Canon imagePROGRAF IPF9100 User manual

GRAPHIC ARTS
LARGE-FORMAT PRINTING

SPECIFICATIONS
Print-Heads
PF-03 (2)
Technology
FINE (Full-photolithography Inkj t Nozzl Engin ring)
Configuration
Two Print-H ads
Print-H ad (L) Y/PC/C/PGY/GY/MBK
Print-H ad (R) PM/M/BK/R/G/B
Nu ber of Nozzles
2,560 p r Color; 30,720 Total
Droplet Size
Uniform 4 Picolit r for All Colors
Nozzle Pitch (Head Resolution)
Up to 1200 dpi
Print-Head Swath
1.07 inch
Print Resolution (Max.)
2400 x 1200 dpi
Ink Type
LUCIA Ink (Pigm nt-bas d)
Replace ent Ink Tank
PFI-702 (700ml) or PFI-302 (330ml) for Bk/MBk/GY/PGY
PFI-701 (700ml) or PFI-301 (330ml) for C/M/Y/PC/PM/R/G/B
Colors
Cyan, Photo Cyan, Mag nta, Photo Mag nta, Y llow,
Black, Matt Black, R d, Gr n, Blu , Gray, Photo Gray
Ink Tank Shipped with Printer
12 Colors (Full 330ml Each Color)
Ink Supply Method
Tubing Syst m with Sub-Tanks for Continuous Ink Supply
Nozzle Recovery Syste
Non-firing Nozzl D t ction and Comp nsation
Printer Controller
L-COA Controll r
Printer Me ory
640MB
Hard Disk Capacity
80GB
Media Feed
Roll Feed
On Roll, Front-Loading, Front Output
Cut Sheet
On Sh t, Front-Loading, Front Output
Media Width
Roll Feed
10”– 60”
Cut Sheet
8”– 60”
Mini u Media Length
8” (203mm)
Maxi u Print Length
Manual Feed
63” (1.6m)
Roll Feed
59’ (18m)*
Borderless Printing Width (Roll Media Only)
10”, 14”, 16”, 24”, 36”, 42”
B2 (20.28”/515mm), A1 (23.38”/594mm)
A0 (33.11”/841mm), B0 (40.55”/1030mm)
Media Cutter
Us r-r plac abl Durabl Rotary Blad (CT-06)
Media Thickness
0.07mm–0.8mm (2.8mil–31.4mil)
Media Core Sizes
2” (3” Cor with Optional 3” Cor Spool)
Media Output
Automatically Winding M dia Tak -up R l,
Bask t (Optional)
Printable Margins
Manual Feed (Top/F ont)
L ading and L ft/Right Edg s: 0.20” (5mm),
Trailing Edg : 0.90” (23mm)
Roll Feed
All Sid s: 0.20” (5mm) or 0” for Bord rl ss
Maxi u Media Roll Outer Dia eter
5.9” (150mm)
Built-in Hard Disk Capacity
80GB
Bundled Software
P inting Softwa e
Canon Print r Driv r, Print Plug-in for Photoshop®,**
Print Plug-in for Digital Photo Prof ssional, Print r Driv r
Extra Kit5(Fr Layout, imag RUNNER®Linking Function),
Print Plug-in for Microsoft Offic 55
Applications
Digital Photo Front-Acc ss55
Post rArtist (Optional)55
Utilities
GARO Status Monitor with SMTP E-mail Print r Status
Notification, M dia Configuration Tool, R mot UI
Printer Language
GARO (Canon Propri tary)
Operating Syste
g
Windows®2000 (32 bit), XP (32/64 bit), S rv r 2003
(32/64 bit), S rv r 2008 (32/64 bit), Windows Vista® (32/64
bit), Windows 7 (32/64 bit);
Macintosh®OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 -
10.6 (64 bit)
Interface
Standa d
USB 2.0; 10/100Bas -T/TX
Optional
IEEE1394 (Fir Wir ®)
Acoustic Noise
Ope ation
51dB or L ss
Standby
35dB or L ss
Acoustic Power (Operation and Standby)
6.7 B ls or L ss
Power Supply
AC 100–240V (50–60Hz)
Power Consu ption
Maximum
190W or l ss
Standby (100–120V)
5W or l ss
Powe Off (Standby, 100–120V)
L ss than 1W
(Compliant with Ex cutiv Ord r)
Certifications
Elect ical Safety Regulations
UL (USA), C-UL (Canada), S mark (Arg ntina),
CB c rtification (Oth rs)
Elect omagnetic Inte face Regulations
FCC Class B (USA), IC Class B (Canada)
Envi onmental Ce tifications
ENERGY STAR®(World Wid ), RoHS Dir ctiv ,
WEEE, Ex cutiv Ord r (USA)
Operational Environ ent
Tempe atu e
59–86 F° (15–30 C°)
Relative Humidity
10–80% (Cond nsation Fr )
Di ensions with Stand (H x W x D)
45" x 90.5" x 30.2" (1144mm x 2299mm x 766mm)
Weight with Stand
Approx. 362 lb. (162kg)
User-Replaceable Ite s
Ink Tanks
Print-H ad (PF-03)
Maint nanc Cartridg (MC-08)
Durabl Rotary M dia Cutt r (CT-06)
Options
IEEE1394 Expansion Board (EB-05)
Bask t (BU-01)
Post rArtist
2” Cor Roll Hold r (RH2-63)
3” Cor Roll Hold r (RH3-63)
* Th maximum printabl l ngth vari s d p nding on th application,
OS, and RIP us d. Th maximum printabl l ngth from Canon
Print r Driv r is 50 f t.
** For Adob Photoshop 6, 7, CS, CS2, CS3, CS4 running on
Windows 2000/XP/Windows Vista (32/64 bit)/Windows 7 (32/64
bit) or Macintosh OS X 10.2/10.3/10.4/10.5/10.6.
5Not compatibl with Windows 64-bit OS.
55 Windows 2000/XP/Windows Vista/Windows 7 (32 bit)
gFor Canon Print r Driv r. For printing from PostScript®applications
such as Adob Illustrator®or QuarkXPr ss®, pl as us a
PostScript compatibl RIP packag . For a list of Canon
r comm nd d RIP packag s, pl as consult with Canon Allianc
and Industry Mark t program list of RIP v ndors.
