Canon Creative Park Elastic-powered Duck User manual

1. Carefully cut out the parts.
2. Fold along the dotted lines, making mountain
or valley folds as indicated.
3. Attach the glue spots on each part together.
4. Glue the parts together, and you’re done!
*Please read the Assembly Instructions
carefully before you begin.
Tools
Scissors
Glue (We recommend quick-drying paper glue)
3 rubber bands (preferably brand new ones)
Actual size illustration:
check the size of your rubber bands here.
How to assemble your model neatly
Scoring along the fold lines in advance with a dried
up pen or a ruler with slightly sharp corners will result
in a neater model.
*Be careful not to press too hard as the paper may tear.
Caution
Keep scissors and glue away from small children.
Be careful not to cut your fingers when using scissors.
Scissors line
Cut in line
Glue spot
Notation Key
Assembly Instructions
About 1.57 inches in diameter
Mountain fold
Valley fold
Elastic-powered Duck : Assembly Instructions

Assemble the tires
Wind part H around and glue it down.
Glue down the end after rolling.
Attach part K, enveloping it
around the parts you cut
and bent back.
Attach the other side too.
View from above
Glue
Fold in half along the fold lines,
glue together at the back and make a ring.
Adding curves to the part first will make it
easier to form a ring.
Glue
Back
After gluing parts L and M together back to back,
attach the ring you have made.
Assemble the front tires using parts C, D and F, in the same way.
Assemble the axle
Add curves by pressing and rolling it
against the corner of a table,
with the printed side face up.
Fold the edge to make a triangular prism,
and roll the piece up to form a stick
(about 4mm wide).
Cut three, equally-spaced slots in both ends
of part G, up to the grey valley fold line,
and bend them back.
*The fine strips of paper are thick and hard
so be careful of paper cuts.
Glue
Attach part O to both ends.
Follow the same process to
assemble the other axle.
Elastic-powered Duck : Assembly Instructions

Tie one end of the band to the band stopper,
and the other end to the middle of the axle.
Glue together as shown in the diagram,
and assemble the duck's head.
Glue together as shown in the diagram,
and assemble the duck's body.
Glue together as shown in the diagram,
and assemble the duck's beak.
Assemble the front and back wheels
Cut the rubber band
to make a string.
If necessary, cut off the ends.
Attach the back tires to both ends of the axle.
Follow the same process to assemble
the front wheels.
*Do not attach a rubber band to the front wheels.
Assemble the head and beak
Do not attach.
Do not attach.
Fold along the fold line,
and glue together
at the reverse side.
Assemble the body
Elastic-powered Duck : Assembly Instructions

Attach the wheels
Assemble together
Glue
Attach. Attach.
Follow the fold lines,
and glue together
at the back.
After turning the duck's body over,
glue the tummy to it.
Being careful not to mix up the front and back wheels,
put the axles into the grooves on the body.
Check that the wheels spin smoothly.
Feed the band stopper through the hole
at the front of the body to the outside.
Be careful that the band doesn't come undone.
Check that the band stopper doesn't come loose,
and wind the rubber band around the back wheels
(with the larger tires).
Attach the duck's head and beak
to the completed body, and you're done!
Elastic-powered Duck : Assembly Instructions

If your car doesn't run well, check the following points to repair it.
Are the axles or tires stuck against the body? Are the wheels or tires bent?
Has the band lost its elasticity? Is the band wound up too tightly?
Has the band come loose from the tire? Is the band tangled up around the axle?
How to play
Pull the car backwards along the ground, gently
pushing down on the back wheels.
Point the car in the direction you want it to run,
let it go and watch it take off!
Be careful not to wind the band too tightly
as it may snap or come untied.
Play with it on a flat surface such as a table or the floor
(wooden floorboards work better than carpet).
