Manual
celexon projector ceiling mount
universal PS Ultraat
Thank you for purchasing a celexon ceiling mount. Please read the
instrucons carfully and ensure that the mount is suitable for your
projector prior to installaon.
Cauon:
DO NOT EXCEED RATED LISTED WEIGHT.
SERIOUS INJURY OR PROPERTY DAMAGE MAY
OCCUR!
celexon.
TM
Gutenbergstraße 2
48282 Emsdetten
www.celexon.com
SKU: 1091279

Warning
Components
• Do not begin the installation until you have read and understood all the instructions
and warnings contained in this installation sheet. If you have any questions
regarding any of the instructions or warnings, please contact your local distributor.
• This mounting bracket was designed to be installed and utilised ONLY as specified
in this manual. Improper installation of this product may cause damage or serious
injury.
• This product should only be installed by someone with good mechanical ability who
has basic building experience and fully understands this manual.
• Make sure that the supporting surface will safely support the combined weight of
the equipment and all attached hardware and components.
• Always use an assistant or mechanical lifting equipment to safely lift and position
the equipment.
• Tighten screws firmly, but do not over tighten. Over tightening can cause damage to
the items, This greatly reduces their holding power.
• This product is intended for indoor use only. Using this product outdoors could lead
to product failure and personal injury.
Important: Ensure that you have received all parts according to the component
checklist prior to installation. If any parts are missing or faulty, telephone your local
distributor for a replacement.
Note: Read the entire instruction manual before you start installation and assembly.
ceilingplate (x1) projector plate assembly (x1) B
safe cover (x4) C padlock (x1) D
ceilingplate (x1) projector plate assembly (x1) B
adapter bracket (x1) E
M-J
M-L
Use the padlock in the locking plate and then fix the locking plate with a screw to
prevent the projector plate assembly rocking in use.
Pitching Angle Adjustment
Adjust to the desired angle.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least
every three months).
• Please contact your distributor if you have any questions.
61

Installing the Safe Covers
C
Insert the four safe covers into the
arms of adapter bracket till they fit
mounting hole pattern.
Use four screws to fix the safe covers
and tighten all screws with a proper
screwdriver.
Hanging the Bracket onto the Ceiling Plate
Carefully guide the projector bracket with the four screws into the keyhole opening,
slowly turn the projector bracket clockwise into place.
For Solid Brick and Concrete Mounting
Drill three pilot holes
Package M
M3x25 (x4) M4x25 (x4) M5x25 (x4) M6x25 (x4)
M-A M-B M-C M-D
D4 washer (4x) D6 washer (x4) M5x8 (x4) M8x20 (x1)
M-E M-F M-G M-H
ø12xø6x13 (x4) 4mm allen key (x1) 6mm allen key (x1) M5x10 (x1)
M-I M-J M-K M-L
Package W
ST6.3x50 (x3) concrete anchor (x3) D6 washer (x3)
W-A W-B W-C
25

Screw the ceiling
plate onto the
ceiling
WARNING
Installer must verify that the supporting surface will safely support the combined
weight of the equipment and all attached hardware and components.
Installing the Projector Plate Assembly
M-H
M-K
M-J
Attach the projector plate assembly to
the ceiling plate using the supplied screw.
It is necessary to loosen or tighten the
adjust screws with an Allen key according
to the weight of the projector installed.
Installing the Adapter Bracket
Place the projector bracket as close as
possible to the projector‘s center of
gravity. Position the holes of arms over
the mounting holes.
Arm
Make sure three point in a line to
help with screwing the safe covers.
M-I
M-A
M-B
M-C
M-D
M-E
M-F
Note: If there are only three mounting holes using three arms of adapter bracket.
Important: If the projector does not have at least three mounting holes, do not use
this adapter bracket.
Screw the adapter bracket onto the projector.
TIGHTEN ALL SCREWS BUT DO NOT OVER TIGHTEN!
