INSTRUCTIONS FOR USE
WINE CELLARS
WCI45 & 46B Built-in
WCF32 Freestanding
For Spare Parts, Technical Advice
or Product Service call the
CAPLE HELPLINE on 0870 850 8734

2 of 8
Thank you for buying your new CAPLE Wine Cellar. To ensure that you get the best
results from your new purchase, we strongly suggest that you read this instruction
manual thoroughly before use. This manual contains installation advice, usage
instructions and other important facts about your CAPLE Wine Cellar. If treated with
care, your CAPLE Wine Cellar should give you many years of trouble-free use.
IMPORTANT WARNINGS AND ADVICE
• Unpack your cabinet carefully and remove all of the protective packing from inside and
outside the wine cellar.
• Packing (plastic bags, polystyrene, nails, metal, etc.) must not be left within the reach of
children because they are a potential source of danger.
• After unpacking, make sure that the appliance is in perfect order. If you have any doubt, do
not use it and contact the retailer or call a qualified engineer.
• Check that all the fittings are in the correct position on the inside of the cabinet.
• Release the mains lead which is fitted with a 13 amp UK type plug.
• Move your wine cellar to its final location.
• DO NOT MOVE YOUR CABINET WHILE LOADED WITH WINE as this could distort the
cabinet.
• Ensure that the specified ventilation instructions are adhered to.
• Do not try to modify the appliance's technical characteristics because this could be
dangerous
• This appliance should only be used for the specific purpose for which it was designed, i.e
storage of wine. It is not designed for food storage.
• Do not clean or maintain the appliance without previously disconnecting it.
• Ensure that you fully understand these instructions before operating this appliance.
• The manufacturer is not responsible for damage caused by incorrect, mistaken or irrational
use.
• Caple cannot be held responsible for any errors in this manual, or for any damage linked to
or following the provision, performance or use of wine cellar.
• The information in this document is subject to modification without prior notice.
DISPOSAL OF OLD APPLIANCE
Discarded appliances are potentially dangerous to CHILDREN.
Before you throw away your old Wine Cellar:
• Take off the door. Leave the shelves in place so that children may not easily climb
inside.
• Never allow children to operate, play with, or crawl inside the appliance.

3 of 8
INSTALLATION INSTRUCTIONS
BEFORE TURNING ON THE WINE CELLAR ENSURE IT IS PERFECTLY LEVEL
Your cabinet is equipped with 4 adjustable feet. However, we do recommend that you tighten
the back feet to the maximum and use the front feet to create a level.
Stainless Steel Plinth for WCi46B (Supplied separately)
When the Wine Cellar is installed in the final position the stainless steel plinth should be fitted:
Remove the protective tape from the adhesive strips on the rear of the plinth.
• Place firmly in position onto the bottom of the Wine Cellar cabinet.
THE FLOW OF AIR THROUGH THE GRILL MUST NOT BE OBSTRUCTED AT ANY
TIME. FAILURE TO ADHERE TO THIS WILL INVALIDATE THE GUARANTEE.
DOOR REVERSAL
WE RECOMMEND SOMEONEASSISTYOU DURING THIS PROCESS. TOOLS REQUIRED:
PHILIPS SCREWDRIVER. ALSO SUPPLIED WITH EACH CABINET IS A LEFT HAND
BOTTOM HINGE.
• Lay the unit on its back.
• Remove the three (3) screws from the bottom hinge and remove the bottom hinge.
NOTE: Keep this hinge in a safe place in the event you ever need to revert back to a right hand
door swing.
• Remove the door from the cabinet and carefully set aside.
• Remove the two (2) plastic screw covers located on top of the hinge cover.
• Remove the screws holding the hinge cover to the top hinge.
• Remove the three (3) plastic screw covers from the top hinge.
• Remove the top hinge.
• Remove the three (3) plastic screw covers from the top left side of the wine cellar.
• Install the top hinge on the left side of the unit and secure with three (3) screws.
• Install the hinge cover back on the top hinge.
• Install the two (2) plastic screw covers to the top right hand side of the cabinet.
• Carefully install the door on the cabinet. (Insert upper door into top hinge pin.)
• Using the left hand bottom hinge (To order), insert the hinge pin into the bottom of the
door. (Align the hinge holes with the holes in the cabinet, and secure to cabinet with
three (3) screws.
• Check alignment of door and door seal before tightening screws.
• Tighten all hinge screws.
• Place unit in the upright position.
IMPORTANT: WAIT 2 HOURS BEFORE TURNING ON THE WINE CELLAR.

4 of 8
SAFETY INSTRUCTIONS
Freestanding model WCF32
• The place you have selected for your cabinet should be well ventilated.
• This is a FREESTANDING product and the sides and top of the cabinet must have a
clear 10cm air gap to allow for cooling.
• A minimum 10 cm space must be left between the wall and the back of the cabinet.
Built-in model WCI45B
• The built-in model is provided with a fan to evacuate heat via the bottom vents.
• Must be well away from any heat source.
• Must not be in direct sun light.
• Must not be in a damp location (laundry, pantry, bathroom, etc)
• Must be perfectly level.
• Must have a correctly installed and reliable electricity supply correctly earthed.
• It is not recommended to use a multi-socket or extension lead.
Earthing Instructions
• This wine cellar must be earthed in the event of an electrical short circuit.
• This wine cellar is equipped with a power cord having an earth wire terminating in a
13amp UK plug.
• Consult a qualified electrician or service person if the earthing instructions are not
completely understood.
WARNING: IMPROPER USE OF THE GROUNDING PLUG CAN RESULT IN THE RISK OF
ELECTRIC SHOCK.
OPERATING INSTRUCTIONS
There are 2 different temperature control systems:
For WCI45B Electrical dual zone, built-in model
For WCF32 Mechanic control, freestanding model.
Before starting the wine cellar, ensure that the cabinet is level. This will eliminate any vibrations.
Note: -
The power (RUN) indicator light is located on the LED control panel inside the unit and
illuminates when the compressor (cooling) cycle is working and turns off when the compressor
(cooling) cycle is finished.

5 of 8
SETTING THE TEMPERATURE CONTROLS
ELECTRICAL DUAL ZONE (Model WCI45B
1. Each cooling compartment of the wine cooler (upper & lower) is independently
controlled.
2. To set the temperature: Connect the power cord to a properly grounded outlet. In the
event of a power interruption, all previous temperature settings are automatically
erased and each compartment will default to a preset temperature setting of: 6oc for
upper compartment and 12oc for lower compartment.
3. Set the desired cooling temperature by pressing the buttons adjacent to the “set
upper/set lower” program. Each depression of the buttons will scroll through the
available temperature settings (for each compartment) in increments of 1 degree. The
temperature selected will flash in the LED display for approximately 5 seconds, then
revert back to display the temperature of the internal cabinet
4. Upper compartment: The temperature setting can be adjusted from 5oc to 10oc.
5. Lower compartment: The temperature setting can be adjusted from 10oc to 18oc.
6. To view the “set” temperature. (anytime) press and hold the corresponding button for
approximately 5 seconds, the “set” temperature will temporarily “flash” in the LED
display for 5 seconds.
7. Flashing LED = Set Temperature
8. Steady LED = Cabinet Temperature
9. This unit has the option to display temperatures in either Celsius or Fahrenheit. To
change the setting, press and hold both buttons (Set Upper/Set Lower) simultaneously
for approximately 5 seconds, a prompt (beep) will sound and the blue pilot light
adjacent to the C or F mode illuminates.
NOTE:
To temporarily disconnect (stop) the cooling cycle, you must disconnect the power cord from the
electrical outlet. NOTE: There is no “OFF” position on the electronic control panel. When
disengaging cooling (operation) for long periods of time, leave the door partially open to prevent
mould/mildew from forming inside the cabinet.
NOTE:
Always wait 4 minutes before restarting the unit if operation has been interrupted.
RUN
Lower chamber Upper chamber
Set upper
Set lower

6 of 8
MANUAL CONTROL (Model WCF32)
1. The initial setting is NORMAL. Please run the wine cellar empty at least 30 minutes before
adjustment.
2. “MAX” can be adjusted from 5oc to 9oc . “NORMAL” can be adjusted from 10oc to 14oc .
“MIN” can be adjusted from 15oc to 18oc.
INTERIOR LIGHTS
The interior lights operate “automatically” with the opening/closing of the door. The light turns on
when the door is open and turns off when the door is closed.
DEFROSTING/CONDENSATION
Your wine cellar is designed with an “Auto-cycle” defrost system. During the “Off Cycle” the
refrigerated surfaces of the wine cellar (interior rear wall) defrost automatically. The defrost
water is channeled into a condensate drain pan which is located at the back of the wine cellar
next to compressor from where it evaporates.
CARE AND MAINTENANCE
Upon receiving your wine cooler, leave the door open for 24 hours. When cleaning the inside of
the wine cooler you can use a solution of a tablespoon of baking soda to one (1) quart of water,
or a mild soap suds solution, or some mild detergent. Wood shelving does not require cleaning.
To clean the exterior cabinet of your wine cooler, use a soft damp cloth with mild detergent or
appliance cleaner.
STORAGE OF WINE
The humidor should be positioned in the center of the top rack in each compartment.
To achieve maximum storage capacity, it will be necessary to position (store) the bottles
alternately on the racks. (See below diagram)
Humidor

7 of 8
TROUBLE SHOOTING GUIDE
You can solve many common Wine Cellar problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling the
service engineer.
PROBLEM POSSIBLE CAUSE
Wine Cellar does not operate. Not plugged in.
The appliance is turned off.
The circuit breaker tripped or a blown fuse.
Wine Cellar is not cold enough. Check the temperature control setting.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Turns on and off frequently. The room temperature is hotter than normal.
A large amount of contents has been added to the
wine Cellar.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work. Not plugged in.
The circuit breaker tripped or a blown fuse.
The bulb has burned out.
The light button is “OFF”.
Vibrations. Check to assure that the Wine Cellar is level.
The Wine Cellar seems to make too much noise. The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
Wine Cellar.
Contraction and expansion of the inside walls may
cause popping and crackling noises.
The Wine Cellar is not level.
The door will not close properly. The Wine Cellar is not level.
The door was reversed and not properly installed.
The gasket is dirty.
The shelves are out of position.

8 of 8
HUMIDITY MAINTENANCE SYSTEM
The wine cellar is equipped with a system for maintaining the correct level of humidity. If
humidity is too low, insert the small plastic reservoir on to the top rack of the wine cooler. Fill this
reservoir 3/4 full with water. Check water level occasionally and refill as necessary.
RECOMMENDED TEMPERATURE
For keepingALL TYPES OF WINES 12oc to 14oc
Wine service temperature (Provided as an indicator only)
Champagne NV, Sparkling 6oc
Champagne Vintage 10oc
Dry White Semillon, Sauvignon Blanc 8oc
DryWhiteGewurstraminer,Riesling 10oc
Dry White Chardonnay 10oc
Vintage chardonnay 14oc
Sweet White Sauternes Monbazillac, Late Harvest ice wine 10oc
Sweet whites vintage Sauternes 14oc
Beaujolais 13oc
RedPinotNoir 16oc
Vintage Pinot noir red 20oc
Red Cabernet, Merlot, French,Australian, New Zealand, Chilean,
Argentinean, Italian, Spanish, Californian 20oc
RedGrenache,Syrah 16oc
