Thank you purchasing CHIAYO’s professional modular wireless system.
This versatile modular cabinet can be used for four RECEIVER modules!
Before operation, please read this manual thoroughly to familiarize with the function of each
part and the flexibility of this versatile cabinet.
Parts and functions of QR-4000N
Front panel
1.Power switch.
2.Channel 1 RECEIVER module slot
3.Channel 2 RECEIVER module slot
4.Channel 3 RECEIVER module slot
5.Channel 4 RECEIVER module slot
Rear panel
6. Antenna B
7. MIC-LINE level switch. MIC level for low-impedance audio output . LINE for high-
impedance audio output .
8. Unbalanced audio output (MIXED. Switch to LINE level when using this output.)
9. Balanced audio output (MIXED. Switch to MIC level when using this output.)
10.Channel-4 balanced audio output
11.Channel-3 balanced audio output
12.Channel-2 balanced audio output
13.Channel-1 balanced audio output
14.DC-input
15.Antenna A
Connection
There are two kinds of audio connecters on the rear of this unit, MIC-level balanced and LINE-
level unbalanced.
1. Low-impedance: Mixed-○
9｜Individual-○ 10 ○ 11 ○ 12 ○ 13
2. High-impedance: Mixed-○
8
Use shielded audio cable for the connection between this unit and the mixer/amp or audio
source. If the mixer/amp has a 1/4"(6.3mm) phone jack, connect a cable from the 1/4"(6.3mm)
unbalanced audio output from the receiver to the mixer/amp. If the mixer has an XLR input,
connect a cable from the balanced XLR audio output from the receiver to the mixer input.
12 3 4 5
678910 11 12 13 14
15

ISO 9001｜ISO 14001｜OHSAS 18001
-2-
Installation
For best operation, this unit should be at least 1m above the
ground and at least 1m away from a wall or metal surface to
minimize reflection. The transmitter should also be at least 1m
away from a wall or metal surface to minimize reflection. The
transmitter should also be at least 1m away from the receiver.
Rack mounting
QR-4000N has a 19"-casing design. It can be cabinet-mounted with provided kits. Please refer
to the following assembly illustration.
SDR-5200M IrDA｜SDR-5100M receiver modules
1.Channel indicator
2.Diversity A/B indicator
3.Audio signal indicator
4.IR sensor area
5.Channel Selector
6.IRDA synchronizing button
7.Squelch control
8.Power switch/volume
control
First turn on the Power of the main unit. Then turn on the individual power of the receiver
module. Select a channel that corresponds to the transmitter. When transmitter is turned on,
either A or B diversity indicator will flash to indicate that signal has been received.
SQUELCH (SQ) setting
When a channel is in use and undesired interference signal is received, turn the SQ in
clockwise direction to make the receiver less sensitive and thus less susceptible to interference.
If this still does not solve the problem, it means this frequency is not applicable at current
position. Please switch over to the next channel.
Channel synchronizing of the receiver and transmitter
1.To achieve a trouble-free synchronization, please limit the distance between the receiver and
transmitter to within 30cm.
2.Align both sensor areas
3.To change the receiver’s channel, please press the synchronizing button of the transmitter.
The transmitter will transmit synchronizing signal to the receiver and change its channel.
4.To change the transmitter’s channel, please press the synchronizing button of the receiver.
The receiver will transmit synchronizing signal to the transmitter and change its channel.

-3-
UHF handheld transmitters（SQ-6100 IrDA(R)｜SQ-6100 IrDA｜SQ-2100 IrDA｜SQ-1100 IrDA）
→SQ-6100 IrDA(R)｜SQ-6100 IrDA
→SQ-2100 IrDA
→SQ-1100 IrDA
Parts and functions
SQ-6100 IrDA(R)
SQ-6100 IrDA
SQ-2100 IrDA
SQ-1100 IrDA
Cartridge
1
1
1
1
Battery power LED
2
2
2
2
Power switch
3
3
3
3
LCD
4
4
-
-
Menu button
5
5
-
-
Setting button
6
6
-
-
IrDA synchronizing button
7
7
4
4
Battery compartment
8
8
5
5
Color cap
9
9
6
-
IrDA sensor area
10
10
7
6
Charging port
11
-
-
7
Battery installation & indicator
This transmitter requires 2 x AA batteries to operate.
To install, remove the battery cover and slide the batteries into the battery compartment &
replace the battery cover.
Note: Batteries contain a corrosive acid that may leak and damage the transmitter when stored
for a long period. Batteries should be removed from the transmitter before storing without use
for more than 4 weeks.
When the transmitter is switched ON, a red LED will blink once to indicate the batteries
installed are in good condition. If the LED remains illuminated, it means the batteries are
weak and require replacement.
1 2 3 7 4 5 6

ISO 9001｜ISO 14001｜OHSAS 18001
-4-
Channel synchronizing of the receiver and transmitter
1.To achieve a trouble-free synchronization, please limit the distance between the receiver and
transmitter to within 30cm.
2.Align both sensor areas
3.To change the receiver’s channel, please press the synchronizing button of the transmitter.
The transmitter will transmit synchronizing signal to the receiver and change its channel.
4.To change the transmitter’s channel, please press the synchronizing button of the receiver.
The receiver will transmit synchronizing signal to the transmitter and change its channel.
Other settings（SQ-6100 IrDA(R)｜SQ-6100 IrDA）
1. Channel setting
Use MENU button to go to the CHANNEL｜FREQUENCY page.︰
After pressing the SET button for 3 seconds, the cursor will flash to allow changes to be made.
Pressing SET / MENU buttons will increase / decrease the channel number. The corresponding
frequency will change accordingly. 3 seconds after selecting a channel, it will be automatically
saved.
2. Battery type setting
Use MENU button to go to the BATTERY TYPE page.︰
After pressing the SET button for 3 seconds, the cursor will flash to allow changes to be made.
Press SET button to select either NiMH (rechargeable battery) or AKLN (alkaline battery). 3
seconds after selecting a battery type, it will be automatically saved.
Remark: NiMH battery must be selected when rechargeable battery is being used. Never
select AKLN (alkaline) when transmitter is intended for charging as alkaline battery isn’t
rechargeable. Wrong battery selection will result in battery sensing electronics to display wrong
and misleading status information.

-5-
UHF belt-pack transmitters（SM-7100 IrDA｜SM-6100 IrDA｜SM-2100 IrDA｜SM-1100 IrDA）
SM-7100 IrDA｜SM-6100 IrDA｜SM-2100 IrDA
SM-1100 IrDA
Parts and functions
SM-7100 IrDA
SM-6100 IrDA
SM-2100 IrDA
SM-1100 IrDA
Antenna
1
1
1
1
LCD
2
2
-
-
Cover release button
3
3
3
6
Power switch
4
11
11
3
IrDA synchronizing button
5
5
5
7
Menu button
6
6
6
-
Setting button
7
7
7
-
High-impedance gain control (GT)
8
8
8
8
Low-impedance gain control (MT)
9
9
9
9
Battery compartment
10
10
10
10
Audio mute switch
11
-
-
-
Battery power LED
12
12
12
2
IrDA sensor area
13
13
13
4
Mini XLR connector
14
14
14
5
Charging contacts
15
15
15
11
Battery installation & indicator
This belt-pack requires 2 x AA batteries to operate.
To install, open the battery cover using the cover release buttons and insert the batteries into
the battery compartment.
1
2
3 3
9
7
84 5
6
10
11 12
13
14
15
1
23
45
6
7
8
10
11 11
9

ISO 9001｜ISO 14001｜OHSAS 18001
-6-
Note: Batteries contain a corrosive acid that may leak and damage the belt-pack when stored
for a long period. Batteries should be removed from the belt-pack before storing without use for
more than 4 weeks.
When the transmitter is switched ON, the battery power LED (red) will blink once to indicate the
batteries installed are in good condition. If the LED remains illuminated the batteries have
expired and require replacement.
Channel synchronizing of the receiver and transmitter
1.To achieve a trouble-free synchronization, please limit the distance between the receiver and
transmitter to within 30cm.
2.Align both sensor areas
3.To change the receiver’s channel, please press the synchronizing button of the transmitter.
The transmitter will transmit synchronizing signal to the receiver and change its channel.
4.To change the transmitter’s channel, please press the synchronizing button of the receiver.
The receiver will transmit synchronizing signal to the transmitter and change its channel.
GAIN setting (GT｜MT)
Gain control enables the user to set different output levels. GT is for the use of instrument with
high impedance, such as guitar while MT is for the use of low impedance such as lapel or
headset microphones.
Other settings（SM-7100 IrDA｜SM-6100 IrDA）
1. Channel setting
Use MENU button to go to the CHANNEL｜FREQUENCY page.︰
After pressing the SET button for 3 seconds, the cursor will flash to allow changes to be made.
Pressing SET / MENU buttons will increase / decrease the channel number. The corresponding
frequency will change accordingly. 3 seconds after selecting a channel, it will be automatically
saved.
2. Battery type setting
Use MENU button to go to the BATTERY TYPE page.︰
After pressing the SET button for 3 seconds, the cursor will flash to allow changes to be made.
Press SET button to select either NiMH (rechargeable battery) or AKLN (alkaline battery). 3
seconds after selecting a battery type, it will be automatically saved.
Remark: NiMH battery must be selected when rechargeable battery is being used. Never
select AKLN (alkaline) when transmitter is intended for charging as alkaline battery isn’t
rechargeable. Wrong battery selection will result in battery sensing electronics to display wrong
and misleading status information.
