Clean Logix BLX-400 User manual

USER
MANUAL
English (Original Instrucons)
Updated: 02/11/21
MODEL:
BLX-400
Compact Boot Scrubber

BLX-400 User Manual Page 2 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
!WARNING:
1. All personnel using this unit must be familiar with
the informaon contained in this manual. Follow all
installaon and maintenance instrucons.
2. Always wear appropriate footwear. Secure or remove
loose items on footwear.
3. Ensure solid foong and use both hands when operang
the unit.
4. Avoid contact of chemicals with skin and eyes. If contact
occurs, see MSDS sheet for further rst aid measures.
5. Follow safety instrucons of chemical manufacturer
(MSDS).
6. Always follow plant and OSHA guidelines about the use
of equipment.
7. Disconnect power before servicing equipment.
8. Always follow safety precauons and obey warning
labels. Failure to do so could result in injury or death.
Table of Contents
System Requirements
Installaon
Physical Set-Up
Plumbing Connecons
Motor Speed Adjustment
Operaon
Start Up
Use
Shut Down
Cleaning
Removing Brushes
03
04
05
06
07
07
07
08
Advanced Conguraon
Motor Current Sensor
Brush Adjustments
Drive Parameters
Timing Relay
Maintenance
Troubleshoong
Appendices
Parts Callouts
Electrical Schemacs
Venturi System
Non-Diluon Specic
09
09
10
10
11
12
14
18
20
22

BLX-400 User Manual Page 3 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Water Supply
• Flow: 5 GPM (3.8L/m) minimum*
• Pressure: 35-50 psi (207-414 kPa)**
• Temperature: 40-100⁰F (4-38⁰C)
3/8" supply piping size recommended
*Minimum pressure must be maintained during
specied water ow!
**For consistent operaon of Venturi Injector and
spray nozzles, a water pressure regulator and lter is
recommended.
Electrical
• BLX-400 (120V):
• 120 VAC Single Phase
• 60 Hz 15 Amps
• Supplied with 8 . power cable with NEMA
5-15P plug
• BLX-400 (230V):
• 230 VAC Single Phase
• 60 Hz 15 Amps
• Supplied with 8 . power cable with NEMA
5-15P plug
The BLX-400 is a compact semi-automated footwear
scrubbing unit built to accommodate 1 user at a me.
The included user manual contain installaon,
operaon, and maintenance instrucons for BLX-
400 units. For further support or informaon please
contact your sanitaon representave, manufacturer,
or Clean Logix technical support.
Overview
NOTE: Back ow prevenon must be installed
in the water line to this unit. Check local
codes to ensure proper installaon.
System Requirements
!
WARNING:
DO NOT EXCEED maximum water
temperature! Damage to brushes can result.
• Construcon: 304L stainless steel, UHMW,
Polypropylene
• Weight: 167 lb (75.75 kg)
• Dimensions: 20.5” x 26” x 47”
(52 x 66 x 119.4 cm)
• Water Consumpon: 1.5 GPM
(3.8 L/m)
• Minimum Chemical Diluon Rao: 1:230*
Specicaons
*NOTE: Unit tested at 70°F using water with
30-50 psi injector inlet pressure.
!
WARNING:
DO NOT use ammable liquids (i.e. alcohol
based soluons or similar) without diluon.
NOTE: Instrucons and specicaons are for
standard units only. See page 22 for units
equipped with Non-diluon kits (NDF).

BLX-400 User Manual Page 4 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
NOTE: For xed installaons, area in front of electrical panel must be clear at least 36"
Installaon

BLX-400 User Manual Page 5 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Physical Set Up:
1. Set unit in desired locaon.
2. Aspects to consider when deciding on placement:
• Clearance for general use
• Locaon of drain
• Emergency exit paths or egress
• Access to control box
• Connecons for water and electricity
3. Use a level to make sure the unit is stable and
leveled in all direcons [Figure 5.1].
4. Adjust leveling feet as necessary by rotang them
clockwise/counter-clockwise.
5. Connect unit to electrical supply.
Plumbing Connecons:
1. Connect water source to solenoid valve ng
inlet (located under control box). Fing is 3/8"
[Figure 5.2].
2. Connect the soluon source to the hose barb of
the Venturi Injector (located under water inlet)
using 1/4" PVC tubing [Figure 5.2].
3. If necessary, adjust the diluon rao using the
included metering ps and test [Figure 5.3].
• The smallest metering p is a yellow p with a
small tube aached [Figure 5.3]. This tube can
be trimmed to alter the diluon rao.
• Full length capillary tube results in a diluon
rao of approximately 1:670 at 30-50 psi water
inlet pressure.
• To adjust injector, turn the bypass screen
clockwise unl soluon ows at a desired
range. (See page 21 for more informaon.)
Installaon
NOTE: To move the unit use a dolly, pallet
jack, or a hi-lo to li from the boom. Pad the
forks to protect the nish. Fig. 5.1: Level and stabilize unit using a leveling device
Capillary
Tube
Addional
Metering Tips
Fig. 5.3: Metering Tips and Capillary Tube
Fig. 5.2: Water and Venturi Injector (soluon) inlets

BLX-400 User Manual Page 6 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Motor Speed Adjustment
The speed of the motor is controlled by a variable
frequency motor drive. As the drive decreases the
frequency of the motor, the RPMs decrease. The V.F.
drive displays the Hz. on a small display and the knob
next to it adjusts the Hz. The worm gear reducer has a
20:1 rao.
Default: 1750 RPM at 60 Hz.
To Adjust the Speed:
1. Open the control box.
2. Acvate the sensor to turn on the motor.
3. As the motor is spinning, the unit will display the
operang speed in Hz.
4. Turn the knob counter-clockwise to decrease the
Hz, therefore decreasing the RPMs. Turning the
knob clockwise will increase the RPMs [Figure 6.1]
5. Adjust the Hz. on the variable frequency drive to
the desired brush speed. The minimum frequency
is 15 Hz and the maximum is 60 Hz Clean Logix
recommends 70 RPM/48 Hz.
Installaon (connued)
!
DANGER:
Do not open control box during wash down
or cleaning. Only authorized personnel should
open the control box.
Speed
Adjustment
Fig. 6.1: PowerFlex 4M Variable Frequency Drive

BLX-400 User Manual Page 7 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Start Up
1. Verify installaon has been completed:
• Brushes and grate are secured
• Unit is plugged in and receiving power
• Water and soluon have been plumbed
2. Pull the E-STOP switch up to engage power, when
illuminated the unit has power [Figure 7.1].
Use
1. Using both hands, grasp the handlerail to acvate
the sensor.
2. When acvated, the brush will begin to rotate and
the soluon/water will spray [Figure 7.1].
3. While maintaining grip on the handrail, place one
boot in between the side brushes. With the sole
of the boot posioned against the boom rotang
brush, push the boot forward and backwards to
scrub the sides ensuring all areas make contact.
4. When complete, remove the rst boot and repeat
with second.
5. Once the user removes their hands the brushes
and sanizer will stop.
Shut Down
• Press the red E-STOP buon on the control box.
• Disconnect power and follow lockout-tagout
procedures as necessary.
Operaon
!
CAUTION:
When operang always ensure solid foong
and use handrail for stability.
NOTE: Prior to placing footwear into the unit,
test that it is working properly by acvang
the sensor (wave hand in front of sensor).
Fig. 7.1: Emergency stop and acvaon sensor locaons
Sensor E-Stop

BLX-400 User Manual Page 8 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Removing & Replacing Brushes
1. Shut down the unit (see pg. 7).
2. Remove the two side brushes by liing each of
them up and out of their brackets [Figure 8.1].
3. Remove the grate by pulling the grab bar out and
away from its alignment notches [Figure 8.2].
4. Once released, the enre grate can be pulled up
and out from the tub to be removed.
5. Li the sole brush out of the tub by grabbing the
open end and liing up to clear the opposing drive
sha anchor [Figure 8.3].
6. Brushes can be washed individually in a COP tank
or wash machine.
7. The tub can be washed by convenonal means.
Cleaning Procedures
Fig. 8.1: Removing side brushes
NOTE: It is NOT recommended to use hot
water (over 120°F) to clean brushes.
Fig. 8.3: Removing sole brush
Fig. 8.2: Removing grate
Use Case Chemical Type
Organic Soils Chlorinated Alkaline or Alkaline based
foaming cleaner
Mineral Buildup Acid based foaming cleaner
NOTE: Chemistry used must be compable
with materials of construcon (page 3).
!
CAUTION:
Use of high pressure (above 400 PSI) is not
Recommended on sensive areas such as electrical
Components, motors, or gearboxes.

BLX-400 User Manual Page 9 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Motor Current Sensor
Automaon Direct ACS-200 Current Switch
The motor current sensor monitors the current draw
of the motor and will stop the motor if an over-torque
condion occurs.
To adjust the Set-Point:
1. 1-6A Seng (Jumper Removed)
2. Two loops of wire through sensor.
3. Turn trimpot counterclockwise at least 5 turns.
4. Turn trimpot clockwise for 3-1/2 turns.
5. Test and adjust accordingly in 1/8 turn
increments.
Advanced Conguraon Opons
!
DANGER:
Do not open control box during wash down
or cleaning. Only authorized personnel should
open the control box.
Brush RPM Formula
The formula for calculang Speed in RPM from Drive
Frequency in Hertz is:
[Motor Nameplate RPM] x [Drive Frequency (Hz)]
÷ [Motor Nameplate Frequency (Hz)] ÷ [Gear
Reducon]
Example:
• Motor Nameplate RPM = 1750
• Motor Nameplate Frequency (Hz) = 60
• Gear Reducon = 20
• Drive Frequency (Hz) = 48
1750 x 48 ÷ 60 ÷ 20 = 70 RPM
The formula for calculang Drive Frequency in Hertz
from Desired Speed in RPM is:
[Desired Speed RPM] x [Gear Reducon] x [Motor
Nameplate Frequency (Hz)] ÷ [Motor Nameplate
RPM]
Example:
• Desired Speed in RPM = 70
• Gear Reducon = 20
• Motor Nameplate Frequency (Hz) = 60
• Motor Nameplate RPM = 1750
70 x 20 x 60 ÷ 1750 = 48 Hz
Brush Direcon
By default, the rotaon direcon for the sole brush is
clock-wise. To reverse the direcon switch 2 of the 3
motor lead wires (T1, T2, or T3).
See electrical schemacs on pages 18-19 for more
informaon.
SET-POINT
Fig. 9.1: Current Sensor Sengs Idencaon
RANGE JUMPER

BLX-400 User Manual Page 10 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Advanced Conguraon Opons (connued)
Drive Parameter Sengs
Allen Bradley 4M Variable Frequency Drive
Timing Relay Sengs
Eaton TRL04
• Funcon: R (O Delay)
• Time Range: 1 sec.
Schneider Electric Magnecra
• Funcon: S (O Delay)
• Time Range: 1 sec.
Parameter
Number Descripon Seng Units
P102 Motor NP Hertz 60 Hz
P104 Minimum Freq 30 Hz
P105 Maximum Freq 60 Hz
P106 Start Source 2N/A
P109 Accel Time 1 s
P110 Decel Time 2 s
t201 Digital In1 Sel 3N/A
t221 Relay Out Sel 1 N/A
!
DANGER:
Do not open control box during wash down
or cleaning. Only authorized personnel should
open the control box.
FUNCTION
TIME RANGE
ADJUSTMENT RANGE
Fig. 10.2: Schneider Magnecra Seng Idencaon
FUNCTION
TIME RANGE
ADJUSTMENT RANGE
Fig. 10.1: Eaton TRL04 Seng Idencaon

BLX-400 User Manual Page 11 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
The following maintenance procedures are
recommended for normal use. Units which see a high
amount of use should be inspected more frequently.
Weekly:
• Check unit for proper sensor funcon and brush
rotaon.
• Ensure grate is secure and funconing properly.
• Inspect brushes for damage or wear. Check for
missing or deformed bristles.
• Inspect electrical cords and plumbing for
damage.
• Inspect and test funcon of emergency stop
switches.
Monthly:
• Check all fasteners to ensure they are ght.
• Ensure warning labels and decals are present
and in good condion.
• Inspect grate spring assemblies (M1896) and
spring balancer bearings (M1904, M1905) for
wear
• Inspect motors, gearboxes, and reducers for
signs of oil leakage.
• Inspect electrical enclosure for signs of water
intrusion.
• Inspect sensors for damage.
• Inspect moving parts for damage or wear.
Quarterly:
• Inspect structure for cracked welds or bent
components.
Gear Reducer:
• The gear reducer is supplied lled to capacity
with Mobil Cibus SHC 634 NSF H1 Food Grade
or equal synthec oil.
• The synthec lubricaon provided is good
for ambient temperatures -10°F - 105°F and
is compable with standard compounded
oil.
• Oil should be changed every 2 years (or 6,000
operang hrs.)
• Designed with a bladder type vent system:
• Consists of an internal bladder that
seals the oil chamber from the outside
environment at all mes - as pressure
builds, the bladder contracts keeping the
internal pressure to a minimum.
• Advantage: The internal oil chamber is
completely sealed, ensuring oil is not
released causing contaminaon in the
applicaon.
Motor:
• Inspect at regular intervals.
• Verify the mounng bolts and couplings to
ensure that they are ght and properly adjusted.
• Motor bearings are sealed and not
re-greasable.
• Bearings should be replaced approximately
every 5 years for 8 hr./day service.
Preventave Maintenance

BLX-400 User Manual Page 12 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Unit is leaking onto oor:
• Check to make sure all joints are sealed.
Verify water and soluon inlets are aached and
rmly in place.
Leaner Diluon Raos Required:
• Verify metering p is installed in the injector
chemical inlet hose barb
• Change the metering p for a more appropriate
size (see pg. 4 for further informaon)
• If the desired diluon rao sll cannot be
achieved pre-diluon of the chemical may be
necessary.
Venturi will not draw Chemical Soluon:
• Verify water supply is sustaining 30 psi at the
injector inlet while unit is running
• Elevate the chemical jug above the injector (a jug
hook is provided for this purpose)
• Verify spray nozzles are not clogged. The nozzles
supplied with the equipment are rated at 0.2GPM
@ 10psi (0.28GPM @ 20 psi)
• Ensure the sucon lter is not clogged, kinked or
obstructed in any way that would restrict ow.
Unit not operang & E-STOP not Illuminated:
• Verify unit is plugged in.
• Verify E-STOP is not pushed down.
• Verify main power going to the unit.
• Verify circuit breakers in the building have not
been tripped.
Unit not operang & E-STOP is Illuminated:
• Check sensor is operang properly and is
connected via orange M12 cable.
• Verify all physical connecons to the brushes are
in place.
• Restart unit by pushing down the E-STOP, waing
10 seconds, then turning the unit on again.
Unit will not spray:
• Verify water pressure at the inlet to the water (30
psi min.)
• Verify water and soluon lines are aached and
rmly in place
• Inspect spray nozzles for clogging.
• Verify that the orange LED light on the solenoid
valve connector illuminates when the brushes are
rotang.
Troubleshoong

BLX-400 User Manual Page 13 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Troubleshoong
F002 Fault Code on Variable Frequency Drive:
Cause: Power may have been cycled to the unit
while it was “ON”. To solve:
1. While power is sll applied, turn the unit “o”
by pushing down hard on the e-stop buon
2. Wait at least 5 seconds, then pull the e-stop
buon out again. DO NOT stand on the
walkway grate during this process.
3. The unit should now be ready for use.
Cause: If the brushes stop suddenly during normal
use and the fault is displayed, the Motor Current
Sensor set point may be too low. To solve:
1. Turn the set point adjusng screw clockwise ½
turn to raise the set point and re-test.
Please contact your equipment representave
or manufacturer for further support.
iMore Informaon?
F004 Fault Code on Variable Frequency Drive:
• If unit is connected to a GFCI, verify its rangs
(class, mA restricons, etc.)
• Verify frequency seng on VFD is set above 20 Hz.
• VFD Parameter: P104 [Minimum Freq.]
• Manufacturer Default: 30 Hz.
• Set the lowest carrier frequency on the VFD
(lower carrier = less switching on/o)
• VFD Parameter: A446 [PWM Frequency]
• Manufacturer Default: 4.0 kHz.
• Minimum: 2.0 kHz.
NOTE: Clean Logix recommends Leviton's
GFI protecon device [# GFRBF-W]for
circumstances where the facility's original
GFCI plug is not applicable.

BLX-400 User Manual Page 14 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Appendix A - Parts Callout

BLX-400 User Manual Page 15 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Appendix A - Parts Callout (connued)
Part No. Descripon
F1056 WASHER 1/4 SS TYPE A
F1064 WASHER SPLIT LOCK 5/16 SS
F1105 BOLT HHC 1/4-20 X 1/2 SS
F1130 BOLT HHC 5/16-18 X 5/8" SS
F1131 KEY 3/16" X 3/16" X 1" SS
M1134 SOLENOID BRACKET
M1183 DRIVE SHAFT MOTOR-BRUSH WELDMENT
M1238 TUB WELDMENT BLX-400
M1248 GRATE WELDMENT BLX-400
M1258 GRATE LATCH BAR
M1260 SPRAY BAR WLDMNT BLX-400
M1262 BRUSH FIXED 10-1/2 X 3
M1263 BRUSH LOWER BLX-400
M1319 ELECTRICAL ASSEMBLY BLX-400
M1420 BRUSH SUPPORT WELDMENT
P1005 SS MOTOR 1/2HP, 1800 RPM, 230/460/3/60,
TENV, 56C FOOTLESS
P1006 GEAR REDUCER 20:1, 56C, HOLLOW QUILL, .625
HOLLOW OUTPUT, 1.33" CENTER DISTANCE,
P1041 PHOTOEYE SENSOR
P1046 VALVE, SOLENOID, 3/8" SS 24VDC DIN COIL,
DEMA 463PS.4D
P1047 VENTURI INJECTOR SS BODY & METER KNOB
3/8'
P1100 PIPE HEX NIPPLE 3/8 SS
P1101 PIPE BUSHING 3/8 x 1/4 SS
P1107 PIPE ELBOW STREET 1/4 SS
P1109 PIPE ELBOW STREET 3/8 SS
P1147 CORD GRIP 1/2 NPT X .170-.450 BLK HEYCO
M3231
P1148 CORD GRIP NUT 1/2" NPT BLACK - HEYCO 8463
P1187 SOLENOID CABLE 18MM DIN 24V LED 3M SC18-
LS24-3
P1242 CRIMP ON TERMINAL, RING 1/4" ID, 14-16 AWG
INSULATED
P1599 METERING TIP, CAPILLARY TUBE
P1677 SPLICE TERMINAL 10-16 AWG NATURAL
P1769 METERING TIPS, ULTRA LEAN 100-15KU
P1934 GREASE, ELECTRIC INSULATING .17OZ ONE TIME
USE PACK
Please contact your equipment representave
or manufacturer for further support.
iMore Informaon?

BLX-400 User Manual Page 16 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Appendix B - Electrical Panel Parts Callout
Part No. Descripon
F1172 SCREW THEAD FORMING 10-32 X 1/2 HEX WASHER
HEAD ZINC
P1111 END STOP TERMINAL BLOCK
P1122 POWER SUPPLY 24VDC 60W
P1180 VARIABLE FREQUENCY DRIVE 0.5HP 120VAC
P1323 CIRCUIT BREAKER 10A SINGLE POLE
P1873 TERMINAL BLOCK SPRING CLAMP 5.1mm GRAY
P1874 TERMINAL BLOCK SPRING CLAMP 5.1mm GROUND
Part No. Descripon
P1875 TERMINAL BLOCK SPRING CLAMP 5.1mm DUAL-
LEVEL GRAY
P1877 TERMINAL BLOCK END BARRIER L3 SERIES
P1880 TERMINAL JUMPER 5.1mm
P1939 RELAY, TIMER, MULTIFUNCTION 24VDC (REPLACES
P1115)
P1940 SWITCH, CURRENT SENSING WITH TIME DELAY,
1-175A ADJUSTABLE, FIXED CORE, NC

BLX-400 User Manual Page 17 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Appendix B - Electrical Panel Parts Callout
Part No. Descripon
F1172 SCREW THEAD FORMING 10-32 X 1/2 HEX WASHER
HEAD ZINC
P1111 END STOP TERMINAL BLOCK
P1122 POWER SUPPLY 24VDC 60W
P1325 CIRCUIT BREAKER 13A DOUBLE POLE
P1347 VARIABLE FREQUENCY DRIVE 0.5HP 240VAC
P1873 TERMINAL BLOCK SPRING CLAMP 5.1mm GRAY
P1874 TERMINAL BLOCK SPRING CLAMP 5.1mm GROUND
Part No. Descripon
P1875 TERMINAL BLOCK SPRING CLAMP 5.1mm DUAL-
LEVEL GRAY
P1877 TERMINAL BLOCK END BARRIER L3 SERIES
P1880 TERMINAL JUMPER 5.1mm - 10 POSITION
P1939 RELAY, TIMER, MULTIFUNCTION 24VDC (REPLACES
P1115)
P1940
"SWITCH, CURRENT SENSING WITH TIME DELAY,
1-175A ADJUSTABLE, FIXED
CORE, NC"

BLX-400 User Manual Page 18 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Appendix C - Electrical Schemac (120VAC)

BLX-400 User Manual Page 19 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General
Installaon
OperaonAppendix Maintenance ConguraonTroubleshoong
Appendix C - Electrical Schemac (230VAC)

BLX-400 User Manual Page 20 of 25 Updated: 02/11/21
USER MANUAL: BLX-400
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Appendix D - Venturi System Maintenance
Solenoid & Venturi Injector Disassembly:
1. Shut down the unit (see page 7)
2. Shut OFF the sanizer supply and remove
pressure from the line.
3. Using a small phillips screwdriver, loosen the set-
screw from the solenoid to the control box.
4. Using a 7/16” socket wrench, remove the bolts
holding the solenoid bracket to the unit.
5. Pull the assembly away from the unit and unscrew
the Venturi injector and solenoid assembly from
the spray bars.
6. Unscrew the Venturi injector from the 3/8” pipe
nipple.
7. Take a 1/4” socket wrench and remove the
solenoid from the solenoid bracket. The insides of
the solenoid and Venturi can now be accessed and
cleaned to remove any debris or residue.
Fig. 10.1: Solenoid set screw and mounng bolts
Fig. 10.2: Removing Venturi and Solenoid from pipe ngs
DEMA ADJUSTABLE SINGLE STAGE INJECTORS
MODELS 202B, 202BP, 202 BT, 203B, 203BP, 203 BT, 204B, 204BP, 204 BT, 206B, 206BP, 206BT
INSTALLATION INSTRUCTIONS
I-119 Pg. 4 of 4
Rev. C-39817 5/20/14
NO. PART NO. DESCRIPTION
1 24-33 Screw #8-32 x 7/8” Lg. (4-Reqd.)
2 24-32 Metering Knob Assy.
3 24-32PS Metering Knob Assy.
4 24-32S Metering Knob Assy. (Stainless)
5 24-32ST Metering Knob Assy. (Stainless Steel
with Tips
6 24-32T Metering Knob Assy. (Tips)
7 100-24 Metering Screw
8100-24PS Metering Screw (-BP Injectors)
924-25 Check Valve O-Ring (EP)
10 24-24P Check Valve Ball (Teflon)
11 24-24S Check Valve Ball (Stainless)
12 24-23 Check Valve Spring
13 24-34- Check Valve Core (Specify Model
No.)
14 25-29 O-Ring (EP)
15 100-12 Vinyl Tubing (3/8” OD x 8’ Lg.)
16 61-107-2 Ceramic Weight (1/4” ID 3/8” OD
Tubing
17 24-11P Foot Strainer
NO. PART NO. DESCRIPTION
USED ON 202B, 202BP, 202BT
18 24-48 By-Pass Screw Retainer
19 24-49 O-Ring (Buna) (3/16x5/16x1/16)
20 24-47 By-Pass Screw
USED ON 203B, 203BP, 203BT
21 24-36 By-Pass Screw Retainer
22 24-25 O-Ring (EP) (7/32x11/32x1/16)
23 24-35 By-Pass Screw
USED ON 204B, 204BP, 204BT
24 24-40 By-Pass Screw Retainer
25 26-17 O-Ring (Buna) (3/4x7/8x1/16)
26 24-39 By-Pass Screw
USED ON 206B, 206BP, 206BT
27 24-38 By-Pass Screw Retainer
28 25-29 O-Ring (EP) (3/8x1/2x1/16)
29 24-37 By-Pass Screw
ACCESSORIES
NO. PART NO. DESCRIPTION
30 100-15- Metering Tip (Specify Color)
31 100-15K Metering Tip Kit
MODEL #'S MAY ALSO INCLUDE S, E, C AND/OR -2.
MODEL
15 16
14
13
12
8
10
11
7
9
?
1
19 22 25
(STAINLESS WITH TIPS)
(TIPS)
(STAINLESS)
6
5
3
4
2
2320 26
MODEL
203B
203BP
203BT
21
202BT
18
MODEL
202B
202BP 204BT
24
204B
204BP
28
17
29
206BT
27
MODEL
206BP
206B
Metering Tip
Metering
Screw
O-Ring
Check Valve Ball
Spring
Check Valve Core
O-Ring
Metering
Knob
Assembly
DEMA ADJUSTABLE SINGLE STAGE INJECTORS
MODELS 202B, 202BP, 202 BT, 203B, 203BP, 203 BT, 204B, 204BP, 204 BT, 206B, 206BP, 206BT
INSTALLATION INSTRUCTIONS
I-119 Pg. 4 of 4
Rev. C-39817 5/20/14
NO. PART NO. DESCRIPTION
1 24-33 Screw #8-32 x 7/8” Lg. (4-Reqd.)
2 24-32 Metering Knob Assy.
3 24-32PS Metering Knob Assy.
4 24-32S Metering Knob Assy. (Stainless)
5 24-32ST Metering Knob Assy. (Stainless Steel
with Tips
6 24-32T Metering Knob Assy. (Tips)
7 100-24 Metering Screw
8100-24PS Metering Screw (-BP Injectors)
924-25 Check Valve O-Ring (EP)
10 24-24P Check Valve Ball (Teflon)
11 24-24S Check Valve Ball (Stainless)
12 24-23 Check Valve Spring
13 24-34- Check Valve Core (Specify Model
No.)
14 25-29 O-Ring (EP)
15 100-12 Vinyl Tubing (3/8” OD x 8’ Lg.)
16 61-107-2 Ceramic Weight (1/4” ID 3/8” OD
Tubing
17 24-11P Foot Strainer
NO. PART NO. DESCRIPTION
USED ON 202B, 202BP, 202BT
18 24-48 By-Pass Screw Retainer
19 24-49 O-Ring (Buna) (3/16x5/16x1/16)
20 24-47 By-Pass Screw
USED ON 203B, 203BP, 203BT
21 24-36 By-Pass Screw Retainer
22 24-25 O-Ring (EP) (7/32x11/32x1/16)
23 24-35 By-Pass Screw
USED ON 204B, 204BP, 204BT
24 24-40 By-Pass Screw Retainer
25 26-17 O-Ring (Buna) (3/4x7/8x1/16)
26 24-39 By-Pass Screw
USED ON 206B, 206BP, 206BT
27 24-38 By-Pass Screw Retainer
28 25-29 O-Ring (EP) (3/8x1/2x1/16)
29 24-37 By-Pass Screw
ACCESSORIES
NO. PART NO. DESCRIPTION
30 100-15- Metering Tip (Specify Color)
31 100-15K Metering Tip Kit
MODEL #'S MAY ALSO INCLUDE S, E, C AND/OR -2.
MODEL
15 16
14
13
12
8
10
11
7
9
?
1
19 22 25
(STAINLESS WITH TIPS)
(TIPS)
(STAINLESS)
6
5
3
4
2
2320 26
MODEL
203B
203BP
203BT
21
202BT
18
MODEL
202B
202BP 204BT
24
204B
204BP
28
17
29
206BT
27
MODEL
206BP
206B
By-Pass Screw
Retainer
O-Ring
By-Pass Screw
