CAS DB-II series User manual

2

3
CONTENTS
PRECAUTIONS......................................................... 4
PREFACE........................................................................ 6
NAMESAND FUNCTIONS.............................. 6
OPERATIONS............................................................. 8
SETUPMODE........................................................... 20
ERROR MESSAGES............................................ 25
SERIALINTERFACE.......................................... 25
SPECIFICATIONS................................................. 26
HOWTO INSTALLDB –II Series............... 27
ASSEMBLINGTHE DISPLAY
OF DB-II WALLTYPE........................................ 28

4
PRECAUTIONS

5

6
PREFACE
Thank you for the purchasing of CAS DB-II series.
This series have been designed with CAS reliability, under rigid quality control
and with outstanding performance. Your specialty departments can enjoy with
CAS products.
We hope that CAS product meets your needs.
The user manual is designed to guide you to understand product operation and
proper care of product.
NAMESAND FUNCTIONS
OVERALLVIEW

7
DISPLAYAND KEYBOARD
■KEY FUNCTIONS
KEYS DESCRIPTIONS
Used to set the zero point to 0.00.
Used as an ESC key in Setup Mode.
Used to enter a tare weight and used to cancel a tare weight.
Used to convert the mode as below.
[WEIGHING] [pcs] [%][WEIGHT LIMIT ON/OFF] 
[COUNT LIMIT ON/OFF] [UNIT CONVERSION] [WEIGHING]
Used as an ENTER key.
Used to calculate a unit weight of a sample.
[ ] Used to enter next digit.▶
Used to display average weight.
[▲] Used to have number up.

8
KEY DESCRIPTIONS
PRINT key.
[▼] Used to have number down.
Used to turn ON or OFF the power.
OPERATIONS
1. General Weighing
■The display indicates if the scale is at zero or if there is a tare entered into the
scale by way of a ZERO and NET.
①Turn on the power.
The display shows 0.00.
Make sure that STABLE and
ZERO lamps are on.
②When the display is not zero
though there is nothing on
the platter, press the ZERO
key.
③Place an item on the platter.
When the STABLE lamp is
on, read the weight.
2. Weighing with Tare
■Tare is the weight of container being used for a commodity.
The TARE key subtracts the weight of the container.
①Place the container on the
platter.
②Press the TARE key, NET
lamp is on.
③Place an item in the
container.

9
④To release the TARE function, remove an item and
container from the platter and press the TARE key.
3. Counting Mode
■If you want to count parts, first you have to set sample size.
OR
①Press the MODE key until the display shows “PCSSET”. Make
sure that PCS lamp is on. If you have set sample size before,
the display shows “0”.
②Press the SAMPLE key,
then the display shows “10”.
③If you want to increase sample size, press the SAMPLE key.
The display shows 10, 20, 30, 40, 50, 100, 150 and 200 every
time pressing the SAMPLE key.
④If you set sample size to 10, place 10 samples on the platter.

10
⑤If the display shows “LACK”, the counting result may not correct. (LCD version : Lack of Unit lamp is On) If the
display shows “ LOW”, it is impossible to count samples because the unit weight is too small. (Refer to Table 1)
Model DB-II6kg DB-II15kg DB-II30kg DB-II60kg DB-II150kg DB-II300kg
Range of Lack (Single) 2g ≥Lack ≥0.1g 5g ≥Lack ≥0.1g 10g≥Lack ≥0.1g 20g ≥Lack ≥1g 50g ≥Lack ≥1g 100g ≥Lack≥1g
Range of Lack (Dual) 1g ≥Lack ≥0.1g 2g ≥Lack ≥0.1g 5g ≥Lack ≥0.1g 10g ≥Lack ≥1g 20g ≥Lack ≥1g 50g ≥Lack ≥1g
Range of Low 0.1g ≥Low 0.1g ≥Low 0.1g≥Low 1g ≥Low 1g ≥Low 1g ≥Low
< Table 1 >
⑥Place parts on the platter, then the display shows the number
of parts. You can also use tare function in counting mode.
4. Percent Weighing Mode
■The weight is displayed as a percentage of the reference.
OR
①Press the MODE key until the display shows “PErSEt”. If you
have set reference sample before, the display shows “0.0”.
②If you want to use container,
place it and press the TARE key.
③Place reference sample on the platter and press the SAMPLE
key.
T
he display shows “100.0”.
Make sure that reference sample should be bigger than 3% of
maximum capacity. If it is lower than 3% of maximum capacity,
t
he display shows “low”. In this case, increase the weight of
reference sample and press the SAMPLE key.

11
5. Hold Function(Weight Mode ONLY)
■Key hold
①Place an item on the platter and then press the HOLD key.
①“HOLD” is shown on the
display.
②Average weight is shown on
the display.
■After average weight display 3 times, HOLD function will be release automatically.
■Auto Hold function
①After weighing item
remove all of the container
from the platter, press Hold key.
②Use “TARE” key to select
one of Auto Hold function.
③Press “Hold” key to save
and exit to normal mode.
④Place an item on the platter.
Then weight display will show “Hold”.
The “Hold” blinks for two times, and then
the average weight blinks continuously.
⑤After remove the item of the platter, place another item on the platter.
Then display will show average weight again.
If you don’t want use auto-hold function, remove the item and press hold key.
Display shows AH_on. Press tare key. İt will be changed AH_off.
Then press Hold key. Auto-hold function will not operate.
④Place an item on the platter, then the weight is displayed as a
percentage of the reference.

12
6. Cumulative Weight Sum
The function of cumulative weight sum is to be showing the aggregate times and
weight as adding the value of weighing a several times. Even though power is
off, the scale stores data. This function is only available in weighing mode.
①Place an item on the platter. ②To add this weight, press the SAMPLE key. Make sure that
SUM lamp is on.
③The display shows cumulative weight sum and aggregate times every time pressing the SET key.
The SUM key is flashed.
④To cancel last added weight, press the SET key to display cumulative weight sum or aggregate
times and then press the SAMPLE key. The display shows “S SUB”.

13
⑤You can delete cumulative weight sum or aggregate times. Press the SET key to display
cumulative weight sum or aggregate times and then press the ZERO(ESC key).
⑥To print out cumulative weight sum, press the SET key to display cumulative weight sum or
aggregate times and then press the PRINT key. (DEP only)

1
4
7. Weight Comparison Function(HI/OK/LOW)
7-1. How to compareweight
①Press the MODE key until
the display shows “WL OFF”.
It means that weight limit
function is deactivated.
②Press the HOLD key to
activate this function, the
display shows “WL ON”.
③Press the SET key to set up
low value, the display shows
“L000.00”.
④Press the HOLD(▲) or
PRINT(▼) key to have
number up or down. To enter
next digit, press the SAMPLE
key.
⑤Press the SET key to set up
high value, the display
shows “H000.00”.
⑥Press the HOLD(▲) or
PRINT(▼) key to have
number up or down. To enter
next digit, press the
SAMPLE( ) key.▶
⑧If you set up LOW/HIGH limit wrong, “WL ERR” will be shown on the display. Then you have to set it
up again. For example) LOW=100.00kg HIGH=90.00kg High limit is lower than Low limit.
⑨Press the MODE key to go to weighing mode.
⑦Press the SET key, the
display shows “WL ON”.

15
⑩Suppose that the High limit of 70kg and the Low limit of 30kg are set up. In this condition, OK lamp is
lighted on if the weight is 40kg, HI lamp is lighted on if the weight is 80kg and if the weight is 20kg,
LO lamp is lighted on. It beeps as fixed on User Setup Mode.
(Refer to Setup Mode Table on page 17)
7-2. Counting comparison function
①Press the MODE key until
the display shows “CL OFF”.
It means the counting
comparison function is
deactivated.
②Press the HOLD(▲) key to
activate this function, the
display shows “CL ON”.
③Press the SET key, the
display shows “L00000”.
④Press the HOLD(▲) or
PRINT(▼) key to have
number up or down. To enter
next digit, press the
SAMPLE( ) key.▶
⑤Press the SET key, the
display shows “H00000”.
⑥Press the HOLD(▲) or
PRINT(▼) key to have
number up or down. To enter
next digit, press the
SAMPLE(▶) key.

16
⑧If you set up LOW/HIGH limit wrong, “CL Err” will be shown on the display. Then you have to set it
up again. For example) LOW=00100, HIGH=00090 or LOW=00100, HIGH=00100
⑨Press the MODE key to go to weighing mode.
⑩Suppose that the High limit of 200 and the Low limit of 80 are set up. In this condition, OK lamp is
lighted on if the weight is 120, HI lamp is lighted on if the weight is 220 and if the weight is 60,
LO lamp is lighted on. It beeps as fixed on User Setup Mode.
(Refer to Setup Mode Table on page 17)
⑦Press the SET key, the
d
isplay shows “CL ON”.

1
7
8. Print Out
8-1. Manual Print
■You can print out data every time pressing the PRINT key. You can setup
print function depends on your need. Refer to Setup Mode Table on page 20.
Sample format(DEP-50):
-Weighing Function-
======== WEIGHT ========
WELCOME TOCAS
DATE . 07/30/2007
TIME. 17:35:58
Weight: 0.000kg
-Counting Function-
======== COUNT ========
WELCOME TOCAS
DATE. 07/30/2007
TIME. 17:35:58
Weight: 40.200kg
Quantity: 50pcs
- WEIGHT LIMIT SETVALUE-
Limit(H): 40.000kg
Limit(L): 30.000kg
-COUNTLIMIT SET VALUE-
Limit(H): 2000pcs
Limit(L): 1000pcs
When‘theweightcomparisonfunction’isset. When‘thecounting comparisonfunction’is set.
-Cumulative Weight Sum Function-
(DEPonly)
======== WEIGHT ========
WELCOME TOCAS[DB-2]
DATE . 07/30/2007
TIME. 17:35:58
Weight: 40.180kg
Weight: 40.200kg
Weight: 40.200kg
Weight: 40.200kg
Weight: 40.200kg
Weight: 40.200kg
Weight: 40.200kg
Weight: 40.200kg
Weight: -40.200kg
Weight: 40.200kg
Weight: 40.200kg
Weight: 40.200kg
- - - - - -- - - - - -- - - - - - -- - - - -- -
Total: 401.980kg
Count: 10times
Label Caption
Date
Time
- means that you cancel the weight right before
this weight.
Cumulative weight sum
Aggregate times
※Please take a reference of page 12(cumulative weight sum) for printing process details.

1
8
Sample format(DEP-50):
Notice. 4 kinds of Print forms should downloaded to the DLP Printer to use all the features and
Function smoothly
1. Weight + tare
※ In order to use the above label format, Barcode
set as OFF and weight comparison function as
OFF in SETUP MODE
2. Weight + Tare + Barcode
※ In order to use the above label format, Barcode
set as ON and weight comparison function as
OFF in SETUP MODE
3. counting function
※ Quantity Comparison Functions should set as ON
4. Weight comparison function
※ Weight comparison functions should set as ON
※When using DLP printer, it could not print in the percentage mode

19
8-2.Auto Print
①To use auto print function, you have to set printer menu to “Pr AUt” in setup mode.
Refer to Setup Mode Table on page 20.
②If the weight is stable, it is printed out automatically.
And You can print out data every time pressing the PRINT key.
8-3. Stream Print
To use auto print function, you have to set printer menu to “Pr Str” in setup mode.①
Refer to Setup Mode Table on page 20.
If the weight is stable, it is printed out continuously②
9. Battery Charge
■Warning massage is shown when the battery voltage is very low. ( )
■At this time, charge the battery. (a charging battery only)
■The display will show a red lamp and the battery will begin a fast charge
automatically.
- Use only the ac adapter which comes with the scale. Other AC adapter may
cause damege.
10. Unit conversion (kg, lb, oz)
①Press the MODE key until
the display shows “U kg” or
your last unit.
②Use “HOLD key” or
“PRINT key” you can set which
unit you want to use.kg, lb, oz.
③Press “SET key” and
“CHAnGE” will display.
④Press the “MODE” key to go
to the weighing mode.
※Tare, Unstable, when the display weight is not 0 when change is not working.
Leave the platter empty, and weighing is at Zero and stable, the scale should work.

20
SETUP MODE
1. How to Go to Setup Mode
Make sure that power is OFF. While pressing the PRINT key, press the POWER
key. The display shows “U SEt”. You can select each menu by pressing the
MODE key and change the setting by pressing the HOLD or PRINT key. If you
press SET key, you will save current setting and finish this mode. To finish this
mode without saving, press the ZERO key.
2. Set up Mode Table
MENU DISPLAY DESCRIPTIONS
“ b on ” You can hear buzzer.
Buzzer “b oFF ” You cannot hear buzzer.
“Pr oFF” Do not use printer.
“Pr DLP” DLP50 printer interface. (Label)Printer
“Pr DEP” DEP50 printer interface. (Ticket)
“Pr key” Manual print. (DLP, DEP)
“Pr AUt” Auto print when the scale is stable. (DLP, DEP)Printmethod
“Pr Str” Ptint continually when the scale is stable. (DEP)
Linefeed
(DEPonly) LF1~LF9 Linefeed
Barcode
(DLP only) “BC on/off” Print out barcode on/off.
“br 48” 4,800 bps
“ br 96 ” 9,600 bps
“br 192 ” 19,200 bps
Baud Rate
“br 384 ” 38,400 bps
“bL on ” Use back-light.
“bL 10 ” Back-light is on 10 seconds.
“bL 30 ” Back-light is on 30 seconds.
Backlight
“ bL oFF ” Do not use back-light.
Brightness “1~7 ” You can set backlight brightness. (Default : 3)
“ AP oFF ” Do not use Auto Power Off function.
“AP 10 ” Power turns to be off automatically when the scale is
not in operation over for 10 minutes.
“AP 30 ” Power turns to be off automatically when the scale is
not in operation over for 30 minutes.
Auto Power Off
“AP 60 ” Power turns to be off automatically when the scale is
not in operation over for 60 minutes.

21
“ WL M0 ” HIGH Limit ≥Weight ≥LOW Limit - You will hear buzzer.
“WL M1 ” HIGH Limit ≤Weight, Weight ≤LOW Limit
- You will hear buzzer.
“WL M2 ” Weight ≤LOW Limit - You will hear buzzer.
Weight Limit
“WL M3 ” HIGH Limit ≤Weight - You will hear buzzer.
“ CL M0 ” HIGH Limit ≥Counting result ≥LOW Limit
- You will hear buzzer.
“CL M1 ” HIGH Limit ≤Counting result,
Counting result ≤LOW Limit - You will hear buzzer.
“CL M2 ” Counting result ≤LOW Limit - You will hear buzzer.
Count Limit
“CL M3 ” HIGH Limit ≤Counting result - You will hear buzzer.
“ dy on ” Print out date/day.
Date “dy oFF ” Do not print out date/day.
“ ti on ” Print out time.
Time “ti oFF ” Do not print out time.
“LA off ” Do not print out label caption.
Label
“ LAon ” Print out label caption.
“ dFno” Default setting is released.
Default “dF YES ” Everything is setup in default.
※ Italic Bold : Default Setting
※Select the DEP printer in the Set up mode, LINE Feed Features are enable to use and if DLP printer is
selected then Barcode features are enable to use. However, both Line Feed and Barcode features
could not use at the same time.
