CAS CL5000J Series User manual

1
CL5000J Series
User’s Manual
Rev 2007.09.06

2
Table of Contents
1. GENERAL ........................................................................................................................................................ 5
1.1 PRECAUTIONS ....................................................................................................................................... 5
1.2 INTRODUCTIONS................................................................................................................................... 7
1.3 SPECIFICATIONS ................................................................................................................................... 8
1.4 NAME AND FUNCTIONS ..................................................................................................................... 10
1.5 Basic set-up ......................................................................................................................................... 12
1.6 SYMBOLS.............................................................................................................................................. 13
1.7 KEY FUNCTIONS ................................................................................................................................. 13
1.8 Installation of the Label Roll ................................................................................................................ 16
2. PROGRAMMING ............................................................................................................................................ 19
2.1 PLU Programming................................................................................................................................. 21
2.1.1 Create By-Weight PLU (Menu code 1120) .............................................................................. 22
2.1.2 Create By-Count PLU (Menu code 1120) ................................................................................ 27
2.1.3 Create By-PCS PLU (Menu code 1120) ................................................................................... 32
2.1.4 Editing PLU (Menu code 1120) ................................................................................................. 37
2.1.5 Expand PLU (Menu code 1144) ................................................................................................ 37
2.1.6 Listing PLU (Menu code 1150) ................................................................................................. 37
2.2. Programming PLU Data Table I .......................................................................................................... 38
2.2.1 New/Edit Sales Message (Menu code 1240) ............................................................................ 38
2.2.2 Origin (Menu code 1250) ........................................................................................................... 39
2.2.3 Barcode (Menu code 1260) ....................................................................................................... 40
2.2.4 Tare (Menu code 1270) ............................................................................................................. 42
2.2.5 List Unit Symbol (Menu code 1280) ......................................................................................... 43
2.3 Programming PLU Data Table II .......................................................................................................... 44
2.3.1 Ingredient (Menu code 1310) .................................................................................................... 44
2.4 Speed Key Setting ................................................................................................................................ 45
2.4.1 Speed Key (Menu code 1160) ................................................................................................... 45
2.5 Programming Store Data ...................................................................................................................... 46
2.5.1 Store Data (Menu code 1410) ................................................................................................... 46
2.6 Programming Global Setting................................................................................................................. 47
2.6.1 Global Label Format (Menu code 1510) ................................................................................... 47
2.6.2 Barcode Format (Menu code 1520) .......................................................................................... 48
2.7 Printing Programming........................................................................................................................... 49
2.7.1 Printing (Menu code 1700) ........................................................................................................ 49
2.7.2 Print Inhibit Item(Menu code 1710) ........................................................................................ 49
2.7.3 Printer Hardware (Menu code 1730) ........................................................................................ 50
2.7.4 Label Size (Menu code 1732) .................................................................................................... 50

3
2.7.5 Sensor Calibration (Menu code 1733) ...................................................................................... 50
2.7.6 Sensor & Motor (Menu code 1734) .......................................................................................... 50
2.7.7 Print Intensity (Menu code 1735) ............................................................................................. 51
2.7.8 Adjust Feed Length (Menu code 1736) .................................................................................... 51
2.7.9 Label Preprint (Menu code 1737) ............................................................................................. 51
2.7.10 Printer Initialize (Menu code 1738) ........................................................................................ 51
2.8 Programming Scale Configuration........................................................................................................ 52
2.8.1 Department (Menu code 1830).................................................................................................. 52
2.8.2 Date & Time (Menu code 1840)................................................................................................ 52
2.8.3 Change Password (Menu code 1852) ....................................................................................... 53
2.8.4 Display Test (Menu code 1861) ................................................................................................ 53
2.8.5 A/D Test (Menu code 1862)...................................................................................................... 53
2.8.6 Keyboard Test (Menu code 1863) ............................................................................................ 53
2.8.7 Chess Printer Test (Menu code 1864) ..................................................................................... 53
2.8.8 Scale Parameter (Menu code 1870).......................................................................................... 54
2.8.9 Clear Memory (Menu code 1890) ............................................................................................. 54
2.8.9.1 Clear PLU (Menu code 1891)................................................................................................. 54
2.8.9.2 Clear Table1 (Menu code 1892) ............................................................................................ 54
2.8.9.3 Clear Table2 (Menu code 1893) ............................................................................................ 54
2.8.9.3 Clear ALL (Menu code 1894) ................................................................................................. 54
2.9 Report.................................................................................................................................................... 55
2.9.1 Report Menu (Menu code 1600)................................................................................................ 55
2.9.2 Print Report (Menu code 1610)................................................................................................. 55
2.9.3 Scale Sales Report (Menu code 1611) ...................................................................................... 55
2.9.4 PLU Report (Menu code 1612).................................................................................................. 55
2.9.5 Miscellaneous PLU Report (Menu code 1613) ......................................................................... 56
2.9.6 Group Report (Menu code 1614)............................................................................................... 56
2.9.7 Deptment Report (Menu code 1615) ......................................................................................... 56
2.9.8 Hourly Report (Menu code 1616).............................................................................................. 57
2.9.9 Clear All Report (Menu code 1650) .......................................................................................... 57
2.10 Communicaation.................................................................................................................................. 58
2.10.1 Communication (Menu code 1900).......................................................................................... 58
2.10.2 Network Setting (Menu code 1910) ........................................................................................ 59
2.10.3 DHCP (Menu code 1912) ......................................................................................................... 59
2.10.4 IP (Menu code 1913)................................................................................................................ 60
2.10.5 RS232C Setting (Menu code 1915) ......................................................................................... 60
3. SALES OPERATION...................................................................................................................................... 61
3.1 Basic Operation..................................................................................................................................... 61
3.2 Zero....................................................................................................................................................... 61

4
3.3 Tare....................................................................................................................................................... 61
3.3.1 Manual Tare Entry ..................................................................................................................... 62
3.3.2 Weighed Tare Entry................................................................................................................... 62
3.3.3 How to Clear Tare ..................................................................................................................... 63
3.3.4 Preset Tare ................................................................................................................................ 63
3.3.5 Successive Tare......................................................................................................................... 63
3.3.6 Tare Override............................................................................................................................. 64
3.4 Calling Up a PLU .................................................................................................................................. 65
3.4.1 Using Numeric Key .................................................................................................................... 65
3.4.2 Using Speed Key........................................................................................................................ 65
3.5 Override (FOR key) .............................................................................................................................. 66
3.5.1 By-Weight PLU.......................................................................................................................... 66
3.5.2 By-Count PLU............................................................................................................................ 67
3.5.3 By-PCS PLU .............................................................................................................................. 68
3.6 Sales Operation..................................................................................................................................... 69
3.6.1 Weighed Item Operation ............................................................................................................ 69
3.6.2 By Count Item............................................................................................................................. 70
3.6.3 By PCS Item ............................................................................................................................... 71
3.7 Add-Up Transaction............................................................................................................................. 72
3.8 Void....................................................................................................................................................... 74
3.9 Return.................................................................................................................................................... 75
3.10 Prepack Key ....................................................................................................................................... 76
3.11 Direct Discount ................................................................................................................................... 77
3.11.1 % Discount Price Key .............................................................................................................. 77
4. Appendix........................................................................................................................................................ 78
4.1 Label Format (TO DO : change)........................................................................................................... 78
4.2 Label Format Sample............................................................................................................................ 82
4.3 Label Field ............................................................................................................................................ 83
4.3.1 Item Label Field (TODO : change) ............................................................................................ 83
4.4 ASCII Code Table ................................................................................................................................. 84
4.5 Window Character Set Information ...................................................................................................... 85

5
1. GENERAL
1.1 PRECAUTIONS

6
※This equipment is indoor use and all the communication
wirings are limited to inside of the building.

7
1.2 INTRODUCTIONS
Thank you for purchasing the CAS CL5000J price computing electronic
printing scale. We have designed this equipment with many advanced features,
high quality construction, and user-friendly menu driven programming. We are
confident that you will find the CAS CL5000J scale will meet all of your most
demanding needs.
Remember, for proper installation and maintenance please have your
Authorized CAS Dealer do the primary installation, programming, and
demonstration. Your CAS Authorized Dealer also has a wide variety of supplies,
accessories, and expansion options for whatever your new and increasing demands
may require. Authorized CAS dealers are trained to help you with every aspect of
the CL5000J and should you need servicing, they are expertly trained by CAS to
assist you with virtually any problem.

8
1.3 SPECIFICATIONS
Max. Capacity
3/6 kg
6/15 kg
15/30 kg
Interval
1/2 g
2/5 g
5/10 g
Max. Tare
- 2.999 kg
- 5.998 kg
- 9.995 kg
A/D Conversion Rate
Approx. 8 times/sec.
Measurement Type
Load Cell
Platter Size
380 x 244 mm
Key
Standard
Type
(B)
48 PLU key,
36 function key
Pole Type(P,R)
72 PLU key,
36 function key
Speed Key
96 PLU
144 PLU
Display
VFD
Preset Tare : 4 digit
Weight : 5 digit
Unit Price : 6 digit
Total Price : 6 digit
Printer
Speed 75 mm/sec.
Printing Resolution
202 dpi
Label Size
Width: 40mm~60 mm
Length: 30mm~80 mm
Barcode Type
EAN13, I2OF5, CODE128C
Font
Small, Middle, Large Size, Free Format, Italic, Bold, Underline, Through Line, Double
through line, Reverse, shadow, outline
Printer Type
DIRECT THERMAL PRINT
Operating Temp.
-10° C~ 40° C (14° F~ 104° F)
Power
AC 100~240V 50/60Hz 1.5A

9
Number
Range
Programmable Data
PLU
6000
1-999999
direct ingredients 300 chracter
1000
PLU
Indirect Ingredient 400 character
100
1~100
User Defined Barcode Format
20
1~20
Department
99
1~99
Origin
500
1~500
Group
99
1~99
Bitmap Image
5
1~5
Quantity Symbol
8
1~8
Report
Tare Table
99
1~99
Label Format
30
1~30
10
51~60
Sales Period
user selectable reporting period.
Sales Report Mode
Read & Reset
Note: Specifications are subject to change without notice.

10
1.4 NAME AND FUNCTIONS
■Standard Type ■Pole Type P
■Pole Type R

11
DISPLAY
TO DO : Insert Picture
KEYBOARD
B-Type (Standard)
P Type, R-Type (pole type)

12
1.5 Basic set-up
How to install tray
B,P,R type

13
1.6 SYMBOLS
SYMBOLS
DESCRIPTION
ST ( )
Stable indicator
▶0◀
Zero weight indicator
NET ( )
Net weight indicator
AUTO
Auto Print Mode indicator
SAVE
Auto clearing status indicator
PREPACK
Prepack Mode indicator
DC ( )
Discount status indicator
SHIFT ( )
Speed key shift status indicator
TR
Data transmission status indicator
1.7 KEY FUNCTIONS
KEYS
FUNCTIONS
~
Numeric keys. Used to enter pricing, qty, count, tare,
etc.
Double zero key
Clear key. Used to clear erroneous entries and error
conditions.
Re-Zero key. Use to remove small variations in the
scale’s zero.
Tare key. Use to manually enter and remove tare
weights.
Override key. For temporary price change entry.
Date & Time key. Toggles the display between time,
date, scale number and department number.
MENU key. This key toggles from program menu to
sale mode.
Page up key: CL5000 only
For key. Use this key for by- count or by pcs pricing:
3 @ 3 FOR $1.00. It toggles between the QTY, PIECE,
and PRICE fields.
0
9
00
C
ZERO
TARE
OVER
RIDE
DATE
/TIME
▲
MENU
PG UP
FOR

14
AUTO key. Auto-print mode
Pre-Pack key. Used to enter Pre-Packaging mode in
which the scale Auto-prints for every transaction and
prevents the auto clearing of data.
Save key. Save mode prevents the auto clearing of
any called-up data like tare weight, PLU pricing, etc.
Void key. To remove erroneous sales from ADD-Up
When you type a PLU number and press this key, it
calls-up that PLU.
ADD-Up key. This key when used in conjunction with
ST/TTL key allows you print a customer-total label as
well as individual transaction labels.
Page Down key. CL5000 only
Multi-Label key. Use this key to print multiple sales of
the same transaction.
Escape key. It is used to exit in program mode.
Subtotal / Total key. Used with the ADD key in order
to print customer-totals.
Feed key. Use this key to feed labels or paper through
printer
Pay key. Use this key to calculate change.
Test key.
Print key. Used to manually print transactions and
also serves as an ENTER key.
Return key. Used to credit sales for erroneous
transactions or returns.
Shift Key. Used to SHIFT function in program Mode
Discount % key. Used to discount price.
Insert key: CL5000 only
WT/CT key. Toggles between Weight PLU and Count
PLU.
CAPS Key: Used to type a small letter in program
mode.
Miscellaneous By-Weight PLU key.
Miscellaneous By-Count PLU key.
FEED
PAY
TEST
PRINT
RETURN
SHIFT
DISC%
INSERT
WT/CT
CAPS
MISC.
By
WEIGHT
MISC.
BY
COUNT
AUTO
PRE
PACK
◀
SAVE
VOID
▶
PLU
▼
ADD
PG DOWN
X
ESC
ST
TTL

15
Negative Discount
DELETE key. CL5000 only
~
Alpha keys. Used to type text data.
Used to type $
For future
Backspace key. Used to backspace and delete text
data.
Space bar.
Used to go to next line to enter text
~
Special symbol keys.
Used to type special symbol. (See ASCII code table on
page 192)
Note : Xkey is only used in sale mode and ESC key is only used in program
mode.
Sale mode : X key
Program mode : ESC key
X
ESC
DISC-
DEL
A
Z
$
Currenc
y
←
SPACE
/
Ü
CHAR

16
1.8 Installation of the Label Roll
■Label Specifications
Outer diameter of roll : 100mm
Inner diameter of roll : 40mm
Width of receipt roll : 40, 50, 60mm
Width of label roll : 60mm(MAX)
■Print Area
Width of label : 60mm(MAX)
Length of label : 80mm(MAX)

17
To install the label roll at ANY time you must follow the directions in this
section:
1) Press the ON/OFF key and make sure that the display is completely off. Open the
printer’s side-access panel. (See fig.1)
2) Lift up TPH lever as fig 2.
3) Remove cartridge as fig. 3.
4) Remove Pick-Up Spool assembly and paper guide from the cartridge as fig. 4.

18
4
5) Place the label in the scale as fig. 5
5
6) Press the FEED key.
*If label position is not correct, you have to check follows :
a, Label size.(Label setting menu)
b. Feed Adjustment .(Feed adjustment menu)
c. Sensor calibration(Sensor Calibration menu)

19
2. PROGRAMMING
Program Mode Menu Tree (Menu code : 1000)
CODE
Menu
CODE
Sub Menu
CODE
Sub Menu
1100
PLU
1120
New/Edit
1150
LIST
1144
Expand
1160
Speed Key
1200
PLU Table1
1240
Sales Message
1250
Origin
1260
Barcode
1270
Tare
1280
Unit Symbol
1300
PLU Table2
1310
Message
1400
Store Data Table
1410
Store
1500
Global Setting
1510
Label Format
1520
Barcode
1600
Report
1610
Report Print
1611
Scale
1612
PLU
1613
Misc. PLU
1614
Group
1615
Department
1616
Hourly
1650
Clear All
1700
Printing
1710
Print Label Item
1730
H/W Setting
1732
Label Size
1733
Sensor Calibration
1734
Peel Sensor
1735
Print Intensity
1736
Adjust Feed Length
1737
Label Preprint
1738
Initialize Printer
1800
Scale Config
1830
Department/Store/speed key number
1840
Date/Time
1852
Change Password
1860
Test
1861
Display
1862
A/D
1863
Keypad
1864
Chess Printer
1865
Printer Sensor
1870
Scale Parameter
1890
Clear Memory
1891
PLU
1892
Table1
1893
Table2
1894
All

20
1900
Communication
1910
Network
Setting
1912
DHCP
1913
IP
1915
RS232C Baudrate
How to access PROGRAM MODE
You can see the Program Menu screen by pressing the MENU key.
You can use both keys, DATE-TIME/▲and PLU/▼to move other menu. Once you choose a
suitable menu, press PRINT key to execute program.
NOTE: Refer to the function keys avaiable program and calibration menu.
Program and Calibration Menu, Function Key
Description
DATE-TIME/▲, PLU/▼
Selects a different menu
PRINT
Executes command or selects the submenu
X/ESC
Exits the Menu
Digit 1100 indicates Menu code. You should press PRINT key at prior menu to see sub menu screen
as below.
Edit
1120
PLU
PLU
1100
PGm
PLU
1100
PGm
Other manuals for CL5000J Series
1
Table of contents
Other CAS Scale manuals
