CAS CL8000 Series User manual

1

2
Contents
1.GENERAL ................................................................8
1.1. PRECAUTION .........................................................8
1.2. INTRODUCTION .......................................................10
1.3. SPECIFICATIONS .......................................................11
1.4. DIMENSIONS .......................................................14
1.5. SETUP .......................................................17
1.5.1. Basic Setup ..................................................17
1.5.2. Rear Display Assembly.........................................20
1.5.3. Installation of the Label Roll................................22
1.5.4. Power On/Off ..................................................27
2.SALESOPERATION...........................................................32
2.1. STANDARD SALES OPERATION ...................................32
2.1.1. Sales operation - General type ...........................32
2.1.1.1. Selling Weighed Products.........................32
2.1.1.2. Selling Counted Products..........................35
2.1.2. Salesoperation - Full type...................................37
2.1.2.1. Selling Weighed Products.........................37
2.1.2.2. Selling Counted Products..........................40
2.1.3. Using Product Search Function...........................42
2.1.4. Add Sales 44
2.1.5. Change keypad settings on the sales mode......49

3
2.1.5.1. Change a product keypad settings ..........49
2.1.5.2. Change a function keypad settings..........50
3.PROGRAMING 53
3.1. BOOKMARK MENU......................................................55
3.2. DATA MENU .......................................................57
3.2.1. Data –PLU ..................................................57
3.2.1.1. Create New PLU ......................................57
3.2.1.2. ModifyPLU ......................................62
3.2.1.3. Delete PLU ......................................63
3.2.1.4. PLU List ......................................65
3.2.2. Data –Department..............................................68
3.2.3. Data –Group ..................................................69
3.2.4. Data –Sales Message ..........................................69
3.2.5. Data –Origin ..................................................70
3.2.6. Data –Barcode ..................................................70
3.2.6.1. Create New Barcode .................................71
3.2.7. Data –Tare ..................................................73
3.2.7.1. Create New Tare ......................................73
3.2.8. Data –Quantity Unit Symbol..............................76
3.3. DATA MAINTENANCE MENU......................................77
3.3.1. Data Maintenance –Select PLU Items...............77
3.3.2. Data Maintenance –Import PLU data...............80
3.3.2.1. FTP ......................................80
3.3.3. Data Maintenance –Delete data .......................90
3.3.4. Data Maintenance –Label Form........................93
3.3.5. Data Maintenance –Select Nutrifact Items......95
3.3.6. Data Maintenance –Delete File.........................97
3.4. STORE MENU 98
3.4.1. Store –Store Info98
3.4.1.1. Register New Store Info ............................99

4
3.4.1.2. Modify Store Info ................................... 100
3.4.1.3. Delete Store Info ................................... 101
3.4.2. Store –User & Security..................................... 102
3.4.2.1. User ................................... 102
3.4.2.2. Menu Permission ................................... 107
3.4.2.3. Function Permission............................... 110
3.4.2.4. Security Config ................................... 112
3.4.3. Store –Advertisement...................................... 113
3.4.3.1. Slide Show ................................... 113
3.4.3.2. Advertising Setting.................................. 118
3.4.4. Store –Category ............................................... 119
3.4.4.1. Create New Category ............................. 120
3.4.4.2. ModifyCategory ................................... 121
3.4.4.3. Delete Category ................................... 122
3.5. REPORT .................................................... 124
3.5.1. Report –Standard............................................. 125
3.5.1.1. Period ................................... 125
3.5.1.2. ReportType ................................... 131
3.5.2. Report –Management..................................... 134
3.5.2.1. Delete Transactions ................................ 134
3.5.2.2. Other Report Settings ............................ 135
3.5.3. Report –Realtime Report.................................136
3.6. SETUP MENU .................................................... 138
3.6.1. Setup –Global setting....................................... 138
3.6.1.1. Label ID ................................... 138
3.6.1.2. Barcode ................................... 139
3.6.1.3. ScaleConfig ................................... 140
3.6.2. Setup –Print ............................................... 142
3.6.2.1. Print Label Items ................................... 142

5
3.6.2.2. Label Caption ................................... 143
3.6.3. Setup –Config ............................................... 144
3.6.3.1. Sale ................................... 144
3.6.4. Setup –Keypad ............................................... 145
3.6.4.1. Keypad Layout Type................................ 145
3.6.4.2. Keypad Arrangement............................. 147
3.6.4.3. Function Keypad ................................... 155
3.6.4.4. Keypad Config ................................... 159
3.6.4.5. Product Info ................................... 161
3.6.5. Setup –Date Time............................................. 162
3.6.5.1. Setup –Date Time Format..................... 164
3.7. DEVICE MENU .................................................... 166
3.7.1. Device –Printer ............................................... 166
3.7.1.1. Label Size ................................... 167
3.7.1.2. Sensor Calibration................................... 167
3.7.1.3. Sensor & Motor ................................... 168
3.7.1.4. Print Intensity ................................... 169
3.7.1.5. Adjust Feed Length.................................169
3.7.1.6. Label Preprint ................................... 170
3.7.1.7. Reverse Feed ................................... 170
3.7.2. Device –Network.............................................. 171
3.7.2.1. Network Setting ................................... 171
3.7.3. Device –Scale Info............................................. 174
3.7.3.1. Version .................................... 174
3.7.3.2. License ................................... 176
3.7.4. Device –Test ............................................... 177
3.7.4.1. Test Main Screen .................................... 177
3.7.4.2. Display Test ................................... 180
3.7.4.3. Touch Test .................................... 181
3.7.4.4. AD Test ................................... 182

6
3.7.4.5. Printer Sensor Test.................................. 183
3.7.4.6. Print Test ................................... 184
3.7.4.7. Cash Drawer Test ................................... 185
3.7.4.8. IO Test ................................... 187
3.7.5. Device –Remote Support ................................ 189
3.8. ADMIN MENU .................................................... 191
3.8.1. Admin –Parameter........................................... 191
3.8.1.1. Sale ................................... 191
3.8.1.2. Barcode ................................... 193
3.8.1.3. Print ................................... 195
3.8.1.4. Round ................................... 197
3.8.1.5. Tare .................................... 199
3.8.1.6. Weighing .................................... 200
3.8.1.7. Weight Unit .................................... 201
3.8.1.8. Communication ................................... 201
3.8.1.9. Currency ................................... 202
3.8.1.10.Discount .................................202
3.8.1.11.Display .................................203
3.8.1.12.Keypad .................................204
3.8.1.13.Management .................................204
3.8.1.14.Menu .................................205
3.8.1.15.Report .................................206
3.8.1.16.Sign .................................207
3.8.1.17.Nutrifact .................................209
3.8.1.18.Date Time .................................210
3.8.2. Admin –Language / Keyboard ........................ 211
3.8.2.1. Display Language ................................... 211
3.8.2.2. Keyboard ................................... 213
3.8.3. Admin –Initialization........................................ 221

7
3.8.3.1. Mart ................................... 221
4.TROUBLESHOOTING.....................................................226

8
1. GENERAL
1.1. PRECAUTION
Warning Precautions when installing the scale. To ensure that you get the
most from your scale, please follow these instruction.
Do not disassemble the scale.
When any damage or defect occurs, contact your
CAS authorized dealer immediately for proper repair.
Do not overload beyond the maximum weight limit.
Scale must be grounded to minimize electricity static.
This will minimize defect or electric shock.
Do not pull the plug by its cord when unplugging.
Damaged cord could cause electric shock or fire.
To prevent from fire occurring, Do not place or use
the scale near flammable or corrosive gas.
To reduce electric shock or incorrect reading,
Do not spill water on the scale or place it in
humid condition.
Avoid placing the scale near heater or in direct sunlight.

9
Insert plug firmly to wall outlet to prevent electric shock.
Attention Make sure to plug your scale into the proper power outlet.
For maximum performance, plug into a power outlet 30 minutes before the usage for warm up.
For consistent and accurate reading, maintain
periodical check by your CAS authorized dealer.
Avoid sudden shock to the scale.
Grab on the bottom of the scale when moving.
Keep the scale away from other electromagnetic
generating devices.
This may interfere with accurate reading.
Place the scale on firm and temperature consistent
environment.
By adjusting 4 comers of the scale, set the scale
even using the built in scale leveling indicator.

10
1.2. INTRODUCTION
Thank you for purchasing CAS CL8000 series.
CL8000 is a PC-based price computing electronic scale. We have integrated intuitive and
powerful functionalities in its design to address the needs of users in various
applications, and we are confident that CL8000 will make operating your business easier.
Remember, for proper installation and maintenance please have your CAS authorized
dealer do the primary installation, programming, and demonstration. Your CAS
authorized dealer also has a wide variety of supplies, accessories, and expansion
options for whatever your new and increasing demands may require. Authorized CAS
dealers are trained to help you with every aspect of the CL8000 series and should you
need servicing, they are highly trained by CAS to assist you with virtually any problem.
●Included Accessories

11
1.3. SPECIFICATIONS
Max. Capacity
3/6 kg
6/15 kg
15/30 kg
Interval
1/2 g
2/5 g
5/10 g
Max. Tare
-2.999 kg
-5.998kg
-9.995 kg
A/D Conversion Rate
Approx. 8 times / s
Measurement Type
Load cell
Operating Temp.
-10°C ~ 40°C (14°F ~ 104°F)
Power
AC 100~240V 50/60Hz 1.5A
Printing Rate
Max. 150 mm/sec
Printing Resolution
202 dpi
Label Size
Width: 40 mm ~ 60 mm / Length: 30 mm ~ 200 mm
Printer Type
Direct thermal print
●System
CPU
Intel® Celeron™ J1900 (2.0 GHz) Quad-Core Processor / Fanless
(Standard)
Chipset
Intel® Bay Trail
Storage
PCA, PCB type : SATA 2 (3Gb/s) 2.5 inch SSD 64GB, Support AHCI
B, U, SU type : mSATA SSD 64GB
System Memory
4GB Standard (Type: DDR3L, Socket 1 x SODIMM)
Graphics
Integrated Intel HD Graphics
Sound
Realtek ALC662-VD 5.1 CH Audio
●Display
Size/Type
PCA, PCB type : 15" TFT LED backlight, 9.7” TFT LED backlight
B, U, SU type : 10.1" TFT LED Backlight, 7" TFT LED Backlight
Resolution
PCA, PCB type : 1,024 x 768
B, U, SU type : 1,024 x 600
Brightness
PCA, PCB type : 300 cd/m²(typ.)
B, U, SU type : 10.1” = 180 cd/m² (typ.), 7” = 350 cd/m² (typ.)

12
●Touchscreen
Type
Projective capacitive touch
Interface
USB
●I/O Interface –PCA type
Video Out
1 x VGA (with 12V power output)
USB Port
6 (Rear 2, Back 4 / USB 2.0 x 6 Ports
Serial Ports
5 (COM1 with 5V/12V Power Output on 9 Pins, BIOS)
(COM2 ~ 3 RJ-45, full signal)
(COM4 RJ-11, Only TX/RX, 12V power output)
(COM5 Reserved)
(COM6 RJ-45, Only TX/RX, 5V Power Output)
LAN
1 x gigabit ethernet, RJ-45
Audio Out
Line-out
Power
AC 100~240V 50/60Hz 1.5A
OS
Windows 10
●I/O Interface –PCB type
Video Out
1 x VGA
USB Ports
3x I/O panel, 2 x left side, 1 x right side(MSR)
Parallel Ports
1*LPT
Serial Ports
4 DB9 (only COM4 5V/12V)
LAN
1 x 100 Megabit ethernet, RJ-45
Audio In/Out
Line-in, Line-out
Power
AC 100~240V 50/60Hz 1.5A
OS
Windows 10

13
●I/O Interface –B, U, SU type
USB Ports
6 (USB 3.0 x 1 / USB 2.0 x 5)
Parallel Ports
2(COM1, COM4 full signal)
1(COM 3 with 5V/12V power output on 9 pins, factory setting)
LAN
1 x 100 Megabit ethernet, RJ-45
Audio Out
Line-in, Line-out
Power
AC 100~240V 50/60Hz 1.5A
OS
Windows 10
●Instrument & Environment
Color
Dark gray
Load Tray Size
368 x 288 (mm)
Dimensions
PCA, PCB type : 399(W) x 447 (D) x 631(H)(mm)
B-Type : 399(W) x 450(D) x 171(H)(mm)
U-Type : 399(W) x 485(D) x 578(H)(mm)
SU-Type : 399(W) x 485(D) x 292(H)(mm)
* Height: excluding rear LCD
Note: Some of the specifications may change without prior notice.

14
1.4. DIMENSIONS
●PCA type

15
●PCB type
●B type
●U type

16
●SU type

17
1.5. SETUP
1.5.1. Basic Setup
●PCA type

18
●PCB type
●B type

19
●U type
●SU type

20
1.5.2. Rear Display Assembly
●PCA type
