Canon imagePRESS Server G100 Operating and maintenance manual

ENGLISH 日本語
imagePRESS Server G100 Installation Procedure
imagePRESS Server G100 設置手順書
This installation procedure is written in Japanese and English. The installation procedure for Japan model is described in Japanese and one for the other models is
described in English. These procedures are different from each other. Follow the procedure corresponding to the installed model.
- Japanese: The installation procedure for Japan model
- English: The installation procedure for the other models except for Japan model
この設置手順書には、和文と英文の設置手順が記載されている。和文では日本モデル用の設置手順が記載されており、英文では日本モデル以外のその他のモデル用の設
置手順が記載されている。それぞれの設置手順は異なっているので、モデルに応じた手順に従うこと。
・和文： 日本モデル用設置手順
・英文： 日本モデル以外のその他のモデル用設置手順
PRINTED IN USA 45128775 PUB No. FT2-0109-000
© CANON INC. 2014

2
2
Before Connection > Installing the license
Before Connection > Installing the license
How to Check this Installation Procedure
Symbols in the Illustration
The frequently-performed operations are described with symbols in this procedure.
1x 1x 1x
Install
Screw
Packaged Item Remove Tighten Loosen
1x
Connect
Connector
Disconnect
Install
Harness
(Common for Guides and Clamps)
Remove
1x 1x
1x 1x
Connect
Power Cord
Disconnect
Check visuallyCheck the sound Check
OFF Cleaning ON Push
Power
Unused Parts
F-1-1
Before Connection
Installing the license
Be sure to take out the license certicate included in the package and obtain the license key
in advance. Make the setting of the EFI Controller by the Web browser in the Control Panel.
Register the license by the following procedure.
1) Log in to the host machine as an administrator (mode).
Factory default password is as follows.
• System administration division ID: 7654321
• System administration password: 7654321
CAUTION:
When [System Manager Information Settings] is set, it is required to log in as a system
manager in accordance with instructions from the user administrator.
2) Select Settings/Registration > [Management Settings] > [License/Other] > [Register
License].
3) Enter the license key of the Web browser.
Example: 8888-7777-6666-5555-4444-3333
4) Press [Start] > [OK].
5) Turn OFF and then ON the main power switch to determine the registration.

3
3
Checking the Contents
Checking the Contents
The IP addresses for communication between the host
machine and server are set automatically
1) Enter the Service Mode (level 1).
2) Select: COPIER > OPTION > INT-FACE > IMG-CONT > "3".
3) Exit the Service Mode.
Securing space for installation
A space of 200 mm or more is required from the back of this equipment.
200mm or more
Rear
Equipment
Front
Checking the Contents
NOTE:
[3] Power Cord: The connector has a different shape depending on locations.
Use the correct power code to match the location/area of installation.
Make sure not to leave unused power code at the site.
The parts ([10] to [12], and [13] to [16]) are packed in single bags.
• [10] to [12]: To be used when installing the Open I/F PCB.
• [13] to [16]: To be used when installing the PS Unit.
F-1-2
Europe X2
USA X 1
[1] PS Unit X 1 [3] Power Cord X 1[2] PS Unit Fixation Plate
X 1
[4] Cross Ethernet
Cable X 1
[6] Open I/F PCB X 1
[7] Support Plate X 2 [8] Interface Cable
(1.0 m) X 1
[10] Open I/F PCB
Mounting Plate X 1
[11] Card Spacer X 1 [12] Screw (TP; M3x6) X 4
[5] Shield Ethernet
Cable (3.0 m) X1
[9] License Access
Number Certificate X 1
F-1-3

4
4
Installation Outline Drawing
Installation Outline Drawing
Use 2 of them
[13] Wire Saddle X 4 [15] Stepped Screw
(M4) X 2
[14] Screw with
Toothed Washer
(Binding; M4x8) X 4
[16] Screw (TP; M3x6) X 6
< CD/Guides >
• Media Pack
• QUICK SETUP POSTER
F-1-4
Turning OFF the power of the host machine
Check that the main power switch is OFF.
1) Turn OFF the main power switch of the host machine.
2) Be sure that display in the Control Panel and the lamp of the main power supply are turned
off, then disconnect the power plug.
Check when Connecting the Power Plug to an Outlet
When connecting the power plug of this equipment to an outlet, be sure to use an outlet of a
system different from that of the host machine.
Installation Outline Drawing
F-1-5

5
5
Installation Procedure > Installing the Open I/F PCB
Installation Procedure > Installing the Open I/F PCB
Installation Procedure
Installing the Open I/F PCB
1) Remove the Box Left Cover.
• 4 Screws
4x
F-1-6
2) Disconnect the Reader Communication Cable and release the 2 Lock Levers.
1x
3) Hold the grip to remove the Main Controller PCB 2.
• 2 Screws
2x
F-1-7
F-1-8

6
6
Installation Procedure > Installing the Open I/F PCB
Installation Procedure > Installing the Open I/F PCB
4) Remove the Face Plate (the removed Face Plate will not be used).
• 2 Screws (The removed screws will be used in step 8.)
NOTE:
Ask the user to store the Face Cover, in case it is needed in the future.
2x
5) Remove the screw and replace it with the Card Spacer (the removed screw will be used in
step 8).
1x
F-1-9
F-1-10
6) Remove the Bypass PCB (the removed Bypass PCB will not be used).
• 2 Screws (The removed screws will be used in step 8.)
• 1 Connector
NOTE:
Ask the user to store the Bypass PCB, in case it is needed in the future.
2x
1x
7) Install the Open I/F PCB Mounting Plate.
• 1 Screw (TP; M3 x 6)
1x
TP
M3x6
F-1-11
F-1-12

7
7
Installation Procedure > Installing the Open I/F PCB
Installation Procedure > Installing the Open I/F PCB
8) Install the Open I/F PCB.
• 1 Connector
• 5 Screws (Use the screws removed in steps 4, 5, and 6.)
• 3 Screws (TP; M3 x 6)
TP
M3x6
2x
6x
1x
9) Release the 2 Lock Levers in the direction of the arrows, and uniformly push in the Main
Controller PCB 2 with both hands until it stops.
CAUTION:
Install the Main Controller PCB 2 while paying attention not to trap cables.
Lock
Lever
F-1-13
F-1-14
10) Turn over the 2 Lock Levers, and push in and secure the Main Controller PCB 2.
• 2 Screws (Install in order of bottom and top.)
CAUTION:
Be sure to perform the work in the order from 1 to 5 in the gure because the connector
of the Main Controller PCB 2 may not be connected.
2x
11) Connect the Reader Communication Cable.
12) Connect the Interface Cable to the Open I/F PCB.
1x
F-1-15
F-1-16

8
8
Installation Procedure > Installing the PS Unit
Installation Procedure > Installing the PS Unit
13) Put the Interface Cable through the hole of the Box Left Cover to install the Box Left
Cover.
• 4 Screws
CAUTION:
When installing the Box Left Cover, be careful not to trap cables.
4x
F-1-17
Installing the PS Unit
1) Remove the 2 Face Seals of the Rear Upper Cover and loosen the 2 Screws.
(the removed Face Seals will not be used)
2x
2) Hook the Support Plate to the screw (right side) loosened in step 1, and install it in the
direction of the arrow..
• 1 Screw (TP; M3 x 6)
1x
Screw
Screw Support Plate
TP
M3x6
F-1-18
F-1-19

9
9
Installation Procedure > Installing the PS Unit
Installation Procedure > Installing the PS Unit
3) Hook the Support Plate to the screw (left side) loosened in step 1, and install it in the
direction of the arrow.
• 1 Screw (TP; M3 x 6)
Screw
Screw
Support Plate
1x
TP
M3x6
4) Tighten the 2 screws loosened in step 1.
Screw
2x
F-1-20
5) Install the 2 Stepped Screws (M4) to the Support Plate.
Support Plate
Support Plate
Stepped Screw
Stepped Screw
2x
Stepped Screw
M4
6) Remove the 8 screws of the PS Unit. (the removed screw will be used in step 7)
8x
F-1-21
F-1-22

10
10
Installation Procedure > Installing the PS Unit
Installation Procedure > Installing the PS Unit
7) Install the PS Unit Fixation Plate.
• 4 Screw (Use the screws removed in steps 6.)
CAUTION:
Be sure to install it in the correction direction.
4x
8) Hook the PS Unit to the 2 Stepped Screws (M4) tightened in step 5, and install it.
• 4 Screws with Toothed Washer (Binding; M4 x 8)
Screw with
Toothed Washer
Binding; M4x8
4x
F-1-23
F-1-24
9) Remove the 2 Face Seals of the Rear Lower Cover (the removed Face Seals will not be
used).
10) Install the 4 Wire Saddles.
F-1-25
F-1-26

11
11
Installation Procedure > Installing the PS Unit
Installation Procedure > Installing the PS Unit
11) Connect the Interface Cable to the PS Unit.
• 2 Wire Saddles
2x
1x
12) Open the HDD Cover, connect one end of the Cross Ethernet Cable to the host
machine and then connect another end to the PS Unit.
1x
1x
F-1-27
F-1-28
13) Close the HDD Cover.
14) Connect the Shield Ethernet Cable to the PS Unit.
1x
F-1-29

12
12
Installation Procedure > Installing the PS Unit
Installation Procedure > Installing the PS Unit
15) Remove the label, and connect the Power Cord.
16) Secure the Power Cord and the Shield Ethernet Cable in place.
• 2 Wire Saddles
CAUTION:
• Use the correct power code to mach the location/area of installation. Make sure not
to leave unused power code at the site.
• Be sure to use the network cable with Category 5e or higher. In addition, a sealed
type (STP cable) is recommended. When using the non-sealed type (UTP cable),
it may inuence the surrounding electronic equipments via network cable.
2x
1x
F-1-30
17) Connect the power plug to the outlet of the host machine.
18) Connect the power plug to the outlet of the PS Unit.
CAUTION:
Be sure to use an outlet of a system different from that of the host machine.
19) Turn ON the main power switch of the host machine.
20) "Turn ON the main power of the host machine again." is displayed on the touch panel,
turn OFF the main power switch of the host machine.
21) Turn ON the main power switch again.
22) Check that the value of CNT-TYPE is "454".
• Service Mode (level 1) > COPIER > OPTION > INT-FACE > CNT-TYPE

13
13
Installation Procedure > Settings after Installation
Installation Procedure > Settings after Installation
Setting of the display range of the Web browser
1) Select Settings/Registration > [Function Settings] > [Web Access] > [Settings] > [Privacy
Policy and Regulations], and set the following items to "ON".
• Full Screen: ON
• Hide Buttons in Toolbar: ON
• Hide Address in Toolbar: ON
The display range of the Web browser is extended.
F-1-31
F-1-32
Settings after Installation
1) Select [Fiery] from the main menu on the host machine's LCD.
2) Select [Login] to log in as a system administrator.
Input of password:
A password input screen is displayed at the time of installation.
Entering "Fiery.1" in the password eld displays the setting screen.
CAUTION:
Use single-byte upper case to enter F of "Fiery.1". Use single-byte lower case to enter
other characters.
F-1-33
F-1-34

14
14
Installation Procedure > Settings after Installation
Installation Procedure > Settings after Installation
3) Select [Tools] > [Setup].
4) Check the settings of server, network, printer and PDL. When making each setting, the
setting will not be completed unless [Save Changes] is pressed.
F-1-35
F-1-36
Example) Select [Server] > [General].
1
2
Check that the items in the General Setup are set, and perform [Save Changes] even if there
is no change. The setting will not be completed unless [Save Changes] is pressed.
F-1-37
F-1-38

15
15
Installation Procedure > Checking the Operation After Making the Settings
Installation Procedure > Checking the Operation After Making the Settings
5) Press [Exit Setup] after all settings are completed.
6) The conrmation screen will appear, and then press [Reboot Now].
7) The PS Unit will be restarted (approx. 10 min.).
F-1-39
F-1-40
Checking the Operation After Making the Settings
Output Test Page and Conguration by the following procedure, and check the connection
between the host machine and this equipment as well as the settings of this equipment.
1) Select [Fiery] from the main menu on the host machine's LCD.
2) Select [Login] to log in as a system administrator.
A password input screen is displayed at the time of installation.
Entering "Fiery.1" in the password eld displays the setting screen.
F-1-41
F-1-42

16
16
Installation Procedure > Executing image Quality Adjustment
Installation Procedure > Executing image Quality Adjustment
3) Select [Info] > [Print Pages] > [PS Test Page].
1
2
3
4) Press [Yes].
F-1-43
F-1-44
Connecting to the Network
Ask the network administrator to connect to the network, make settings and output the test
print.
Refer to "Conguration and Setup" in User's Manual for details of checking work.
Executing image Quality Adjustment
Execute the image quality adjustment shown below at installation. (Refer to "Installation" in
Service Manual for host machine.)
• Auto Gradation Adjustment
• Register Paper to Adjust
• Execution of Correct Shading
• Auto Correct Color Tone Settings (Only when installing the Image Reader Unit)

17
17
接続前の準備 > ライセンスのインストール
接続前の準備 > ライセンスのインストール
本設置手順書の見方について
注意 :
以下は日本モデル用の設置手順が記載されている。
日本モデル以外の設置手順は、 英文設置手順に従うこと。
イラスト内のシンボルマークについて
本手順書では、 よく行う動作などについてシンボルマークで表現している。
1x 1x 1x
取付け
ビス
同梱部品 取外し 締める 緩める
1x
取付け
コネクタ
取外し
取付け
束線
(ガイド・クランプ共通)
取外し
1x 1x
1x 1x
取付け
電源コード
取外し
目視確認音確認 確認
OFF 清掃 ON 押下
電源
不要部品
F-1-1
接続前の準備
ライセンスのインストール
同梱されているライセンス証書を取出し、事前にライセンスキーを取得しておく。 EFI コントロー
ラーの設定は、 本体の操作部から Web ブラウザで行う。
以下の手順でライセンスの登録を行う。
1) 管理者 ( モード ) で本体にログインする。
工場出荷時のパスワードは下記である。
・ システム管理部門 ID ： 7654321
・ システム管理暗証番号 ： 7654321
注意 :
[ システム管理者情報の設定 ] がされている時は、 ユーザー管理者の指示に従い管
理者としてログインする必要がある。
2) 設定 / 登録 > [ 管理設定 ] > [ ライセンス / その他 ] > [ ライセンスの登録 ] を選択する。
3) WEB ブラウザのライセンスキーを入力する。
例 ： 8888-7777-6666-5555-4444-3333
4) [ スタート ] > [OK] を押下する。
5) 登録を確定するため主電源スイッチを OFF/ON する。

18
18
同梱部品の確認
同梱部品の確認
本体と本機間の通信用 IP アドレスを自動で設定する
1) サービスモード ( レベル 1) に入る。
2) COPIER > OPTION > INT-FACE > IMG-CONT > "3" を選択する。
3) サービスモードから抜ける。
設置するスペースを確保する
本機の背面から 200 mm 以上のスペースが必要である。
200 mm以上
背面
本機
前面
同梱部品の確認
メモ :
[10] ～ [12]、 [13] ～ [16] はそれぞれ 1 つの袋にまとめて梱包されている。
・ [10] ～ [12]: Open I/F PCB 取付け時に使用する。
・ [13] ～ [16]: PS ユニット取付け時に使用する。
F-1-2
[1] PSユニット X 1 [3] 電源コード X 1[2] PSユニット固定板 X 1
[4] クロスイーサネット
ケーブル X 1
[6] オープンI/F基板 X 1
[7] 支持板 X 2 [8] インターフェース
ケーブル (1.0 m) X 1
[10] オープンI/F基板
取付け板 X 1
[11] カードスペーサー X 1 [12] ビス (TP; M3x6) X 4
[5] シールドイーサネット
ケーブル (3.0 m) X1
[9] ライセンス証書 X 1
F-1-3

19
19
取付け概略図
取付け概略図
[13] ワイヤサドル X 4 [15] 段ビス (M4) X 2[14] 歯付き座金付ビス
(バインド; M4x8) X 4
[16] ビス (TP; M3x6) X 6
2本使用
< CD/ ガイド類 >
・ メディアパック
・ クイックセットアップペラ
F-1-4
本体主電源 OFF の確認事項
本体の主電源が OFF であることを確認する。
1) 本体の主電源スイッチを OFF する。
2) 操作パネルの表示と主電源ランプが消えたことを確認してから電源プラグを外す。
電源接続時の確認
本機の電源プラグをコンセントに差込む場合、 本体と別系統のコンセントを使用すること。
取付け概略図
F-1-5

20
20
設置手順 > オープン I/F 基板の取付け
設置手順 > オープン I/F 基板の取付け
設置手順
オープン I/F 基板の取付け
1) ボックス左カバーを外す。
・ ビス 4 本
4x
2) リーダー通信ケーブルを外し、 ロックレバー 2 箇所を解除する。
1x
F-1-6
F-1-7
3) 取っ手を持ち、 メインコントローラー基板 2 を外す。
・ ビス 2 本
2x
4) 目隠し板を外す ( 外した目隠し板は使用しない )。
・ ビス 2 本 ( 外したビスは手順 8) で使用する )
メモ :
外した目隠し板はユーザーに渡し、 保管して頂くこと。
2x
F-1-8
F-1-9
