Clas Ohlson DAB373 User manual

EnglishSvenskaNorskSuomi
Hand crank radio
with DAB+/FM
SE | Vevradio med DAB+/FM
NO | Sveiveradio med DAB+/FM
FI | Kampiradio, jossa DAB+/FM
Art.no. Model
31-3267 DAB373 Ver. 20230904
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL- VOL+
SOS
MODE
SCAN
SELECT
INFO

3
2 3

3
English
3
Hand crank radio with DAB+/FM
Art. no. 31-3267 Model DAB373
Please read the entire instruction manual before using the product
and then keep it for future reference. We accept no liability for any
errors in the text or images and we reserve the right to make any
necessary changes to technical data. If you have technical problems
or other queries, please contact our customer service team (see
the address details on the back).
Safety
• The product must not be opened or modified.
• The product must only be repaired by a qualified
service technician.
• Do not expose the product to extremely high temperatures, for
example by leaving it in a car on a hot summer’s day.
• Do not point the beam of the torch directly into anyone’s eyes.
• Do not use the product in an area where flammable liquids or
gases are used or stored.
• Protect your hearing. Do not listen at a high volume for long
periods as this can lead to permanent hearing loss.
• The product should never be used if the battery compartment
cover is damaged in any way or cannot be closed properly.
• Never let children play with the product.
Cleaning and care
• Clean the radio by wiping it with a damp cloth. Use only mild
cleaning agents. Never use solvents or corrosive chemicals.
• Store the radio in a dry, dust-free environment out of the reach
of children if you will not be be using it for some time.

4 5
English
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL- VOL+
SOS
MODE
SCAN
SELECT
INFO
15
16
17
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL-
VOL+
SOS
MODE
SCAN
SELECT
INFO
18 19
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL-
VOL+
SOS
MODE
SCAN
SELECT
INFO
20
21
22 23
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL- VOL+
SOS
MODE
SCAN
SELECT
INFO
1
2
12
14
13
11
3
4
910
6 8
5 7
Buttons and functions

4 5
English
1. [ ] Press repeatedly to switch the light on/off and to select
the light setting.
2. Loudspeaker
3. [SCAN/SELECT] Press to select the menu and confirm
your selection. Hold to scan for radio stations.
4. [MENU/INFO] Press for programme information and
to exit the menu. Hold to display the menu.
5. [◄] DAB: Scroll down through the stations.
FM: Scan for a station with a lower frequency.
Press to scroll manually, hold to scan automatically.
6. [VOL −] Reduce the volume
7. [►] DAB: Scroll up through the stations.
FM: Scan for a station with a higher frequency.
Press to scroll manually, hold to scan automatically.
8. [VOL +] Increase the volume
9. [SOS] Hold to activate the emergency signal.
10.[ /MODE] Hold to switch the radio on/off, press to select
the radio mode: Digital (DAB) or analogue (FM).
11.Wrist strap ring.
12.Display
13.“INPUT” LED indicates that the built-in battery is charging.
14.“TUNE” LED indicates that the radio is switched on.
15.Aerial
16.Crank to generate electricity
17.Battery cover
18.Reading light
19.Torch function
20. : 3.5 mm headphone socket.
21.DC OUT: USB-A port for charging external devices.
22.DC IN: USB-C port for charging the built-in battery.
23.Solar panel

6 7
English
Using the radio
Power supply
Emergency radio that can be powered by the built-in rechargeable
lithium-ion battery and by standard replaceable AAA batteries.
Charging the built-in lithium-ion battery
The battery can be charged in 3 different ways:
1. USB: Connect the USB cable supplied to the USB-C port (22)
and a USB charger (sold separately). It takes approximately
6–8 hours to fully charge the battery.
2. Dynamo: In an emergency, the battery can be charged using
the built-in electricity generator. Extend the crank and turn it to
charge the battery.
3. Solar panel: Put the solar panel in the sun to trickle charge
the battery. This is primarily intended to extend the battery time,
not to charge the battery fully.
The battery indicator on the display shows the current charge
status. When the battery is charging, the “INPUT” LED (13) is red.
Operating the radio using AAA batteries
We recommend that you mainly use the radio’s built-in
lithium-ion battery. If AAA batteries are inserted, the radio
will use them regardless of the charging status of the built-in
lithium-ion battery. We therefore recommend that you only
use AAA batteries when the built-in lithium-ion battery is flat
and you are not able to charge it.
1. Remove the battery cover (17) by sliding it downwards.
2. Insert 3 x AAA/LR03 batteries. Check the polarity markings
in the bottom of battery compartment to make sure that you
insert the batteries correctly.
3. Refit the battery cover.

6 7
English
Wrist strap
Attach the wrist strap to the
radio by threading it through
the ring (11).
Aerial
Fold out and extend the aerial (15) fully for the best signal reception.
The radio signal reception is usually best when the aerial is in an
upright, vertical position.
Listening using headphones (sold separately)
1. Turn the volume down.
2. Connect the headphones to the 3.5mm headphone socket (20).
3. Put the headphones on and carefully increase the volume to a
comfortable level.
Note: Audio output through the loudspeaker stops as soon as
headphones are connected.
On/off
1. Switch on the radio by holding [ /MODE ]. “Welcome to
Digital Radio” will appear on the display.
2. Switch off the radio by first holding [ /MODE] until the radio
is in standby mode, and then holding [ /MODE] again until
“Good Bye” appears on the display.
Standby mode
1. Put the radio in standby mode by holding [ /MODE] when
the radio is switched on until the time and date are shown on
the display.
2. To switch the radio on from standby mode, press
[ /MODE] briefly.

8 9
English
• Standby mode is only suitable for use for short periods or if an
alarm has been set. To save the battery, switch the radio off
completely.
• If the radio is switched on for around 15 minutes without radio
reception, it will automatically go into standby mode.
Adjusting the volume
Adjust the volume by pressing [VOL − ] (6) or [ VOL + ] (8).
Selecting radio mode (DAB/FM)
Press [ /MODE] to switch between DAB and FM radio.
DAB radio
The first time the radio is switched on it will automatically scan
for DAB stations. While the radio is scanning, “Scanning…” will
appear on the display along with a progress bar indicator and a
number showing how many stations have been found and saved
in the station list.
Note: If no stations are found, “No Station!” will appear on the display.
• Make sure that DAB broadcasting is available in your
geographical area.
• If the reception is poor, try changing the position of the aerial
or moving the radio to another location.
• Refer to the Settings/Auto Scan section to carry out a new
station scan.
Press[◄] (5) or [►] (7) and then [ SCAN / SELECT ] (3) to select
a radio station in the station list. The display will show the station
name and its number in the list.

8 9
English
Favourites list
Save up to 40 DAB stations in a favourites list.
Saving a station
1. Choose the station that you want to save.
2. Hold in [MENU/INFO] until the menu appears.
3. Press [◄] or [►] until the display shows “Preset Store”.
Confirm by pressing [SCAN / SELECT ].
4. Select a place in the list by pressing [◄] or [►] and then
press [SCAN / SELECT ] to save the station.
5. “Preset # stored” will appear on the display.
Listening to saved stations
1. Hold [MENU/INFO] until the menu appears.
2. Press [◄] or [►] until the display shows “Preset Recall”.
Confirm by pressing [SCAN / SELECT ].
3. Select the station you want from the list by pressing [◄] or [►].
Confirm by pressing [SCAN / SELECT ].
FM radio
Automatically saving the stations with the strongest signal
on your favourites list (P##)
Hold [SCAN/SELECT] to scan and save the stations with the
strongest signal on your favourites list automatically. “Scanning…”
will appear on the display with a number showing how many
stations have been found and saved.
If the radio is moved to a new location or if radio stations
change frequencies, some preset stations might become
unavailable. If the radio cannot find the selected station,
“No Station!” will appear on the display. Refer to the Settings
section to carry out a new scan and to clear any unavailable
stations from the station list.

10 11
English
If certain stations are not found during a scan, the sensitivity of the
scan can be adjusted. See the Settings – Scan setting section.
Listening to saved stations
1. Press [SCAN / SELECT ] until “P##” is shown on the display.
2. Use [◄] or [►] to scroll through the stations on the list.
Manual tuning
1. Press [SCAN / SELECT ] until “P##” is shown on the display.
2. Press[◄] or [►] repeatedly to scroll downwards or upwards
in the frequency band.
Automatic scan
Hold [◄] or [►] to scan for the next radio station. The scan stops
when the next station has been found.
Favourites list (P##)
Save up to 40 FM stations in a favourites list.
Saving/sorting stations manually
1. Choose the station that you want to save.
2. Hold [MENU/INFO] until the menu appears.
3. Press [◄] or [►] until the display shows “Preset Store”.
Confirm by pressing [SCAN / SELECT ].
4. Select a place on the list by pressing [◄] or [►] and
then press [SCAN / SELECT ] to save.
5. “Preset # stored” will appear on the display.
Display options
Press [MENU / INFO ] repeatedly to display information about
the station you are listening to.
The display will show different information depending on whether
the radio is inDAB or FM mode:

10 11
English
DAB mode
• Radio Text: Shows text information transmitted by the station.
• Signal Strength: Shows the station signal strength.
• Programme Type: Shows the current programme type (genre).
• Ensemble Name: Shows the group name of the stations that
transmit on the same frequency.
• Channel Number/Frequency: Shows the number and fre-
quency of the radio station.
• Signal Error: Shows the signal quality of the station.
• Audio Bit Rate: Shows the bit rate of the audio stream.
• Time: The current time.
• Date: The current date.
FM mode
Note: Information about the current radio station is only shown if
the FM station sends out RDS data.
• Radio Text: Shows text information transmitted by the station.
• Programme Name: The station name.
• Programme Type: Shows the current programme type (genre).
• Frequency: Shows the frequency of the station.
• Time: The current time.
• Date: The current date.
• Signal Strength: Shows the signal strength of the station.
Setting the clock
The time and date are normally set automatically with the help
of DAB or FM radio signals (the time is set approximately
1–2 minutes after the radio is switched on).
If the time and date are not set automatically, they can also be
set manually. See the Settings section.

12 13
English
Sleep timer
The sleep timer function allows you to set the radio to switch itself
off automatically after a set period.
1. With the radio on, hold [MENU/INFO] until the menu appears.
2. Press [◄] or [►] and select “System”. Confirm by pressing
[SCAN/SELECT].
3. Press [◄] or [►] and select “Sleep”. Confirm by pressing
[SCAN/SELECT].
4. Press [◄] or [►] to select the time. Confirm by pressing
[SCAN/SELECT]. Choose from: 15, 30, 45, 60, 75 or 90
minutes or OFF.
The display will show the remaining time before the radio switches off.
Alarm
Setting the alarm
Press [◄] or [►] to scroll through the menu/change the value and
then press [SCAN / SELECT ] to select the menu/function.
1. With the radio on, hold [ MENU / INFO ] until the menu appears.
2. Select “System” and then “Alarms”.
3. Select an alarm to set, either “Alarm 1” or “Alarm 2”.
4. Activate the alarm by selecting “Alarm 1/2 ON”.
5. Choose the following settings in this order:
- Alarm time: Hours and minutes.
- Alarm sound: Buzzer (signal), DAB or FM (If you select
DAB or FM radio, we recommend you also select a
radio station).
- Choose when you want the alarm to sound: Daily,
Weekends, Workdays or Once.
- Alarm volume: The alarm signal starts quietly and gradually
increases in volume until it reaches the set level.
- Alarm duration: 15,30,45,60, 90 or 120seconds.

12 13
English
“1”or “ 2” shows on the display to indicate that the alarm is active.
Note: The emergency radio must be on or in standby mode for
the alarm to go off at the set time.
Deactivating the alarm
Deactivate the alarm by selecting “Alarm 1/2 OFF” in step 4 above.
Snooze
When the alarm sounds, press any of the buttons (3, 4, 5, 6, 7, 8)
to mute the alarm temporarily for 5 minutes.
Switching the alarm off
Press [ /MODE] to switch the alarm off. “Alarm OFF!!!” will
appear on the display.
If the alarm is set for every day, it will go off at the same time
the next day.
Settings (Menu)
1. Press and hold [MENU / INFO ] to display the menu.
2. Press [◄] or [►] repeatedly to scroll through the menu.
3. Press [SCAN / SELECT ] to select a menu/function.
4. Press [MENU / INFO ] to go back one step in the menu.
The menu selection differs depending on whether the radio is
inDAB or FM mode. The settings in the radio menu marked
with an asterix (*) show the current setting.

14 15
English
Preset Recall
Preset Store
Scan Seng
Staon List
Preset Recall
Preset Store
Auto Scan
Manual Tune
Prune
DAB mode
FM mode
System
Time/Date
Set Time/Date
Set Hour System
Set Date Format
Auto Update
Backlight
Timeout
Level
Alarms
Alarm 1
Alarm 2
Sleep
Factory Reset
System Version
• Station List (DAB): Displays the saved DAB radio stations.
If the list is empty, an automatic scan for stations will start.
• Preset Recall (DAB/FM): Listen to a radio station on your
favourites list.
• Preset Store (DAB/FM): Save the current radio station on
the favourites list.
• Auto Scan (DAB): Automatic scan for DAB radio stations.
- Press [SCAN / SELECT ] to confirm. The radio automatical-
ly starts scanning for DAB radio stations. When the scan
is complete, the station number, frequency and signal
strength are displayed.
Alternatively, hold [SCAN/SELECT] in DAB mode to start a scan.

14 15
English
• Manualtune (DAB): Manual scan for DAB radio stations.
- The station number and frequency will be displayed.
Press [◄] or [►] repeatedly to select a station.
Press [SCAN / SELECT ] to confirm.
• Prune (DAB): Clear the unavailable radio stations from
the station list. “Yes” clears the station list and “No” cancels
the clearance.
• Scan setting (FM): Select the sensitivity when scanning
FM radio stations. All Stations (high sensitivity) or
Strong Stations (low sensitivity).
• System: Choose from the following list of sub-menus:
- Time/Date Set Time/Date: Time and date settings.
Set Hour System: Select 12- or 24-hour
display.
Set Date Format: Select the date format.
Auto Update: Update From Radio
(Update the time and date
from the radio)
No Update
(Set the time and date
manually)
- Backlight Timeout: Set how long the backlight stays
on after the last button push. Select a time
between 10 and 180 seconds or Always On.
Level: Set the brightness of the backlight.
Select Low, Medium or High.
- Alarms: Refer to the Alarm section.
- Sleep: Refer to the Sleep timer section.
- Factory Reset: Reset the radio to the factory settings.
- System Version: Shows the current software version.

16 17
English
Torch function
Press the [ ] repeatedly when the radio is on to select from
3 different light modes.
Hold the [ ] when the radio is off to switch the light on.
Press repeatedly to select a light mode.
Reading light
Extend the solar panel (23) to switch on the reading light.
The light will switch off when the panel is folded down again.
USB socket 5V
The radio can be used to charge mobile phones in an emergency.
Do not use it as a normal powerbank, but only in an emergency.
1. Put the radio in standby mode or switch it off completely.
2. Open the cover and connect the USB cable supplied to
the USB OUT 5V port (21).
SOS/emergency signal
Note: The emergency signal is very loud!
1. Hold the [SOS] button (9) to activate the emergency signal.
2. Then press it repeatedly to select different audio/light settings.

17
English
Troubleshooting guide
The radio will
not switch on.
• Is the lithium-ion battery flat?
• Make sure there are no flat AAA batteries
in the battery compartment.
• If the radio is powered via the USB-C
socket, check that the cable is properly
connected to the USB adapter and that
the wall socket is working.
No sound from
the loudspeaker.
• Check the volume.
• Make sure that there are no headphones
connected to the 3.5mm headphone
socket. When headphones are connected,
the loudspeaker turns off.
Poor radio
reception.
• Move the radio to another location.
• Perform a factory reset. Refer to the
Settings – Factory Reset section.
Responsible disposal
This symbol indicates that the product should not be
disposed of with general household waste. This applies
throughout the entire EU. In order to prevent any harm
to the environment or health hazards caused by incorrect
waste disposal, the product must be handed in for
recycling so that the material can be disposed of in a
responsible manner. To recycle the product, take it to your
local recycling facility or contact the retailer. They will ensure that
the product is disposed of in a way that does not harm the
environment.

1918 19
English
Specifications
Frequency range DAB: 174–240 MHz
FM: 87.5–108 MHz
Battery 3.7 V, 4000 mAh, Type 21700
Operating time Radio approx. 26 hours, torch ≥10 hours,
reading light ≥48 hours
USB-A out 5 V, 1 A
IP rating IPX3
Dimensions 152x77x51mm
Weight approx. 345 g
Simplified EU Declaration Of Conformity
Hereby, Clas Ohlson AB declares that the radio equipment type Hand crank radio with
DAB+/FM is in compliance with Directive 2014/53/EU. The full text of the EU declaration
of conformity is available at the following internet address: www.clasohlson.com

19
Svenska
19
Vevradio med DAB+/FM
Art.nr 31-3267 Modell DAB373
Läs igenom hela bruksanvisningen före användning och spara den
sedan för framtida bruk. Vi reserverar oss för ev. text- och bildfel
samt ändringar av tekniska data. Vid tekniska problem eller andra
frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
• Produkten får inte öppnas eller modifieras.
• Produkten får endast repareras av kvalificerad servicepersonal.
• Utsätt inte produkten för extremt höga temperaturer som t.ex
en varm sommardag i bilen.
• Lys inte med ficklampan direkt in i ögonen.
• Använd inte produkten i miljöer där brandfarliga vätskor eller
gaser används eller förvaras.
• Skydda din hörsel. Lyssna inte med hög volym under lång tid
då det kan leda till bestående hörselskador.
• Använd aldrig produkten om locket över batterihållaren på
något sätt är skadat eller inte går att stänga ordentligt.
• Låt aldrig barn leka med produkten
Skötsel och underhåll
• Rengör radion med enlätt fuktad trasa. Använd ettmilt ren-
göringsmedel, aldrig lösningsmedel eller frätande kemikalier.
• Förvara radion torrt och dammfritt om den inte ska användas
under enlängre period.

20 21
Svenska
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL- VOL+
SOS
MODE
SCAN
SELECT
INFO
15
16
17
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL-
VOL+
SOS
MODE
SCAN
SELECT
INFO
18 19
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL-
VOL+
SOS
MODE
SCAN
SELECT
INFO
20
21
22 23
USB OUT
5V
DC IN
5V
TUNE
INPUT
VOL- VOL+
SOS
MODE
SCAN
SELECT
INFO
1
2
12
14
13
11
3
4
910
6 8
5 7
Knappar och funktioner
