Childcare Vogue Lite Stroller 015262-314 User manual

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
Vogue
Lite Stroller “Grey”
Model # 015262-314

2
Read all instructions before assembly and use of the stroller / pram.
Keep instructions for future use.
BEFORE ASSEMBLINGTHIS STROLLER / PRAM READ AND UNDERSTANDTHE INSTRUCTIONS.
To avoid injury or death:
Always apply the brakes whenever the stroller / pram is parked.
Do not leave children unattended.
Secure the child in the harness at all times.
Do not carry extra children or bags on this stroller / pram.
Make sure children are clear of any moving parts if you adjust the stroller / pram.
To avoid injury ensure that your child is kept away when folding and unfolding the stroller /
pram.
Ensure that all locking devices are engaged before use.
Use the tether strap to stop the stroller / pram rolling away.
Do not use this bassinet once the child can sit up unaided.
Be aware that moving parts may cause injury if care is not taken.
KEEP INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY PRECAUTIONS
WARNING
The weight of the child using the product should not exceed 20kgs.
The height of the child using the product should not exceed 96cm.
Fingers or parts of the body could be injured when the stroller / pram is being folded or unfolded. Please use caution when folding or
unfolding the stroller / pram.
Always check that safety locks are engaged before placing a child in the stroller / pram.
Ensure your child is secured with a correctly adjusted safety harness.
DO NOT allow children to stand on the seat.
DO NOT hang bags or goods from the handle as this could cause the stroller / pram to tip over.
DO NOT place more than 5kgs in the basket or 1kg in the hood pocket (if supplied).
It is unsafe to use parts other than those approved by the manufacturer.
NEVER use with more than one child in the stroller / pram.
This stroller / pram has been designed for use on at or gently sloped surfaces. Using this stroller / pram on uneven or higher sloped
surfaces may cause the stroller / pram to become unstable and tip over.
Regularly inspect all parts and locking devices,promptly replace worn out or broken parts.
Care mush be taken if the stroller / pram is used on stairs or escalators.Always remove the child from the stroller / pram before going up or
down stairs and escalators.
To prevent the risk of the stroller / pram catching re,DO NOT park it near an open re,heater or barbecue.
DO NOT make any changes or alterations to this product,unless through an approved service agent.
To avoid the risk of suffocation,keep all plastic packaging materials out of reach of children.
NEVER leave safety harness connected when not tted to a child in the stroller / pram as this may create loops that could cause a
strangulation hazard.
Ensure the storage latch is fully engaged when lifting or carrying the stroller / pram.
Care must be taken when lifting or carrying the stroller / pram.

3
Due to variations in the style and design of our products, the photographs and illustrations shown in this
instruction manual are generic,therefore product fabrics,colour and design may vary from images shown.
CNP Brands reserves the right to alter product specications without notice as a result of our ongoing
policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Vogue Lite Stroller
Congratulations on your purchase of the Vogue Lite
Stroller“Grey”
This product has been designed and developed with safety,
comfort and functionality in mind. Please take the time to read
this manual carefully before using this product and keep it in a
safe place for future reference.
CONGRATULATIONS

4
ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the
box against the list below. If anything is missing, please contact
Customer Service.
InAustralia,contact CNP Brands on 1300 667 137,in New Zealand
contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
Carry Cot/Seat
Unit Boot Cover
x 1 x 1
x 1 x 1
x 2
x 2
x 1
Frame Canopy
Rear Wheels
Front Wheels
Bumper Bar
There are no accessories recommended for use with this Childcare Vogue Lite Stroller.
x 1Rain Cover

5
ASSEMBLY CONTENTS / ASSEMBLY / OPERATING INSTRUCTIONS
To unfold Stroller...
1
2
Disengage uplock to release the stroller frame.
Lift stroller handle upward until the stroller opens
fully and ‘clicks’ into position.
1a.
2a.
To assemble Rear Wheels...
1Insert rear wheel into the rear wheel housing until
wheel‘clicks’into position.
Repeat for other rear wheel.
1a.
1b.

6
To use Rear Brakes...
1
2
To lock brakes,push down on the brake lever,
located on the rear wheel axle.
To unlock brakes,lift the brake lever.
1a.
2a.
Always apply brakes when parking stroller.
WARNING
ASSEMBLY / OPERATING INSTRUCTIONS
To remove Rear Wheels...
1
2
Push in and hold the quick release tab.
Remove rear wheel from the rear wheel housing.
1a.
2a.

7
ASSEMBLY / OPERATING INSTRUCTIONS
To operate Swivel Function...
1
2
To lock swivel function, push lever downward.
To unlock swivel function, push lever upward.
To assemble Front Wheels...
1Insert front wheel into the front wheel housing until
wheel ‘clicks’into position.
Repeat for other front wheel.
1a.
1b.
1a.
2a.
On unmade or uneven surfaces,swivel wheels must be locked.
WARNING

8
ASSEMBLY / OPERATING INSTRUCTIONS
To prepare Seat...
1
2
Turn bassinet upside down.Lift rear bar.
Wrap and secure Velcro fabric around the rear bar.
1a.
2a.
To remove Front Wheels...
1
2
Push in and hold the quick release tab.
Remove front wheel from the front wheel housing.
1a.
2a.

9
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble Bassinet...
1
2
3
Completely loosen the seat adjuster straps under the
backrest.
Unclasp the clips at the legrest and foot of the
bassinet,located on the underside of the seat.
Adjust the seat to a parallel position.
1a.
2a.
3a.
Bassinet cannot stand alone.
Do not use this bassinet once the child can sit up unaided.
Bassinet mode should not be used once the child has reached the maximum bassinet
weight of 9kg.
WARNING
NOTE: This step is easier to complete before attaching seat to the frame.

10
ASSEMBLY / OPERATING INSTRUCTIONS
To attach Seat...
1Slide both sides of the seat into the frame
housings until both sides ‘click’into position.
Pull up on seat to conrm it is secured correctly.
1a.
1b.
To adjust Seat Position...
To attach Bumper Bar...
1
1
This stroller has 4 lockable seat positions.
Push both seat adjustment buttons
simultaneously and move the seat upward or
downward to desired position.
Insert bumper bar into the bumper bar
openings on each side of the seat assembly.
Bumper bar will ‘click’ when locked in.Ensure
bumper bar is secured correctly before use.
1a.
1b.
1a.
1b.
Never use the bumper bar to carry the carry cot.
WARNING

11
ASSEMBLY / OPERATING INSTRUCTIONS
To assemble / disassemble Canopy...
1
1
2
Push the buttons on the underside of the
bumper bar.
Pull bumper bar away from the seat.
To assemble the canopy, attach the canopy
clips to each side of the stroller frame.
Push the clips onto the stroller frame until they
‘click’into position.
Attach the press studs on the canopy to the
press studs on the side of the seat frame.
Attach the press stud on the back of the canopy
to the press stud on the back of the seat frame.
1a.
1b.
1a.
1b.
2a.
2b.
To remove Bumper Bar...
To operate Canopy Functions...
1Pull the canopy forward or backward.
Pull out the sunvisor from the inside of the hood.
1a.
1b.

12
ASSEMBLY / OPERATING INSTRUCTIONS
To operate Canopy Functions continued...
2To open the mesh extension,unzip the zip around
the bottom of the canopy.
Secure ap with the toggle and elastic strap.
2a.
2b.
To attach Boot Cover...
To use Tether Strap...
1
1
Wrap the boot cover around the bottom end of
the seat frame.
Attach both side wing press studs to the press
studs on the outside of the seat.
Wrap the boot cover up and around the bumper
bar.
Secure with the two press studs.
Feed your hand through the tether strap loop as
shown in image.
1a.
1b.
1c.
1d.
1a.
Always remove boot cover before folding the stroller.
WARNING
CAUTION: Canopy must be fully closed before folding the
stroller.
NOTE: Tether strap must be used at all times.

13
ASSEMBLY / OPERATING INSTRUCTIONS
To convert to Stroller...
To adjust Backrest...
1
1
2
3
Push the seat adjustment buttons on the stroller
frame. Move the seat upright until seat is locked
into position.
This stroller has an adjustable backrest.The upright position on the backrest is not suitable for use
with children less than six months old.
For use with newborns (0-6 months),the seat must be fully reclined.The backrest should only be
adjusted to a more upright position as the child grows older and is able to support their head
without assistance.
To recline the seat,press and pull adjuster in a
downward motion and lower to desired position.
Tighten backrest adjuster to the desired upright
position.
Buckle the straps under the legrest and foot of the
seat assembly.
1a.
1a.
2a.
3a.
NOTE: This step is easier to complete before attaching seat to the
frame.

14
To assemble Rain Cover...
1Fully open rain cover.
Cover stroller completely.
1a.
1b.
ASSEMBLY / OPERATING INSTRUCTIONS
Do not adjust the backrest whilst the child is in the stroller.
WARNING
To adjust Backrest continued...
2To incline the seat,hold both adjustment straps
and pull outward to desired position.
2a.

15
ASSEMBLY / OPERATING INSTRUCTIONS
Restraints - Harness...
1
2
3
4
5
To secure the child in the harness,place
left hand buckle prong (b) on top of (a).
Hold both left hand buckle prongs (a)
and (b) together and insert it into buckle
housing (e) until it snaps into position.
Repeat previous steps for right hand
buckle prongs (c) and (d).
Once all attached,carefully adjust the
harness straps by pulling each slider (f)
until the desired t is achieved in the lap,
shoulder and crotch straps.
To release the buckles,squeeze the top
and bottom prongs (a) and (b),(c) and
(d) together until harness disengages.
(a),(b): Left hand buckle prongs
(c),(d): Right hand buckle prongs
(e): Buckle housing
(f): Strap adjustment sliders
CAUTION: Always adjust the harness
when changing the seating position of
the child.
a
ff
ff
f
c
e
b d
USETHIS HARNESS AT ALLTIMES
WARNING

16
To adjust Waist Strap...
1To loosen waist strap,push up both top and bottom
straps through buckle.
To place waist strap in desired position,slide the
bottom strap into position then pull the top strap and
tighten into position.
1a.
1b.
USETHIS HARNESS AT ALLTIMES
WARNING
ASSEMBLY / OPERATING INSTRUCTIONS
To fold Stroller...
1
2
3
Ensure that the stroller seat recline is in the fully
upright position.
Ensure the canopy is pushed all the way back.
Slide the handle lever to the left,whilst holding in
the handle button.
Push handle down towards the back wheels.
Secure the folded stroller with the upfold lock.
Use the rst loop when stroller is folded in seat
mode.
Use the second loop when stroller is folded in
bassinet mode.
1a.
1b.
1c.
2a.
3a.
3b.
3c.
NOTE: Remove seat assembly from the frame when folding
for a smaller fold.

17
HOW TO CARE FOR YOUR CHILDCARE STROLLER
Cleaning
Maintenance
To ensure the long-lasting use of your stroller,dry it with a soft absorbent
cloth after use in rainy weather. Use a damp cloth to clean the
frame. Do not use abrasive cleaners. After using your stroller on the
beach,clean the frame and wheels thoroughly with water to remove
the sand and salt. Allow it to dry thoroughly. Removable and non
removable fabric covers and trims maybe cleaned using a damp
cloth with soap or mild detergent. Allow it to dry completely before
folding or storing it away. Do not dry clean, or use bleach on fabrics
or trims. Do not machine wash, tumble or spin dry, unless the care
labelling on the product permits these methods.
Always check parts regularly for tightness of screws, nuts and other
fasteners – tighten or replace if required. To maintain the safety of
your stroller, seek prompt repairs for bent, torn, worn or broken parts.
Use only those parts and accessories approved by CNP Brands.
If you have any difculties in assembling the stroller, please contact
our Service Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand
contact Wainhouse Distribution on 0800 567 5000.

18
ABOUT US
About CNP Brands
Currently,CNP Brands boasts one of the most diverse brand portfolios
with a combination of company owned brands and distribution
agreements.These include distribution lines for Eveno, Good Baby,
Lascal, Maclaren, Project Nursery, Summer Infant and Yookidoo.
Our own brands, including Childcare, have gone from strength to
strength in recent years. Childcare, and our premium brand bebe
care, demonstrate our commitment to quality and continuing
investment in product development.

19
NOTES

Distributed in Australia by CNP Brands
Customer Service 1300 667 137
W: www.cnpbrands.com.au
E: [e-mail]
F: www.facebook.com/CNPBrands
I: @cnp_baby
Distributed in New Zealand by Wainhouse
Distribution
2-6 Argyle St, Morningside,
PO Box 41-014,
St Lukes,Auckland, New Zealand
Customer Service: 0800 567 5000
E: [e-mail]
