IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Dupo
Twin Stroller “Cinder”
Model # 019113-384

2
Read all instructions before assembly and use of the stroller / pram.
Keep instructions for future use.
SAFETY PRECAUTIONS
WARNING
TO AVOID INJURY OR DEATH:
FOLLOWTHE MANUFACTURER’S INSTRUCTIONS.
ALWAYS APPLYTHE BRAKES WHENEVERTHE STROLLER IS STATIONARY.
USETHETETHER STRAP AT ALLTIMESTO PREVENTTHE STROLLER ROLLING AWAY.
DO NOT LEAVE CHILDREN UNATTENDED.
SECURETHE CHILD INTHE HARNESS AT ALLTIMES.
DO NOT CARRY EXTRA CHILDREN OR BAGS ONTHIS STROLLER.
MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IFYOU ADJUSTTHE STROLLER,
OTHERWISETHEY MAY BE INJURED.
TO AVOID INJURY ENSURETHATYOUR CHILD IS KEPT AWAY WHEN FOLDING AND
UNFOLDINGTHE STROLLER.
ENSURETHAT ALL LOCKING DEVICES ARE ENGAGED BEFORE USE.
Check that all safety locks are engaged before placing a child in the stroller.
Ensure your child is secured with a correctly adjusted safety harness.
DO NOT allow children to stand on the seat.
DO NOT hang bags or goods from the handle as this could cause the stroller to tip over.
DO NOT place more than 3kgs in each basket,or 1kg in each hood pocket.
The weight of the child should not exceed 20kgs (each seat).
The height of the child using the stroller should not exceed 96cm.
Only use accessories recommended by manufacturer.Using non-approved accessories may be unsafe.
NEVER ride with more than two child in the stroller.
It is recommended not to use stroller on escalators and stairs for safety reasons while child is in it.
This stroller is designed for use on at or gently slopped surfaces and may become unstable (tipping over) on uneven surfaces
and slops of moderate to high elevation.
Always use safety locks.
Promptly replace worn out or broken parts.
Remove the child from the stroller before going up or down stairs and escalators.
DO NOT lift the stroller by the front bumper bar or tray (if supplied).
To prevent the risk of the stroller catching re,do not park it near an open re,heater or barbecue.
For warranty purposes,keep your sales receipt to provide proof of purchase.
DO NOT make any changes or alterations to this product,unless through an approved service agent.
To avoid the risk of suffocation,keep all plastic packaging materials out of reach of children.
NEVER leave safety harness connected when not tted to a child in the stroller as this may create loops that could cause a
strangulation hazard.
When seat is in the fully reclined position,the canopy must be attached and fully secured at the back of the seat frame,as this
forms a safety head barrier at the top of the seat.
Ensure the storage latch is fully engaged when lifting or carrying the stroller.

3
Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Dupo Twin Stroller
Congratulations on your purchase of the Dupo Twin
Stroller“Cinder”
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

4
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Bumper Bar x 2
x 2
x 2 x 2
x 2
x 4
x 2
Front Dual Swivel
Wheels
Stroller Frame
(Pre-Assembled)
• Five Point Safety Harness
• Storage Basket
• Shoulder Pads
• Hood
Rear Wheels
There are no accessories recommended for use with this Childcare Dupo Twin Stroller.

5
ASSEMBLY / OPERATING INSTRUCTIONS
To unfold Stroller...
1
2
Release the folding lock as shown in image.
Lift handle and seat apart until the frame ‘clicks’
and locks on both sides.
Ensure stroller is locked on both sides before
continuing.
1a.
2a.
2b.
To attach Front Swivel Wheels...
1
2
Insert the metal shaft of the wheel into the front
wheel housing on the stroller frame until it‘clicks’
into position.
Pull the wheel downwards to make sure it is
securely attached before using stroller.
Repeat for other Front Swivel Wheel.
1a.
1b.
2a.
2b.
ENSURE CHILDREN STAY CLEAR WHEN UNFOLDING/FOLDINGTHE STROLLER.
WARNING

6
To operate Swivel Function...
1
2
To lock swivel wheels, slide lever downwards until
it ’clicks’.
Repeat for other Front Swivel Wheel.
To unlock swivel wheels, slide lever upwards until it
‘clicks’.
Repeat for other Front Swivel Wheel.
1a.
1b.
2a.
2b.
ASSEMBLY / OPERATING INSTRUCTIONS
To remove Front Swivel Wheels...
1
2
Press button on the top of the wheel housing.
Pull the wheel downwards to release from housing.
Repeat for other Front Swivel Wheel.
1a.
2a.
2b.
CAUTION: Always unlock the swivel function before folding
the stroller.

7
ASSEMBLY / OPERATING INSTRUCTIONS
To attach Rear Brake Housings...
To use Rear Brake...
1
1
2
2
Slide brake housing on to rear leg until secure.
To lock rear wheels,push down on the rear red
brake pedal on the rear wheel housing with foot.
Make sure that the pop-pin is visible in the housing.
Repeat for other side.
To unlock rear wheels,lift the rear red brake pedal
with foot.
1a.
1a.
2a.
2a.
CAUTION: Always apply rear brake when parking stroller.

8
ASSEMBLY / OPERATING INSTRUCTIONS
To adjust Backrest (5 positions)...
1
2
To lower backrest,pull metal adjuster outwards and
lower backrest to desired position.
Release adjuster and check that the backrest is
secure.
To raise backrest, pull the adjuster outwards and
raise backrest to desired position.
Release adjuster and check that the backrest is
secure.
1a.
1b.
2a.
2b.
To attach Rear Wheels...
1
2
Lift the rear of the stroller slightly upwards.
Insert the rear wheel axle into the housing until it clicks
into place.
Pull wheel outwards to check it is secure.
Repeat for other Rear Wheel.
1a.
1b.
2a.
2b.

9
ASSEMBLY / OPERATING INSTRUCTIONS
To attach Canopy...
1
2
Slide outer hood adjusters onto the outer mounting
blocks until they lock into place.
Slide the inner hood adjusters onto the mounting
block one at a time until they lock into place.
1a.
2a.
To adjust Canopy...
1
2
To open,pull canopy forward until extended.
To close,push canopy back.
1a.
2a.
CAUTION: The canopy must be fully closed before folding the
stroller.

10
ASSEMBLY / OPERATING INSTRUCTIONS
To adjust Viewing Window...
1
2
To open,lift viewing window ap forward.
To close,lower back into place and ap will secure
with magnets.
1a.
2a.
To adjust Sun Visor...
1
2
To open,lift out from front of hood.
To close,push back.
1a.
2a.

11
ASSEMBLY / OPERATING INSTRUCTIONS
Restraints - Harness...
1
2
3
4
5
To secure the child in the harness,place
left hand buckle prong (b) on top of (a).
Hold both left hand buckle prongs (a)
and (b) together and insert it into buckle
housing (e) until it snaps into position.
Repeat previous steps for right hand
buckle prongs (c) and (d).
Once all attached,carefully adjust the
harness straps by pulling each slider (f)
until the desired t is achieved in the lap,
shoulder and crotch straps.
To release the buckles,squeeze the top
and bottom prongs (a) and (b),(c) and
(d) together until harness disengages.
(a),(b): Left hand buckle prongs
(c),(d): Right hand buckle prongs
(e): Buckle housing
(f): Strap adjustment sliders
CAUTION: Always adjust the harness
when changing the seating position of
the child.
a
ff
ff
f
c
e
b d
USETHIS HARNESS AT ALLTIMES
WARNING

12
To adjust Waist Strap...
1To loosen waist strap,push up both top and bottom
straps through buckle as circled in diagram.
To place waist strap in desired position,slide the
bottom strap into position then pull the top strap and
tighten into position.
1a.
1b.
USETHIS HARNESS AT ALLTIMES
WARNING
ASSEMBLY / OPERATING INSTRUCTIONS
Tether Strap...
1Ensure tether strap is used at all times.
Make sure your hand is fed through the loop as
shown to the right.
1a.
To attach Bumper Bar...
1To attach the bumper bar, gently insert the
bumper into the slots until they click into position.
1a.
Top strap
Bottom
strap

13
ASSEMBLY / OPERATING INSTRUCTIONS
To adjust Footrest (3 positions)...
1
2
To adjust the footrest, press both buttons located
at the pivot point of the footrest as shown.
Once both buttons are depressed manually
adjust the footrest to the desired position.
1a.
2a.
To attach Bumper Bar continued......
To fold Stroller...
1Ensure the both canopies are closed and the both
seats are fully reclined before folding.
1a.
2To remove,push release button on inside of
mountings and pull bar outwards.
2a.

14
ASSEMBLY / OPERATING INSTRUCTIONS
To fold Stroller continued...
2
3
4
Push button on plastic barrel of handle while
twisting barrel forward.
Continue pushing downwards until the stroller is
folded.
Ensure folding lock is engaged.
2a.
3a.
4a.

15
HOW TO CARE FOR YOUR CHILDCARE STROLLER
Cleaning
Maintenance
To ensure the long-lasting use of your stroller,dry it with a soft absorbent
cloth after use in rainy weather. Use a damp cloth to clean the
frame. Do not use abrasive cleaners. After using your stroller on the
beach,clean the frame and wheels thoroughly with water to remove
the sand and salt. Allow it to dry thoroughly. Removable and non
removable fabric covers and trims maybe cleaned using a damp
cloth with soap or mild detergent. Allow it to dry completely before
folding or storing it away. Do not dry clean, or use bleach on fabrics
or trims. Do not machine wash, tumble or spin dry, unless the care
labelling on the product permits these methods.
Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required. To maintain the safety of
your stroller, seek prompt repairs for bent, torn, worn or broken parts.
Use only those parts and accessories approved by CNP Brands.
If you have any difculties in assembling the stroller, please contact
our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
