ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
BARRINGTON
STOOL
PRODUCT NO. 168-0112-6

We believe in the power of décor and its
ability to make up the fabric of your home.
That’s why CANVAS™collections draw
inspiration from Canadians and the way
they live.
From on-trend furniture pieces to holiday
décor and all your outdoor living essentials,
CANVAS™makes it easy to refresh your
space to re ect your unique style and the
way you live every day.
We would love to hear from you and welcome
your thoughtful feedback. Visit our website
at canadiantire.ca to tell us about your
experience, and share your photos with us
using #myCANVASstyle.
Show us how you bring CANVAS™products
to life. We can’t wait to see!

Parts List 4
Exploded View 5
Hardware List 6
Before You Begin Assembly 7
TABLE OF CONTENTS
TOOLS REQUIRED
• Pleasereadandunderstandthisentiremanualbeforeattemptingtoassemble,
operate,orinstalltheproduct.
• Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
• Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary.
• Topreventdamage,placeallpartsonalevelsurfaceduringassembly.Adda
layerofprotectivesurfaceifneeded.
• Duetothenatureofsteel,surfaceoxidation(rusting)willoccurifthisprotective
coatingisscratched.Thisisanaturalprocess.Tominimizethiscondition,itis
recommended that care be taken when assembling and handling the product in
ordertopreventthepaintfrombeingscratched.
WARNING!TOREDUCETHERISKOFSERIOUSINJURY,
READTHEFOLLOWINGSAFETYINSTRUCTIONSBEFORE
ASSEMBLINGANDUSINGTHEPRODUCT.
Hex Key 1 person
8
9
10
11
Assembly Guide
Technical Data
Troubleshooting
Warranty

BARRINGTON STOOL
4
PARTS LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
1 Seat 1
2Base 1

BARRINGTON STOOL
5
EXPLODED VIEW
1
2

BARRINGTON STOOL
6
HARDWARE LIST
ITEM DESCRIPTION THUMBNAIL QUANTITY
AHex Key 1
B ScrewM6 4
CWasher 4

BARRINGTON STOOL
7
BEFORE YOU BEGIN ASSEMBLY
?
MAKE SURE ALL PARTS ARE PRESENT
Compareallpiecestothepartsandhardwarelists,and
makesureyouhavealltoolsrequiredforassembly.
REMOVE PACKAGING MATERIALS
Place packing materials back in the box. Do not dispose of
packaging materials until assembly is complete.

READ EACH STEP CAREFULLY
Makesureyouunderstandeachstep.Ifyouhaveanyquestions,
contactCANVAS®customerserviceat1-888-670-6684(toll free)
ASSEMBLE IN A CLEARED AREA
Placeallpartsfromtheboxontheoorinfrontofyouinaclean,
dry,levelsurfacetoprotecttheproductasitisbeingbuilt.

BARRINGTON STOOL
8
ASSEMBLY GUIDE
STEP 1
1
2
A
B
C
Align the holes in the underside of seat 1with the holes in the
tabs on base 2. Attach using screws Bwith washers C.
Whenassembled,tightenthescrewswiththehexkeyA.
NOTE:
Do not tighten screws all
thewayuntilyouhave
assembled the stool. Once
assemblyiscomplete,
tighten each screw.
1
2
4
3
Fasten bolts in a
criss-cross pattern.
2 x1B x4 1 x1A x1C x4

BARRINGTON STOOL
9
TECHNICAL DATA
SPECIFICATIONS
ASSEMBLED DIMENSIONS (W x D x H) 17 3/4 x 19 3/4 x 37 1/4"
45.1 x 50.1 x 94.6 cm
ASSEMBLED WEIGHT 11 lb
5 kg
MAXIMUM WEIGHT CAPACITY 250 lb
113 kg
19 3/4"
(50.1cm)
37 1/4"
(94.6 cm)
19 3/4"
(50.1cm)
17 3/4"
(45.1cm)
26"
(66cm)
8 1/4"
(21cm)

BARRINGTON STOOL
10
CARING FOR YOUR ITEM
TROUBLESHOOTING
CALL US;
WE CAN HELP
BEFORE RETURNING
YOUR PRODUCT Ifyouhavequestionsregardingyourproductorrequire
warrantyassistance,pleasecallourcustomerservicehelpline.
TOLL-FREE:
1-888-670-6684
HAVING TROUBLE?
LET US HELP YOU!
1 Checkallnutsandboltsperiodicallyfortightness.Whenrequired,tightenthemagain.
CLEANING: Forbestresults,cleantheframeandfabricwithadampcloth,anddrythoroughly.

BARRINGTON STOOL
11
WARRANTY INFORMATION

ThisCANVAS™productcarriesaone(1)yearwarrantyagainstdefectsinworkmanshipand
materials.TrileafDistributionagreestoreplacethedefectiveproductfreeofchargewithinthe
statedwarrantyperiod,whenreturnedbytheoriginalpurchaserwithproofofpurchase.This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
PRODUCT NO. 168-0112-6
Made in China
ImportedbyTrileafDistributionTrifeuilToronto,CanadaM4S2B8
