CAS PW-II User manual

PW-II Service Manual
1
PW-II SERVICE MANUAL

PW-II Service Manual
2
< Table of Contents >
1. Introduction ............................................................................................................................... 4
1.1. Preface................................................................................................................................... 4
1.2. Precaution............................................................................................................................ 4
1.3. Specifications..................................................................................................................... 5
1.3.1. PW-II Specifications ...................................................................................... 5
1.4. Key............................................................................................................................................ 6
1.5. Sealing Method ................................................................................................................. 7
2. Calibration................................................................................................................................... 8
2.1. General Calibration......................................................................................................... 8
2.1.1. C4 Setting ............................................................................................................. 9
2.1.1.1. C4-1 Setting................................................................................................. 9
2.1.1.2. C4-2 Setting................................................................................................. 9
2.1.1.3. C4-3 Setting................................................................................................. 9
2.1.1.4. C4-4 Setting................................................................................................. 9
2.1.1.5. C4-5 & 4-6 Setting................................................................................. 10
2.1.2. SPAN Calibration Setting (C-3).............................................................. 10
2.1.3. Gravity Constant Value Setting (C-9) ................................................ 11
2.1.4. Displaying Real A/D Value (C-5).......................................................... 11
2.1.5. How to confirm SPAN calibrated A/D value (C-1) ..................... 12
2.1.6. Back to the normal weighing mode (C-0)....................................... 12
2.1.7. Calibration Block Diagram........................................................................ 13
3. The Schematics and Diagram......................................................................................... 14
3.1. System Block Diagram................................................................................................ 14
3.2. Circuit Diagram............................................................................................................... 15
3.2.1. Main........................................................................................................................ 15
3.2.2. A/D ......................................................................................................................... 16
4. Exploded View......................................................................................................................... 17

PW-II Service Manual
3
5. Part Location............................................................................................................................ 18
5.1. Main PCB (Front) ........................................................................................................... 18
5.2. Main PCB (Rear)............................................................................................................. 19
5.3. Battery PCB....................................................................................................................... 20
5.4. Key PCB ............................................................................................................................. 201
6. Partlist ......................................................................................................................................... 22
6.1. Circuit Part .................................................................................. 22
6.1.1. Main PCB Ass'y....................................................................22
6.1.2. Battery PCB Ass'y................................................................23
6.1.3. Key PCB Ass'Y………………………………………………………………23
6.2. Mechanism Part ........................................................................... 24
6.2.1. Body Ass'y...........................................................................24
6.2.2. C/T Box Ass'y......................................................................25
6.2.3. Loadcell Ass'y………………………………………………………………25
7. Error Message & Solution…………………………………………………………...26
7.1. Beep : Re-zero…...........................................................................26
7.2. Err : Initial zero…………………………………………………………………….26
7.3 Init : Failure of Analog Module……………………………………………….26
7.4 UNSTA : A/D Value Unstable………………………………………………….26

PW-II Service Manual
4
1. Introduction
1.1. Preface
Thank you for purchasing of our CAS scale.
This scale has been designed with CAS reliability, under rigid quality control
and with outstanding performance.
WE hope that your departments enjoy with high quality of CAS product.
This manual will help you with proper operations and care of the PW series.
Please keep it handy for the future references.
1.2. Precaution
•Make sure that you plug your scale into the proper power outlet.
•Place the scale on a flat and stable surface.
•Plug into a power outlet 30 minutes before operations.
•Keep the scale away from strong EMI noises may cause incorrect weight readings.
•This scale must be installed in a dry and liquid free environment.
•Do not subject the scale to sudden temperature changes.
•Do not subject the platter to sudden shocks.
•If the scale is not properly level, please adjust the 4 legs at the bottom of the
scale (turn legs clockwise or counterclockwise) so as to center the bubble of the
leveling gauge inside the indicated circle.

PW-II Service Manual
5
1.3. Specifications
1.3.1.PW-II Specifications
PW-II(2kg) PW-II(5kg) PW-II(10kg)
Capacity / e
Low
Resolution
2,000g / 1 g
(2 kg / 0.001 kg)
5 lb / 0.002 lb
80 oz / 0.05 oz
5,000g / 2 g
(5 kg / 0.002 kg)
10 lb / 0.005 lb
160 oz / 0.1 oz
10,000g / 5 g
(10 kg / 0.005 kg)
20 lb / 0.01 lb
400 oz / 0.2 oz
High
Resolution
2,000.0g / 0.5 g
2 kg / 0.0005 kg
(1/4,000)
5 lb / 0.001 lb
(1/5,000)
80 oz / 0.02 oz
(1/4,000)
5,000.0g / 1 g
5 kg / 0.001 kg
10 lb / 0.002 lb
(1/5,000)
160 oz / 0.05 oz
(1/3,200)
10,000g / 2 g
10 kg / 0.002 kg
(1/5,000)
20 lb / 0.005 lb
400 oz / 0.1 oz
(1/4,000)
Internal
Resolution 1 / 20,000 1 / 25,000 1 / 20,000
External
Resolution 1 / 2,000 1 / 2,500 1 / 2,000
Display 91 X 39 [mm] / 3.6 X 1.5 [inch] 5 digits LCD
Symbols
(Indicators) STABLE, ZERO, TARE, g, kg, lb, oz, Low Battery HI/OK/LO, PCS
Keys ZERO, TARE, HOLD, UNIT, POWER
Functions
•Simple Weighing function
•Hold function
•Weight Unit Conversion Function (g/kg/lb/oz)
•Auto Power Off
Dimension 239(Width) ×227(Depth) ×66(Height) [mm] /
9.4(Width) ×8.9(Depth) ×2.6(Height) [inch]
Platter Size 222(Width) ×151(Depth) [mm]/
8.7(Width) ×5.9(Depth) [inch]
Weight 1.5 kg
Power 1.5V x 6 (AA size battery) or 9 V Adaptor
Op.Temperature - 10 °C ~ +40 °C
Op. Power 9V/300mA Adaptor

PW-II Service Manual
6
1.4. Key
Key Function
HOLD To make the weight of item stable. This weight is average value.
UNIT Used to convert the unit of weight
TARE To input or cancel the tare (the weight of container).
ZERO (-O-)
[Set]
To set zero point
To do [SET] key in the SETUP mode.
POWER To turn on or off.

PW-II Service Manual
7
1.5. Sealing Method

PW-II Service Manual
8
2. Calibration
2.1. General Calibration
Pressing and holding calibration switch press [POWER] key to go to calibration mode.
User can move to other mode by using [ZERO] key in the calibration mode.
User also moves to other sub-modes for each mode by using [HOLD] and [TARE] key.
Please simply follow below procedure to move to other mode.
(1) Calibration Mode: Pressing and holding “Calibration Switch” press [POWER]
key.
It displays “C-0” after “CAL”, and it blinks the version of scale three times.
(2) Selecting menu: press [TARE] and then [HOLD].
(3) ENTER(Setting) : [ZERO] key
MODE Function
C – 0 To go back to simple weighing mode
C – 1 To display internal value of weight
C – 2 -
C – 3 Weight Setting Mode
(“UnLoad” →[ZERO] →“Load”→[ZERO] after loading →“END” on display)
C – 4 Capacity displayed and Option Setting
C – 5 Net internal value of weight (zero value confirmed)
C – 6
C – 7
C – 8
C – 9 Gravity constant

PW-II Service Manual
9
2.1.1.C4 Setting
2.1.1.1. C4-1 Setting
B7 B6 B5 B4 B3 B2 B1 B0
Weight
Unit
External
Resolution Display Unit TARE
0:kg
1:lb
00: Low
01: High
00:kg
01:lb
10:oz
11:g
00: (+)One Time (-) One Time
01: (+)Successive (-) One Time
10: (+)One Time (-) Successive
11: (+)Successive (-)Successive
User should input Hexa code to set C4.
User should input “weight unit”, “external resolution”, “display unit”, and “tare”.
For example, if you want to set “kg (0)” as the weight unit, “low (00)” as the external
resolution, or “(0)” as TARE you may input “00” as Hexa value.
User can set 2,000~2,500 for low external resolution or 4,000~5,000 for high external
resolution.
2.1.1.2. C4-2 Setting
Capacity Setting
UNIT
kg g lb oz C4-2 Value
2 2,000 5 80 0000 1XXX
5 5,000 10 160 0001 1XXX
10 10,000 20 400 0010 1XXX
PW-II has four different weight units, g, kg, lb, or oz as shown in shaded area. You can set
the capacity to input first 5 bits, for example, “00011” for 5 kg capacity.
Next three (3) bits represent “Interval” information. For example, if you set 5 kg interval the
Hexa value will be “0x18”.
2.1.1.3. C4-3 Setting (Function Setting)
ROM VERSION 1 (Hold) ROM Version 2 (lb)
Function Function
S-HOLD XXXX XX00
HOLD XXXX XX00 Lb XXXX XX10

PW-II Service Manual
10
2.1.1.4. C4-4 Setting
UNIT CHANGE Comma Setting lb ROM Version Only
Buzzer Setting
ENABLE 1XXX XXXX ENABLE XXX1 XXXX
ENABLE XXXX 0XXX
DISABLE 0XXX XXXX DISABLE XXX0 XXXX
DISABLE XXXX 1XXX
C4-4 is to set to use the unit change function and the displaying unit.
2.1.1.5. C4-5 & C4-6 Setting
2.1.2. SPAN Calibration Setting (C-3)
(1) Pressing and holding “Calibration Switch” press [POWER] key.
After “CAL” message blinks three times and shows the version of scale, it displays “C-0”
message.
(2) Press [TARE] to display “C-3”.
(3) Press [ZERO] key and then it displays “UnLOAd” message.
(4) Press [ZERO] key if you want to scroll it.
Ú To exit from SPAN Calibration mode press [TARE] key when “UnLOAd” or “LOAd” message is
displayed.
C4-5 C4-6
Op Amp Setting Zero Range Setting
HA17358 XXXX XXX1 2% 10% 15% 20%
OP2177 XXXX XXX0 XXXX XX01
XXXX XX00
XXXX XX10 XXXX XX11

PW-II Service Manual
11
2.1.3. Gravity Constant Value Setting (C-9)
Current gravitational Acceleration value is set to 9.7994 m/s2 .
(1) Pressing and holding “Calibration Switch” press [POWER] key.
After “CAL” message blinks three times and shows the version of scale, it displays “C-0”
message.
(2) Press [TARE] to display “C-9”.
(3) Press [ZERO] key, and then “ G-1“ message and “9.7994” will be shown. The first
digit,”9” will blink.
(4) Input a gravitational acceleration value by using [HOLD] and [TARE] key.
(5) Press [ZERO] key, and then “G-2“ message blinks.“9.7994” will be shown. The first
digit,”9” will blink.
(6) Input a gravitational acceleration value by using [HOLD] and [TARE] key.
(7) Press [ZERO] key to save the gravitational acceleration value, and “C9 END” message
will be shown shortly.
2.1.4. Displaying Real A/D Value (C-5)
(1) Under Calibration switch on press [POWER] key.
After “CAL” message blinks three times and the version of scale is displayed, “C-0” message
will be displayed.
Press [TARE] to display “C-5”.
Press [ZERO] key, and then the display will show a real A/D value.
Press [ZERO] key to exit from it.

PW-II Service Manual
12
2.1.5. How to confirm SPAN calibrated A/D value (C-1)
(1) Pressing and holding Calibration Switch please press [POWER] key.
After “CAL” message blinks three times and the version of scale is displayed, “C-0” message
will be displayed.
(2) Press [TARE] to change “C-0” to “C–1”.
(3) Press [ZERO] key, and then it displays SPAN calibrated A/D value, “0”.
(4) When the weighing value of maximum capacity is not stable you may use
[TARE] key to decrease or [HOLD] key to increase the value.
For example, when you weigh maximum capacity on the platter in case of 1/20,000 it
may display “19,999” or “20,001”. You can adjust up or down to “20,000” using [HOLD] or
[TARE] key.
(5) Press [ZERO] to go to and display “C – 1” and you may scroll it at this point.
Then, if you press [ZERO] key again it automatically saves “Span Factor” on it.
2.1.6. Back to the normal weighing mode (C-0)
(1) Under the Calibration Switch ON press [POWER] key.
9After “CAL” message blinks three times and the version of scale is
displayed, “C-0” message will be displayed.
(2) You may exit from Calibration mode by pressing [ZERO] key.

PW-II Service Manual
13
2.1.7. Calibration Block Diagram
START
C - 4 C - 4 - 1
C - 4 - 2
교정 단위
외부분해능
Display Unit
TARE Option
C - 4 - 6
Unit Change
표시 단위
C - 9
(Gravity)
1
2G - 1
G - 2
C - 3
(SPAN) UnLOAd
LOAd
3
C - 1
(Trimming)
4Factored
Value
LOAd
Up/Down
END
Capacity
Interval
C - 4 - 4
Initial Zero

PW-II Service Manual
14
3. The Schematics and Diagram
3.1. System Block Diagram
Load
Cell A/D
Converter
(ADS1100)
CPU
( NEC 78Fseries)
KEY
EEPROM
(24C02)
AMP
&
Filter
POWER
(DC 9V/300mA)
Battery_AA SIZE
(1.5V x 6)
LCD
Driver
DISPLAY
(LCD)

PW-II Service Manual
15
3.2. Circuit Diagram
3.2.1.Main
S1 ZERO
C
Q2
KTN2222AS
Q4
KTN2222AS
VDD
R6
100K
C13
0.1uF
Vbat
0
PW-2 MAIN CIRCUIT DIAGRAM
A3
11Saturday, August 26, 2006
Title
Size Document Number Rev
Date: Sheet of
S3 HOLD
C19
0.1u
Low Battery Check
R15
100k
R3
10K
C12
0.1u
R13
10k
CN62
J1
1
2
3
S4
ON/OFF
CAL S/W
E
VDD
L6
471u
CY1
Q3
KTA1504SY
Q1
2N2222AS
R14
10k
V+
Vin
POWER_CHK
1
+
C3
330u/25v
C10
30p
B
S2 TARE
U5
1
2
3
4
5
6
VIN+
GND
SCL
SDA
VDD
VIN-
R9
0.5%
10k
BUZZER
1 2 3 4 5
6 7 8 9 10
1 2 3 4 5
6 7 8 9 10
+
C1
1u/50v
R4
10k
VDD
R7
100K
C5
0.1uF
D1
KDS184
2 1
3
KTA1504
U3
24C02
1
2
3
45
6
7
8A0
A1
A2
VSSSDA
SCL
WP
VDD
VDD
LCD1 SW-II LCD
1 2 3 4 6 7 8 9 5 11 12 13 14 15 16 17 18 19 20 21 10 22
C0 C1 C2 C3
STABLE/ L/O/K
1F/1G/1E/1D
1A/1B/1C/
/ /1P/1Z
S2/S3/ S4/HI
2A/2B/2C/
/ /2P/2Z
3F/3G/3E/3D
3A/3B/3C/
/ /3P/3Z
4F/4G/4E/4D
4A/4B/4C/
/ /4P/4Z
5F/5G/5E/5D
5A/5B/5C/
OZ/LB/ K/ G
2F/2G/2E/2D
PCS
VDD
AUTO POWER
2E
C11
30p
R22
100
U2
XC6204C502MR 1
2
3
5VIN
VSS
CE
VOUT
VDD
FROM A/D
VDD
KTN2222AS
C
+
C4
100u/16v
R10 10k
R18
2.2k
JP1
1 2
B
R12
10k
6100-PW2-0000-0
KTN2222AS
R11 10k
CAL S/W
C6
0.1uF
POWER_CHK
AUTO POWER
B
KDS184
R5
100
C3
E
U2 uPD789324
1 2
3
4
5
6
7
8
9
10
11 12 13
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 35
38 39 40
41
42
43
44
45
46
47
48
49
50
51
52
34 31 32 33
reset
P60/TO40
P43/KR03
P42/KR02
P41/KR01
P40/KR00
P03
P02
P01
P00
INT/P61
P11 P10
COM0 COM1 COM2 COM3 S0 S1 S2 S3 S4 S5 S6 S7 S8 S9 S10 S11 S12 S17
P82/S20 P81/S21 P80/S22
S23
VLC0
P22/SI10
P21/SO10
P20/SCK10
ICO(VPP)
XT1
XT2
Vss
VDD
X2
X1
S16 S13 S14 S15
VDD
L5
471u
VDD
VIN+
R8
12K

PW-II Service Manual
16
3.2.2. A/D
VCC
VIN+
C8
1 uF
C23
1uF(105)
R20
600k
L9
1 2
MMZ1608Y102C
C22
0.1uF
+VIN
VIN-
L8
1 2
SIG-
VCC
6100-PW2-0000-0
C14
미사용
C17
0.1uF
0
PW-II A/D CIRCUIT DIAGRAM
11Saturday, August 26, 2006
Title
Size Document Number Rev
Date: Sheet of
R21
150K
VDD
(C105)
+
C2
330u
A4
MMZ1608Y102C
L2
471u
MMZ1608Y102C
R17
100k
VIN+
L1
471u
L7
1 2
J2
L/C CON 1
1
2
3
4
56
7
8
9
10
L10
1 2
SIG+
C18
0.1uF
C20
1 uF
MMZ1608Y102C
VCC
CHIP BEAD
C9
0.1uF
R16
50k
VDD
(C105)
SIG+
SIG-
+
-
U4B
HA17358
5
67
84
C15
0.1uF
R19
150K
To L/C
L4
471u
VIN-
(C105)
+
-
U4A
HA17358
3
21
84
C7
1 uF
L3
471u
C16
0.1uF

PW-II Service Manual
17
4. Exploded View

PW-II Service Manual
18
5. Part Location
5.1. Main PCB (Front)

PW-II Service Manual
19
5.2. Main PCB (Rear)

PW-II Service Manual
20
5.3. BATTERY PCB
