Childcare LiTE Grey 015261-314 User manual

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
LiTE
Stroller “Grey”
Model # 015261-314

2
Fingers or parts of the body could be injured when the stroller is being folded or unfolded.Please use caution
when folding or unfolding the stroller.
Always check that safety locks are engaged before placing a child in the stroller.
Ensure your child is secured with a correctly adjusted safety harness.
Do not allow children to stand on the seat.
Do not hang bags or goods from the handle as this could cause the stroller to tip over.
Do not place more than 5kgs in the basket.
The weight of the child using the product should not exceed 17kgs.
The height of the child using the product should not exceed 96cm.
It is unsafe to use parts other than those approved by the manufacturer.
Never ride with more than one child in the stroller.
Regularly inspect all parts and locking devices, promptly replace worn out or broken parts.
Remove the child from the stroller before going up or down stairs and escalators.
To prevent the risk of the stroller catching re, do not park it near an open re, heater or barbecue.
Do not make any changes,repairs or alterations to this product, unless through an approved service agent.
To avoid the risk of suffocation, keep all plastic packaging materials out of reach of children.
Never leave safety harness connected when not tted to a child in the stroller as this may create loops that
could cause a strangulation hazard.
The vehicle is designed for use on at or gently sloping surfaces and may be unstable on higher sloping and
uneven surfaces; and users should be made aware of the possibility of the vehicle tipping over.
Ensure the storage latch is fully engaged when lifting or carrying the stroller.
Care must be taken when lifting or carrying the stroller.
Read all instructions before assembly and use of the stroller. Keep
instructions for future use.
TO AVOID INJURY OR DEATH:
ALWAYS APPLYTHE BRAKES WHENEVERTHE STROLLER IS STATIONARY.
DO NOT LEAVE CHILD UNATTENDED.
SECURETHE CHILD INTHE HARNESS AT ALLTIMES.
DO NOT CARRY EXTRA CHILDREN OR BAGS ONTHIS STROLLER.
MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IFYOU ADJUSTTHE STROLLER.
TO AVOID INJURY ENSURETHATYOUR CHILD IS KEPTAWAYWHEN FOLDING AND UNFOLDING
THE STROLLER.
ENSURETHAT ALL LOCKING DEVICES ARE ENGAGED BEFORE USE.
Be aware that moving parts may cause injury if care is not taken.
SAFETY PRECAUTIONS
WARNING

3
Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Childcare LiTE Stroller
Congratulations on your purchase of the Childcare
LiTE Stroller“Grey”.
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

4
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Rear Wheels x 2
x 1
Bumper Bar
There are no accessories recommended for use with this Childcare Stroller.
Stroller frame, with the
following components
pre-assembled on frame:
• Canopy
• Five point safety
harness
• Basket
• Seat lining
• Front Wheels
x 1

5
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Rear Wheels...
Unfolding the Stroller...
1
1
2
Position the Stroller Frame on a stable oor.
Insert Rear Wheel into rear wheel housing on back
leg until it“clicks”into position.
Repeat for remaining Rear Wheel.
Lift the stroller uplock by unhooking it from the
latch.(highlighted in the image)
Lift the stroller handle to unfold the stroller.
The stroller should then lock into position.
This can be determined by a clicking sound
once unfolded.
1a.
1b.
1c.
1a.
2a.
2b.
2c.

6
ASSEMBLY / OPERATING INSTRUCTIONS
To attach the Bumper Bar......
To operate Rear Brakes...
1
2
1
Align the Bumper Bar with the housing on the
front of the stroller.
Insert Bumper Bar into the housing until it“clicks”
into position.
To remove Bumper Bar,press the release buttons
and pull Bumper Bar away from stroller.
To lock the brakes,push down on the brake lever.
To release brakes,lift up the brake lever.
1a.
1b.
2a.
1a.
1b.
CAUTION: Always apply the brakes when parking stroller.

7
ASSEMBLY / OPERATING INSTRUCTIONS
To operate Leg Rest Extension...
1The leg extension has two adjustable positions.
Horizontal position for full recline mode.
Adjusted down for seat mode.
Pull leg extension adjustment handle on underside
of leg extension and adjust to desired position.
1a.
1b.
To operate Viewing Window...
1
2
The stroller must be in the full lay back position.
Roll up viewing window ap and secure with toggle
and strap.
When nished,release toggle.
Viewing window ap will unroll and secure via 2 x
magnets.
1a.
1b.
2a.

8
ASSEMBLY / OPERATING INSTRUCTIONS
The stroller is now ready for use.
Adjusting the Backrest...
This stroller has a multiple position adjustable backrest.The upright position on the backrest is not suitable for use with
children less than six months old.
For use with a newborn (0 - 6mths),the seat should be fully reclined.The backrest should only be adjusted to a more
upright position as the child grows older and is able to support their head without assistance.
1
2
To Lower
Press both sides of backrest adjuster and pull
seat down to desired position.
To Raise
Pull left and right adjuster straps outwards until
seat is at desired height.
1a.
2a.
CAUTION: Do not adjust the backrest while child is in the stroller.

9
ASSEMBLY / OPERATING INSTRUCTIONS
Using the Tether Strap...
1Ensure tether strap is used at all times.
Make sure your hand is fed through the loop as
shown in the image.
1a.
1b.
USETHIS STRAPTO STOPTHE STROLLER ROLLING AWAY
WARNING

10
ASSEMBLY / OPERATING INSTRUCTIONS
Restraints - Harness...
1
2
3
4
5
To secure the child in the harness,place
left hand buckle prong (b) on top of (a).
Hold both left hand buckle prongs (a)
and (b) together and insert it into buckle
housing (e) until it snaps into position.
Repeat previous steps for right hand
buckle prongs (c) and (d).
Once all attached,carefully adjust the
harness straps by pulling each slider (f)
until the desired t is achieved in the lap,
shoulder and crotch straps.
To release the buckles,squeeze the top
and bottom prongs (a) and (b), (c) and
(d) together until harness disengages.
(a),(b): Left hand buckle prongs
(c),(d): Right hand buckle prongs
(e): Buckle housing
(f): Strap adjustment sliders
CAUTION: Always adjust the harness when
changing the seating position of the child.
a
f f
ff
f
c
e
b d

11
ASSEMBLY / OPERATING INSTRUCTIONS
To fold Stroller...
1
2
Before folding stroller, close the hood and ensure
the stroller backrest is in the upright position.
Push folding buttons on the inside of the stroller
frame to release stroller handle and canopy.
Keep folding handle and canopy until they
“click”up and into the locked position.
Bring the bumper bar and seat back towards
each other to continue folding the stroller until
the secondary lock is engaged.
1a.
1b.
1c.
2a.
To adjust Harness Straps...
1To adjust straps,hold the strap with one hand and
slide the adjuster up or down the strap.
Sliding the adjuster down will loosen the strap,while
sliding the adjuster up will tighten the strap.
1a.
1b.
(a): Slide up or down
(b):Adjuster
a
b
NOTE: Care must be taken when lifting or carrying the stroller.
Ensure the storage latch is fully engaged when lifting or carrying the stroller.

12
HOW TO CARE FOR YOUR CHILDCARE STROLLER
Cleaning
Maintenance
To ensure the long-lasting use of your stroller, dry it with a soft absorbent
cloth after use in rainy weather.Use a damp cloth to clean the frame.Do not
use abrasive cleaners.After using your stroller on the beach,clean the frame
and wheels thoroughly with water to remove the sand and salt. Allow it to
dry thoroughly. Removable and non-removable fabric covers and trims may
be cleaned using a damp cloth with soap or mild detergent.Allow it to dry
completely before folding or storing it away. Do not dry clean,or use bleach
on fabrics or trims. Do not machine wash,tumble or spin dry, unless the care
labelling on the product permits these methods.
Check stroller regularly to ensure that locking devices and components
are secure and working properly.Always check parts regularly for tightness
of screws, nuts and other fasteners – tighten or replace if required. To
maintain the safety of your stroller, seek prompt repairs for bent, torn,worn
or broken parts. Use only those parts and accessories approved by CNP
Brands.If the wheels squeak, use silicone based spray or light oil ensuring
it penetrates the wheel and axle assembly.To prevent mould or mildew,do
not fold or store the product if it is damp or wet.Allow it to dry thoroughly.
Always store the product in a well ventilated area and away from direct
sunlight.
If you have any difculties in assembling the stroller, please contact our
Service Department. In Australia, contact CNP Brands on 1300 667 137,
in New Zealand contact Wainhouse Distribution on 0800 567 5000.

13
ABOUT US
About CNP Brands
Currently,CNP Brands boasts one of the most diverse brand portfolios
with a combination of company owned brands and distribution
agreements.These include distribution lines for Eveno, Good Baby,
Lascal, Maclaren, Project Nursery, Summer Infant and Yookidoo.
Our own brands, including Childcare, have gone from strength to
strength in recent years. Childcare, and our premium brand bebe
care, demonstrate our commitment to quality and continuing
investment in product development.

14
NOTES
