions.
Also on the Internet at:
www.burkert.com
4.2 Warranty
Apreconditionforthewarrantyisthatthedeviceisusedasintendedinconsiderationofthespeciedoper-
ating conditions.
4.3 Information on the Internet
OperatinginstructionsanddatasheetsforType3281canbefoundontheInternetat:
www.burkert.com
english

10
Product description
Type 3281
5 PRODUCT DESCRIPTION
5.1 Intended area of application
ThemotorvalveType3281isdesignedtocontroltheowofliquidandgaseousmedia.Onlyclean,liquidor
gaseous media that do not attack the valve body and seal materials may be controlled.
NOTE
Damagetothevalvebodyandsealsduetounsuitablemedia.
Unsuitable media can cause damage to the valve body and seals.
▶Use only suitable media.
▶Check resistance in each individual case.
5.2 Structure and function
The valve spindle is driven by a stepper motor. The rotary rotational movement of the motor is converted into
a linear movement by means of a threaded spindle. The valve spindle is rigidly connected to the threaded
spindle. The valve spindle is connected to a control cone.
Circular plug-in connector
Valve body
Actuator cover
Control cone
Valve spindle
Stepper motor
Wrenchatofthebody
connection
Fig. 1: Structure of the valve
Theoworswitchingofthevalveisregulatedbymeansofasteppermotoractuator,whichiscontrolledby
the integrated control electronics. No external motor control is required for step control.
5.2.1 Functions of the control electronics
• Control of the valve opening by processing the external set-point values.
• Output of the valve statuses via the LED display.
• Detection of the position after power failure.
- In the event of a power failure, the current position of the valve is retained.
english

11
Product description
Type 3281
- When the voltage is applied again, the control electronics automatically detect the current position.
• Reduction of energy consumption.
- The stepper motor is only supplied with energy when it opens or closes the valve further. Owing to the
internal holding torque, the stepper motor only moves when it is controlled. In the remaining time, only the
control electronics need a basic voltage supply in order to adjust or move the stepper motor and thus the
motor valve in the event of a change in the signal input.
5.3 Variants
Type Seatdiameter Variants Options
3281 4, 6, 8, 10 with integrated positioner analogue
digital(eldbus)
with integrated process
controller
analogue
digital(eldbus)
Table 1: Variants
The variants with integrated positioner or process controller are available in 2 options:
• Analogue: Set-point values are transmitted analogue via the standard signals,
• Digital: Set-point values are transmitted digitally via CANopen/büS.
ThevariantscanberecognizedbytheplugcongurationorontheTypelabel:Cstandsforpositioner
and D for process controller.
Both variants have special functions that can be set using the Bürkert Communicator.
5.3.1 Positioner
The positioner converts a set-point position into a valve position. The position of the actuator is regulated
according to the set-point position. The position sensor records the current position (POS) of the electro-
motive valve. This actual position is compared by the positioner with the set-point value (CMD)speciedas
thestandardsignal.Ifthereisacontroldierence(Xd1),amotorcontrolsignalisgiventotheactuatorasthe
actuating variable. Z1 is a disturbance.
Positioner
Positioncontrolloop
CMD CTRL POS
Z1
POS
Valve opening
+
Xd1
-
Position sensor
Continuous valve
Electromotive
actuator
Set-point
position
Fig. 2: Signal Flow Plan Positioner
The two end positions of the valve are signaled by status LEDs. The actual position recorded by the position
sensor is output via the M12 circular plug-in connector. It is possible to communicate with the device digitally
via CANopen or büS.
english

12
Product description
Type 3281
5.3.2 Process controller
The additionally implemented PID controller can, except for the position control, also be used to conduct a
process control for purposes of cascade control.
Positioner
Positioncontrolloop
CMD CTRL POS
Z1
POS
Valve opening
+
Xd1
-
Position sensor
Continuous valve
Electromotive
actuator
Set-point
position
Process
controller
Position
control
loop
SP CMD
Z2
PV
Measured
quantity
+
Xd2
-
Transmitter
Process
Set-point
position
Valve
opening
Fig. 3: Signal Flow Diagram Process Controller
The process controller is integrated into a control loop. The set-point position of the valve is derived from the
process set-point value and the process actual value, with the control parameters (PID controller). The process
set-pointvaluecanbespeciedbyanexternalsignal.
For process control, the position control mentioned above becomes an auxiliary control loop, which creates
a cascade control. The process controller in the main control loop has a PID function. The process set-point
value(SP)isspeciedastheset-pointvalueandcomparedwiththeactualvalue(PV)ofthemeasuredvariable
being controlled. The position sensor records the current position (POS) of the electromotive linear actuator.
Thisactualpositioniscomparedbythepositionerwiththeset-pointvalue(CMD)speciedbytheprocess
controller.Ifthereisacontroldierence(Xd1), the actuatingvariable(CTRL)isusedtochangetheactual
position (POS) and thus the valve opening. Z2 is a disturbance.
english

13
Technical Data
Type 3281
6 TECHNICAL DATA
6.1 Conformity
TheType3281conformstotheEUdirectivesaccordingtotheEUdeclarationofconformity(ifapplicable).
6.2 Standards
The standards applied to demonstrate conformity with the Directives can be found in the EU type examination
certicateand/ortheEUdeclarationofconformity(ifapplicable).
6.3 Operating conditions
WARNING
Riskofinjuryduetomalfunctionifusedoutdoors.
▶Do not use the device outdoors and keep it away from heat sources that could cause the permissible
temperature range to be exceeded.
▶Protect the device from direct sunlight and humidity.
Ambient temperature -10...+60°C(notederatingcurve,seechapter“6.6.1”)
Medium temperature -10...+130°C
Air humidity < 95%, non-condensing
Media non-aggressive, pure and non-corrosive liquid and gaseous media that
do not attack valve bodies and seal materials.
Check resistance in each individual case.
In the case of dirty media, pre-connect a suitable dirt trap with a mesh
sizeof≤0.3mm.
Circuitfunction
2 (A)
1 (P)
Direct-acting 2-way valve, motor-driven, currentless in position
6.4 Mechanical data
Materials
Actuator cover Plastic parts black: PPS GF40,
Plastic parts anthracite: PC GF10
Valve body Stainless steel VA
Seal material PTFE
Othermaterialsintheuid
sector
Stainless steel VA
Connections G1/2, RC1/2, NPT1/2 and welded connection
Weight DN10withVAstraightglobebody1113g
Dimensions see data sheet
english

14
Technical Data
Type 3281
6.5 Type label
3281 X DN10 PTFE VA
D-74653 Ingelfingen
268611 SN000000
W3ZLT
24 V DC 20 W
G 3/8 PN 6 bar
Tamb see manual
Type
Electronic variant of
the valve
Seat diameter
Order number, serial number
Seal material
Body material
Ambient temperature
Voltage, max. power consumption
Port connection, pressure range
Fig. 4: Location and description of the type label (example)
6.6 Electrical data
Electricaldata
Positioner Processcontroller
Analog Digital(eldbus) Analog Digital
(eldbus)
Connections Circular
plug-in con-
nector
(M12 x 1,
8-pin)
Circular plug-in con-
nector
(M12 x 1, 5-pin)
Circular plug-in
connectors
(M12 x 1, 8-pin
and
M12 x 1, 5-pin)
Circular plug-in con-
nectors
(M12 x 1, 5-pin and
M12 x 1, 5-pin)
Operating voltage 24VDC±10%-
residualripple<10%
24VDC±10%-
residualripple<10%
Power consumption max.12W
short-term20W
max.12W
short-term20W
Standby power consumption approx.2W approx.2W
Actuating time (0-100%) approx.2.5s approx.2.5s
Analogue input (set-point value
input)
0...20mA,
4...20mA,
0...5Vor
0...10V,see
chapter “8.5”
-0...20mA,
4...20mA,0...5V
or0...10V,see
chapter “8.5”
-
english

15
Technical Data
Type 3281
Electricaldata
Positioner Processcontroller
Analog Digital(eldbus) Analog Digital
(eldbus)
Analogue input (actual value
input)
- - 0...20mA,
4...20mA,
0...5Vor
0...10V,see
chapter "8.2.1"
0...20mA,
4...20mA,
0...5V,
0...10Vorfrequency:
Measuring range
5...2000Hz
Input resistance
>22kΩ
Inputsignal>10Vss
signal form square
wave
Input impedance for analogue
input
60Ωat
0...20mAand
4...20mA/
Resolution
40μA
22kΩat
0...5Vand
0...10V/
Resolution
20mV
-60Ωat0...20mA
and4...20mA/
Resolution40μA
22kΩat0...5V
and0...10V
/ Resolution
20mV
-
Analogue output
(actual value output)
0...20mA,
4...20mA,
0...5V,
0...10V
(adjustable,
see chapter
“8.5”)
-0...20mA,
4...20mA,
0...5V,0...10V
(adjustable, see
chapter “8.5”)
-
Analogue output max. Current
for voltage
output10mA
max. Load for
current output
560Ω
- max. Current for
voltage output
10mAmax.
Load for current
output560Ω
-
Position sensor Contactless, high-resolution and thus
wear-free position sensor
Contactless, high-resolution and thus
wear-free position sensor
Parameterisation interface büS or
CANopen2)
- büS or
CANopen2)
-
Communication interface - CANopen/büS - CANopen/büS
Duty cycle accordingtoEN60034-1:S350%,
depending on the operating
conditions.
Observe the derating curve, see
chapter “6.6.1”
accordingtoEN60034-1:S350%,
depending on the operating conditions.
Observe the derating curve, see chapter
“6.6.1”
1) Fortheanaloguevariant:3.3Vsignalvoltage,thesafecommunicationdecreaseswithincreasinglinelengthand
transmission speed.
english

16
Technical Data
Type 3281
6.6.1 Derating
The maximum duty cycle of the valve depends on the maximum ambient temperatures, the media temperature
and the coil current of the stepper motor.
The duty cycle does not mean the duty cycle of the device but the duty cycle of the stepper motor.
This is only switched on when the valve is to move. Frequent set-point value changes drastically
increase the duty cycle of the motor.
From the derating curve it can be read which maximum duty cycle is permissible at which maximum ambient
temperature. At lower medium temperatures, higher duty cycles can be achieved.
10 %
20 %
30 %
40 %
50 %
60 %
70 %
80 %
90 %
100 %
0510 15 20 25 30 35 40 45 50 55 60
Ambienttemperature[°C]
Dutycycle[%]
Fig. 5: Derating curve at max. media temperature for positioner and process controllers
6.7 Fluidic data
Type Seatdiameter KVs-value[m³/h]2) Max.pressure[bar]
3281
4 0.57
See indication on the type label
6 1.25
8 1.8
10 2.25
2) The KVs valueisaowvalueforwater,measurementat+20°Cand1barpressuredierenceabovethefullyopen
valve.
english

17
Installation
Type 3281
7 INSTALLATION
DANGER
Riskofinjuryduetohighpressureinthesystemordevice.
▶Beforeworkingonthesystemordevice,switchothepressureanddeaeratelines.
Riskofinjuryfromelectricshock.
▶Beforeworkingonthesystemordevice,switchothepowersupplyandsecuretopreventreactivation.
▶Observe any applicable accident prevention regulations and safety regulations for electrical devices.
WARNING
Riskofinjuryduetoimproperinstallation.
▶Installation may only be performed by trained technical personnel with suitable tools.
▶Secure the system against unintentional activation.
▶Following installation, ensure a controlled restart.
7.1 Installing the device uidically
Installationposition:arbitrary, preferably actuator at the top and with vertical installation position actuator
cover upwards.
→Cleanpipelinesandangeconnections.
→Installadirttrapupstreamofthevalveinlet(≤0.3mm).
NOTE
Caution:riskofbreakage.
▶Do not use the plastic actuator cover as a lever arm.
→Hold the device on the housing using an appropriate tool (e.g. open-end wrench) and screw into the pipeline.
→Notetheowdirection.
  Thedigitsonthevalvebodyindicatethedirectionofow(owdirectionalwaysundervalveseat2→1).
7.2 Mounting the valve seat
Valve seat set consists of valve seat and graphite seal.
WARNING
Riskofinjuryfromimproperinstallation.
▶Only mount the valve seat with a special installation tool.
▶Observe the tightening torque.
english

18
Installation
Type 3281
When mounting the valve seat, the actuator must be removed. The work steps required are
described in chapter “7.4.1”.
→Screw suitable tool insert into the assembly tool.
The suitable assembly tool (order number 625604) is not included in the valve set and must be ordered
separately.
Assembly tool
Tool insert (depending on seat size)
Valve seat
Fig. 6: Mounting the valve seat
DANGER
Dangerduetolubricant.
Lubricant may contaminate the medium. There is a risk of explosion in oxygen applications.
▶Forspecicapplications,e.g.oxygenoranalysisapplications,useapprovedlubricantsonly.
→Apply lubricant to the valve seat thread (e.g. Klüberpaste UH1 96-402 from Klüber).
→Screw the attached valve seat into the thread of the valve body manually using the assembly tool.
→Tighten the valve seat using a torque wrench. Observe the tightening torques in the following table.
Tightening torques for valve seat assembly:
Valveseatsize Tighteningtorquesforcoatedseats[Nm]
4...10 20 ±3
→Screw the actuator to the valve body. The work steps required are described in chapter “7.4.2”.
7.3 Installing valve body
→Connect valve body to pipeline.
→Devices with welded connection: Weld the valve body into the pipeline. To do this, observe chapter on
Installing devices with welded connection.
english

19
Installation
Type 3281
7.4 Installing devices with welded connection
NOTE
Damagetotheactuatorwhenweldingthevalvebodyintothepipeline.
▶Before welding into the pipeline, remove the actuator.
7.4.1 Removing actuator from the valve body
NOTE
Damagetothevalveseatsealorseatcontour.
▶When removing the actuator, the valve must be in the open position.
→Connect the valve to the Bürkert Communicator and open the valve 100% in the MANUAL operating state.
→Placeasuitableopen-endwrenchonthewrenchatofthebodyconnection.
Open-end wrench
Wrenchatofthe
body connection
Fig. 7: Unscrewing the actuator
→Unscrew actuator from the valve body.
7.4.2 Installing actuator on valve body
Graphite seal
Fig. 8: Seal position
→Check the seal for damage and replace it if necessary.
english

20
Installation
Type 3281
DANGER
Dangerduetolubricant.
Lubricant may contaminate the medium. There is a risk of explosion in oxygen applications.
▶Forspecicapplicationsuseonlyapprovedlubricants(e.g.foroxygenapplicationsoranalysis
applications).
→Beforere-installation,greasethethreadofthebodyconnection(e.g.withKlüberpasteUH196-402from
Klüber).
NOTE
Damagetothevalveseatsealorseatcontour.
▶When installing the actuator, the valve must be in the open position.
→Screw actuator into the valve body. Observe the tightening torque of 45±3Nm.
7.5 Turning actuator
Thepositionoftheportscanbeseamlesslyalignedbyturningtheactuator360°.
NOTE
Damagetothevalveseatsealorseatcontour.
▶When turning the actuator, the valve must be in the open position.
→Clamp valve body in a holding device (only for valves which have not yet been installed).
→Move the actuator into the required position by turning it clockwise (seen from above).
Fig. 9: Rotating the actuator
DANGER
Riskofinjuryduetohighpressureandescapingmedium.
If the direction of rotation is incorrect, the body connection can detach.
▶Rotatetheactuatoronlyinthespecieddirectionofrotation.
english
