Cembre B600CND User manual

1
BATTERY OPERATED HYDRAULIC CRIMPING TOOL
OUTIL HYDRAULIQUE DE SERTISSAGE SUR BATTERIE
HYDRAULISCHES AKKU-PRESSWERKZEUG
HERRAMIENTA HIDRÁULICA DE CRIMPADO A BATERíA
UTENSILE OLEODINAMICO DA COMPRESSIONE A BATTERIA
B600CND
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
ITALIANO
OPERATION AND MAINTENANCE MANUAL .................5
NOTICE D’UTILISATION ET ENTRETIEN...........................13
BEDIENUNGSANLEITUNG..............................................21
MANUAL DE USO Y MANTENIMIENTO .........................29
MANUALE D’USO E MANUTENZIONE...........................37
20M015

2
FIG. / BILD 1 FIG. / BILD 2
FIG. / BILD 3
FIG. / BILD 4
FIG. / BILD 5
9
15
Connector
Connecteur
Kabelschuh
Conector
Connettore
Battery - Batterie - Akku
Batería - Batteria 12
12
12
21
˜0 %
50 %
100 %
P
11
14
14
13
Sequence and direction of the compressions
Séquence et direction des sertissages
Reihenfolge und Richtung der Pressvorgänge
Secuencia y dirección de las compresiones
Sequenza e direzione delle compressioni
3
Die set
Matrices
Presseinsätze
Matrices
Matrici

3
1
HEAD / TETE / KOPF / CABEZA / TESTA
2
LED WORKLIGHT / ECLAIRAGE PAR LED / LED-BELEUCHTUNG / LUCES LED / ILLUMINAZIONE LED
3
OPERATING BUTTON / GACHETTE DE COMMANDE / STARTKNOPF / BOTÓN DE ACCIONAMIENTO
/ PULSANTE DI AZIONAMENTO
4
BATTERY / BATTERIE / AKKU / BATERÍA / BATTERIA
5
DISPLAY / ECRAN / DISPLAYANZEIGE / PANTALLA / DISPLAY
6
PRESSURE RELEASE BUTTON / GACHETTE DE DECOMPRESSION / DRUCKABLASSKNOPF / BOTÓN
DESBLOQUEO PRESIÓN / PULSANTE SBLOCCO PRESSIONE
7
TOUCH BUTTON FOR MENU SELECTION / TOUCHE POUR SELECTIONNER LE MENU / TOUCH-
TASTE FÜR AUSWAHLMENÜ / TECLA PARA SELECCIONAR EL MENÚ / TASTO A SFIORAMENTO
PER SELEZIONE MENU
8
HANDLE / POIGNEE / GRIFF / EMPUÑADURA / IMPUGNATURA
9
BATTERY RELEASE / DEBLOCAGE BATTERIE / AKKU ENTRIEGELUNG / DESBLOQUEO BATERÍA /
SBLOCCO BATTERIA
10
WRIST STRAP / DRAGONNE / HANDGURT / CORREA PARA LA MUÑECA / CINTURINO DA POLSO
FIG. / BILD 6
3
4
10
9
8
2 (x4)
1
5
7
6

4
– Never throw batteries into fire or water.
– Jamais jeter les batteries dans le feu ou dans l'eau.
– Werfen Sie Akkus nicht ins Feuer oder Wasser.
– Nunca tire las baterías al fuego o al agua
– Mai gettare le batterie nel fuoco o in acqua.
– Always recycle the batteries.
– Recycler toujours les batteries.
– Verbrauchte Akkus stets dem Recycling zuführen.
– Reutilizar siempre las baterías.
– Riciclare sempre le batterie.
– Do not discard batteries into domestic refuse or waste disposal.
– Ne pas jeter de batteries dans une poubelle ou autre lieu non prévu à cet effet.
– Verbrauchte Akkus nicht der allgemeinen Abfallentsorgung zuführen.
– No tirar las baterías al cubo de basura o lugar parecido.
– Non buttate le batterie fuori uso nei cestini della spazzatura o luoghi simili.
Battery - Batterie - Akku - Batería - Batteria
– Before using the tool, carefully read the instructions in this manual.
– Avant d'utiliser cet outil, lire attentivement les instructions de cette notice.
– Vor Inbetriebnahme unbedingt die Bedienungsanleitung durchlesen.
– Antes de utilizar la herramienta, leer atentamente las instrucciones en este manual.
– Prima di utilizzare l'utensile, leggere attentamente le istruzioni riportate in questo manuale.
– When operating the tool, keep hands away from the danger zone.
– Au cours du sertissage, tenir les mains éloignées de la zone de travail.
– Während des Verpressens nicht mit den Händen in den Pressbereich gelangen.
– Durante su utilización, mantenga las manos fuera de la zona de peligro.
– Durante l'utilizzo, mantenere le mani fuori dalla zona di pericolo.
– Do not operate when dies are not in place.
– Insérer les matrices avant d'actionner l'outil.
– Nicht ohne Presseinsatzpaar betätigen.
– No poner en presión sin matrices.
– Non mandare in pressione l'utensile senza le matrici inserite.
WARNING SYMBOLS - SYMBOLES D'AVERTISSEMENT - WARNSYMBOLE -
SÍMBOLOS DE ADVERTENCIA - SIMBOLI DI AVVERTENZA
– User information (Directives 2011/65/EU and 2012/19/EU), see page 46.
– Information pour les utilisateurs (Directives 2011/65/EU et 2012/19/EU) voir page 46.
– Information für den Benutzer (Richtlinien 2011/65/EU und 2012/19/EU) siehe Seite 46.
– Informe para los usuarios (Directivas 2011/65/EU y 2012/19/EU) vease página 46.
– Informazione agli utenti (Direttive 2011/65/EU e 2012/19/EU) vedere pagina 46.
Tool - Outil - Werkzeug - Herramienta - Utensile

5
(1) Directive 2006/42/EC, annexe 1, point 1.7.4.2 letter u
LpA = weighted continuous acoustic pressure level equivalent.
LpCPeak = maximum value of the weighted acoustic displacement pressure at the work place.
LWA = acoustic power level emitted by the machine.
(2) Directive 2006/42/EC, annexe 1, point 2.2.1.1
Weighted root mean square in frequency of the acceleration the upper limbs are exposed to for each biodynamic
reference axis. Tests carried out in compliance with the indications contained in EN ISO 5349-1/2 Standard, and under
operating conditions much more severe than those normally found.
1. GENERAL CHARACTERISTICS
ENGLISH
Application range suitable for installing electrical compression connectors
on conductors up to 300 mm2 (600 MCM)
Rated crimping force
kN
60
Minimum operating pressure
bar 742
Dimensions (ref. to Fig. 7) mm (inches) 398x136x81 (15.6x5.3x3.2)
Weight with battery kg (lbs) 3,15 (6.9)
Motor V18
Operating temperature °C (°F) -15 to +50 (+5 to +122)
Recommended oil TOTAL DIEKAN 1640 or equivalents
Operating speed twin speed operation and automatic switching from
a rapid advancing speed of the ram to a slower,
more powerful crimping speed
Safety maximum pressure valve
Rechargeable battery V / Ah / Wh 18 / 2,0 / 36
Type CB1820L (Li-Ion)
Weight kg (lbs) 0,4 (0.9)
Battery charger
Input
type ASC55-EU
V / Hz 220 - 240 / 50 - 60
W 85
Acoustic noise (1)
LpA dB (A)
67,7
LpCPeak dB (C) 89,2
LWA dB (A) 74,2
Vibration (2) m/s2ahv 0,724

6
ENGLISH
WARNING
Do not use the tool for purposes other than those intended by Cembre.
The operator should concentrate on the work being performed and be careful to maintain
a balanced working position.
Before starting work on electrical equipment, please ensure that either there are no live
parts in the immediate working area or that precautions are taken for working near live
parts in accordance with EN50110-1.
Do not use this tool on or near live conductors without proper personal protective equip-
ment. Failure to observe this warning could result in severe injury or death.
The tool is unsuitable for continuous use and should be allowed to cool down following
uninterrupted, successive crimping operations. For example, having exhausted a fully
charged battery in one session, delay battery replacement for a few minutes.
Protect the tool from rain and moisture. Water will damage the tool and battery.
Electro-hydraulic tools should not be operated in pouring rain.
2. INSTRUCTIONS FOR USE
When introducing or changing dies, the battery must first be removed from the tool.
The part reference includes the following:
Hydraulic crimping tool.
Li-Ion rechargeable battery (2 pcs).
Battery charger.
Shoulder strap.
Plastic carrying case.
USB cable (Ref. to section 5).
2.1) Preparation
The tool can be easily carried using either the main handle (8) or the shoulder strap attached to the
two eyelets of the wrist strap (10) (Ref. to Fig. 6).
The tool can be held in one hand while positioning the conductor with the other.
Before starting any work, check the battery charge (Ref. to section 2.8) and recharge if
necessary, following the instructions in the battery charger user manual.

7
ENGLISH
To replace the battery, remove it by pressing the release button (9) (Ref. to Fig. 1), then insert the
new battery, sliding it into the guides until it locks.
The display shows the operational parameters of the tool; to customise, proceed as described in
section 2.7.
2.2.1) Inserting of dies
When introducing or changing dies, the battery must first be removed from the tool.
Select the appropriate die set for the connector.
Open the head (if required) by pressing the latch (11) and release the upper die holder (14) (Ref.
to Fig. 2).
Keep release pin (12) depressed and insert one die into the seat on the ram (15) and the other
die into the upper die holder (14) until they are locked by retaining pin (13).
Insert the battery.
2.2) Die advancement
Insert the conductor into the connector.
Position the connector between the dies and ensure the correct location
of the crimp (Ref. to Fig. 3) then close the head by the upper die holder (14).
Ensure that the latch and the upper die holder are fully secured, otherwise
damage may occur during tool operation.
Press the operating button (3) (Ref. to Fig. 4) to activate the motor-pump and advance the lower
die.
To halt the advancement, release the operating button (3) and the motor will cut out.
Makesurethediesareexactlypositioned on the desired crimp point otherwisere-opendies
following instructions as per section 2.4 and reposition the connector.
2.3) Compression
By keeping the operating button (3) pressed, the motor continues to operate and the ram will
gradually move forward until the two dies touch.
The motor will stop automatically when the set pressure has been reached.
When more compression is required, proceed according to the sequence and direction indicated
in figure 5, uniformly spacing the compressions.
Toperform a fullcompression,pressandholdtheoperatingbutton(3) until themotorstops
automatically.

8
ENGLISH
NOTE:Todisplaythemomentaryforceorpressureduring
the work cycle, select the appropriate display from the
menu (Ref. to section 4). When the operating button is
releasedbeforethemotorstopsautomatically,thedisplay
will show the peak force (Fp) or the peak pressure (Pp)
reached at that point.
Tocompletethecycle,presstheoperatingbuttonagainuntilthemotorstopsautomatically;thedisplay
will show the maximum force or pressure reached followed by "OK" to confirm correct operation.
The display "ERROR", combined with a beep and the LEDs flashing,
indicates an incorrect crimping procedure caused by the work cycle
being interrupted before the controlparameters (force/pressure)of the
tool are reached.
This error appears when the pressure release button has been operated and the tool has already
reached a pressure >100 bar. In this case, repeat the compression by pressing and holding the op-
erating button until the motor stops automatically.
2.4) Release of dies
Once the motor has stopped automatically, release the operating button (3), the ram will return,
allowing access and release of the dies.
The oil discharge to reservoir can also be performed in manual mode (Refer to § 4.2 for
further details).
2.5) LED Worklights
Whilst the tool is in operation, the compression area is illuminated by four high luminosity LED
Worklights that switch off automatically at the end of the cycle.
The LED Worklights can be disabled by following the procedure described in section 4.3.
2.6) Head rotation
For ease of operation, the tool head can rotate through 180°, allowing the operator to work in the
most comfortable position.
Do not attempt to rotate the head when the hydraulic circuit is pressurised.
2.7) Capacitive touch button for menu selection
This button is located under the display and allows selection of various
screens (Ref. to section 4); accessible only when the display is on.
Wearing gloves or using other objects may inhibit the operation of the
button, therefore use a bare finger to apply only a light touch.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

9
ENGLISH
Do not apply pressure to or stab at the touch button, a light touch using a bare finger is
sufficient. The command pulse is sent when the finger releases the button.
2.8) Battery status
The battery is equipped with LED indicators that indicate the remaining battery life at any time
by pressing the adjacent button (P) (Ref. to Fig. 1):
4 LEDs illuminated: fully charged
2 LEDs illuminated: 50 % capacity
1 LED flashing: minimum charge, replace the battery
With the batteryinsertedinthe tool,the remaining battery
life can also be checked on the display, via touch button
selection (Ref. to section 4).
The screen shown alongside indicates that the battery Voltage has
droppedbelowaminimumsafetythreshold;undertheseconditionsthe
tool will not start, and it is necessary to recharge or replace the battery.
The approximate time to fully recharge a battery is about 40 minutes.
2.9) Using the battery charger
Carefully follow the instructions in the battery charger user manual.
3. MAINTENANCE
The tool is robust, completely sealed, and requires very little daily maintenance. Compliance with
the following points, should help to maintain its optimum performance:
3.1) Thorough cleaning
Dust, sand and dirt are a danger for any hydraulic device.
Every day, after use, the tool must be wiped with a clean cloth taking care to remove any residue,
especially close to pivots and moveable parts.
Do not use hydrocarbons to clean the rubber parts.
3.2) Storage case
When not in use, the tool should be stored and
transported in the plastic case supplied to prevent
damage.The case, type VAL-P63, is suitable for stor-
ing the tool, the accessories, up to 12 die sets and
pre-prepared compression connectors.
VAL-P63: Size 620x360x138 mm (24.4x14.2x5.4 in-
ches) an weight 2,6 kg (5.7 lbs).
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

10
ENGLISH
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
4. NAVIGATION MENU
The navigation menu is shown on the display (5). By touching the button
(7) it is possible to browse the menu via the various screens.
4.1) Structure of the "main menu"
Fm: Operating/minimum set force, expressed in kN.
F: Peak force reached, expressed in kN.
(screen as factory setting)
Fm: Operating/minimum set force, expressed in USA sh. tons.
F: Peak force reached, expressed in USA sh. tons.
Pm: Operating/minimum set pressure, expressed in bar.
P: Peak pressure reached, expressed in bar.
Pm: Operating/minimum set pressure, expressed in psi.
P: Peak pressure reached, expressed in psi.
Battery charge level.
No. of cycles performed.
No. of cycles before scheduled recommended maintenance.
Cembre logo, tool model.
Tool serial number.
Release mode set
(Ref. to section 4.2 for further details).
Enabling/disabling the LED Worklights.
(Ref. to section 4.3 for further details).
Return to original factory settings.
Firmware version (Ref. to section 4.4 for further details).
7
5

11
ENGLISH
To make a selected screen operational and appear at each start up of the
tool, operate the touch button for at least 3 seconds; a continuous beep
will confirm the setting.
Thecapacitivemenu selection button may notworkif touched using objects or when wear-
ing gloves, therefore always operate the button using a bare finger.
4.2) Choosing the "release mode"
The phase of discharging the oil into the tool’s tank can be carried out in two different ways, de-
pending on the mode set in the menu:
Release
mode
Associated
pictogram Function
SMART
factory setting
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
By releasing the operating button (3) the oil is returned in full to
the tool reservoir only following automatic shut-off of the motor.
During the return phase, pressing the buttons enables the ram
stroke to be interrupted at any point so as to be able to restart from
this position in the next work phase, thus saving time and energy.
MANUAL
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
To return the oil to the tool reservoir it is necessary to press and
hold the release button (6).
During the return phase, by releasing the button it is possible for
the ram stroke to be interrupted at any point so as to be able to
restart from this position in the next work phase, thus saving time
and energy.
To change the "release mode", proceed as follows:
Select screen 8 from the“main menu”(Ref. to section 4.1).
Hold finger on the button (7) until a confirmation “beep”is heard. The choice made is shown by
cursor position under the pictogram.
4.3) Enabling/disabling the LED Worklights (factory setting is LED ON)
Select screen 9 from the“main menu”(Ref.
to section 4.1). To deactivate or reactivate
operation of the LED Worklights, hold the
finger on button (7) until a confirmation
“beep”is heard.
4.4) Return to original factory settings / firmware version
Select screen 10 from the“main menu”(Ref. to section 4.1). To return the tool to its factory settings,
hold finger on button (7) until a confirmation“beep”is heard.
The RESET screen also shows the firmware version of the control board.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

12
ENGLISH
4.5) Alarms/Warnings
These appear on the display during operation and inform the operator on the state of the tool.
Message Meaning Description
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
BATTERY
LOW
Replace or recharge the battery.
NOTE: when the battery voltage falls below a minimum safety
threshold, the tool will not start, although it is still possible to
end the work cycle in progress.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
BATTERY
TEMPERATURE
HIGH
Remove the battery and wait until it cools down.
In order to cool quicker, it is possible to insert it into the supplied
battery charger supplied, thus making use of the specific “AIR
COOLED”function.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
REQUEST
MAINTENANCE
No. of cycles to recommended maintenance is reached. The tool
continues to work however, it is recommended that it is sent to
Cembre for a complete overhaul (Ref. to section 7).
NOTE: this message, will reappear when the tool has been idle
for 30 s.
4.6) ERRORS: these appear during operation, combined with a beep and flashing LEDWorklights,
to notify the operator of procedural or operational errors.
Message Error description Solution
The pressure release button (6) was
pressed before the control parameters
were reached (Force/Pressure).
Repeat the work cycle and wait for the
motor to stop automatically.
NTC
FAULT
Interruption of the signal from the NTC
temperature probe of the battery.
Replace the battery.
If the problem persists, please contact
Cembre.
Abnormalpowerconsumptionof themo-
tor for more than 3 seconds.
The tool stops.
Wait for the display to turn off (60 sec.)
or remove and re-insert the battery, then
re-start the tool.
If the error occurs frequently, contact
Cembre.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Outputvoltageofthepressuretransmitter
is out of the pre-set range.
Repeat the work cycle; if the error occurs
frequently, contact Cembre.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Failure to reach the set pressure within
30 seconds of continuous operation of
the machine.
Repeat the work cycle; if the error occurs
frequently, contact Cembre.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Overcharging of the battery with protec-
tion tripping.
The tool stops.
Wait for the display to turn off (60 sec.)
or remove and re-insert the battery, then
re-start the tool.
If the error occurs frequently, contact
Cembre.
Error screens are displayed for about 30 seconds before being reset, but will display repeat-
edly in the event of permanent anomalies.
P
p
= 325 bar P
p
= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
P
n
= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
P
n
= 742 bar
P
p
= 742 bar
RESET
SW:S1J96902
P
m
= 742 bar
P
= 0 bar
P
m
= 10762 psi
LED
ON
LED
OFF
*
1
*
2
*
3
*
4
*
5
*
6
*
7
8
9
10
11
12
P
= 0 psi
P = 0 bar P
= 0 bar
P
n
= 742 bar
P
= 0 bar
BEEP
BEEP
P
n
= 742 bar
OK
Fm = 67.4 kN
OK
F
m
= 67.4 kN
F = 0.0 kN
F
m
= 7.57 ton
F = 0.00 ton
F
m
= 67.4 kN
F
p
= 67.3 kN
F
m
= 134.3 kN
OK
P
m
= 742 bar
P
p
= 741 bar
P
m
= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

13
1. CARACTERISTIQUES GENERALES
Domaine d'application: conçu pour le sertissage des connecteurs électriques
jusqu' à 300 mm2(600 MCM)
Force nom. de sertissage
kN
60
Pression min. de travail bar 742 (10037)
Dimensions mm (inches) 398x136x81 (15.6x5.3x3.2)
Poids avec batterie kg (lbs) 3,15 (6.9)
Moteur V 18
Température de fonctionne-
ment °C (°F) -15 to +50 (+5 to +122)
Huile recommandée TOTAL DIEKAN 1640 ou équivalents
Avance rapide l’outil passe automatiquement de la vitesse rapide
d’approche des matrices à la vitesse lente de sertissage
Sécurité valve de surpression
Batterie rechargeable V / Ah / Wh 18 / 2,0 / 36
Type CB1820L (Li-Ion)
Poids kg (lbs) 0,4 (0.9)
Chargeur de batterie
Alimentation
Type ASC55-EU
V / Hz 220 - 240 / 50 - 60
W 85
Bruit aérien sonore (1)
LpA dB (A)
67,7
LpCPeak dB (C) 89,2
LWA dB (A) 74,2
Vibrations (2) m/s2ahv 0,724
FRANÇAIS
(1) Directive 2006/42/CE, annexe 1, point 1.7.4.2, lettre u
LpA = niveau de pression sonore continue équivalente pondérée A sur le poste de travail.
LpCPeak = valeur de pression sonore instantanée pondérée C sur le poste de travail.
LWA = niveau de puissance acoustique dégagée par la machine.
(2) Directive 2006/42/CE, annexe 1, point 2.2.1.1
Valeurquadratiquemoyenne pondérée en fréquence del'accélérationà laquelle sont exposés lesmembressupérieurs
pour chaque axe biodynamique de référence. Relevés réalisés suivant les indications de la Norme EN ISO 5349-1/2,
dans des conditions de service largement représentatives des conditions d'emploi normales.

14
FRANÇAIS
AVERTISSEMENT
Ne pas utiliser cet outil à des fins différentes que celles prévues par le constructeur.
Restez bien attentif tout au long du travail, ne soyez pas distrait, ne perdez pas l’équilibre
pendant l'utilisation.
Avant d’entreprendre des travaux sur des équipements électriques, veuillez vous assurer
qu’aucun élément aux abords de la zone de travail n’est sous tension.
Dans le cas contraire, veuillez prendre les précautions nécessaires pour opérer à proximité
d’éléments sous tension, en conformité avec la norme EN50110-1.
Nepasutilisercetoutilsurouàcôtédeconducteurssoustension,sansprotectionindividuelle
adéquate. La non observation de cette précaution peut provoquer des lesions graves ou
mortelles.
L’outil n’est pas conçu pour une utilisation en continu; après avoir effectué une quantité de
sertissages consécutifs à partir d’une batterie complètement chargée, au moment du
remplacementdelabatterie,noussuggéronsd'observerunepérioded’arrêtpourpermettre
le refroidissement de l’outil.
Protéger l’outil de la pluie et de l’humidité. L’eau pourrait endommager l’outil et la batterie,
les outils hydroélectriques ne devraient pas être utilisés sous la pluie.
2. INSTRUCTIONS D'UTILISATION
IMPORTANT: Pour éviter d’endommager l’outil, il est déconseillé de l’actionner à vide et à
la pression maximale, sans avoir inséré les matrices dans la tête.
Les opérations d’introduction ou de remplacement des matrices doivent être effectuées
avec l’outil dépourvu de batterie.
L' ensemble comprend:
Outil hydraulique de sertissage.
Batterie rechargeable Li-Ion (2 pcs).
Chargeur de batterie.
Bandoulière.
Coffret de rangement.
Câble USB (Voir § 5).
2.1) Mise en service
L'outil peut être facilement transporté en utilisant la poignée principale (8) ou la bandoulière fixée
aux deux oeillets de la dragonne (10) (Voir Fig. 6).
L'outil peut être tenu dans une main tout en positionnant le conducteur avec l'autre.
Avant de commencer toute opération, contrôler l’état de charge de la batterie (voir § 2.8)
et, si nécessaire, la recharger en suivant les instructions contenues dans le manuel d’utili-
sation du chargeur de batteries.

15
FRANÇAIS
Pour remplacer la batterie, la retirer en appuyant sur le mécanisme de déblocage (9) (voirFig.1),
puis introduire la nouvelle batterie en la faisant coulisser sur les guides jusqu’au blocage complet.
L’écran permet d’afficher les paramètres opérationnels de l’outil. Pour personnaliser ces derniers,
suivre les instructions décrites au § 2.7.
2.2.1) Insertion des matrices
Les opérations d’introduction ou de remplacement des matrices doivent être effectuées
avec l’outil dépourvu de batterie.
Choisir le couple de matrices approprié pour le type de connexion à réaliser; pour cela, consulter
le catalogue.
S’il est nécessaire ouvrir la tête de l'outil en appuyant sur le crochet (11), libérant ainsi le porte
matrice supérieur (14) qui s'écartera complètement (voir Fig. 2).
En appuyant sur l’axe de déblocage (12) insérer une matrice dans le guide du piston (15) et l'autre
matrice dans porte matrice supérieur (14) jusqu’à son verrouillage par l’axe (13).
Insérez la batterie.
2.2) Avance des matrices
Insérer le conducteur dans le connecteur.
Positionner ce dernier entre les deux matrices (voir Fig. 3) en alignant
la zone à sertir avec l'empreinte des matrices et refermer la tête par le
porte matrice supérieur (14).
Avant de poursuivre les opérations, vérifier que la tête soit parfaitement fermée.
Appuyer sur la gâchette de commande (3) (voir Fig. 4) pour mettre en marche le groupe moteur
pompe; les matrices commencent alors à se rapprocher du connecteur.
Lagâchettedecommande(3)relâchée,lemoteuretl'avancedesmatricescessentimmédiatement.
S'assurerquelesmatricessontbienpositionéessurlazoneàsertir,sinondessererlesmatrices
en suivant les instructions du § 2.4 et repositioner le connecteur.
2.3) Sertissage
En maintenant pressée la gâchette de commande (3), on maintient la rotation du moteur;
lepistonavanceprogressivementjusqu'àcequelesmatricesarriventenbutéel'une contrel'autre.
L’outil s’arrêtera automatiquement dès qu’il aura atteint la pression de tarage.
S’ilestnécessairedeprocéderàplusieurssertissagesdecossesoudemanchons,suivrelaséquence
et la direction reportée dans la figure 5 en espaçant les empreintes de façon uniforme.
Pour effectuer un bon sertissage, maintenir la gâchette de commande (3) pressée jusqu’à
l’arrêt automatique du moteur.

16
FRANÇAIS
REMARQUE:Pourafficherlaforceoulapressionentemps
réel, lors du cycle de travail, configurer les écrans corres-
pondants (voir § 4). En relâchant le bouton de démarrage
avant l’arrêt automatique du moteur, l’écran affichera
les valeurs de pic de la force (Fp) et de la pression (Pp)
atteintes à ce moment.
Pour terminer l’opération, ré-appuyer sur la gâchette de commande jusqu’à l’arrêt automatique
du moteur; l’écran affichera la force ou la pression maximale atteinte, suivie de l’inscription "OK"
indiquant que l’opération a été correctement effectuée.
Le message "ERROR" associé à l’avertisseur sonore ainsi que le cligno-
tement des LED indiquent que la procédure de sertissage n’a pas été
correctement effectuée en raison d’un arrêt anticipé du cyclede travail
avant d’avoir atteint les paramètres réglés (force/pression) de l’outil. Ce message d’erreur s’affiche
lorsque l’opérateur appuie sur la gâchette de déblocage pression après que l’outil ait atteint une
pression > 100 bar. Dans ce cas, effectuer à nouveau le sertissage en maintenant la gâchette de
commande appuyée jusqu’à l’arrêt automatique du moteur. Pour terminer l’opération, ré-appuyer
sur la gâchette de commande jusqu’à l’arrêt automatique du moteur; l’écran affichera la force ou la
pression maximale atteinte, suivie de "OK" indiquant que l’opération a été correctement effectuée.
2.4) Réouverture des matrices
Après l'arrêt automatique du moteur, relâcher le bouton d'actionnement (3), le piston revient, avec
l'ouverture conséquente des matrices.
La phase de vidange d'huile dans le réservoir peut également être effectuée manuellement
(voir § 4.2 pour plus de détails)
2.5) Led
Lors de l’actionnement de l’outil, la zone de sertissage est éclairée au moyen de quatre LED haute
luminosité qui s’éteignent automatiquement à la fin du cycle.
Pour désactiver les LED, suivre la procédure décrite au § 4.3.
2.6) Rotation de la tête
La tête de l'outil pivote de 180° par rapport au corps, permettant à l'utilisateur de travailler dans la
meilleure position.
Ne pas forcer la rotation de la tête, lorsque le circuit hydraulique est sous pression.
2.7) Touche tactile de type capacitif
Cettetoucheestsituéesousl’écranetpermetdesélectionnerlesdifférents
écrans (voir § 4); elle fonctionne uniquement lorsque l’écran est allumé
et il suffit de l’effleurer à mains nues. L’utilisation de gants ou d’autres
objets risquerait de compromettre son activation.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

17
FRANÇAIS
Ne jamais appuyer avec force sur la touche tactile, il suffit de l’effleurer avec un doigt, à
mains nues. La commande envoie l’impulsion dès le retrait du doigt.
2.8) Autonomie de la batterie
La batterie est équipée d’indicateurs à LED qui permettent de contrôler, à tout moment, son
autonomie résiduelle en appuyant sur la touche (P) (voir Fig. 1):
4 led allumées: autonomie maximale
2 led allumées: autonomie à 50 %
1 led clignotante: autonomie minimale, remplacer la batterie
Lorsque la batterie est insérée dans l’outil, il est possible
de vérifier l’autonomie résiduelle à partir de l’écran, en
appuyant sur la touche tactile (voir § 4).
L’écranci-contreindiquequelabatterieestdéchargée et que sa tension
estdescendueau-dessousduseuilminimaldesécurité;danscettesitua-
tion, l’outil ne démarre pas, il est donc nécessaire de recharger ou de
remplacer la batterie.
À titre indicatif, le délai de recharge complète de la batterie correspond à environ 40 min.
2.9) Utilisation du chargeur de batterie
Suivre attentivement les instructions indiquées sur le manuel.
3. ENTRETIEN
L'outil est robuste, complètement scellé et ne nécessite aucune préoccupation ou attention parti-
culière. Les recommandations qui suivent sont néanmoins souhaitables pour assurer une longévité
optimum:
3.1) Nettoyage élémentaire
Veiller à protéger l'outil de la poussière, du sable et de la boue qui sont un danger à tout système
hydraulique. Chaque jour après utilisation, l'outil doit être nettoyé à l'aide
d'un chiffon propre, tout particulièrement aux endroits de
pièces mobiles.
Ne jamais utiliser d’hydrocarbures pour le nettoyage
des parties en caoutchouc.
3.2) Rangement
Au repos, pour protéger l'outil des coups accidentels
et de la poussière, il convient de le ranger dans le cof-
fret. Ce coffret (type VAL-P63) a comme dimensions:
620x360x138 mm (24.4x14.2x5.4 inches) et un poids de
2,6 kg (5.7 lbs). Le coffret adapté pour contenir l'outil,
ses accessoires et 12 paires de matrices
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

18
FRANÇAIS
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
4. MENU DE NAVIGATION
Le menu de navigation est affiché sur l'écran (5). En touchant le bouton (7)
il est possible de parcourir le menu via les différents écrans.
4.1) Structure du "menu principal"
Fm: Force minimale de réglage, exprimée en kN.
F: Force atteinte en temps réel, exprimée en kN.
(écran tel que configuré par les paramètres standards d’usine).
Fm: Force minimale développée, exprimée en tonnes courtes (USA).
F: Force atteinte en temps réel, exprimée en tonnes courtes (USA).
Pm: Pression nominale / minimale garantie, exprimée en bar.
P: Pression instantanée.
Pm: Pression nominale / minimale garantie, exprimée en psi.
P: Pression instantanée.
Niveau de charge de la batterie.
Nbr de cycles effectués.
Nbr de cycles restant à effectuer avant l'entretien préconisé.
Logo Cembre, type de outil.
Numéro de série.
Mode de décompression défini.
(voir § 4.2 pour plus de détails).
Activation/désactivation des LED
(voir § 4.3 pour plus de détails).
Version du firmware (voir § 4.4 pour plus de détails).
7
5

19
FRANÇAIS
Unefoisquel’écranprésélectionnés’estaffiché,pourlerendreopérationnel
et fixe à chaque démarrage de l’outil, maintenir la touche tactile appuyée
pendant une période prolongée (au moins 3 secondes). Un signal sonore
continu confirmera la configuration effective.
La touche capacitive risque de ne pas fonctionner si celle-ci est effleurée avec des objets ou
des gants, appuyer sur cette touche uniquement à mains nues.
4.2) Sélection du "mode de décompression"
Le retour d'huile dans le réservoir de la pompe peut être réalisé de deux façons différentes selon
le mode défini dans le menu:
Mode de
décompression
Pictogramme
associé Fonction
SMART
Réglage d’usine
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Seulement après un arrêt automatique du moteur, en relâchant le
bouton(3)demiseenmarcheonassisteautomatiquementauretour
complet de l'huile dans le réservoir de l'outil. Au cours de la phase
de retour, une impulsion sur les boutons permet d'interrompre la
course du piston à tout moment afin de recommencer à partir de
cette position la prochaine phase de travail, économisant ainsi du
temps et de l'énergie.
MANUAL
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pour obtenir le retour de l'huile dans le réservoir de l'outil il faut
maintenir appuyé le bouton (6) de décompression.
Au cours de la phase de retour, en relâchant le bouton, il est à tout
moment possible d'interrompre la course du piston afin de recom-
mencer à partir de cette position la prochaine phase de travail
économisant ainsi du temps et de l'énergie.
Pour changer le "mode de décompression", procéder comme suit:
Dans le "Menu principal", sélectionner l'écran 8 (voir § 4.1).
Presser le touche tactile (7) jusqu'à entendre le signal sonore de confirmation "beep", le choix
effectué est indiqué par le positionnement du curseur sous le pictogramme.
4.3) Activation/désactivation des LED (paramètre standard d’usine: LED ACTIVÉE)
Dans le "Menu principal", sélectionner
l'écran 9 (voir § 4.1).
Pourledésactiverouréactiverledémarrage
desLED,presserletouchetactile(7)jusqu'à
entendre le signal sonore de confirmation
"beep".
4.4) Retour au paramètres d’usine de départ / Version du firmware
Dans le "Menu principal", sélectionner l'écran 10 (voir § 4.1), presser le touche tactile (7) jusqu'à
entendre le signal sonore pour retourner au paramètres d’usine de départ.
L’écran RESET affiche également la version du firmware de la carte électronique.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK

20
FRANÇAIS
4.5) Alarmes / Avertissements
S’affichentlorsdufonctionnement.Associéàunsignalsonore,informentl'opérateursurl'étatdel'outil.
Message Signification Description
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
BATTERIE
DÉCHARGÉE
Remplacer ou recharger la batterie
NOTE: lorsque la tension de la batterie est inférieure au seuil
minimal de sécurité, l'outil ne démarre pas mais l’opérateur peut,
quoiqu’il en soit, terminer le cycle de travail en cours.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
TEMPÉRATURE
ÉLEVÉ DE
LA BATTERIE
Retirer la batterie et patienter jusqu’à ce qu’elle se refroidisse.
Pour la faire refroidir plus rapidement, il est possible de l’insérer
danslechargeurfourniafindebénéficierdelafonctionspécifique
"AIR COOLED" dont il est équipé.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
ENTRETIEN
A EFFECTUER
Lenombredecyclesprévusavantl'entretienpréconiséest atteint
l'outil continue à fonctionner, il est recommandé d’envoyer la
pompeàCembre afindeprocéderàune révisioncomplète(voir
§ 6). Ce message, apparaît à nouveau au bout de 30 secondes
d’inutilisation de l'outil.
4.6) ERREURS:apparaissentlorsdufonctionnement.Lorsqu’ellessontassociéesàunsignalsonore
et lumineux, elles indiquent à l’opérateur la présence d’éventuelles erreurs de procédure ou de
fonctionnement.
Message Description erreur Solution
Actionnementdelagâchettededéblocage
pression(6) avantque l’outiln’aitatteintles
paramètres de réglage (Force/Pression).
Procéder à nouveau au cycle de travail et
attendre l’arrêt automatique du moteur.
NTC
FAULT
Interruption du signal de la sonde de tem-
pérature NTC de la batterie.
Remplacer la batterie.
Sileproblèmepersiste,contacterCembre.
Absorptionanormale de courantdela part
du moteur pendant plus de 3 secondes.
L'outil s’arrête.
Patienter jusqu’à l’arrêt de l’écran (60
secondes) ou retirer, puis réinsérer la bat-
terie. Redémarrer l’outil.
Si ce signal d’erreur apparaît souvent,
contacter Cembre.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Tensiondesortiede l’émetteurdepression
en dehors de l’intervalle configuré.
Procéderànouveauaucyclede travail.Sice
signal d’erreur apparaît souvent, contacter
Cembre.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Impossible d’atteindre la pression de
tarage dans les 30 secondes à compter de
l’actionnement continu de l’outil.
Procéderànouveauaucyclede travail.Sice
signal d’erreur apparaît souvent, contacter
Cembre.
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Surchargedelabatterieavecactionnement
de la protection.
L'outil s’arrête.
Patienter jusqu’à l’arrêt de l’écran (60
secondes) ou retirer, puis réinsérer la bat-
terie. Redémarrer l’outil.
Si ce signal d’erreur apparaît souvent,
contacter Cembre.
Les erreurs restent affichées à l’écran pendant environ 30 secondes, puis l’erreur est réini-
tialisée. Elles se présentent à nouveau en cas d’anomalie permanente.
P
p
= 325 bar P
p
= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
P
n
= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
P
n
= 742 bar
P
p
= 742 bar
RESET
SW:S1J96902
P
m
= 742 bar
P
= 0 bar
P
m
= 10762 psi
LED
ON
LED
OFF
*
1
*
2
*
3
*
4
*
5
*
6
*
7
8
9
10
11
12
P
= 0 psi
P = 0 bar P
= 0 bar
P
n
= 742 bar
P
= 0 bar
BEEP
BEEP
P
n
= 742 bar
OK
Fm = 67.4 kN
OK
F
m
= 67.4 kN
F = 0.0 kN
F
m
= 7.57 ton
F = 0.00 ton
F
m
= 67.4 kN
F
p
= 67.3 kN
F
m
= 134.3 kN
OK
P
m
= 742 bar
P
p
= 741 bar
P
m
= 742 bar
OK
Pp = 325 bar Pp= 547 bar
RESET
SW:S1J96902
LED
OFF
ERROR
001
15001
BATTERY
Pn= 742 bar
002
003
BATTERY
004
LED
ON
LED
OFF
LED
ON
max.
BATTERY BATTERY
min.
B600ND
20AR112
10
14990
BATTERY
max 90°
90°
OK
Pn= 742 bar
Pp = 742 bar
RESET
SW:S1J96902
Pm= 742 bar
P= 0 bar
Pm= 10762 psi
LED
ON
LED
OFF
* 1
* 2
* 3
* 4
* 5
* 6
* 7
8
9
10
11
12
P = 0 psi
P = 0 bar P = 0 bar
Pn= 742 bar
P= 0 bar
BEEP
BEEP
Pn= 742 bar
OK
Fm = 67.4 kN
OK
Fm= 67.4 kN
F = 0.0 kN
Fm= 7.57 ton
F = 0.00 ton
Fm= 67.4 kN
Fp= 67.3 kN
Fm= 134.3 kN
OK
Pm= 742 bar
Pp = 741 bar
Pm= 742 bar
OK
Table of contents
Languages:
Other Cembre Power Tools manuals

Cembre
Cembre PNB-3 Series User manual

Cembre
Cembre B-TD270 User manual

Cembre
Cembre B1300-UC User manual

Cembre
Cembre RHU 1000 Owner's manual

Cembre
Cembre B1300-C-KV User manual

Cembre
Cembre B135-C-KV User manual

Cembre
Cembre PNB-7KE User manual

Cembre
Cembre PNB-4KE User manual

Cembre
Cembre B500 User manual

Cembre
Cembre B125LN-C User manual

Cembre
Cembre RHU131 User manual

Cembre
Cembre B600 User manual

Cembre
Cembre NR-25B User manual

Cembre
Cembre TW-18B User manual

Cembre
Cembre HT131-C User manual

Cembre
Cembre EPB-1N User manual

Cembre
Cembre B1350L-C User manual

Cembre
Cembre B15 User manual

Cembre
Cembre RHU450 User manual

Cembre
Cembre B600 User manual
