CAS PW-II User manual

2

3
CONTENTS
PRECAUTIONS.................................................. 4
PREFACE ............................................................... 6
NAMES AND FUNCTIONS.......................... 6
OPERATIONS...................................................... 8
1. Simple Weighing Mode ..................................... 8
2. Weighing with Tare............................................ 8
3. Changing Unit of Weight (Unit ver. only)...... 9
4. HOLD Function (Hold ver. only) .................... 9
5. How to Set Auto Power Off ............................ 10
BATTERY MAINTENANCE ......................11
ERROR MESSAGE..........................................11
SPECIFICATIONS .......................................... 12

4
PRECAUTIONS

5

6
PREFACE
Thank you for purchasing CAS PW-II.
This model has been designed with CAS reliability, under rigid quality control
and with outstanding performance. Your special departments can enjoy this
high quality reliable CAS product.
We believe that your needs will be satisfied and you will have proper reliability.
This manual will help you with proper operation and care of the PW-II.
Please keep it handy for future reference.
NAMES AND FUNCTIONS
OVERALL VIEW
DISPLAY & KEYBOARD
■HOLD Version

7
■KEY FUNCTIONS
KEYS FUNCTIONS
Used to set the zero point.
Used to input or cancel the weight of tare.
Used to make the weight of commodity stable.
This weight is average value.
Used to turn on and off the scale.
■Unit Version (Option)
■KEY FUNCTIONS
KEYS FUNCTIONS
Used to set the zero point.
Used to input or cancel the weight of tare.
Used to convert the unit of weight.
Used to turn on and off the scale..

8
OPERATIONS
■Turn on the display by pressing key. Then, the display will show all the segments and
count up "0" to "9". You may stop this automatic counting by pressing the key.
■When you turn on the display, make sure that platter is empty. Otherwise, display will show
"Err 1", an error of initial zero range. Please refer to "ERROR MESSAGE" section for
more information on page 11.
■When the weight becomes stable the display shows the stable sign ( ○) on.
■You may need to make it "0.000" by pressing key unless the display indicate "0.000"
under the empty platter.
1. Simple Weighing Mode
①Place a commodity on
the platter. ②Remove the commodity from the platter.
2. Weighing with Tare
■TARE means the weight of container being used for a commodity.
■TARE key function is to subtract the weight of the container from full weight loaded.
Place a container on①
the platter. ②Press the key. ③Place a commodity into the container, then the
display
will show onlythe weight of
the commodity.

9
④Remove container and
commodity, then the display
will show the weight of the
container with "-" symbol.
⑤Press the key, then
display will show the
"0.000".
3. Changing Unit of Weight (Unit ver. only)
■Press the key in the simple weighing mode.
You may select kg, lb, oz, or gram as the unit of weight.
4. Hold Function (Hold ver. only)
②"HOLD" will be displayed
twice
③ The average weight will be
displayed. The hold function will
be automatically stopped after the
commodity on the tray is removed
or the average weight is blinked 6
times.
①When the weight is
unstable, press the key.

10
5. How to Set Auto Power Off
Auto-Power off function is to automatically power off as time is set.
This function is helpful to save battery, which is not in use.
The following is the setting procedure of Auto-power off.
①When the scale is turned
on press key, holding
key. Then you will see the
"AP-10".(If you have set this
before,display will show
previous value.)
②Press the key, then you
will see the "AP-oF" (If you
have set this before, display
will show previous value.)
③Press the key until the
display shows the "AP-X0"
that you wish to take.
(Refer to TABLE 1.)
④Press the key, and then
the scale saves what you
programmed and shows all
the segments, counting up
"0" to "9".
TABLE 1.
DISPLAY FUNCTION
AP-oF This function does not automatically power off.
AP-10 This function does automatically poweroff when the scale is not in use for 10 minutes.
AP-30 This function does automatically poweroff when the scale is not in use for 30 minutes.
AP-60 This function does automatically poweroff when the scale is not in use for 60 minutes.
* "e" value may be various on capacity of product model.
Please refer to "SPECIFICATION" on page 16. For example, a product model
which capacity is 2.000kg has 1g as "e" value

11
BATTERY MAINTENACE
LOW BATTERY WARNING
When the battery is low the display shows the "BATT" sign.
You can replace the battery new one.
If you still use the scale without replacing the battery the scale may provide
incorrect result on measurement.
※Low Battery status. ※ Battery cut off display.
ERROR MESSAGE
Error Message
on Display Description Solution
"Err 0" The "Err 0" occurs when scale is not stable. Remove unstable
facts.
"Err 1" The "Err 1" occurs when a current zero point has
shifted from the last span calibration. Please call your CAS dealer.
"Err 3" The "Err 3" is an overload error. Please remove the
weight.

12
SPECIFICATIONS
MODEL PW-II
Capacity / e Dual Interval
Max1/2kg
e=0.5/1g
Dual Interval
Max 2.5 /5kg
e=1/2g
Dual Interval
Max 4/10kg
e=2/5g
Internal
Resolution 1/60000 1/60000 1/60000
External
Resolution 1/2000 1/2500 1/2000
MAX Tare -0.9995kg -2.499kg -3.998kg
Display 91 x 36 [mm] / 3.6 x 1.5 [inch] 5 digits LCD
Symbols STABLE, ZERO, TARE, g, Low Battery , (kg, lb, oz Only unit version)
Keys ZERO, TARE, HOLD(Hold Ver.), UNIT(Unit Ver.), POWER
Functions Hold(Hold Ver.), Unit Conversion(Unit Ver.),
Dimensions 239(W) x 227(D) x 66(H) [mm] / 9.4(W) x 8.9(D) x 2.6(H) [inch]
Platter size 222(W) x 151(D) [mm] / 8.7(W) x 5.9(D) [inch]
Weight About 1.7kg / 3.8lb
Power 1.5V x 6 units (AA size Battery)
Operation
Time Approx. 50hours (Manganese battery)/ 250hours (Alkaline at 20°C /68°F)
Operating
Temperature -10°C ~ +40°C / 14°F ~ 104°F
Minimum
Voltage
Level of The
Battery
About 5.5V
Option 9V Adapter
Notice: Specifications are subject to change for improvement※without notice.
