ALPHASONIC
USER MANUAL
brainwave
stimulation system
Body&Mind syncSystem

3
2
healthcare
since
2000
Congratulations!
You've made an outstanding Investment in your health and well-being! Before operating your massage
chair for the first time, please read this user’s manual carefully in order to know how to use this product
correctly, and to get the most out of your chair.
Please pay close attention to the Safety & Maintenance and Massage Chair Usage Precautions sections,
and keep these instructions for future reference.
Please note that Our Company reserves the right to revise the design or description(s) of this product at
any time and without notice.
Elite Massage Chairs
Evergreen, Colorado USA
[phone]
[e-mail]
www.casada.com
Since the company was founded in the year 2000, the name CASADA has stood for high grade products
in the area of wellness and fitness.
Today, CASADA – products are available worldwide. What distinguishes CASADA products is their con-
tinuous development, unmistakable design and their absolute focus on improving quality of life as well as
their reliable and excellent quality.
Table of contents
TABLE OF CONTENTS
<timetorelax
Safety & Maintenance Instructions..................................................................................................................4
Massage Chair Usage Precautions ..................................................................................................................6
Equipment........................................................................................................................................................7
Functional Specifications .................................................................................................................................8
Floor Protection..................................................................................................................................9
Moving the Massage Chair .................................................................................................................9
Storage & Maintenance ...................................................................................................................................9
Remote Control.............................................................................................................................................10
Installation...................................................................................................................................................... 11
Specials...........................................................................................................................................................17
Product Specifications ...................................................................................................................................20
EU-Declaration of conformity ......................................................................................................................20
Unboxing & Assembly ...................................................................................................................................21

5
4
SAFETY & MAINTENANCE INSTRUCTIONS SAFETY & MAINTENANCE INSTRUCTIONS
Safety & Maintenance Instructions Safety & Maintenance Instructions
WARNING:
This Massage Chair is an electrical appliance, and careful considerations must be fol-
lowed when using this device.
Connect the massage chair to a properly grounded outlet ONLY to reduce the risk of burns, fire, electric
shock, or personal injury. Grounding provides a path of least resistance for electric current to reduce the
risk of electric shock. This massage chair is equipped with a cord with a grounding conductor and ground-
ing plug, and the cord must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances. A surge protector is highly recommended.
• Check with a qualified electrician if you are in doubt as to whether the product is properly grounded.
• Do not modify the plug provided with the massage chair.
• This massage chair is for use on a nominal 120-volt circuit that has a grounding plug.
SERVICE & REPAIR
• This massage chair does not require any regular maintenance.
• Only use gentle cleaning products, never products with thinner, benzene or alcohol
• Any possible repairs may only be carried out by authorized service technician.
• Improper use and unauthorised repairs are not permitted for safety reasons and lead to loss of war-
ranty.
• If the massage chair is not used for a longer period of time, the power cable should be wound up and
the device should be stored in a dry environment.
• For questions regarding warranty coverage, please refer to www.elitemassagechairs.com
SAFETY WARNINGS
• In order to avoid injury please do not stick your fingers between the massage rollers.
• Never touch the power plug with wet hands.
• Avoid contact of the massage chair with water, high temperatures and direct sunlight.
• Do not use the massage chair in an environment with high humidity levels; e.g. in the bathroom.
• Do not use the massage chair in an area with insufficient space or in an area where the fans are covered
and a supply of fresh air is not guaranteed.
• To avoid the danger of short-circuits, disconnect the massage chair from the power supply if it is not
being used for a long period of time.
• Do not use any damaged cables, plugs or loose sockets.
• Never position massage chair in proximity to an open fire, and never smoke while in the chair.
• If cables/plugs are damaged, they must be replaced by the manufacturer, a service representative or
by qualified personnel.
• In case of malfunction, disconnect immediately from power, cease any operation of the chair, and
contact the manufacturer.
• Inappropriate or incorrect use disclaims any liability for damage.
• Never use pointed or sharp objects to avoid damaging the massage chair.
• It is essential to use only sockets that fit the plug and ensure that the plug is fully inserted into the
socket in order to reduce the danger of short circuits or fire.
• It is necessary to disconnect the massage chair from the power supply during cleaning.
• If an unexpected power failure occurs during use, set the switch to the OFF position immediately and
disconnect the plug in order to avoid damage to the massage chair.
• Do not use the massage chair if the electric cables are wet or damaged.
• Any children, disabled or frail people who are in the vicinity of the massage chair or who are using the
massage chair must be supervised at all times. This product is not suitable for children under the age
of 12.
• Use the product for the purpose described in the operating instructions only.
• Please only use accessories provided by the supplier, with the exception of any personal mobile device
used for music or other massage chair-specific features.
• Please do not stand, sit or bounce on the footrest in order to prevent damage.
• Do not try to sit on the arm or backrest in order to avoid damage or injuring yourself.
• Please keep the massage chair clean regularly and prevent foreign bodies from penetrating the crevic-
es of the massage chair, and do not consume food while in the massage chair.
• Please do not pull directly on the power supply cable.
• When adjusting the position of the footrest or the backrest, ensure that there are no other objects
underneath, in particular pets, small children, or other obstacles.
• The product is only intended for domestic or in-home use.
• If the flexible power cable becomes damaged, another flexible cable designated for the same purpose
must be used or a designated flexible cable must be purchased from the manufacturer r their service
point as a replacement.

7
6
Massage Chair Usage Precautions
IF YOU ARE UNSURE WHETHER YOU SHOULD USE THE MASSAGE CHAIR,
CONSULT YOUR DOCTOR:
• Massages during pregnancy or in case of one or several of the following complaints in the massaged
area are not recommended.
• Recent injuries, thrombotic diseases, all kinds of inflammations and swellings, and cancer. It is recom-
mended to consult a doctor before having a massage for the treatment of ailments and illnesses.
• Persons with impairments of the body, perception or mind, or persons lacking experience and knowl-
edge of massage should only use this chair under the supervision and guidance of persons responsible
for their safety.
• Recommended maximum daily usage of the massage chair is 30 minutes. Each part of the body should
be massaged for a maximum of 15 minutes. Excessive massaging can have a counterproductive effect.
• In order to avoid unpleasantness or hazards through the use of the massage chair, it is recommended
that the following people consult a doctor before using the product:
• Persons in need of a rest
• Persons receiving medical treatment
• Back patients, persons with spinal problems or malposition
• Persons with pacemakers
• If you feel pain during the massage, stop the treatment immediately.
• Do not use the massage chair immediately after consuming a meal or under the influence of alcohol.
• If you injure yourself when using the chair, seek medical treatment immediately.
• Please do not massage any reddened, swollen or inflamed areas of the skin.
BRAINTRONICS FUNCTIONS SHOULD NOT BE USED BY ANY PERSONS
WITH THE FOLLOWING CONDITIONS:
• Psychoses (e.g. schizophrenia, bipolar disorder, endogenous depression)
• Personality disorders
• Epilepsy and similar seizure disorders
• Heart diseases
• Diseases of the central nervous system
• Thrombosis
• Endogenous depression
• ADS (under-active)
• Recent serious heart attack or stroke
• Mental disability
• Addiction such as drugs, alcohol and drug dependency
• Regular use of psychotropic drugs
• Pregnancy
NOTE: For ethical and legal reasons braintronics should not be used on children under the age of 14 and
adolescents without express permission of the legal representative and on people with religious
conflicts.
MASSAGE CHAIR USAGE PRECAUTIONS
Equipment
12
13
14
15
16
17
18
3
4
5
6
7
2
9
10
11
8
1
12. Back cover
13. Manual controller
14. Manual controller pocket
15. Drive box cover
16. Safety switch
17. Base caster
18. Power line and power plug
19. Power socket
20. Fuse box
21. Power switch
22. Manual controller socket
23. USB port
1. Head cushion
2. Upper arm
air bag components
3. Arm air bag components
4. Seat cushion
5. Leg rest frame
6. Foot rest frame
7. Calf stop sealing plate
8. Back rest pad
9. Armrest decoration
10. Armrest
11. Side cover
19 20 21 22 23
EQUIPMENT

9
8
FUNCTIONAL SPECIFICATIONS
Functional Specications Functional Specications
• Designed with a set of vertically movable, 4-roller system or "massage hands" or "hands"
• Designed with emulated massage methods of Shiatsu, kneading, tapping/flapping/knocking and simul-
taneous kneading and tapping
• Automatic shoulder detection and location acquisition
• Pre-set with characterized auto massage functions including ache-relief, comfort, ease, upper body,
lower body
• Set Memory Functions Indicated as M1 and M2
• Manual massage for the upper body with three options: Fixed, Partial, and Overall massage
• Five levels of speed adjustment for the massage functions of tapping and shiatsu
• Three levels of massage hand width adjustment in select massage types
• On Partial upper body option, massage hands can be moved up and down to adjust the massage point
desired
• Air pressure or Acupressure massage function with three modes: Full body, Air Pressure, Arms, and
Legs
• Leg unit designed with roller massage function at the bottom of foot, two pairs of papillae on the toe
rotating massage, on the arch and heal mastoid skin scraping style massage
• On upper arm, or shoulder airbags there are two levels of width adjustment for various shoulder
sizes; adjustment is made by gently pushing the shoulder unit Inwards, indicated by "clicks" with each
adjustment level.
• Back heating via carbon infrared source
• Footrest Is adjustable via manual pressure to suit various body heights
• Zero-space design allows chair to be positioned very near the wall and still recline for maximum space
utilization
• Footrest lift adjustment, backrest position adjustment, and automatic recline adjustments Including
Zero-G position
• L-track design for longer massage stroke
• Integrated “safety shield” safety switch in the power supply cover, automatically stops all functions
when pressure sensors detect presence of children, pets or other objects.
MOVING THE MASSAGE CHAIR
The massage chair should not be moved on sensitive
floors, but should be carried by at least two persons.
Only if on a safe flooring surface that will not be dam-
aged, to move the chair tilt the backrest backward to
a certain degree (with the center of gravity resting on
the wheels), and push the chair forward or backward
with your hands. When to the desired location gently
lean the chair back to the upright position.
NOTE:
During movement you must turn off the power switch first and then unplug the power line and hand
controller connecting line.
FLOOR PROTECTION
If your massage chair is to be placed on a hardwood
or other damageable floor surface, we recommend
the use of an area rug or other pad under the chair's
base to avoid damage, as well as to dampen sound of
the air compressor.
FUNCTIONAL SPECIFICATIONS / STORAGE & MAINTENANCE
Storage & Maintenance
• Never store the chair at high temperatures or in proximity to open fire. Avoid prolonged exposure to
sunlight.
• If the device is on an uneven surface, do not roll or push it; lift it up in order to move it.
• Please take breaks after each use and do not use the device a number of items without pauses.

11
10
INSTALLATION
Remote control
REMOTE CONTROL
V+V–
6
10
5
15
9
7
3
11
1
8
2
12
13
16
c
c
a
a
e
e
b
b
d
d
14
4
1Display
2ON/OFF
3Adjust Shoulder
During Braintronics mode:
Adjust Volume
4Zero Gravity
5Movement of massage arms
UP/DOWN
6Sole Roller
7Backrest Position Adjustment
8Footrest Postition Adjustment
9Heating Element ON/OFF
10 Air Pressure
11 Air Intensity
12 Auto Programs
aAche relieve
bRelax
c8 braintronics programs
dMemory massage, upper body/M1
eMemory massage, lower body/M2
13 Manual Programs
aKneading
bTapping
cKnead & Tap
dShiatsu
eKnocking
14 Speed – 3 Levels
15 Width 3 Levels
(rolling, tapping, knocking only)
16 Back Stretch
Installation
1 – SWITCH POWER SUPPLY ON
Diagram
of plug in Diagram of the switch position of power supply
To begin, attach the power cable You will note the power is indicated by symbols “l” and “O”. “I” is the Po-
wer ON setting and “O” is the Power OFF setting. We recommend you turn the power to the off position
when the chair is not in use.
NOTE: In order to avoid damage caused by power surges that can damage the chair’s electrical and elec-
tronic components and can void your warranty, we strongly recommend the use of a high quality surge
protector (not a simple power strip) that you would use with any computer or home theatre system.
2 – START TO MASSAGE
1. Press power button on Remote Control, massage chair automatically reclines, and proceed with the
detection of your shoulders and Acupressure points. For an accurate scanning, ensure you have the
back of your head and shoulders firmly against the hedrest cushion, and be careful not to lean forward,
especially with your head.
2. Upon completion of the scan a beeping sound will begin emitting from the controller.
3. If at any time during your massage session you would like to fine tune the location of your shoulders,
you can use teh Shoulder Adjust up and down buttons to a suitable position.
4. If after 10 seconds no massage function has been selected the chair will automatically initiate a massage
sequence.
BUTTON DESCRIPTION DISPLAY
Adjust
shoulder
Move the massage heads upward to a suitable position.
Move the massage heads downward to a suitable position.

13
12
INSTALLATION INSTALLATION
Installation
AUTOMATIC MASSAGE
BUTTON FEATURE DISPLAY
Ache
relieve
Deeply massage on acupressure points, effectively alleviate pain Auto F1
Relax
Promotes circulation of the blood and relaxes the body Auto F2
Upper
body/M1
Massage focus on upper body Auto F3
Lower
body/M2
Massage focus on lower body Auto F4
3 – CHOOSE MASSAGE FUNCTION TO MASSAGE
Memory function massage
Press button Upper body/M1 or Lower body/M2 for 3 sec-
onds, then enter into memory massage function M1 or M2,
it will revert to the previous memory massage mode.
BUTTON FUNCTION DISPLAY
Upper
body/M1
Memory massage Memory
Lower
body/M2
Installation
MANUAL MASSAGE
BUTTON ADJUST MASSAGE BALL DISPLAY
Shiatsu
Shiatsu stimulates specific parts of the body and mobilizes the
muscles. S1 – normal pressure / S2 – deep pressure
Knead & Flap
Combination of kneading and flapping, 3 stage adjustable
intensity and speed
Flap Speed and width adjustable in 3 stages
Kneading
Massage technique to relieve tension with adjustable intensity and
speed
Tapping
Tapping massage promotes circulation of the blood and relaxes
tense muscles. T1 – Consistent Tapping / T2 – Interval Tapping
Speed 3 different speed levels Speed
Width Different width levels Width
Shoulder
adjust
High shoulder position
Suitable shoulder position
Low shoulder position BACK STRETCH
BUTTON DESCRIPTION DISPLAY
Back stretch
Fixed position (fixed point) massage back and forth
H0
Small area (partial area) massage back and forth
H1
Overall massage back and forth
H2
Upper body massage back and forth
H3
Lower body massage back and forth
H4
Massage hand move up / Massage hand move down
Massage point adjust (in fixed point, partial modes you can adjust the massage
position)
AIRBAG-MASSAGE
BUTTON DESCRIPTION DISPLAY
Air
pressure Three air pressure modes(full body, arm and leg )
for lower body
Arm
Feet
Air
intensity With three adjustable setting Arm
Feet
SOLE ROLLER / HEATING
BUTTON DESCRIPTION DISPLAY
Sole roller: sole roller switch, with 3 speed levels available
Heater
Infrared back heating needs about 3 minutes to thoroughly heat
up
FOOT REST / BACK REST / ZERO GRAVITY
BUTTON DESCRIPTION
Foot rest UP: When activating this button, the foot rest will lift slowly. It will stop
when you let go of the button.
Foot rest DOWN: When activating this button, the foot rest will lower slowly. It will
stop when you let go of the button.
Back rest UP: When activating this button, the back rest will lift slowly. It will stop
when you let go of the button.
Back rest DOWN: When activating this button, the back rest will lower slowly. It will
stop when you let go of the button.
Zero Gravity: Each time you press this button, the chair will go to the next of three
different reclining positions.
When

15
14
INSTALLATION
Installation
INSTALLATION
Installation
4 – STOP MASSAGE / MEMORY FUNCTION
1. Press the Power button on the Remote Control at any time during the massage to stop all massage
functions. The back rest and footrest reset to their starting positions.
2. Within this time you can set the memory function. Note that while the memory function can be set,
during memory setting the back and foot rest will not go back to their starting positions.
3. To set Memory, press M1 or M2 within 10 seconds of massage cycle completion to save the adjust-
ments of the last massage.
Diagram of the switch position of power supply Power switch method map
WARNING
Thanks to the safety switch in the power supply
vox, the chair automatically stops all functions,
when there is too much pressure on that part of
the chair. this way, it prevents people from getting
injured.
5 – CALF INSTALLATION
a) Install the rotating shaft into the fixed axle. Please pay attention to the correct alignment of the
R-pin. (Chart 1)
b) After the fixed axle is aligned and connected correctly, put everything together as shown in the
second picture. (Chart 2)
Chart 1 Chart 2
c) As shown in Chart 3, please close the R-pin on the other side of the foot rest.
d) Finished Installation. (Chart 4)
Chart 3 Chart 4
NOTE
•To avoid injuries and damaging the product, the foot rest should not be pressed down or lifted up by
hand during the massage.
•To avoid an uncomfortable sitting position, ensure that the massage mechanism does not stop while
in the area of the still in the seat cushion. (Chart 2)
Chart 1 Chart 2

17
16
Installation
INSTALLATION
6 – HEAD CUSHIONS AND BACK CUSHION
Your Alphasonic comes with an adjustable two-part head cushion for your Individual comfort. You
can remove the outer head cushion If desired, or both head cushions should you wish to experience a
more Intense neck and head massage. The chair is also equipped with a removable back cushion; how-
ever, we recommend that you leave this in place.
Specials
SPECIALS
Top headrest
cushion
Bottom headrest
cushion
SHIATSU
Shiatsu (finger press) is a form of body therapy originating in Japan. The massage technique con-
sists of soft, rhythmic, far-reaching stretches and rotations. The aim of Shiatsu is to simulate indi-
vidual parts of the body and to mobilize the muscles.
2D MASSAGE
The massage chair is equipped with an intelligent 2D massage mechanism. This allows the mas-
sage chair to measure your back to determine a more exact position of the sections of the spine.
KNEADING
Skin and muscles are either clasped and kneaded between the thumb and the index finger or with
both hands. This massage technique is used in particular to ease tension.
FLAP
Circulation in the muscles is stimulated and the tendons are encouraged to stretch by means of light
tapping with a cupped hand, which also reduces tension at the same time.
TAPPING
Short, tapping movements are performed with the edge of the hand, the palm or the fist. This pro-
motes blood circulation in the skin and softens tense muscles. If tapping is performed at lung height,
this can improve the release of mucus in the lung.
KNEAD & FLAP
A massage combination of kneading and flapping.
BACK STRETCH ROLLING
Targeted stretch massages activate the body and have an invigorating effect on the whole body.
ROLLING
Pleasant alternation between relaxation and releasing the muscles – also perfectly suited for a final mas-
sage, for relaxation and recovery of the muscles.
CARBON HEATING
Deeply penetrating Carbon infrared heat, blood vessels expand, the blood flow increases and the
muscle tone is reduced. In addition, it carries out a highly beneficial effect on nerve cells, which are
responsible for reporting pain to the brain.
GUA SHA
The scraping of -GuaSha- with slight pressure opens superficial blood vessels and stimulates blood
circulation. GuaSha is often applied in combination with acupressure „shu points“ to bring additional
stimulation to relieve ache symptoms.
AIR COMPRESSION
Rising and receding airbags have a pumping motion which produces natural muscle reflexes. This is
particularly beneficial in the calf and foot area.
SHOULDER WIDTH
The ability to fine tune the shoulder position generated by the initial scan. Once adjusted the coor-
dinates are stored and utilized for any Memory massage replay..
Headrest cushions
position can be adjusted
using Velcro attachements
Headrest cushions can be
removed for more intense
neck and head massage

19
18
SPECIALS
Specials
ARTHROSIS TRACTION
Arthrosis Traction is a gentle stretching and pressure. This stimulates the cartilages, so that liquid
transport is stimulated, nutrients are better received and Arthrosis symptoms can be alleviated.
MAGNET THERAPY
Magnetic therapy generates magnetic alternating fields in your body. Blood circulation and cell
metabolism can be influenced positively and oxygen content in cell tissues increases.
brainwave
stimulation system
BRAINTRONICS
Braintronics technology synchronizes your brainwaves through audio stimulation. Combined with
a specially developed massage programmes.
L-TR ACK
Refers to the shape of the track along which the massage block and massage hands move. L-shape
tracks enable a longer massage stroke than traditional I-track or S-track designs.
S-LINE
With this automatic program the massage heads are working very close to your body, they
massage the whole back down to your buttocks. The S-shaped mechanic is constructed after
the natural anatomy of the spine.
ZERO SPACE
For the fully reclined or lying-position the massage chair slides forward on the frame and so
that only 2 inches of space is required between the backrest of the chair and the wall.
ZERO GRAVITY
Also referred to as Zero-G body position designed for minimum blood flow resistance and
maximum comfort. Often referenced by the body positioning of astronauts who must be
seated for long periods of time.
AUTOMATIC
Specifically developed automatic programs for the whole body, which offer a wide range of
different massage techniques. Heating can be turned on or off during any Automatic Programs
for personal preference.
MEMORY (M1 AND M2 FUNCTIONS)
Using the intelligent memory function, the massage chair stores your favorite massages as well
as your scan points so that massages can begin immediately without a scan. You have the op-
portunity to save two programs with different buttons (M1 & M2).
BACK AREA
An individual applicable to any size massage area.
ADJUSTABLE FOOTREST
The footrest can be extended up to 5 inches, this way it is adaptable to different body sizes.
ADJUSTABLE PILLOW
If necessary, the double cushion can be placed to reduce the neck and shoulder massage in-
tensity.
SPECIALS
Specials
RECLINING POSITION
The adjustability of the backrest and footrest contributes to personal well-being of the body
position.
SAFETY SHIELD
In case of excessive pressure, security sensors in the power supply stop all functions of the
massage chair to prevent injuries.
ADJUST SHOULDER
The massage heads can be moved upward or downward to a suitable position in the shoulder
area.
AIR INTENSITY
Adjustable airbag massage intensity.
AIR AREA
Three air pressure modes (full body, arm and leg / lower body).
SPOT
The massage heads can massage a particular spot.
SPEED
Massage speed is adjustable.
WIDTH
The distance between the both massage heads can be set (narrow, medium and wide).
VOLUME (BRAINTRONICS FUNCTION)
Adjusting the volume of the audio inputs of the Braintronics programs.
ACUPRESSURE POINTS
Key acupressure points on the, calves and ankles are massaged.

21
20
healthcare
since
2000
EU – Declaration of conformity
Complies with European Regulatory Standards 2006/95/EC.
UNBOXING & ASSEMBLY
Casada USA
Elite Massage Chairs
Evergreen, Colorado USA
[phone]
www.elitemassagechairs.com
Copyright Images and text are subject to the copyright of CASADA International GmbH and may not be
used without express consent.
Copyright © 2016 CASADA International GmbH.
All rights reserved.
PEODUCT SPECIFICATIONS / EU-DECLARATION OF CONFORMITY
Product Specications
Model: Elite Casada Alphasonic
Dimensions: Length 58” x Width 31.5” x Height 35.5”
Chair Weight: 206 lbs.
Maximum User Weight: 270 lbs.
Voltage: 110-120 V ~ 60 Hz
Nominal Power: 150 W
Installation Requirements: Attach footrest and Remote Control
ALPHASONIC UNBOXING AND ASSEMBLY INSTRUCTIONS
1. Using scissors or utility knife, cut all vertical and horizontal plastic shipping bands from around box.
Use caution as straps are applied by machines and so are under tension!
2. Using the cutout handles on each end of the box, lift lid off box and set aside. There is no need to cut
the tape on the lid (top) to remove it.
Unboxing & Assembly
Cut all Green Bands
Remove all banding if not
already completed
Lift upper box and off of
chair with these handles
Lift upper box up from
handles on each end

23
22
UNBOXING & ASSEMBLY
Unboxing & Assembly Unboxing & Assembly
5. Cut the packaging tape on the front edge of the box so that you can lay the box edge flat. This is to allow
the chair to be rolled forward off the base box. As the front edge of the base box is held upright with
tape only, the box may be easily used again if necessary for re-boxing by re-applying packaging tape
where cut.
6. (Solo Removal) Roll chair out of box. Refer to the following diagram for reference. The chair may be
tilted back until the center of gravity is resting on the rear wheels. Roll the chair out of the box and gently
bring back to the ground. Use care not to damage the plastic cover at the rear of the chair.
The chair can now be removed from the base box via two methods. Refer to Step 6 for solo removal of
the chair from the base box, or skip to Step 7 for two-person removal.
UNBOXING & ASSEMBLY
3. Remove top protection board (use caution for any sharp edges), packing materials, and accessories bag
from chair.
Remove
Styrofoam
from each
side and top
board
Accessoires bag
Cut packaging tape
Lay cardboard flet
in order to roll
chair out of box
3. Lift footrest off of seat and remove plastic wrapping from around chair.
Next, you will notice that the massage chair is shipped on a cardboard tray or base box.
Remove plastic wrapping
from around chair.
chair unwrapped
Accessoires bag
and footrest
Use caution
not to damage
plastic cover
Lift from underneth arm
Lift the chair out of lower box
Easiest method:
have third
person pull box
out from under
chair while
lifting

25
24
UNBOXING & ASSEMBLY
Unboxing & Assembly Unboxing & Assembly
UNBOXING & ASSEMBLY
For orientation, this next step referenc-
es the left side of the footrest. For the
purposes of these instructions, the left
side is as you stand in front of the chair,
or where the right leg would be posi-
tioned for someone sitting in the chair.
Proper orientation of footrest plug connection
FOOTREST ASSEMBLY
1. Remove cotter pins, foam, and twist tie used for secure shipping.
Pull out cotter pins
Remove cotter pins
Remove twist tie
and foam
"Left side" area
referenced
2. Connect the air hose and footrest wire (harness) from chair to footrest.
Note the diagram on the chair showing the proper orientation of the plug
Wire and plug Footrest
Chair
3. Starting with the left side, slide the footrest mounting hole (located on the footrest) onto the footrest
mounting rod (located on the chair frame). Insert cotter pin. Press the footrest onto the rod as far as it
will go. Notice there is a plastic sleeve on the rod which may need to be rotated slightly so the cotter pin
can be inserted into the holes on the steel mounting rod. This can be adjusted either while the footrest
mount is in place, or before the footrest is mounted.
Footrest
mounting hole
Cotter pin hole
Cotter pin inserted
Press footrest as far left as it
will go onto rod
Incorrect
Correct
Footrest
mounting rod

27
26
UNBOXING & ASSEMBLY
Unboxing & Assembly Unboxing & Assembly
UNBOXING & ASSEMBLY
4. The opposite side footrest mount requires
a mostly blind install – as the connection
may be hidden from view by the footrest as
you position it for install. The opposite side
footrest mounting bracket will not slide
onto the mounting rod with the footrest
sitting on the floor. However, start by plac-
ing the footrest mount up to the mounting
rod as shown below while the footrest is
on the ground (or in the lowest possible
position).
5. Next lift the footrest upward, while making sure the mounting bracket is resting on top of the mounting
rod as you pivot the footrest upward.
6. Insert the cotter pin as on the opposite side. At this point the foot-
rest installation is completed.
7. Next insert the remote control cable at the rear of the chair, near
the floor. Note the indent on the remote cable is inserted at the top
of the port on the chair, or so that the indent aligns with a corre-
sponding ridge in the controller port.
Elite Massage Chairs
29017 Hotel Way, Unit BO5-C
Evergreen, CO 80439
www.elitemassagechairs.com
All rights reserved.
SAVE THESE INSTRUCTIONS.
Indent
Footrest mount bracket
pivoting on top of mount rod
Power cable port Controller port
Lift the footrest
above level
Insert hand
to help guide mounting
Apply pressure on footrest
toward opposite mount
View from
outside edge
of footrest /
side of chair
